3. Insert the new module into the slot.
Figure 4.3
4. Tighten the screws to secure the module.
5. [Optional] If necessary, install the device in the rack.
4.3

Installing/Removing Power Modules

The RUGGEDCOM RX1511 supports a single power module.
1
Figure 4.4
RUGGEDCOM RX1511
Installation Manual, 12/2019, C79000-G8976-1056-16
All manuals and user guides at all-guides.com
Module
1
Chassis
2
Screw
3
Installing a Module
Power Module
Power Module
4.3 Installing/Removing Power Modules
1
2
3
1
Modules
39
