Epson EB-L260F User Manual

Hide thumbs Also See for EB-L260F:
Table of Contents

Advertisement

Quick Links

Download this manual
EB-L210W/EB-L260F/EB-L265F
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Epson EB-L260F

Summary of Contents for Epson EB-L260F

  • Page 1 EB-L210W/EB-L260F/EB-L265F User's Guide...

  • Page 3: Table Of Contents

    Contents EB-L210W/EB-L260F/EB-L265F User's Guide..................11 Introduction to Your Projector ......................... 12 Projector Features..........................12 Product Box Contents........................13 Additional Components ........................ 14 Optional Equipment and Replacement Parts................. 15 Warranty and Registration Information (U.S. and Canada) ............16 Warranty and Registration Information (Latin America)..............16 Notations Used in the Documentation ....................
  • Page 4 Connecting to an External Computer Monitor ................39 Connecting to External Speakers....................40 Connecting a Microphone ......................40 Connecting to External USB Devices .................... 41 USB Device Projection......................41 Connecting a USB Device or Camera to the Projector.............. 42 Selecting the Connected USB Source ..................43 Disconnecting a USB Device or Camera From the Projector ............
  • Page 5 Setting Up Crestron Connected..................... 80 Controlling a Networked Projector Using Crestron Connected ............82 Registering a Digital Certificate on the Projector ................83 Importing a Web Server Certificate Using the Projector Menus............. 83 Registering Digital Certificates from a Web Browser ..............84 Digital Certificate Types.........................
  • Page 6 Starting a PC Free Slideshow...................... 139 Starting a PC Free Movie Presentation ..................141 PC Free Display Options ......................143 Projecting in Content Playback Mode (EB-L260F/EB-L265F) ............144 Switching to Content Playback Mode ..................144 Projecting a Playlist in Content Playback Mode................146 Creating a Playlist Using Epson Web Control................
  • Page 7 Adjusting RGBCMY ........................173 Scaling an Image......................... 175 Projecting Multiple Images Simultaneously ..................177 Input Sources for Split Screen Projection ..................180 Split Screen Projection Restrictions..................... 180 Projector Security Features......................181 Password Security Types ......................181 Setting a Password ......................... 181 Selecting Password Security Types..................
  • Page 8 Event ID Code List........................236 Network Settings - Network Menu ....................238 Multiple Projector Operation Settings - Multi-Projection Menu ............242 Setup Settings - ECO Menu ......................246 Initial Settings and Reset Options - Initial/All Settings Menu ............249 Maintaining and Transporting the Projector ..................251 Projector Maintenance ........................
  • Page 9 Solutions to Problems Using Content Playback................272 Solving Projector or Remote Control Operation Problems ............... 272 Solutions to Projector Power or Shut-Off Problems ..............273 Solutions to Remote Control Problems..................274 Solutions to Password Problems ....................274 Solutions When a Battery Message Appears ................275 Solving Network Problems .......................
  • Page 10 FCC Compliance Statement......................301 Binding Arbitration and Class Waiver ....................302 Trademarks ............................305 Copyright Notice..........................306 A Note Concerning Responsible Use of Copyrighted Materials........... 306 Copyright Attribution ........................306...

  • Page 11: Eb-L210W/Eb-L260F/Eb-L265F User's Guide

    Welcome to the EB-L210W/EB-L260F/EB-L265F User's Guide. For a printable PDF copy of this guide, click here. Note: The EB-L260F is shown in most illustrations in this manual, unless noted otherwise. Note: Availability of products in this guide varies by country.

  • Page 12: Introduction To Your Projector

    • EB-L210W: Up to 4500 lumens of color brightness (color light output) and white brightness (white light output) • EB-L260F/EB-L265F: Up to 4600 lumens of color brightness (color light output) and white brightness (white light output) Note: Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions.

  • Page 13: Product Box Contents

    • Use Epson iProjection (Windows/Mac) to simultaneously project up to four images from network computers or mobile devices using the Epson iProjection app • Projection from an iOS device, Android device, or Chromebook with the free Epson iProjection app; visit epson.com/iprojection...

  • Page 14: Additional Components

    This allows you to mirror your smartphone or tablet screens, watch movies, and more. Contact your device manufacturer for compatible adapter options. Unless listed as available from Epson in this table, see your local computer or electronics dealer for purchase information.

  • Page 15: Optional Equipment And Replacement Parts

    (Canadian sales). Latin America: You can purchase optional accessories and replacement parts from an Epson authorized reseller. To find the nearest reseller, go to latin.epson.com. Or you can contact your nearest sales office as described in "Where to Get Help."...

  • Page 16: Warranty And Registration Information (U.s. And Canada)

    Your projector comes with a basic warranty that lets you project with confidence. For details, see the warranty that came with your projector. Register your product online at latin.epson.com/support, search for your product, and select Register. Registering also lets you receive special updates on new accessories, products, and services.

  • Page 17: Notations Used In The Documentation

    • If you still need help after checking this manual and any other sources listed here, you can use the Epson PrivateLine Support service to get help fast (U.S. and Canada only). For details, see "Where to Get Help."...
  • Page 18 Lets you update firmware and monitor and Management (Windows Management Operation control your projector through the network. only) Guide You can download the latest software and documentation from the Epson web site. Go to epson.com/support (U.S.), epson.ca/support (Canada), or latin.epson.com/support (Caribbean) and select your projector.

  • Page 19: Projector Part Locations

    Where to Get Help (Latin America) Projector Part Locations Check the projector part illustrations to learn about the parts on your projector. Note: The EB-L260F is shown in most illustrations in this manual, unless noted otherwise. Projector Parts - Front/Top Projector Parts - Rear...

  • Page 20: Projector Parts - Front/Top

    Projector Parts - Front/Top Air intake vent Lens cover Foot release lever Front adjustable foot Lens Remote control receiver Air filter/intake vent Control panel Focus ring Zoom ring Horizontal keystone slider Air exhaust vent...

  • Page 21: Projector Parts - Rear

    Parent topic: Projector Part Locations Projector Parts - Rear AC input RS-232C port L and R audio ports Mic port (EB-L210W/EB-L260F) Audio1 and Audio2 ports Audio Out port Air intake vent Speaker HDMI1 and HDMI2 ports Computer1 and Monitor Out/Computer2 ports...

  • Page 22: Projector Parts - Base

    LAN (network) port USB-A port USB-B port Wireless LAN module cover screw Parent topic: Projector Part Locations Projector Parts - Base Front adjustable foot Ceiling/wall mount holes (9) Rear feet Security cable attachment point...

  • Page 23: Projector Parts - Control Panel

    Note: Use M4×9mm screws for mounting the projector. Parent topic: Projector Part Locations Projector Parts - Control Panel Source Search button (searches for connected video sources) Enter button (selects options) Vertical keystone adjustment buttons (displays the adjustment screen and adjusts screen shape) and arrow buttons Esc button (cancels/exits functions) Volume buttons (adjust speaker volume), horizontal keystone adjustment buttons, and arrow...

  • Page 24: Projector Parts - Remote Control

    Related references Projector Light Status Related tasks Correcting Image Shape with the Keystone Buttons Projector Parts - Remote Control Power button...
  • Page 25 HDMI button (cycles through connected HDMI and video sources) Computer button Numeric buttons Auto button (automatically adjusts position, tracking, and sync settings when projecting analog RGB signals from the Computer ports) Num button (when held down, switches numeric buttons to number function) Menu button (accesses projector menu system) Arrow buttons (move through on-screen options) Enter button (selects options)

  • Page 26: Setting Up The Projector

    Setting Up the Projector Follow the instructions in these sections to set up your projector for use. Projector Placement Projector Connections Installing Batteries in the Remote Control Projector Placement You can place the projector on almost any flat surface to project an image. You can also install the projector in a ceiling mount if you want to use it in a fixed location.
  • Page 27 Front Rear Front ceiling...

  • Page 28: Projection Distance

    Rear ceiling You can mount the projector to the ceiling at any horizontal or vertical angle. Note: When you install the projector in a fixed location, turn on the Fixed Installation setting in the projector's Installation menu. Parent topic: Projector Placement Related references Installation Settings - Installation Menu Projection Distance...
  • Page 29 Use the tables here to determine approximately how far to place the projector from the screen based on the size of the projected image. (Conversion figures may have been rounded up or down.) You can also use the Projection Distance Calculator here (U.S.) or here...
  • Page 30 238.2 to 383.5 inches -2.4 inches (-6 cm) (605 to 974 cm) 250 inches 298 to 479.5 inches -3.1 inches (-8 cm) ( 757 to 1218 cm) 300 inches 357.9 to 575.6 inches -3.9 inches (-10 cm) (909 to 1462 cm) EB-L260F/EB-265F...

  • Page 31: Projector Connections

    16:9 Aspect Ratio Image or Screen Screen or image size Projection distance (1) Offset from lens center (2) Wide to Tele Wide to Tele 31 inches 34.6 to 56.3 inches 0 inches (0 cm) (88 to 143 cm) 40 inches 44.9 to 73.2 inches 0 inches (0 cm) (114 to 186 cm)

  • Page 32: Connecting To Computer Sources

    Caution: If you will use the projector at altitudes above 4921 feet (1500 m), turn on High Altitude Mode to ensure the projector's internal temperature is regulated properly. Connecting to Computer Sources Connecting to Video Sources Connecting External Output Devices Connecting to External USB Devices Connecting to a Document Camera Parent topic:...

  • Page 33: Connecting To A Computer For Vga Video And Audio

    (Make sure the HDMI audio playback device on your computer's audio settings is set to EPSON PJ.) Note: If you have problems hearing audio through the HDMI connection, you can use one of the projector's audio ports instead to play sound.
  • Page 34 projecting the computer source as the Audio Output setting in the projector's Signal I/O menu. Make sure the audio cable is labeled "No resistance." 1. If necessary, disconnect your computer's monitor cable. 2. Connect the VGA computer cable to your computer's monitor port. 3.

  • Page 35: Connecting To A Computer For Usb Video And Audio

    4. Connect the other end to any available USB port on your computer. 5. Do one of the following: • Windows 11/Windows 10/Windows 8.x: Click EPSON_PJ_UD when it appears on the desktop, then select Run EMP_UDSE.EXE in the dialog box that appears to install the Epson USB Display software.

  • Page 36: Connecting To Video Sources

    • Mac: The USB Display setup folder appears on your screen. Select USB Display Installer and follow the on-screen instructions to install the Epson USB Display software. Follow any on-screen instructions. You need to install this software only the first time you connect the projector to the computer.

  • Page 37: Connecting To A Composite Video Source

    2. Connect the other end to one of the projector's HDMI ports. Note: The projector converts the digital audio signal sent from your video source into a mono analog signal for the internal speaker or a stereo analog signal if you are connecting to external speakers. Note: If you have problems hearing audio through the HDMI connection, you can use one of the projector's audio ports instead to play sound.

  • Page 38: Connecting External Output Devices

    1. Connect the cable with the yellow connector to your video source's yellow video output port. 2. Connect the other end to the projector's Video port. 3. Connect the audio cable to your video source's audio out ports. 4. Connect the other end to the projector's L and R audio ports. Parent topic: Connecting to Video Sources Connecting External Output Devices...

  • Page 39: Connecting To An External Computer Monitor

    Connecting to External Speakers Connecting a Microphone Parent topic: Projector Connections Connecting to an External Computer Monitor If you connected a computer to the projector's Computer1 port, you can also connect an external monitor to the projector. This lets you see your presentation on the external monitor even when the projected image is not visible.

  • Page 40: Connecting To External Speakers

    Connecting a Microphone You can connect a microphone to the projector's Mic port to provide audio support during presentations (EB-L210W/EB-L260F). Note: The projector does not support plug-in-power microphones. If you want to output audio from the microphone when the projector is off, select Always On as the A/V Output setting in the Signal I/O...

  • Page 41: Connecting To External Usb Devices

    1. Connect the microphone cable to the projector's Mic port. 2. Turn on the microphone, if necessary. 3. If you hear a crackling noise or the volume is too high or low, adjust the Mic Input Level setting in the Signal I/O menu. Parent topic: Connecting External Output Devices Related references...

  • Page 42: Connecting A Usb Device Or Camera To The Projector

    Starting a PC Free Slideshow Related topics Projecting in Content Playback Mode (EB-L260F/EB-L265F) Connecting a USB Device or Camera to the Projector You can connect your USB device or camera to the projector's USB-A port and use it to project images and other content.

  • Page 43: Selecting The Connected Usb Source

    2. Connect the USB cable (or USB flash drive) to the projector's USB-A port. Note: Use the USB cable supplied with or specified for use with your device. Do not connect a USB hub or a USB cable longer than 10 feet (3 m), or the device may not operate correctly. 3.

  • Page 44: Connecting To A Document Camera

    Parent topic: Connecting to External USB Devices Connecting to a Document Camera You can connect a document camera to your projector to project images from the camera. Note: The connection method varies depending on your document camera model. For additional features supported by software, connect your document camera to your computer using the camera's USB port instead of connecting the camera to the projector.
  • Page 45 2. Insert the batteries with the + and – ends facing as shown. Warning: Make sure the batteries are inserted in the correct positions. If the batteries are not inserted correctly, they could explode or leak, causing a fire, injury, or damage to the product. 3.

  • Page 46: Using The Projector On A Network

    CD, if included, or download the software and manuals as necessary. Note: If your projector is connected via a LAN (Ethernet) cable to a network that includes a wireless access point, you can connect to the projector wirelessly through the access point using the Epson network software.

  • Page 47: Selecting Wired Network Settings

    2. Connect the other end of the cable to the projector's LAN port. Parent topic: Wired Network Projection Selecting Wired Network Settings Before you can project from computers on your network, you must select the network settings for the projector using its menu system. Note: Make sure you already connected the projector to your wired network using the LAN port.
  • Page 48 3. Select the Network menu and press Enter. 4. Select Network Settings and press Enter. 5. Select Projector Name and enter a name up to 16 alphanumeric characters long to identify the projector on a network. 6. Set the Priority Control Interface setting to Wired LAN. 7.
  • Page 49 8. Select IP Settings and press Enter. 9. Select your IP settings as necessary: • If your network assigns addresses automatically, turn on the DHCP setting. • If you must set addresses manually, turn off DHCP and enter the projector's IP Address, Subnet Mask, and Gateway Address as needed.

  • Page 50: Wireless Network Projection

    CD, if included, or download the software and manuals as necessary. Note: If your projector is connected via a LAN cable to a network that includes a wireless access point, you can connect to the projector wirelessly through the access point using the Epson network software.

  • Page 51: Connecting Directly To A Smartphone Or Tablet

    You can display a QR code on the screen and use it to connect a single smartphone or tablet to your projector with the Epson iProjection app. 1. Download the latest version of the Epson iProjection app from the App Store or Google Play and install it on your smartphone or tablet.
  • Page 52 3. Select the Management menu and press Enter. 4. Select On as the Wireless LAN Power setting.
  • Page 53 5. Select the Network menu and press Enter. 6. Select Network Settings and press Enter. 7. Set the Priority Control Interface setting to Wireless LAN.
  • Page 54 Note: The projector displays a random keyword that you must enter from a computer using the Epson iProjection (Windows/Mac) software to access the projector. 11. Select On as the Epson iProjection setting. 12. Select the following settings as necessary: •...

  • Page 55: Using Quick Wireless Connection (Windows)

    You can create a Quick Wireless Connection USB Key to quickly connect the projector to a Windows computer wirelessly. Then you can project your presentation and remove the key when you are done. 1. Create a Quick Wireless Connection USB Key with a USB flash drive and the Epson iProjection (Windows) software.
  • Page 56 6. Remove the USB key. 7. Insert the USB key into a USB port on your computer. 8. Follow the on-screen instructions to install the Epson iProjection software. Note: If you see a Windows Firewall message, click Yes to disable the firewall. You need administrator authority to install the software.

  • Page 57: Selecting Wireless Network Settings Manually

    9. Run your presentation as necessary. 10. When you finish projecting wirelessly, select the Safely Remove Hardware option in the Windows taskbar, then remove the USB key from your computer. Note: You can share the USB key with other computers without disconnecting your computer. You may need to restart your computer to reactivate your wireless LAN connection.
  • Page 58 5. Select the Network menu and press Enter. 6. Select Network Settings and press Enter. 7. Select Projector Name and enter a name up to 16 alphanumeric characters long to identify the projector on the network. 8. Set the Priority Control Interface setting to Wireless LAN. 9.
  • Page 59 10. Select the Wireless LAN menu and press Enter. 11. Select Search Access Point and press Enter. The projector searches for wireless networks. 12. Select the network you want to connect to and enter the password, if necessary. Note: If you need to assign the SSID manually, select SSID to enter the SSID. The SSID and password are case-sensitive.
  • Page 60 18. Turn on the Projector Keyword setting if you want to prevent access to the projector by anyone not in the room with it. Note: The projector displays a random keyword that you must enter from a computer using the Epson iProjection (Windows/Mac) software to access the projector. 19. Set the Epson iProjection setting to On.

  • Page 61: Wireless Lan Menu Settings

    • Moderator Password lets you enter a password up to 4 numbers long for accessing the projector as a moderator with the Epson iProjection (Windows/Mac) software or the Epson iProjection app. • Keyword Interrupt Display lets you select whether to display a projector keyword on the projected image when accessing the projector using Epson iProjection.
  • Page 62 Setting Options Description SSID Up 32 alphanumeric characters Manually set the SSID (network name) of the wireless LAN system the projector is connecting to Security WPA2/WPA3-PSK Selects the type of security used on the wireless network WPA2/WPA3-EAP WPA2/WPA3-PSK: uses WPA3-PSK WPA2/WPA3 personal mode;...
  • Page 63 The DNS server resolves the host name IPv6 Enables IPv6 to allow monitoring and control of the projector over a network using Epson Web Control and PJLink. When enabled, the following settings are available: Auto Configuration: selects whether to automatically assign...

  • Page 64: Selecting Wireless Network Settings In Windows

    Selecting Wireless Network Settings in Windows Before connecting to the projector, select the correct wireless network on your computer. 1. To access your wireless utility software, access the Desktop and double-click the network icon on the Windows taskbar. 2. Do one of the following: •...
  • Page 65 1. Press the Menu button. 2. Select the Network menu and press Enter. 3. Select Network Settings and press Enter. 4. Do one of the following: • To connect directly to a wireless device (Simple AP mode), select Passphrase, press Enter, and enter a passphrase from 8 to 63 characters long.

  • Page 66: Installing The Wireless Lan Module

    Registering Digital Certificates from a Web Browser Installing the Wireless LAN Module To use multiple wireless connection methods at the same time, install the optional Epson 802.11b/g/n wireless module in the projector. Do not install any other type of wireless module.
  • Page 67 2. Insert the wireless LAN module into a USB-A port. 3. Attach the wireless LAN module cover and secure it using the screw you removed. The light on the wireless LAN module turns on when the module is installed and operating. The light flashes when the module is communicating over the network.

  • Page 68: Wireless Network Projection From A Mobile Device Or Windows Computer (Screen Mirroring)

    Wireless Network Projection from a Mobile Device or Windows Computer (Screen Mirroring) You can send images to your projector from mobile devices such as laptops, smartphones, and tablets using Miracast technology or from a Windows computer. If your device supports Miracast, you do not need to install any additional software.
  • Page 69 1. Press the Menu button. 2. Select the Management menu and press Enter. 3. Set the Wireless LAN Power setting to On.
  • Page 70 4. Select the Network menu and press Enter. 5. Select Network Settings and press Enter. 6. Select Priority Control Interface and press Enter. 7. Choose one of the following options: • If you are casting images over a wired LAN, select Wired LAN. •...

  • Page 71: Connecting For Screen Mirroring With A Windows 8.X/Windows 10/Windows 11 Computer

    • Screen Mirroring Info displays connection information when projecting from a Screen Mirroring source. 12. When you finish selecting settings, select Return and press Enter to return to the Network Settings screen. 13. Select Set, and follow the on-screen instructions to save your settings and exit the menus. Parent topic: Wireless Network Projection from a Mobile Device or Windows Computer (Screen Mirroring)

  • Page 72: Connecting For Screen Mirroring With Miracast

    Note: It may take some time to establish the connection. Do not disconnect the projector's power cord while it is connecting to your device. This may cause your device to freeze or malfunction. Parent topic: Wireless Network Projection from a Mobile Device or Windows Computer (Screen Mirroring) Related references Network Settings - Network Menu...

  • Page 73: Setting Up Projector Network E-Mail Alerts

    Related tasks Selecting Screen Mirroring Settings Setting Up Projector Network E-Mail Alerts You can set up the projector to send you an e-mail alert over the network if there is a problem with the projector. Note: If the Standby Mode setting is set to Communication On in the Operation menu, you can receive e-mail alerts even if the projector is in standby mode (the power is off).

  • Page 74: Network Projector E-Mail Alert Messages

    • The email address entered as the From setting • Epson Projector on the subject line • The name of the projector experiencing a problem • The IP address of the affected projector •...

  • Page 75: Controlling A Networked Projector Using A Web Browser

    3. Enter up to two IP addresses to receive SNMP notifications as the Trap IP Address setting, using 0 to 255 for each address field. Note: To enter the IP address using the numeric keys on the remote control, press and hold the Num button.
  • Page 76 Note: If you attempt to connect to the Web Control screen via a proxy server, the screen will not be displayed. Make a direct connection to the Web Control screen. Caution: Do not remove the USB flash drive from the projector or disconnect the projector's power cord when the Playlists or USB Memory Device screens are displayed in Content Playback mode.
  • Page 77 In Content Playback mode (EB-L260F/EB-L265F): Note: To disable this mode, set Content Playback to Off in the Operation menu. 4. To control projection remotely, select the Basic Control option from the Web Control screen. Note: If you see a log in window, enter your user name and password. (The default user name is...
  • Page 78 Selects the USB Display source Selects the Screen Mirroring source A/V Mute button control Freeze button control Closed captioning control (not available in all countries) Displays a QR code for connecting with iOS or Android devices using the Epson iProjection...

  • Page 79: Using Crestron Connected

    Crestron Connected lets you control and monitor your projector using a web browser. Note: You cannot use the Message Broadcasting feature in the Epson Projector Management software when you use Crestron Connected. For additional information on Crestron Connected, contact Crestron.

  • Page 80: Setting Up Crestron Connected

    Setting Up Crestron Connected To set up your projector for monitoring and control using a Crestron Connected system, make sure your computer and projector are connected to the network. 1. Press the Menu button. 2. Select the Network menu and press Enter.
  • Page 81 Enter. 5. Set the Crestron Connected setting to On to allow the projector to be detected. Note: Enabling Crestron Connected disables the Message Broadcasting feature in the Epson Projector Management software. 6. When you are finished selecting settings, select Return and press Enter to return to the Network Settings menu.

  • Page 82: Controlling A Networked Projector Using Crestron Connected

    1. Start your web browser on a computer connected to the network. 2. Type the projector's IP address into the browser's address box and press the computer's Enter key. You see the Epson Web Control screen: 3. Select Crestron Connected to view the configuration page. Please see your network administrator for setting up the configuration page.

  • Page 83: Registering A Digital Certificate On The Projector

    Registering a Digital Certificate on the Projector Follow the instructions here if you need to install a digital certificate on the projector to provide security for your presentation files. Note: You can register a digital certificate over a network. However, be sure to register just once or the certificate may not install correctly.

  • Page 84: Registering Digital Certificates From A Web Browser

    Related references Network Settings - Network Menu Related tasks Registering Digital Certificates from a Web Browser Registering Digital Certificates from a Web Browser You can register the digital certificates on the projector for wireless LAN authentication. Note: You can also register the digital certificates in the projector's Network menu. However, be sure to register just once or the certificate may not install correctly.

  • Page 85: Digital Certificate Types

    You see a screen like this: 7. Click the Choose File button, select the certificate file, and click Open. Note: The button name may vary depending on the browser you are using. 8. Enter a password in the Password box and click Send. 9.
  • Page 86 Specification Description Encryption Hashes MD5/SHA-1/SHA-256/SHA-384/SHA-512 Key length 512/1024/2048/4096 bit Password Up to 64 alphanumeric characters; required CA Certificate (PEAP/PEAP-TLS/EAP-TLS/EAP-FAST) Specification Description Format X509v3 Extension DER/CER/PEM Encryption Hashes MD5/SHA-1/SHA-256/SHA-384/SHA-512 Key length 512/1024/2048/4096 bit Encoding BASE64/Binary Web Server Certificate (Secure HTTP) Specification Description Format PKCS#12...

  • Page 87: Art-Net Channel Definitions

    Art-Net is an Ethernet communication protocol based on the TCP/IP protocol. You can control the projector by using a DMX controller or an application system (EB-L260F/EB-L265F). The following table lists the channel definitions used to control the projector in Art-Net.
  • Page 88 Channel/Function Operation Parameters Description 3 Switch source Non-operational 0 to 7 (default is 0) Switches to the specified source HDMI1 8 to 15 HDMI2 16 to 23 Non-operational 24 to 31 Non-operational (DVI-D) 32 to 39 Non-operational (Display 40 to 47 Port) 48 to 55 Non-operational (SDI)
  • Page 89 Channel/Function Operation Parameters Description 10 Content playback Non-operational 0 to 3 (default is 0) Plays the specified playlist Playlist 1 4 to 7 Playlist 2 8 to 11 Playlist 3 12 to 15 Playlist 4 16 to 19 Playlist 5 20 to 23 Playlist 6 24 to 27...
  • Page 90 Channel/Function Operation Parameters Description 10 Content playback Playlist 16 64 to 67 Playlist 17 68 to 71 Playlist 18 72 to 75 Playlist 19 76 to 79 Playlist 20 80 to 83 Playlist 21 84 to 87 Playlist 22 88 to 91 Playlist 23 92 to 95 Playlist 24...
  • Page 91 Channel/Function Operation Parameters Description 10 Content playback Playlist 41 164 to 167 Playlist 42 168 to 171 Playlist 43 172 to 175 Playlist 44 176 to 179 Playlist 45 180 to 183 Playlist 46 184 to 187 Playlist 47 188 to 191 Playlist 48 192 to 195 Playlist 49...

  • Page 92: Using Basic Projector Features

    Controlling the Volume with the Volume Buttons Selecting a Quick Startup Setting Projecting a PC Free Presentation Projecting in Content Playback Mode (EB-L260F/EB-L265F) Turning On the Projector Turn on the projector before you turn on the computer or video equipment you want to use.
  • Page 93 1. Open the projector's lens cover. 2. Connect the power cord to the projector's power inlet. 3. Plug the power cord into an electrical outlet.
  • Page 94 The projector's power light turns blue. This indicates that the projector is receiving power. Note: With Direct Power On turned on, the projector turns on as soon as you plug it in. If you enable the Auto Power On setting in the projector's Operation menu, the projector turns on when it detects a signal or cable connection from the selected port.

  • Page 95: Using The Home Screen

    Related references Feature Settings - Operation Menu Projector Light Status Using the Home Screen You can select input sources and other frequently used options from the Home screen. 1. To display the Home screen, do one of the following: • Press the Home button on the control panel or remote control. •...

  • Page 96: Turning Off The Projector

    Displays the Connection Guide You can view steps for different wireless connection methods depending on the devices you are using, such as smartphones or computers. Lets you select the following common projector settings (these settings may vary depending on other selected settings): •...
  • Page 97 2. Press the power button again. (To leave it on, press any other button.) The projector beeps twice, the laser turns off, and the Status light turns off. Note: With Epson's Instant Off technology, there is no cool-down period so you can pack up the projector for transport right away (if necessary).
  • Page 98 3. To transport or store the projector, make sure the power light is blue (not flashing) and the Status light is off, then unplug the power cord. Caution: To avoid damaging the projector or laser, never unplug the power cord when the Status light is on or flashing.

  • Page 99: Selecting The Language For The Projector Menus

    Parent topic: Using Basic Projector Features Related references Administration Settings - Management Menu Projector Light Status Selecting the Language for the Projector Menus If you want to view the projector's menus and messages in another language, you can change the Language setting.

  • Page 100: Setting The Date And Time

    Parent topic: Using Basic Projector Features Setting the Date and Time You can set the date and time for the projector. 1. Press the Menu button. 2. Select the Management menu and press Enter. 3. Select the Date & Time setting and press Enter.

  • Page 101: Adjusting The Image Height

    12. Select Internet Time and press Enter. 13. Enter the IP address for the Internet time server you want to use and select OK. 14. Select Set and press Enter. 15. Press Menu or Esc to exit the menus. Parent topic: Using Basic Projector Features Adjusting the Image Height If you are projecting from a table or other flat surface, and the image is too high or low, you can adjust...

  • Page 102: Image Shape

    If the projected image is unevenly rectangular, you need to adjust the image shape. Parent topic: Using Basic Projector Features Related tasks Turning On the Projector Image Shape You can project an evenly rectangular image by placing the projector directly in front of the center of the screen and keeping it level.

  • Page 103: Correcting Image Shape With The Keystone Buttons

    After correction, your image is slightly smaller. Parent topic: Image Shape Related tasks Turning On the Projector Correcting Image Shape with the Keystone Buttons You can use the projector's keystone correction buttons to correct the shape of an image that is unevenly rectangular on the sides.
  • Page 104 3. Press a keystone button on the projector's control panel to adjust the image shape. After correction, your image is slightly smaller. Note: If the projector is installed out of reach, you can also correct the image shape with the remote control using the H/V-Keystone settings in the projector menus.

  • Page 105: Correcting Image Shape With Quick Corner

    Related references Installation Settings - Installation Menu Related tasks Turning On the Projector Correcting Image Shape with Quick Corner You can use the projector's Quick Corner setting to correct the shape and size of an image that is unevenly rectangular on all sides. Note: If you change the Screen Type setting or adjust the image position, your image adjustments are reset.
  • Page 106 3. Select the Installation menu and press Enter. 4. Select the Geometry Correction setting and press Enter. 5. Select the Quick Corner setting and press Enter. Note: You may see a confirmation screen. Select Yes and press Enter again.
  • Page 107 You see the Quick Corner adjustment screen: 6. Use the arrow buttons on the projector or remote control to select the corner of the image you want to adjust. Then press Enter. Note: To reset your adjustments, press and hold the Esc button for at least 2 seconds to display a reset screen.

  • Page 108: Correcting Image Shape With Arc Correction

    7. Press the arrow buttons to adjust the image shape as necessary. Press Enter to return to the area selection screen. Note: You can also use the numeric buttons on the remote control to adjust the image shape. If one of the directional arrows on the screen turns gray, you cannot adjust the shape any further in that direction.
  • Page 109 1. Turn on the projector and display an image. 2. Press the Menu button. 3. Select the Installation menu and press Enter. 4. Select the Geometry Correction setting and press Enter. 5. Select the Arc Correction setting and press Enter. Then select Yes and press Enter again.
  • Page 110 You see the Arc Correction adjustment screen: Note: To reset your adjustments, press the Esc button for at least 2 seconds to display a reset screen, and select Yes.

  • Page 111: Correcting Image Shape With Point Correction

    6. Use the arrow buttons on the projector or the remote control to select the corner or side of the image you want to adjust. Then press Enter. Note: You can also use the numeric buttons on the remote control to adjust the image shape. If one of the directional arrows on the screen turns gray, you cannot adjust the shape any further in that direction.
  • Page 112 4. Select the Point Correction setting again and press Enter. Note: For fine tuning, select Quick Corner to roughly correct the shape and size of an image and then select Point Correction to adjust them more precisely. 5. Select the number of grid lines to display and press Enter.

  • Page 113: Resizing The Image With The Zoom Ring

    9. When you are finished, press the Menu button. Note: If necessary, you can fine-tune your image adjustments using the Quick Corner setting. Parent topic: Image Shape Related references Installation Settings - Installation Menu Related tasks Turning On the Projector Correcting Image Shape with Quick Corner Resizing the Image with the Zoom Ring You can resize the image using the projector's zoom ring.
  • Page 114 1. Turn on the projector and display an image. 2. Press the Menu button on the control panel or remote control. 3. Select the Installation menu and press Enter. 4. Select Screen Position and press Enter.

  • Page 115: Focusing The Image Using The Focus Ring

    5. Use the arrow buttons on the remote control or projector to adjust the position of the image. 6. When you are finished, press the Menu button. Parent topic: Using Basic Projector Features Related references Installation Settings - Installation Menu Related tasks Turning On the Projector Focusing the Image Using the Focus Ring...

  • Page 116: Remote Control Operation

    2. To sharpen the image focus, rotate the projector’s focus ring. Parent topic: Using Basic Projector Features Related tasks Turning On the Projector Remote Control Operation The remote control lets you control the projector from almost anywhere in the room, up to 19.7 feet (6 m) away.
  • Page 117 19.7 feet (6 m) 30° With cable cover installed (EB-L260F/EB-L265F): 19.7 feet (6 m) 20° 30° 10° Note: Avoid using the remote control in conditions with bright fluorescent lights or in direct sunlight, or the projector may not respond to commands. If you will not use the remote control for a long time, remove the batteries.

  • Page 118: Selecting An Image Source

    Selecting an Image Source If you connected multiple image sources to the projector, such as a computer and DVD player, you may want to switch from one image source to the other. Note: If you turned on the Auto Source Search setting in the Operation menu, the projector automatically switches to another detected image source if the signal to the current image source is lost.
  • Page 119 Note: Your Home screen may look different from the illustration shown here. A checkmark appears on the image from the current input source. You can see thumbnail previews of most input sources (except the USB input source when in Content Playback mode [EB-L260F/EB- L265F]).

  • Page 120: Projection Modes

    Projection Modes Depending on how you positioned the projector, you may need to change the projection mode so your images project correctly. • Front (default setting) lets you project from a table in front of the screen. • Front/Ceiling flips the image over top-to-bottom to project upside-down from a ceiling or wall mount. •...

  • Page 121: Changing The Projection Mode Using The Menus

    3. To change projection back to the original mode, hold down the A/V Mute button for 5 to 10 seconds again. Parent topic: Projection Modes Related tasks Turning On the Projector Changing the Projection Mode Using the Menus You can change the projection mode to flip the image over top-to-bottom and/or left-to-right using the projector menus.

  • Page 122: Image Aspect Ratio

    Note: Set the Screen Type setting in the projector's Installation menu before changing the aspect ratio. Note: This setting is available only when the Scale setting is turned off or the Scale Mode setting is set to Full Display (EB-L260F/EB-L265F). 1. Turn on the projector and switch to the image source you want to use.

  • Page 123: Available Image Aspect Ratios

    3. To cycle through the available aspect ratios for your input signal, press the Aspect button repeatedly. Note: To remove black bars when projecting from a computer, set the Resolution setting to Wide or Normal in the Image menu, depending on your computer's resolution. Parent topic: Image Aspect Ratio Related references...

  • Page 124: Color Mode

    Related references Installation Settings - Installation Menu Image Quality Settings - Image Menu Color Mode The projector offers different Color Modes to provide optimum brightness, contrast, and color for a variety of viewing environments and image types. You can select a mode designed to match your image and environment, or experiment with the available modes.

  • Page 125: Available Color Modes

    Best for standard sRGB computer displays Blackboard Best for projecting images directly on a green chalkboard DICOM SIM (EB-L260F/EB-265F) Best for projecting X-rays and other medical images (shows clear shadows) Multi-Projection (EB-L260F/EB- Best for projecting from multiple projectors (reduces the color tone...
  • Page 126 3. Select the Image menu and press Enter. 4. Select RGBCMY and press Enter. 5. Select the color to adjust and press Enter.

  • Page 127: Adjusting Gamma

    6. Do the following as necessary for each setting: • To adjust the overall hue of the color (bluish, greenish, reddish), adjust the Hue setting. • To adjust the overall vividness of the color, adjust the Saturation setting. • To adjust the overall brightness of the color, adjust the Brightness setting. 7.
  • Page 128 3. Select the Image menu and press Enter. 4. Select the Gamma setting and press Enter. 5. Select and adjust the correction value. You see a screen like this:...
  • Page 129 Note: If you set the Color Mode setting to DICOM SIM in the projector's Image menu, select the adjustment value according to the projection size (EB-L260F/EB-L265F). If the projection size is 80 inches (203 cm) or less, select a small value. If the projection size is 80 inches or more, select a large value.

  • Page 130: Adjusting The Image Resolution

    Adjusting the Image Resolution You can adjust the image resolution to project a clear image with an emphatic texture and material feel. 1. Turn on the projector and switch to the image source you want to use. 2. Press the Menu button. 3.

  • Page 131: Adjusting The Projector's Brightness Level

    • Super-resolution • Detail Enhancement 7. Adjust each setting in the projector's Image menu individually as necessary. • Adjust the Noise Reduction setting to reduce flickering in images. • Adjust the MPEG Noise Reduction setting to reduce the noise or artifacts seen in MPEG video. •...
  • Page 132 3. Select the Operation menu and press Enter. 4. Select Light Source Brightness Control and press Enter. 5. If you want to maintain the brightness at a specific level, select the Maintain Brightness setting and select On. 6. If you turn on Maintain Brightness, select the Maintain Brightness Level setting.

  • Page 133: Turning On Dynamic Contrast

    9. Press Menu or Esc to exit the menus. Note: For the best results in maintaining the brightness level, set the Light Source Calibration setting to Run Periodically in the projector's Management menu (EB-L260F/EB-L265F). Parent topic: Using Basic Projector Features...
  • Page 134 3. Select the Image menu and press Enter. 4. Select the Dynamic Contrast setting and press Enter. 5. Choose one of the following options and press Enter: • Normal to adjust brightness at the standard speed. • High Speed to adjust brightness as soon as the scene changes. 6.

  • Page 135: Controlling The Volume With The Volume Buttons

    Controlling the Volume with the Volume Buttons You can use the Volume buttons on the projector or the projector remote control to adjust the volume of your projected content. The volume buttons control the projector’s internal speaker system or any external speakers you connected to the projector.
  • Page 136 1. Turn on the projector. 2. Press the Menu button. 3. Select the Operation menu and press Enter. 4. Select the Quick Startup setting and press Enter. 5. Select how long you want to enable Quick Startup mode for and press Enter.

  • Page 137: Projecting A Pc Free Presentation

    This lets you quickly and easily display the contents of the files and control their display using the projector's remote control. Note: Make sure Content Playback is disabled in the projector's Operation menu (EB-L260F/EB- L265F). PC Free Precautions...

  • Page 138: Supported Pc Free File Types

    • You can use the following features while projecting in PC Free: • Freeze • A/V Mute • E-Zoom Parent topic: Projecting a PC Free Presentation Supported PC Free File Types You can project these types of files using the projector's PC Free feature. Note: For best results, place your files on media that is formatted in FAT16/32.

  • Page 139: Starting A Pc Free Slideshow

    File type and Details extension Motion JPEG Supports only AVI 1.0 movie (.avi) Make sure the file is not: • Saved with a video codec other than Motion JPEG • Saved with an audio codec other than LPCM or IMA ADPCM •...
  • Page 140 Note: You can change the slideshow operation options or add special effects by highlighting Option at the bottom of the screen and pressing Enter. Note: Make sure Content Playback is disabled in the projector's Operation menu (EB-L260F/EB- L265F). 1. Press the USB button on the projector remote control.

  • Page 141: Starting A Pc Free Movie Presentation

    3. Do one of the following: • To display an individual image, press the arrow buttons to highlight the image and press Enter. (Press the Esc button to return to the file list screen.) • To display a slide show of all the images in a folder, press the arrow buttons to highlight the Slideshow option at the bottom of the screen and press Enter.
  • Page 142 The PC Free screen appears. 2. Do the following as necessary to locate your files: • If you need to display files inside a subfolder on your device, press the arrow buttons to highlight the folder and press Enter. • To move back up a folder level on your device, highlight Back to Top and press Enter.

  • Page 143: Pc Free Display Options

    Parent topic: Projecting a PC Free Presentation Related tasks Connecting a USB Device or Camera to the Projector PC Free Display Options You can select these display options when using the projector's feature. Setting Options Description Display Order Name Order Displays files in name order Date Order Displays files in date order...

  • Page 144: Projecting In Content Playback Mode (Eb-L260F/Eb-L265F)

    Parent topic: Projecting a PC Free Presentation Projecting in Content Playback Mode (EB-L260F/EB-L265F) You can project images or other content from an external storage device using Content Playback mode. You can also add color or effects to the projected image.
  • Page 145 1. Turn on the projector. 2. Press the Menu button. 3. Select the Operation menu and press Enter. 4. Select the Content Playback setting and press Enter. 5. Select the On setting and press Enter. You see a confirmation prompt. 6.

  • Page 146: Projecting A Playlist In Content Playback Mode

    You can project playlists that contain images and movies in Content Playback mode. 1. Create a playlist and export it to a USB device using the Epson Projector Content Manager software. Note: See the Epson Projector Content Manager Operation Guide for more information.
  • Page 147 Note: To select a specific playlist, select the USB Viewer setting in the Operation menu and use the arrow buttons to select your playlist. Parent topic: Projecting in Content Playback Mode (EB-L260F/EB-L265F) Related references Additional Projector Software and Manuals...

  • Page 148: Creating A Playlist Using Epson Web Control

    Connecting a USB Device or Camera to the Projector Switching to Content Playback Mode Creating a Playlist Using Epson Web Control You can create playlists using a web browser and save them to a USB flash drive connected to a projector on a network when the projector is in Content Playback mode.

  • Page 149: Adding Effects To The Projected Image

    You can play the playlist from the Remote or Playlist screen. If you want to specify when the playlist starts and finishes, schedule the playlist using the Epson Projector Content Manager software. See the Epson Projector Content Manager Operation Guide for details.
  • Page 150 3. Select the Shape Filter setting and adjust the options as necessary. • Shape: Select a circle, rectangle, or other shape effect Note: You can add your images as customized shapes using the Epson Projector Content Manager software. See the Epson Projector Content Manager Operation Guide for details.

  • Page 151: Using Spotlight Mode

    Using Spotlight Mode You can use spotlight mode to project a virtual spotlight and customize the position, size, shape and width of the light. 1. Press the Menu button on the projector or remote control.
  • Page 152 2. Select the Management menu and press Enter. 3. Select the User Button setting and press Enter. 4. Select the Spotlight setting and press Enter. The Spotlight function is assigned to the User button on the remote control. 5. Press the User button on the remote control. The projected image becomes a spotlight.
  • Page 153 Parent topic: Projecting in Content Playback Mode (EB-L260F/EB-L265F) Related references Administration Settings - Management Menu Feature Settings - Operation Menu...

  • Page 154: Adjusting Projector Features

    Adjusting Projector Features Follow the instructions in these sections to use your projector's feature adjustments. Shutting Off the Picture and Sound Temporarily Stopping Video Action Temporarily Zooming Into and Out of Images Using Multiple Projectors Projecting Multiple Images Simultaneously Projector Security Features Adjusting the Color Convergence (Panel Alignment) Creating a User Pattern to Display Copying Menu Settings Between Projectors...

  • Page 155: Stopping Video Action Temporarily

    Note: You can also stop projection using the A/V Mute slide lever on the projector. Parent topic: Adjusting Projector Features Related references Feature Settings - Operation Menu Stopping Video Action Temporarily You can temporarily stop the action in a video or computer presentation and keep the current image on the screen.

  • Page 156: Using Multiple Projectors

    Note: This feature is unavailable if the Scale setting in the Image menu is enabled (EB-L260F/EB- L265F). 1. Press the E-Zoom + button on the remote control. The center of the projected image is enlarged. 2. Use the following buttons on the remote control to adjust the zoomed image: •...

  • Page 157: Projector Identification System For Multiple Projector Control

    Using Multiple Projectors Setting the Projector ID If you want to control multiple projectors from a remote control, give each projector a unique ID. 1. Press the Menu button. 2. Select the Multi-Projection (EB-L260F/EB-L265F) or Installation (EB-L210W) menu and press Enter.

  • Page 158: Setting The Remote Control Id

    3. Select Projector ID and press Enter. 4. Press the arrow buttons on the remote control to select the identification number you want to use for the projector. Then press Enter. Repeat these steps for all the other projectors you want to operate from one remote control. Note: If you don't know the projector's ID, aim the remote control at the projector and press the ID button to temporarily display the projector's ID on the screen.

  • Page 159: Adjusting Color Uniformity

    2. Make sure you know the projector's ID number as set in the Multi-Projection or Installation menu's Projector ID setting. Note: If you have forgotten the projector's ID, aim the remote control at the projector and press the ID button to temporarily display the projector's ID on the screen. If you turn off the Projector ID setting, the remote control will operate the projector regardless of the ID selected on the remote.
  • Page 160 1. Press the Menu button on the remote or control panel, select the Management menu, and press Enter.
  • Page 161 2. Select the Color Uniformity setting and press Enter. 3. Select On as the Color Uniformity setting and press Enter, then press Esc. 4. Select Adjustment Level and press Enter. 5. Select an adjustment level and press Esc. 6. Select Start Adjustments and press Enter.
  • Page 162 7. Select the area you want to adjust and press Enter. 8. Select Red, Green, or Blue and press the left arrow button to weaken the color tone or the right arrow button to strengthen the color tone. Note: The adjustment screen changes each time you press Enter.

  • Page 163: Configuring Tiling Manually

    Configuring Tiling Manually You can project the same image from multiple projectors to create one large image (EB-L260F/EB- L265F). 1. Turn on the projector. 2. Press the Menu button. 3. Select Multi-Projection > Tiling > Layout. 4. Select the number of rows and columns you are setting up as the Row and Column settings. Then select Set and press Enter.

  • Page 164: Blending The Image Edges

    After performing the steps here, adjust the images for any gaps and differences in color. Parent topic: Using Multiple Projectors Blending the Image Edges You can use the projector's Edge Blending feature to create a seamless image from multiple projectors (EB-L260F/EB-L265F). 1. Press the Menu button.
  • Page 165 2. Select the Multi-Projection menu and press Enter. 3. Select the Edge Blending setting and press Enter. 4. Turn on the Edge Blending, Line Guide, and Pattern Guide settings. Note: If the projected guide is unclear, try changing the Guide Color setting. 5.
  • Page 166 You see a screen like this: 6. Select the Blending setting and select On. 7. Press Esc to return to the previous screen. 8. Select the Blend Start Position setting and adjust the point where edge blending begins. Note: If you created a unified image area using the Edge Blending feature, set the Blend Start Position setting to 0.

  • Page 167: Matching The Image Colors

    If the blended area does not overlap exactly, correct the shape of the blended area using Point Correction. Parent topic: Using Multiple Projectors Matching the Image Colors You can match the display color of multiple projectors that will project next to one another (EB- L260F/EB-L265F).
  • Page 168 You see this screen: 4. Press the left or right arrow button to select Adjustment Level 8. Note: There are several adjustment levels and you can adjust each level individually. 5. Press the left or right arrow buttons to adjust the Brightness setting. 6.

  • Page 169: Adjusting The Black Level

    Adjusting the Black Level When two images overlap, the overlapping area can appear differently from the areas that do not overlap. You can use the projector's Black Level setting to make the difference less noticeable (EB- L260F/EB-L265F). Note: You cannot adjust the black levels while projecting a test pattern, and you may not be able to adjust the black levels correctly if the Geometry Correction settings are set too high.
  • Page 170 2. Select the Multi-Projection menu and press Enter. 3. Select the Black Level setting and press Enter. Note: The Black Level setting is displayed only if Edge Blending is enabled and at least one (top, bottom, left, right) edge is set to On. 4.
  • Page 171 5. Select the area you want to adjust and press Enter. Note: The area you selected is displayed in orange. Adjust overlapping areas starting with the brightest areas first. For example, adjust area 2 to match area 1, then adjust area 3 to match area 2. 6.
  • Page 172 11. Select the Start Adjustments setting and press Enter. You see a screen with boundary lines indicating areas that are overlapping. The boundary lines are based on the Top Edge, Bottom Edge, Right Edge, and Left Edge settings you selected for the Edge Blending setting.

  • Page 173: Adjusting Rgbcmy

    You can adjust the Hue, Saturation, and Brightness settings for R (red), G (green), B (blue), C (cyan), M (magenta), and Y (yellow) color components (EB-L260F/EB-L265F). Turn on all the projectors and select the RGBCMY setting in each projector's Image menu so that the color tone on the combined screen becomes entirely even.
  • Page 174 2. Select the Image menu and press Enter. 3. Select the RGBCMY setting and press Enter. 4. Select the color you want to adjust and press Enter.

  • Page 175: Scaling An Image

    7. Press Menu or Esc to exit the menus. Parent topic: Using Multiple Projectors Scaling an Image You can project the same image from multiple projectors and use the Scale feature to crop and combine them into one large image (EB-L260F/EB-L265F).
  • Page 176 1. Press the Menu button. 2. Select the Multi-Projection menu and press Enter. 3. Select the Scale setting and press Enter. You see this screen: 4. Turn on the Scale setting. 5. Select the Scale Mode setting and select one of these options: •...

  • Page 177: Projecting Multiple Images Simultaneously

    • Full Display to adjust the image to the projector's screen size as you scale the image 6. If you selected Auto as the Scale setting, you can skip the remaining steps. If you selected Manual, adjust each of the following options as necessary: •...
  • Page 178 Note: You cannot use split screen with certain input source combinations. You cannot perform split screen projection in Content Playback mode or when you enable the Scale or Edge Blending options (EB-L260F/EB-L265F). 1. Press the Split button on the remote control.
  • Page 179 You are prompted for the number of screens. 2. Select 2 Screens or 4 Screens, depending on the number of input sources you want to project. If you selected 2 Screens, the currently selected input source moves to the left side of the screen. If you selected 4 Screens and used the split screen feature to project four images before, the projected images are arranged in the same order as they were previously.

  • Page 180: Input Sources For Split Screen Projection

    Input Sources for Split Screen Projection You can choose most input source combinations for split screen projection, but the following combinations are not supported: • Computer1, Computer2, Video • USB, USB Display, LAN Note: When you split the screen into four screens and select the USB and the Screen Mirroring input source at the same time, you can only select one Screen Mirroring source.

  • Page 181: Projector Security Features

    Projector Security Features You can secure your projector to deter theft or prevent unintended use by setting up the following security features: • Password security to prevent the projector from being turned on, and prevent changes to the startup screen and other settings. •...
  • Page 182 1. Hold down the Freeze button on the remote control for about 5 seconds or until you see this menu. 2. Press the down arrow to select Password and press Enter. You see the prompt "Change the password?". 3. Select Yes and press Enter.

  • Page 183: Selecting Password Security Types

    Selecting Password Security Types After setting a password, you see this menu, allowing you to select the password security types you want to use. If you do not see this menu, hold down the Freeze button on the remote control for about five seconds or until the menu appears.

  • Page 184: Entering A Password To Use The Projector

    • You see a "wrong password" message and a prompt to try again. Enter the correct password to proceed. • If you have forgotten the password, make note of the Request Code: xxxxx number that appears on the screen and contact Epson Support.

  • Page 185: Saving A User's Logo Image To Display

    • If you continue to enter an incorrect password many times in succession, the projector displays a request code and a message to contact Epson Support. Do not attempt to enter the password again. When you contact Epson Support, provide the displayed request code and proof of ownership for assistance in unlocking the projector.
  • Page 186 You see a prompt asking if you want to use the displayed image as a user's logo. Note: When you select User's Logo, adjustments such as Geometry Correction, E-Zoom, Aspect, Scale (EB-L260F/EB-L265F), and Screen Type are temporarily canceled. 5. Select Yes and press Enter.

  • Page 187: Locking The Projector's Buttons

    8. Select the Display menu and press Enter. 9. Select when you want to display the User's Logo screen: • To display it whenever there is no input signal, select No-Signal Screen and set it to Logo. • To display it whenever you turn the projector on, select Startup Screen and set it to On. To prevent anyone from changing the User's Logo settings without first entering a password, set a password and enable User's Logo security.

  • Page 188: Unlocking The Projector's Buttons

    3. Select the Control Panel Lock setting and press Enter. 4. Select one of these lock types and press Enter: • To lock all of the projector's buttons, select Full Lock. • To lock all buttons except the power button, select Except for Power. You see a confirmation prompt.

  • Page 189: Adjusting The Color Convergence (Panel Alignment)

    You can use the Panel Alignment feature to manually adjust the color convergence (the alignment of the red and blue colors) in the projected image (EB-L260F/EB-L265F). Note: You can adjust only the red or blue color convergence. Green is the standard color panel and cannot be adjusted.
  • Page 190 4. Select the Panel Alignment setting and press Enter. 5. Select On and press Enter. 6. Select the Select Color setting and choose one of the following: • R to adjust the red color convergence. • B to adjust the blue color convergence. 7.
  • Page 191 You see this screen: 10. Select one of the following: • Select Shift the whole panel to adjust the whole panel at the same time.Continue with the next step. • Select Adjust the four corners to adjust the corners of the panel one at a time. Skip to step 13. 11.
  • Page 192 14. Use the arrow buttons on the remote control to adjust the color alignment in the corner of the screen highlighted by the orange box. 15. Press the Enter button to move to the next corner of the screen. 16. When you are finished adjusting each corner of the screen, press Enter.

  • Page 193: Creating A User Pattern To Display

    Parent topic: Adjusting Projector Features Related references Display Settings - Display Menu Creating a User Pattern to Display You can transfer an image to the projector and then display it as a pattern to aid in presentations when you use the Pattern Display feature. This transferred image is called the User Pattern. 1.

  • Page 194: Copying Menu Settings Between Projectors

    Correction settings. Caution: If the copy process fails due to a power failure, communication error, or for any other reason, Epson will not be responsible for any repair costs incurred. The following settings will not transfer between projectors: • Light Source Hours •...

  • Page 195: Saving Settings To A Usb Flash Drive

    Saving Settings to a Computer Transferring Settings from a Computer Parent topic: Adjusting Projector Features Saving Settings to a USB Flash Drive You can save the projector settings you want to transfer to a USB flash drive. Note: Use an empty flash drive. If the drive contains other files, the transfer may not complete correctly. The flash drive must use the FAT format and cannot have any security features.

  • Page 196: Transferring Settings From A Usb Flash Drive

    The lights flash to indicate that settings are transferring to the flash drive. When the lights stop flashing, the power light turns blue and the projector enters standby mode. Caution: Do not unplug the power cord or remove the flash drive while the lights are flashing. This could damage the projector.
  • Page 197 2. Insert the flash drive into the USB-A port. Note: Connect the flash drive directly to the projector. Do not use a hub or your settings may not be saved correctly. 3. Press and hold the Menu button on the control panel or remote control as you connect the power cord to the projector's power inlet.

  • Page 198: Saving Settings To A Computer

    Related references Projector Light Status Saving Settings to a Computer You can save the projector settings you want to transfer to a computer. Your computer must be running one of the following operating systems: • Windows 10 • Windows 11 •...

  • Page 199: Transferring Settings From A Computer

    • Mac: Drag the removable disk icon for your projector from the desktop into the trash. The projector turns off when you disconnect the USB cable. Note: If the projector does not turn off and the lights continue flashing, see the link below for a solution.

  • Page 200: Scheduling Projector Events

    3. Connect the other end to any available USB port on your computer. 4. Press and hold the Menu button on the control panel or remote control as you connect the power cord to the projector's power inlet. 5. When all of the projector lights turn on, release the Menu button. The projector shows up as a removable disk on your computer.

  • Page 201: Saving A Scheduled Event

    Editing a Scheduled Event Parent topic: Adjusting Projector Features Related tasks Setting a Password Selecting Password Security Types Setting a Password Selecting Password Security Types Saving a Scheduled Event You can select projector commands you want to perform and schedule them as an event. Warning: Do not place flammable objects in front of the lens.
  • Page 202 You see a screen like this: 5. Select Add New and press Enter.
  • Page 203 You see a screen like this: 6. In the Event Settings section, select the events you want to have occur. (Select No Change for events that you do not want to occur.)

  • Page 204: Viewing Scheduled Events

    7. In the Date/Time Settings section, set the date and time for the scheduled events to occur. 8. When you are finished, select Save and press Enter. 9. To schedule more events, repeat the previous steps as necessary. 10. Select Complete and press Enter to save your changes.

  • Page 205: Editing A Scheduled Event

    You see a screen like this: Colored boxes on the calendar indicate the following: One-time event Repeating event Communication is on or off Event is invalid 5. To view an event, press the left and right arrow buttons on the remote to select a day. The screen displays the details of the events scheduled for that day.
  • Page 206 2. Select the Management menu and press Enter. 3. Select the Schedule Settings setting and press Enter. You see a screen like this: 4. Press the left or right arrow buttons to highlight the date on the calendar containing the scheduled event you want to edit.
  • Page 207 Parent topic: Scheduling Projector Events...

  • Page 208: Adjusting The Menu Settings

    Adjusting the Menu Settings Follow the instructions in these sections to access the projector menu system and change projector settings. Note: Not all settings are available, depending on your projector model. Using the Projector's Menus Image Quality Settings - Image Menu Input Signal Settings - Signal I/O Menu Installation Settings - Installation Menu Display Settings - Display Menu...
  • Page 209 You see the menu screen. 2. Press the up or down arrow button to move through the menus listed on the left. The settings for each menu are displayed on the right. Note: The available settings depend on the current input source, resolution, or other menu settings. 3.

  • Page 210: Image Quality Settings - Image Menu

    Parent topic: Adjusting the Menu Settings Image Quality Settings - Image Menu Settings on the Image menu let you adjust the quality of your image for the input source you are currently using. The available settings depend on the currently selected color mode and input source. Color Mode Settings Setting Options...
  • Page 211 Setting Options Description Color Saturation Varying levels available Adjusts the intensity of the image colors Tint Varying levels available Adjusts the balance of green to magenta tones in the image Sharpness Varying levels available Adjusts the sharpness or softness of image details White Balance Color Temp.
  • Page 212 Setting Options Description Image Enhancement Image Preset Mode Selects preset Image Enhancement settings Noise Reduction Reduces flickering in analog images MPEG Noise Reduction Reduces the noise or static in MPEG video Deinterlacing Sets whether to convert interlaced- to-progressive signals for interlaced video signals (480i/576i/1080i) Off: for fast-moving video images Video: for most video images...
  • Page 213 Setting Options Description RGBCMY Varying levels available Adjusts the hue, saturation, and brightness for each color Reset to Defaults — Resets all settings for the Color Mode currently selected Note: The Brightness setting does not affect laser brightness. To change the laser brightness mode, use the Light Source Brightness Control setting in the Operation menu.
  • Page 214 Reset to Defaults — Resets all settings for the currently selected input source Scale (EB-L260F/EB-L265F) Varying levels available When using multiple projectors, adjusts the scale of the image displayed by each projector Note: Select Reset Image Settings to reset all settings on the Image menu to their default values.

  • Page 215: Input Signal Settings - Signal I/O Menu

    Input Signal Settings - Signal I/O Menu Normally the projector detects and optimizes the input signal settings automatically. If you need to customize the settings, you can use the Signal I/O menu. The available settings depend on the currently selected input source. To change settings for an input source, make sure the source is connected and select that source.
  • Page 216 Signal Format: sets the signal type and video range for certain input sources Overscan • Video Signal: specifies the signal type EDID (EB-L260F/EB- from input sources connected to video L265F) ports; if interference appears or no image Reset to Defaults...
  • Page 217 Setting Options Description A/V Output While Projecting Determines when the projector outputs audio and images to external devices; set Always On to Always On to output audio and images when the projector is in standby mode. This setting is only displayed when Quick Startup is set to Off in the projector's Operation menu, Auto Power On is set to Off in the projector's Network menu, and...
  • Page 218 Setting Options Description HDMI Link Device Connections Adjusts the HDMI Link options that allow the projector or remote to control HDMI- HDMI Link connected devices that support the CEC Audio Out Device standard Power On Link Device Connections: lists the devices connected to the HDMI1 and HDMI2 ports Power Off Link when HDMI Link is enabled...

  • Page 219: Installation Settings - Installation Menu

    Parent topic: Adjusting the Menu Settings Installation Settings - Installation Menu Settings on the Installation menu let you set up your projector for your installation environment. The available settings depend on the currently selected input source and other settings. Setting Options Description Fixed Installation...
  • Page 220 Setting Options Description Projection Front Selects the way the projector faces the screen so the image is oriented Front/Ceiling correctly Rear Rear/Ceiling Geometry Correction H/V-Keystone Adjusts image shape to rectangular (horizontally and vertically) Quick Corner H/V Keystone: lets you manually Arc Correction correct horizontal and vertical sides Point Correction...
  • Page 221 Setting Options Description Screen Type Sets the aspect ratio to fit the image on the projection surface; not 16:6 (EB-L260F/EB-L265F) available in Content Playback mode 16:9 (EB-L260F/EB-L265F) 16:10 21:9 (EB-L260F/EB-L265F) Screen Position Varying positions available Shifts the image position on the...

  • Page 222: Display Settings - Display Menu

    Display Settings - Display Menu Settings on the Display menu let you customize various projector display features. The available settings depend on the currently selected input source and other settings. Setting Options Description Pattern Display — Displays the selected pattern type to assist in adjusting the image Pattern Type...
  • Page 223 No-signal Screen Black Select the screen color or logo to display when no input signal is Blue detected; not available in Content Logo Playback mode (EB-L260F/EB- L265F) Gradation Startup Screen Controls whether a logo is displayed when the projector starts up Home Screen Auto Disp.
  • Page 224 Split Screen Setting Display Audio Output Source Adjusts the Split Screen feature; not available in Content Playback Align mode (EB-L260F/EB-L265F) Display Audio Output Source: controls whether an icon is displayed with the source providing audio output during Split Screen projection...

  • Page 225: Feature Settings - Operation Menu

    Settings on the Operation menu let you customize various projector features that control its operation. The available settings depend on the currently selected input source and other settings. Setting Options Description Auto Source Search Enables the projector to automatically select an input source; not available in Content Playback mode (EB-L260F/EB- L265F)
  • Page 226 Setting Options Description Light Source Brightness Maintain Brightness (EB- Controls the constant brightness Control L260F/EB-L265F) of the projector's light source Maintain Brightness Level (EB- Maintain Brightness: maintains L260F/EB-L265F) a constant brightness Light Source Mode Maintain Brightness Level: selects the brightness level to Brightness Level maintain when the Maintain Brightness setting is enabled...
  • Page 227 Setting Options Description Power On Trigger Plug-in Detection Selects the power on condition when Auto Power On is set to Signal Detection HDMI1: • Plug-in Detection: automatically turns on the projector when the device connected to the HDMI1 port is turned on •...
  • Page 228 Port Wired LAN Selects the port to use while the Standby Mode setting is set to Wireless LAN Communication On Startup Source (EB-L260F/EB- Various input sources available Selects the source displayed on L265F) startup in Content Playback mode Quick Startup...
  • Page 229 Setting Options Description Content Playback (EB- Enable to play back a playlist L260F/EB-L265F) created in the Epson Projector Content Manager software Overlay Effect (EB-L260F/EB- Overlay Effect Adds color and shape effects to L265F) the projected image; not Shape Filter available when Edge Blending...

  • Page 230: Administration Settings - Management Menu

    Administration Settings - Management Menu Settings on the Management menu let you customize various projector administrative features. Note: You must disable Schedule password protection to adjust the Schedule Settings settings.
  • Page 231 Setting Options Description User Button Light Source Mode Assigns a menu option to the User button on the remote Information control for one-touch access Deinterlacing Closed Caption Resolution Mic Input Level (EB-L210W/EB- L260F) Pattern Display Display LAN Info. Content Playback Spotlight User's Logo Start Setting...
  • Page 232 Setting Options Description Color Uniformity Color Uniformity Adjusts the color tone balance Adjustment Level Color Uniformity: set to On to adjust the color tone balance for Start Adjustments the whole screen Reset Adjustment Level: sets the adjustment level Start Adjustments: adjusts the red, green, and blue color tones individually for the selected area Reset: resets all Color Uniformity...
  • Page 233 Setting Options Description Light Source Calibration (EB- Run Now Selects options to perform light L260F/EB-L265F) source calibration to maintain the Run Periodically color balance of the projected Last Run image Run Now: Select On to start light source calibration now. Make sure the projector has been turned on for at least 30 minutes for maximum accuracy.
  • Page 234 Internal Memory Selects where you want to save projector error and operation log USB and Internal Memory files; not available in Content Playback mode (EB-L260F/EB- L265F) Batch Setup Range Selects which projector menu settings to copy using the batch Limited setup feature;...
  • Page 235 Setting Options Description Information Operation Hours Displays information about the projector and current input signal; Light Source Hours the displayed items vary Estimated Remains depending on the current input source Source The Version option displays Input Signal version numbers for the projector Resolution and other components Refresh Rate...

  • Page 236: Event Id Code List

    Editing a Scheduled Event Adjusting Color Uniformity Event ID Code List If the Event ID option on the Information screen in the Management menu displays a code number, check this list of Event ID codes for the solution to the projector problem associated with the code. Event ID code Cause and solution 0026...
  • Page 237 0899 A communication error has occurred. Try restarting the network software and restarting your projector. If that does not solve the problem, contact Epson for help. 089A The EAP authentication type does not match the network. Check the wireless LAN security settings and make sure that the security certificate is installed correctly.

  • Page 238: Network Settings - Network Menu

    Key exchange failed. Check the wireless LAN security settings and make sure that the security certificate is installed correctly. 0920 The internal battery that saves the projector's date and time settings is running low. Contact Epson for help. Parent topic: Administration Settings - Management Menu Related references...
  • Page 239 Note: You must disable Network password protection to adjust the network settings. Setting Options Description Wireless LAN Info. — Displays wireless network status and details The Wireless LAN option displays the following: • Projector Name • Antenna level • SSID •...
  • Page 240 • Projector Name • DHCP • IP Address • Subnet Mask • Gateway Address • MAC Address • IPv6 Address Art-Net Channel — Displays features and settings Information (EB-L260F/EB- assigned to the Art-Net channels L265F) Network Settings — Configures your network settings...
  • Page 241 Start Pairing Start Pairing: Updates the network information of the wireless transmitter Auto Power On from your computer using the Epson Connection Guide Display Wireless Transmitter Settings software when the wireless LAN module is installed and Simple AP is set to On Auto Power On: Set to On to turn on the projector automatically.

  • Page 242: Multiple Projector Operation Settings - Multi-Projection Menu

    Multiple Projector Operation Settings - Multi-Projection Menu Settings on the Multi-Projection menu let you set up multiple projectors to project a single unified image (EB-L260F/EB-L265F). Setting Options Description Projector ID Assigns an ID for the projector when you use multiple projectors...
  • Page 243 Setting Options Description Geometry Correction H/V-Keystone Adjusts image shape to rectangular (horizontally and vertically) Quick Corner H/V Keystone: lets you manually Arc Correction correct horizontal and vertical sides Point Correction Quick Corner: select to correct image shape and alignment using an on-screen display Arc Correction: select to adjust the curve or arc of the horizontal and...
  • Page 244 Setting Options Description Color Uniformity Color Uniformity Adjusts the color tone balance Adjustment Level Color Uniformity: set to On to adjust the color tone balance for the Start Adjustments whole screen Reset Adjustment Level: sets the adjustment level Start Adjustments: adjusts the red, green, and blue color tones individually for the selected area Reset: resets all Color Uniformity...
  • Page 245 Setting Options Description Reset Multi-Projection Settings — Resets all settings on the Multi- Projection menu to their default values Parent topic: Adjusting the Menu Settings Related concepts Using Multiple Projectors Projector Identification System for Multiple Projector Control Related tasks Adjusting Color Uniformity Blending the Image Edges Matching the Image Colors Adjusting the Black Level...

  • Page 246: Setup Settings - Eco Menu

    Setup Settings - ECO Menu Settings on the ECO menu let you customize projector functions to save power.
  • Page 247 Setting Options Description Light Source Mode Normal Selects the brightness mode of the projector; only displayed Quiet when the Maintain Brightness Extended setting is disabled Custom Normal: maximum brightness Quiet: 70% brightness with reduced fan noise Extended: 70% brightness and extends the life expectancy of the light source Custom: select a custom...
  • Page 248 Setting Options Description Standby Mode Communication On Enable this setting to allow monitoring and control of the Communication Off projector over a network when the projector is in standby mode; this setting is only displayed in the following cases: • Auto Power On is disabled in the projector's Network menu •...

  • Page 249: Initial Settings And Reset Options - Initial/All Settings Menu

    Initial Settings and Reset Options - Initial/All Settings Menu You can reset most of the projector settings to their default values using the Reset All option on the Initial/All Settings menu. When you select the Reset All option, you see a screen like this:...
  • Page 250 Checkmarks appear next to the menu settings that are selected to be reset. If you do not want to reset settings in some menus, deselect them. When you are ready, select Execute and press Enter. You cannot reset the following settings using the Reset All option: •...

  • Page 251: Maintaining And Transporting The Projector

    The only parts you should replace are the air filter and remote control batteries. If any other part needs replacing, contact Epson or an authorized Epson servicer. This projector uses a sealed laser light source which does not need servicing and cannot be replaced.

  • Page 252: Cleaning The Projector Case

    Filter maintenance intervals will depend on the environment. If regular maintenance is not performed, your Epson projector will notify you when the temperature inside the projector has reached a high level. Do not wait until this warning appears to maintain your...

  • Page 253: Cleaning The Air Filter And Vents

    Damage due to the failure to properly maintain the projector or its filter may not be covered by the projector's Limited Warranty. Cleaning the Air Filter and Vents Replacing the Air Filter Parent topic: Maintaining and Transporting the Projector Cleaning the Air Filter and Vents Clean the projector's air filter or vents if they get dusty, or if you see a message telling you to clean them.

  • Page 254: Replacing The Air Filter

    Replacing the Air Filter You need to replace the air filter in the following situations: • After cleaning the air filter, you see a message telling you to clean or replace it • The air filter is torn or damaged You can replace the air filter while the projector is mounted to the ceiling or placed on a table.

  • Page 255: Replacing The Remote Control Batteries

    4. Place the new air filter in the projector as shown. 5. Close the air filter cover. Parent topic: Air Filter and Vent Maintenance Related references Optional Equipment and Replacement Parts Related tasks Turning Off the Projector Replacing the Remote Control Batteries The remote control uses two AA manganese or alkaline batteries.
  • Page 256 2. Remove the old batteries. Warning: If the battery fluid has leaked, wipe it away with a soft cloth and avoid getting the fluid on your hands. If it gets on your hands, wash them immediately to avoid injury. 3. Insert the batteries with the + and – ends facing as shown. 4.

  • Page 257: Updating The Firmware

    If a firmware update file is not found, the projector enters standby mode. You can contact Epson Support or use the Epson Projector Management software to check for firmware updates for your product. For more information, contact Epson Support.

  • Page 258: Solving Problems

    • The lights on the projector may indicate what the problem is. • The solutions in this manual can help you solve many problems. If none of these solutions help, you can contact Epson for technical support. Parent topic: Solving Problems Related references Where to Get Help (U.S.

  • Page 259: Projector Light Status

    Projector Light Status The lights on the projector indicate the projector status and let you know when a problem occurs. Check the status and color of the lights and look for a solution in the table here. Note: If the Indicators setting in the Operation menu is Off, all lights are off under normal projection conditions.
  • Page 260 • Make sure the environmental temperature is not too hot. • Clean or replace the air filter. • If operating the projector at high altitude, turn on High Altitude Mode. • If the problem persists, unplug the projector and contact Epson for help.
  • Page 261 Status and solution Flashing blue Varies Flashing Varies Laser warning. Turn the projector off, orange unplug it, and contact Epson for help. Flashing blue Orange Laser has a problem. Turn the projector off, unplug it, and contact Epson for help. Flashing blue Flashing A fan or sensor has a problem.

  • Page 262: Using The Projector Menu Displays

    Related tasks Cleaning the Air Filter and Vents Replacing the Air Filter Using the Projector Menu Displays The projector displays descriptions in the menu system to help you navigate the projector's settings. The descriptions appear on the right side of the screen as you scroll the menu settings. Parent topic: Solving Problems Related tasks...
  • Page 263 • If the projector does not respond when you press any buttons on the projector, an internal error may have occurred in the projector. Contact Epson for help. • Adjust the Brightness setting on the Image menu.

  • Page 264: Solutions When Image Is Incorrect Using The Usb Display Function

    USB Display icon menu in the Dock, USB Display does not start automatically when you connect the USB cable. • If the mouse cursor flickers, select Make the movement of the mouse pointer smooth in the Epson USB Display Settings program on your computer.

  • Page 265: Displaying From A Pc Laptop

    • Turn on the connected computer or video source, and press its play button to begin your presentation, if necessary. • Check the connection from the projector to your video sources. • If you are projecting from a laptop computer, make sure it is set up to display on an external monitor. •...

  • Page 266: Displaying From A Mac Laptop

    If there are margins between the edge of the image and the projected screen frame, use the Screen Position setting to adjust the position of the image. • Make sure the Scale setting in the Image menu is turned off (EB-L260F/EB-L265F).

  • Page 267: Solutions When The Image Is Not Rectangular

    • Make sure you selected the correct Projection setting in the Installation menu. • If you are projecting in Content Playback mode, make sure you are using the correct Overlay Effect setting in the Operation > Content Playback menu (EB-L260F/EB-L265F). Parent topic:...

  • Page 268: Solutions When The Image Contains Noise Or Static

    • If you connected an extension power cable, try projecting without it to see if it caused interference in the signal. • If you are using the USB Display function, turn off the Transfer layered window setting in the Epson USB Display Settings program on your computer.

  • Page 269: Solutions When The Image Is Fuzzy Or Blurry

    Related references Input Signal Settings - Signal I/O Menu Image Quality Settings - Image Menu Supported Video Display Formats Related topics Connecting to Computer Sources Connecting to Video Sources Solutions When the Image is Fuzzy or Blurry If the projected image is fuzzy or blurry, try the following solutions: •...

  • Page 270: Solutions When The Image Brightness Or Colors Are Incorrect

    Solutions When the Image Brightness or Colors are Incorrect If the projected image is too dark or light, or the colors are incorrect, try the following solutions: • Press the Color Mode button on the remote control to try different color modes for the image and environment.
  • Page 271 • If you are using the USB Display function, turn on the Output audio from the projector setting in the Epson USB Display Settings program on your computer. • If you are using a Mac and you do not hear sound from an HDMI source, make sure your Mac supports audio through the HDMI port.

  • Page 272: Solutions To Problems Using Content Playback

    Solutions to Problems Using Content Playback If you cannot play back a playlist correctly, try the following solutions (EB-L260F/EB-L265F): • Check the following on all projectors: • All projectors are the same model. If any of the projectors are a different model or have a different resolution, synchronized playback may not be performed properly.

  • Page 273: Solutions To Projector Power Or Shut-Off Problems

    Remote Receiver setting is turned on in the projector's menu, if available. • The power cord may be defective. Try another power cord. If that doesn't work, disconnect the cord and contact Epson. • The cooling fans may run in standby status depending on the projector settings. Also, when the projector wakes from standby status, the fans may cause an unexpected noise.

  • Page 274: Solutions To Remote Control Problems

    • To set the remote control so it will operate any projector, hold down the ID button and press the 0/All button. • If you lose the remote control, you can purchase another from an Epson parts distributor. Parent topic:...

  • Page 275: Solutions When A Battery Message Appears

    • If you set a Epson Web Control password and forgot the user ID or password, try entering the following: • User ID: EPSONWEB • Default password: admin • If you set a Remote password (in Epson Web Control) and forgot the user ID or password, try entering the following: • User ID: EPSONREMOTE • Default password: admin...

  • Page 276: Solutions When Wireless Authentication Fails

    Solutions When Wireless Authentication Fails If you cannot authenticate a wireless connection, try the following solutions: • If the wireless settings are correct, but authentication fails, you may need to update the Date & Time settings in the Management menu, if available. •...

  • Page 277: Solutions When Network Alert E-Mails Are Not Received

    Solutions When Network Alert E-Mails are Not Received If you do not receive an e-mail alerting you to problems with a projector over the network, try the following solutions: • Make sure the projector is turned on and connected to the network correctly. (If an error shut down the projector, it cannot send an e-mail.) •...

  • Page 278: Solutions When The Image Or Sound Contains Static When Using Screen Mirroring

    • Make sure the mobile device settings are correct and restart the device. • You may not be able to connect immediately after disconnecting from the projector. Wait a while and try connecting again. • If you have previously connected to the projector using Screen Mirroring, the device may have saved the previous connection information.

  • Page 279: Where To Get Help (U.s. And Canada)

    FAQs and troubleshooting advice, or e-mail Epson with your questions. Speak to a Support Representative To use the Epson PrivateLine Support service, call (800) 637-7661. This service is available for the duration of your warranty period. You may also speak with a projector support specialist by dialing (562) 276-4394 (U.S.) or (905) 709-3839 (Canada).

  • Page 280: Where To Get Help (Latin America)

    Purchase Supplies and Accessories You can purchase screens, other optional accessories, and replacement parts from an Epson authorized reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766) in the U.S. or 800-807-7766 in Canada. Or you can purchase online at epsonstore.com...
  • Page 281 Purchase Supplies and Accessories You can purchase optional accessories and replacement parts from an Epson authorized reseller. To find the nearest reseller, go to latin.epson.com. Or you can contact your nearest sales office as described in "Where to Get Help."...

  • Page 282: Technical Specifications

    General Projector Specifications Type of display Poly-silicon TFT active matrix Resolution EB-L210W: 1280 × 800 pixels (WXGA) EB-L260F/EB-L265F: 1920 × 1080 pixels (Full HD) Lens F=1.51 to 1.77 Focal length: 18.2 to 29.1 mm Color reproduction Full color, up to 1.07 billion colors...
  • Page 283 (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118. EB-L260F/EB-L265F: Normal Power Consumption mode: White and Color light output 4600 lumens (ISO 21118 standard)

  • Page 284: Projector Light Source Specifications

    USB Type B port compatibility One USB 2.0 compliant port for USB Display, firmware update, or copying menu settings USB Type A port compatibility One USB 1.1 and 2.0 compliant port for USB device input, use of a compatible Epson document camera, use of wireless LAN module, firmware update, or copying menu settings Parent topic:...

  • Page 285: Remote Control Specifications

    Light source life Normal/Quiet Light Source Mode: (approximate) Up to about 20,000 hours Extended Light Source Mode: Up to about 30,000 hours Note: Turn off this product when not in use to prolong the life of the projector. Laser life will vary depending upon mode selected, environmental conditions, and usage.

  • Page 286: Projector Environmental Specifications

    Power consumption Operating: (100 to 120 V) Normal Power Consumption mode: 272 W Quiet Power Consumption mode: 208 W Quiet and Extended Power Consumption mode: 199 W Standby: 0.5 W (Communication Off), 2.0 W (Communication On) Power consumption Operating: (220 to 240 V) Normal Power Consumption mode: 260 W Quiet Power Consumption mode: 199 W Quiet and Extended Power Consumption mode: 191 W...

  • Page 287: Supported Video Display Formats

    For best results, your computer's monitor port or video card resolution should be set to display in the projector's native resolution. However, your projector includes Epson's SizeWise chip that supports other computer display resolutions, so your image will be resized to fit automatically.
  • Page 288 Display format Refresh rate (in Hz) Resolution (in pixels) Composite video TV (480i) 720 × 480 TV (576i) 50/60 720 × 576 Component video SDTV (480p) 59.94 720 × 480 SDTV (576p) 720 × 576 HDTV (720p) 50/59.94/60 1280 × 720 HDTV (1080p) 50/59.94/60 1920 ×...

  • Page 289: Usb Display System Requirements

    1920 × 1080 23.98/24/25/29.97/30/50/59.94/6 3840 x 2160 4K (SMPTE) 23.98/24/50/59.94/60 4096 x 2160 * EB-L260F/EB-L265F only Parent topic: Technical Specifications USB Display System Requirements Your computer system must meet the system requirements here to use the projector's USB Display software.
  • Page 290 Requirement Windows Intel Core2 Duo or faster (Intel Core i3 or Intel Core2 Duo or faster (Intel Core faster recommended) i5 or faster recommended) Memory 2GB or more (4GB or more recommended) Hard disk space 20MB or more Display Resolution between 640 × 480 and 1920 × 1200, 16-bit color or greater Parent topic: Technical Specifications...

  • Page 291: Notices

    Binding Arbitration and Class Waiver Trademarks Copyright Notice Recycling (U.S. and Canada) Epson offers a recycling program for end of life products. Please go to this site for information on how to return your products for proper disposal. Parent topic:...

  • Page 292: Important Safety Instructions

    • If an error occurs in the projector, turn off the power and unplug the projector immediately. Continuing to use the projector could result in an electric shock, fire, or visual impairment. Contact Epson support. • Do not attempt to disassemble or modify the projector. The projector contains a high-power laser component.
  • Page 293 • When turning on the projector at a distance using the remote control, make sure there is no one looking into the lens. • Do not place any flammable objects in front of the projector lens, otherwise, a fire may occur. •...
  • Page 294 • Take the following precautions when handling the plug: Do not hold the plug with wet hands. Do not insert the plug into a dusty outlet. Insert the plug firmly into the outlet. Do not pull the power cord when disconnecting the plug;...
  • Page 295 exhibits a distinct change in performance; if smoke, strange odors, or strange noises come from the projector; if the power cord or plug is damaged or frayed; if liquid or foreign objects get inside the projector, or if it has been exposed to rain or water; if it has been dropped or the housing has been damaged.

  • Page 296: Restriction Of Use

    • Before you move the projector, make sure its power is turned off, the plug is disconnected from the outlet, and all cables are disconnected. • Do not place the source of an open flame, such as a lit candle, on or near the projector. •...
  • Page 297 Symbol Approved Standards Description IEC60417 "ON" (power) No.5007 To indicate connection to the mains. IEC60417 "OFF" (power) No.5008 To indicate disconnection from the mains. IEC60417 Stand-by No.5009 To identify the switch or switch position by means of which part of the equipment is switched on in order to bring it into the stand-by condition.
  • Page 298 Symbol Approved Standards Description IEC60417 Polarity of DC power connector No.5926 To identify the positive and negative connections (the polarity) on a piece of equipment to which a DC power supply may be connected. — Polarity of DC power connector To identify the positive and negative connections (the polarity) on a piece of equipment to which a DC.
  • Page 299 Symbol Approved Standards Description IEC60417 Alternating current No.5032 To indicate on the rating plate that the equipment is suitable for alternating current only; to identify relevant terminals. IEC60417 Direct current No.5031 To indicate on the rating plate that the equipment is suitable for direct current only;...
  • Page 300 Symbol Approved Standards Description ISO 3864 Disassembly prohibition To indicate a risk of injury, such as electric shock, if the equipment is disassembled. IEC60417 Standby, partial standby No. 5266 To indicate that part of the equipment is in the ready status. ISO3864 Caution, movable parts IEC60417...

  • Page 301: Fcc Compliance Statement

    Parent topic: Notices FCC Compliance Statement For United States Users This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 302: Binding Arbitration And Class Waiver

    1.3 Pre-Arbitration Steps and Notice. Before submitting a claim for arbitration, you and Epson agree to try, for sixty (60) days, to resolve any Dispute informally. If Epson and you do not reach an agreement to resolve the Dispute within the sixty (60) days), you or Epson may commence an arbitration. Notice to Epson must be addressed to: Epson America, Inc., ATTN: Legal Department, 3131 Katella Ave., Los...
  • Page 303 Orange County, California, at your option. a) Initiation of Arbitration Proceeding. If either you or Epson decides to arbitrate a Dispute, both parties agree to the following procedure: (i) Write a Demand for Arbitration.
  • Page 304 Epson's last written offer, if any, to settle the Dispute, Epson will: (i) pay you $1,000 or the amount of the award, whichever is greater; (ii) pay you twice the amount of your reasonable attorney's fees, if any;...

  • Page 305: Trademarks

    HDMI and High-Definition Multimedia Interface are the trademarks or registered trademarks of HDMI Licensing LLC. General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks. Parent topic: Notices...

  • Page 306: Copyright Notice

    Seiko Epson Corporation. The information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.
