Page 1
SERVICE MANUAL XT- 3A081U/ M T5658 1. Caution………………………………………………………………………… Specification…………………………………………………………………… 3. Alignment Procedure……………………………………………………… Scheme Diagram …………………………………………………………… 5. Troubleshooting……………………………………………………………… This m nual i the l test at the t me of pr nting, and doe not include the modification which may be made after the printing, by the constant improvement of product...
Page 2
SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
Page 3
SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
Page 4
SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
Page 5
SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
Page 6
REV.NO: Rev No. 2.1 DATE : PRODUCT SPECIFICATIONS LED TV CATEGORY: 43" Android Smart UHD LED TV MODEL NO: XT-43A081U REFERENCE MODEL (Sanyo/COMPETITION): SUPPLIER MODEL NO : SUPPLIER: ASSEMBLER ID PHOTO REMOTE: Add Picture CHASSIS / Main Board: MT5658 PARAMETERS...
GROSS WEIGHT (WITH PACKING BOX) 10.2KG OPERATING VOLTAGE 110V-240V~ at 50/60Hz POWER CONSUMPTION 95 W STD BY POWER CONSUMPTION ≤0.5W REMOTE SANYO remote and RC880(MIC) BATTERY 2 "AA" and 2"AAA" Batteries local India POWER CORD TYPE Detachable POWER CORD IS MARKING POWER PLUG...
Page 8
1. Enter the factory menu mode. (Design mode) 1. Press the Menu then cursor on the Contrast item then press 1950 to enter into factory design mode menu. Design mode Menu : Design Mode Hotkey : Press the left and right keys to turn the design mode on or off. Factory Menu : Press the left and right keys to enter the factory mode menu.
Page 9
2. Enter the factory menu mode. (Factory mode) From the factory menu of the design mode, to enter into factory mode place the cursor on the contrast item and press 9735 to enter into factory mode menu Factory mode menu : Factory Hotkey : Factory mode switch WARM-UP : Press the left and right keys to enter the aging mode.
Page 10
3. White Balance Adjustment Page : Source : Press the left and right keys to select the channel that needs to adjust the white balance Color Temp : Press the left and right keys to adjust the color temperature mode R-Gain : Press the left and right keys to adjust the R-Gain value G-Gain : Press the left and right keys to adjust the G-Gain value B-Gain : Press the left and right keys to adjust the B-Gain value...
Page 23
TU_3V3 TU_3V3 R1007 TU_3V3 3V3_DEMO R1059 VDD_1V8 C1003 C1017 C1054 C1055 C1056 C1057 0.1U 0.1U 0.1U 0.1U Read Add:0xC7 TUNER_ADDR CT14 Write Add:0xC6 XT16M 470K 0.01U TU_3V3 Close to SOC CT13 R1060 TUN1 Or connect to the nearest 3V3 TUNER_ADDR TU_3V3 120P 33NH...
Page 24
FOR CMI/AUO/SAMSUNG/CSOT PANEL FOR LG PANEL 46-FFC15W-51SG VB1 OUT PANEL_VCC PANEL_VCC1 P1101 PANEL_VCC *Take out PIN44---PIN51 FFC wire for SEC* *Take out PIN41\PIN42 FFC wire for AUO* *Take out FFC wire to select 3D_EN* 0R R1195 *Must use independent I2C* R1194 R1199 R1198...
Trouble shooting diagram Terms: 9IR: Infrared Receiver 9RC: Remote Control 9IR logic: IR blink with RC action 9LVDS: Low Voltage Differential Signal, output from processor and input for panel 9O/C: Open Cell, panel with source board 9BL: Back Light, light source for panel module 9LB: LED (Light Emitting Diode) Bar, light source for BL module 9VBL: Voltage for Back Light (before Boost) 9VLED: Voltage for LED (after Boost)
Page 26
1.No power No power LED, RC or Key can not turn on TV. Power LED no light/no change.
Page 27
2.No Display / Black Panel Back light is OK, sound is OK, but no picture.
Page 28
3.No back light Power LED logic OK, sound OK, but no picture(Different from No Display).
Page 29
4.No sound One or all signal source without sound.
Page 30
5.Signal source no function One or several source no function.
