GAMMA instabus
Solar protection actuator 2 x 6 A DC
RL 524D23
A6V12883339_en--_b
2023-10-27
The solar protection actuator is used to control shutters, awnings, sunblinds or
ventilation flaps with DC 24 V.
●
End position detection by current detection for automatic move time determination.
●
Built-in device for installation in an automation module box AP 118 or in a M 590
DIN rail housing, which has to be ordered separately
●
Maintenance-free terminals for connecting and looping through solid, stranded and
fine-stranded conductors.
Functions for configuration with ETS:
●
Extensive control and override functions and status messages for each channel
●
On-site control of the drives
●
Direct moving to element or slat positions.
●
Automatic control of the drives with configurable behavior when the sun is shining
(sun tracking control)
●
Scene control for calling up and storing defined element positions
●
Safety functions through overrides in case of wind, rain, frost, moving blocks etc.
Smart Infrastructure
Building Products
Advertisement
Related Manuals for Siemens KNX RL 524D23
Summary of Contents for Siemens KNX RL 524D23
- Page 1 GAMMA instabus Solar protection actuator 2 x 6 A DC RL 524D23 The solar protection actuator is used to control shutters, awnings, sunblinds or ventilation flaps with DC 24 V. ● End position detection by current detection for automatic move time determination. ●...
- Page 2 Characteristics The solar protection actuators are used to control blinds, roller shutters, sliding shutters, ex- ternal blinds, awnings or ventilation flap drives with DC 24 V. They are used in building auto- mation. Device control is conducted via KNX. Through the selection of various operating modes such as manual and automatic mode, solar protection is controlled both locally and centrally.
- Page 3 ◈ Briefly press the programming button (1) (< 2 seconds). a Programming mode is deactivated. a The programming LED (2) is not illuminated. Resetting the device to factory settings A very long push of the programming button of more than 20 seconds resets the device to its factory settings.
- Page 4 The stored default settings of the positions can also be changed without programming the device via KNX. To do this, the blinds must be moved to the desired element height. This new position with the value “0” and “1” is copied to the memory of the device via the commu- nication objects “position 1/2”...
- Page 5 Schematic design of a solar protection actuator channel The following scheme shows the function of a channel of the solar protection actuator using the “blind” function in a logical context. 8-bit Recall/store positions 1-bit Manual operation Solar protection via dimming Delay Automatic operation Delay...
- Page 6 Technical design Position and function of the operating and display elements and connections Fig. 2: Position and function of the connections and labeling, operating and display elements Solar pro- tection actuator RL 524D23, 2 x 6 A DC Pos. Connection, operating or display Function element 1 Connection pins for KNX bus terminal...
- Page 7 Documents related the product, such as operating and installation instructions, application program description, product database, additional software and CE declarations can be downloaded from the following website: http://www.siemens.com/gamma-td Frequently asked questions For frequently asked questions about the product and their solutions, see: https://support.industry.siemens.com/cs/products?dtp=Faq&mfn=ps&lc=en-WW...
- Page 8 Notes Security The device is designed to be installed in an AP 118 automation module box or a M 590 DIN rail housing. CAUTION National safety regulations Failure to comply with national safety regulations may result in personal injury and property damage.
- Page 9 0.5...2.5 mm² 2.5 mm² Connecting KNX Fig. 4: Solar protection actuator RL 524D23, 2 x 6 A DC 0.6…0.8 mm Testing KNX 24 V DC type. SELV This test can be used to check whether the bus connection cable is connected with the cor- rect polarity and whether device is supplied with bus voltage.
- Page 10 Disposal The device is considered an electronic device for disposal in accordance with European Directive and may not be disposed of as domestic waste. ● Use only designated channels for disposing the devices. ● Comply with all local and currently applicable laws and regulations. If a device is defective, contact the local sales office.
- Page 11 Technical data Power supply KNX bus voltage DC 24 V (DC 21...30 V) KNX power consumption 15 mA KNX power loss (power consumption) 0.15 W Outputs Number of drive channels Switching voltage DC 24 V Output current Rated current per channel Rated current per device 10 A Current sensing for move time determination >...
- Page 12 Protection settings Housing protection class (according to EN IP20 (when installed AP 118) 60529) Electrical safety, bus (SELV) Electrical safety, device fulfills EN 50428 EMC requirements, device complies with EN 50428 Test mark KNX, EAC, RCM, WEEE, China-RoHS CE mark Reliability Failure rate (at 40°C) 1024 fit...
- Page 13 Dimension drawing Compliance information Smart Infrastructure A6V12883339_en--_b GAMMA instabus 2023-10-27...
- Page 14 Issued by © Siemens 2023 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V12883339_en--_b Edition 2023-10-27...
