Summary of Contents for Samsung MM-B5
- Page 1 MICRO COMPONENT SYSTEM CD-R/RW PLAYBACK MM-B5 Instruction Manual...
-
Page 2: Safety Warnings
Safety Warnings CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER. NO USER SERVICEABLE PARTS INSIDE. -
Page 3: Table Of Contents
Before Contacting the After-Sales Service ...22 Technical Specifications ...23 Press Thank you for buying this SAMSUNG micro-component system. Please take time to read these instructions. They will allow you to operate your system with ease and take full advantage of its features. -
Page 4: Front Panel View
Front Panel View On/Standby Skip or Search Function selection (TUNER/CD/ TAPE/AUX) PTY(RDS) Display(RDS) TAPE/CD Repeat A CD Push Open Volume control VOL. Down Tuning Mode TUNER Band REC/Pause CD Sync. S.Bass Repeat REV. Mode Display TAPE Power Sound Push Eject Stop S. -
Page 5: Remote Control
Remote Control On/Standby EQ Preset Power Sound Sleep CD Repeat Tape rewind and fast-forward CD Stop Skip or Search Timer/Clock 10. Timer on/off On/Standby Timer Timer/ On/Off Clock Power Program EQ Preset Sound /Set Sleep CD Repeat Mono/ST. TUNER Band TAPE VOL. -
Page 6: Rear Panel View
Rear Panel View 1. MIC Jack Connector(optional) 2. Headphone Jack Connector 3. FM Aerial Connector Terminal 4. AM Aerial Connector Terminal 5. AUX-Input 6. Loudspeakers Connector Terminals ANTENNA AC CORD... -
Page 7: Where To Install Your Micro-Component System
Where to Install Your Micro-Component System To take full advantage of your new micro-component system, fol- low these installation instructions before connecting the unit. Install the system on a flat, stable surface. Never place this unit on carpeting. Never place this unit in an outdoor area. Maintain an open space of approximately 6 inches (15 cm) on the sides and rear of the system, for ventilation purposes. -
Page 8: Connecting To An External Source
Connecting to an External Source The auxiliary input can be used to take advantage of the sound quality of your micro-component system when listening to other sources. Examples: A television A video disc player A Hi-Fi stereo video cassette recorder To connect the external source, the source must have an audio output. -
Page 9: Connecting The Am (Mw)/Lw Aerial
Connecting the AM (MW)/LW Aerial The AM aerial (for long and medium waves) can be: Placed on a stable surface Fixed to the wall (you must first remove the base) The AM aerial connector terminals are located on the rear of the system and are marked AM . To avoid noise interference, check that the loudspeaker wires do not run close to the aerial wires. -
Page 10: Setting The Clock
Setting the Clock Your system is equipped with a clock which allows you to turn your system on and off automatically. You should set the clock: When you first purchase the micro-component system After a power failure After unplugging the unit For each step, you have a few seconds to set the required options. -
Page 11: Cd Repeat Function
CD Repeat Function You can repeat: A specific track on a compact disc All tracks on the compact disc Press the CD Repeat button. To repeat the... Press CD Repeat... Current track indefinitely Once (REP. 1 is displayed) Disc Twice (REP. ALL is displayed) When you wish to stop the Repeat function, press CD Repeat a third time. -
Page 12: Checking Or Changing Programmed Tracks
Checking and Changing Programmed Tracks You can check and change your selection of tracks at any time. You must have selected at least one track. Press Stop ( ) once if you have started listening to the selection. Press Program/Set. Each time you press Program/Set, the next selection is displayed. -
Page 13: Selecting A Stored Station
Searching for and Storing the Radio Stations(continued) If you do not want to store the radio station found, revert to Step 4 and search for another station. Otherwise: a Press Program/Set. Result: The program number is displayed for a few seconds. b Press Tuning to assign a program number between 1 and 15. -
Page 14: About Rds Broadcasting
About RDS broadcasting This unit has the RDS (Radio Data System) function, which enables for the various information such as broadcasting station, radio text, time and 30 types of programs (News, Rock, Classic, etc.) to be received from the FM RDS station together with normal radio signal. Press the On/Standby ( ) button. -
Page 15: Pty(Program Type) Indication And Pty-Search Function
PTY(Program Type) indication and PTY-SEARCH function The PTY information is composed of an identification symbol, which helps the FM radio to recognize the program type of each FM station. The below 30 PTY information is shown on the display by pressing the Pty button. -
Page 16: Tape
Listening to a Cassette Switch the system on by pressing On/Standby ( Select the TAPE function by pressing TAPE on the front panel. Open the cassette deck by pushing on the corner of the cover marked Push Eject until you hear a click and then releasing it. Insert the pre-recorded cassette with the open edge of the tape facing downwards. -
Page 17: Recording A Compact Disc
Recording a Compact Disc You can record a compact disc on a cassette in two different ways: Synchronised recording Direct recording Synchronised recording This feature enables you to synchronize the start of the recording with the start of the disc or track of your choice. You do not need to adjust the volume, as it has no effect on the recording. -
Page 18: Timer Function
Timer Function The timer enables you to switch the system on or off at specific times. Example: You wish to wake up to music every morning. If you no longer want the system to be switched on or off automatically, you must cancel the timer. Before setting the timer, check that the current time is correct. -
Page 19: Power Sound Function
Power sound function This machine is equipped with the function of POWER SOUND, which amplifies bass treble output to twice as much for powerful real surround-sound. Press the Power Sound button on the front panel. Result: P.SOUND is displayed for a few seconds. A more powerful resonant sound is diffused. -
Page 20: Microphone Function (Option)
Microphone Function (option) The microphone enables the user to mix in his or her vocals to sing-along with the music. Preparation Plug the microphone with a 3.5mm mic jack into microphone terminal. Connecting Headphones You can connect a set of headphones to your micro component system so that you can listen to music or radio programs without disturbing other people in the room. -
Page 21: Safety Precautions
Safety Precautions The following diagrams illustrate the precautions to be taken when using or moving your micro-component system. VOL. Down Tuning Mode TUNER Band REC/Pause CD Sync. S.Bass Display Repeat REV. Mode TAPE Power Sound Push Eject Ambient operating conditions: Do not expose the unit to direct sun Ambient temperature 5°C-35°C... -
Page 22: Precautions When Using Compact Discs
The model and serial numbers, normally printed on the rear of the system Your warranty details A clear description of the problem Then contact your local dealer or SAMSUNG after-sales service. Problem Checks/Explanation • The main lead is not correctly plugged into a wall socket or the wall socket is not switched on. -
Page 23: Technical Specifications
Technical Specifications SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. RADIO Usable sensitivity AM (MW) Signal/noise ratio Usable sensitivity Total harmonic distortion Signal/noise ratio... - Page 24 THIS APPLIANCE IS MANUFACTURED BY: ELECTRONICS AH68-01206B...
