Toyota LAND CRUISER STATION WAGON 2007 Owner's Manual

page of 446

/ 446
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

Table of Contents

Summary of Contents for Toyota LAND CRUISER STATION WAGON 2007

Page 2 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column When driving Driving, stopping and safe-driving information Air conditioning and audio systems, as well as other in- Interior features terior features for a comfortable driving experience Maintenance and Cleaning and protecting your vehicle, performing do-it- care...
Page 3: Table Of Contents
TABLE OF CONTENTS Index 1-5. Refueling Before driving Opening the fuel tank cap ..93 1-6. Theft deterrent system 1-1. Key information Engine immobilizer Keys........22 system........ 97 Alarm........99 1-2. Opening, closing and locking the doors 1-7. Safety information Smart entry &...
Page 4 Rear cooler system .... 252 2-4. Using other driving systems Heater idle up switch..254 Cruise control...... 186 Rear window and outside Toyota parking rear view mirror assist-sensor ....189 defoggers ......255 Four-wheel drive system..198 Rear differential lock 3-2.
Page 5 TABLE OF CONTENTS Index 3-4. Other interior features 4-3. Do-it-yourself maintenance Cool box......268 Do-it-yourself service precautions ...... 295 Sun visors ......270 Hood........298 Vanity mirror ....... 271 Engine compartment ..299 Clock........272 Tires ........313 Outside temperature display ......
Page 6 5-2. Steps to take in an emergency Vehicle specifications If a warning light turns on or a warning buzzer sounds......361 6-1. Specifications If a warning message is Maintenance data displayed ......369 (fuel, oil level, etc.) ... 406 If you have a flat tire ...
Page 7 Pictorial index Exterior ∗ Windshield wipers P. 181 Moon roof P. 90 Hood P. 298 Outside rear view mirrors P. 83 Side turn signal lights P. 164 Headlights (high beam) P. 178 Front turn signal lights P. 164 Headlights (low beam) P.
Page 8 Rear window defogger P. 255 Rear window wiper P. 184 Side doors P. 39 Fuel filler door P. 93 Back door P. 42 License plate lights P. 178 Tires ●Rotation P. 313 Tail lights P. 178 ●Replacement P. 372 Rear turn signal lights P.
Page 9 Pictorial index Interior Head restraints P. 65 Seat belts P. 69 SRS front passenger airbag P. 105 Power window switches SRS driver airbag P. 105 P. 86 Ashtray P. 274 Floor mat P. 281 ITYPC014 Rear seat P. 50 Glove box P.
Page 10 Vanity mirrors P. 271 Sun visors P. 270 Overhead console P. 263 Personal lights P. 259 Interior light P. 258 Rear seat entertainment system Interior light P. 258 ∗ Personal lights P. 259 Interior light P. 258 ∗ SRS curtain shield airbags P.
Page 11 Pictorial index Interior ∗ Driving position memory switches P. 60 Door lock switch P. 39 Window lock switch P. 86 Power window switches P. 86...
Page 12 ∗ Crawl Control switch P. 205 ∗ Seat heater switches P. 278 Shift lever P. 159 Ashtray P. 274 Cigarette lighter P. 275 Power outlet P. 276 AUX port USB port Parking brake lever P. 165 “SHIFT LOCK” button P. 388 ECT switch P.
Page 13 Pictorial index Instrument panel Headlight switch P. 178 Turn signal lever P. 164 ∗ Fog light switch P. 180 Gauges and meters P. 167 ∗ Multi-information display P. 175, 369 Bottle holder Windshield wipers and washer switch P. 181 P. 265 Rear window wiper and washer switch P.
Page 14 Without navigation system Clock P. 272 Front passenger’s seat belt Security indicator light reminder light P. 365 P. 97, 99 SECURITY Outside temperature Emergency flasher display P. 273 switch P. 352 Air conditioning Rear window defogger system P. 236 switch P.
Page 15 Pictorial index Instrument panel With navigation system Clock Front passenger’s seat belt Outside temperature reminder light P. 365 display P. 273 Navigation system Security indicator Air conditioning light P. 97, 99 system P. 236 Rear window defogger switch P. 184 Emergency flasher Audio system switch...
Page 16 Without navigation system ∗ DISP switch P. 175 ∗ Cruise control switch P. 186 With navigation system Telephone switch Talk switch DISP switch P. 175 ∗ Cruise control switch P. 186 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”.
Page 17 Pictorial index Instrument panel ∗ VSC OFF switch P. 209 Center differential lock/unlock switch P. 198 Engine (ignition) switch P. 155 ITYPC029 Four-wheel drive control switch P. 198 ∗ Rear differential lock/unlock switch P. 203...
Page 18 P. 167 Outside rear view mirror control switches P. 83 ∗ Headlight cleaner switch P. 185 Card holder P. 267 Toyota parking assist-sensor ∗ switch P. 189 Roll sensing of curtain shield ∗ airbags off switch P. 119 ∗ Heater idle up switch P.
Page 19 All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.
Page 20 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 21 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 22: Before Driving
Before driving 1-1. Key information 1-4. Opening and closing the windows and moon roof Keys........22 Power windows....86 1-2. Opening, closing and locking Moon roof......90 the doors 1-5. Refueling Smart entry & start system ......24 Opening the fuel tank Wireless remote control ..
Page 23: Key Information
1-1. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system (→P. 24) • Operating wireless remote control function (→P. 37) Mechanical keys Key number plate Using the mechanical key Take out the mechanical key.
Page 24 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer, using the key number plate. (→P. 389) ■...
Page 25: Opening, Closing And Locking The Doors
1-2. Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ITY12C004 Locks and unlocks the doors (→P.
Page 26 The doors cannot be unlocked for 3 seconds after the doors are locked. ITY12C013 Press the lock button to lock the doors. Pressing and holding the button closes the windows and moon roof. (This setting must be cus- tomized at your Toyota dealer.) ITY12C012...
Page 27 1-2. Opening, closing and locking the doors Back door Press the unlock button to unlock the doors. The door cannot be unlocked for 3 seconds after the door is locked. Lock the back door again when you leave the vehicle. The back door will not lock automatically after it has been opened and then closed.
Page 28 1-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Antennas outside cabin Antennas inside cabin Antenna outside luggage com- partment ITY12C019...
Page 29 1-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of an outside door handle.
Page 30 1-2. Opening, closing and locking the doors ■ Operation signals A buzzer sound and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situ- ations, the communication between the electronic key and the vehicle may be affected, preventing the smart entry &...
Page 31 1-2. Opening, closing and locking the doors ■ Switching the door unlock function If it is possible to set which doors the entry function unlocks. STEP Turn the “ENGINE START STOP” switch OFF. When the indicator on the key surface is turned off, press and hold STEP (if equipped) for approximately 5 seconds while pressing...
Page 32 1-2. Opening, closing and locking the doors ■ Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. ● When the entry function has not been used for 2 weeks or more ●...
Page 33 1-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases. • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 34 1-2. Opening, closing and locking the doors ■ Security feature If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning lights and warning messages shown on the multi-information display are used to reduce the chance of vehicle theft and accidents resulting from erroneous operation.
Page 35 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure The “ENGINE START STOP” switch was turned to ACCESSORY mode Turn the “ENGINE while the driver’s door was START STOP” switch open (or the driver’s door OFF and close the was opened while the Interior alarm driver’s door...
Page 36 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure The electronic key has a Replace the electronic low battery key battery An attempt was made to Interior alarm start the engine without the Start the engine with pings once electronic key being the electronic key present, or the electronic...
Page 37 Radio waves could have unexpected effects on the operation of such medical devices. Ask your Toyota dealer for details for disabling the smart entry & start sys- tem.
Page 38: Wireless Remote Control
(press hold) Sounds alarm (press and hold) (→P. 102) : This setting must be cus- tomized at your Toyota dealer. : If equipped ■ Operation signals ● Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ●...
Page 39 →P. 323 ■ Conditions affecting operation →P. 29 ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function) can be changed. (Customizable features →P. 424) CAUTION ■ When closing the windows or moon roof using wireless remote control Observe the following precautions.
Page 40: Side Doors
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry function →P. 25 ■ Wireless remote control →P. 37 ■ Door lock switch Locks all doors Unlocks all doors ■...
Page 41 1-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. STEP Close the door while pulling the door handle. STEP The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 42 Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (→P. 22) ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 424) CAUTION ■...
Page 43: Back Door
1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. ■ Locking and unlocking the back door Door lock switch →P. 39 Entry function →P. 24 Wireless remote control →P.
Page 44 1-2. Opening, closing and locking the doors Rear step bumper The rear step bumper is for rear end protection and easier step- up loading. ■ When closing the back door ● Make sure that the lower side of the back door is closed before closing the upper side of the back door.
Page 45 1-2. Opening, closing and locking the doors CAUTION ■ While driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 46 1-2. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 47 Doing so may cause hands to be caught or the back door damper stay to break, causing an accident. ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may cause the back door to fall closed again after it is opened.
Page 48: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever Seat cushion (front) angle adjustment knob Lumbar support control switch : If equipped on driver’s side ITY13C001...
Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat Seat position fore/aft control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumber support control switch (driver’s side only) Active head restraint (if equipped) When the occupant’s lower back presses against the seatback during a rear-end collision, the...
Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraint Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may make the inner struc- ture of the head restraint appear. This does not indicate a problem. During rear-end collision...
Page 51: Rear Seats
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seat Seatback angle adjustment lever Seat position adjustment lever Third seat (with center seat) Third seat (without center seat)
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) Tumbling the second seats and third seat entry For easy access to the third seat, perform in “Tumbling the STEP second seats”. (→P. 52) ■ Before tumbling the second seats Stow the seat belt buckles and STEP lower the head restraints to the lowest position.
Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Tumbling the second seats Fold down the seatback while STEP pulling seatback angle adjustment lever, and swing the whole seat up and forward. Hook the holding strap to the STEP assist grip and secure the seat by pulling its free end.
Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. When returning the second seat to its original position, remove the seat hook covers from the floor and install them in the back of the ITY13C024 seat cushion.
Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Folding up the third seats ■ Before folding up the third seats Stow the seat belt buckles. STEP With center seat ITY13C018 Without center seat...
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) With center seat: Stow the center head restraint in the seat- STEP back. (→P. 68) Pass the outer seat belts through STEP the seat belt hangers and secure the seat belt plates. This prevents the shoulder belt from being damage.
Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Folding up the third seats Fold down the head restraints STEP while pulling the head restraint angle levers. ITY13C022 Push the seatback angle levers STEP and fold the third seats. Pull the seat leg lock release STEP levers.
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. ITY13C030 ■ Returning the third seats Remove the seat hook covers STEP from the floor and install them...
Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Pull the handle and raise the STEP seatbacks. Fix the handle securely in its orig- inal position after use. Raise the head restraints. STEP...
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
Page 61: Driving Position Memory System
1-3. Adjustable components (seats, mirrors, steering wheel) ∗ Driving position memory system Your preferred driving position (the position of the driver’s seat, steering wheel and outside rear view mirrors) can be entered into the computer’s memory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Recalling the memorized position Check that the shift lever is set in “P”. Turn the “ENGINE START STOP” switch to IGNITION ON STEP mode. Press button “1”, “2” or “3” to STEP recall the desired position.
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) ’ Linking driving position memory with door unlock operation Record your driving position to button “1”, “2” or “3” before performing the following: Using the wireless remote control Turn the “ENGINE START STOP” switch to OFF after closing STEP the driver’s door.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Using the door lock switch Carry only the key to which you want to link the driving position. If 2 or more keys are in the vehicle, the driving position cannot be linked properly. Turn the “ENGINE START STOP”...
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Retained accessory power ● Each memorized position (except for the steering wheel position) can be activated within 3 minutes after the driver’s door is opened, even if the “ENGINE START STOP” switch is turned off. ●...
Page 66: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Front seats Vertical adjustment Pull the head restraint up. Down Press hold lock release button when lowering Lock release button the head restraint. Angle adjustment (if equipped) Second seats Vertical adjustment Down Push the head restraint up or down while pressing the lock...
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) Third outboard seats To fold Pull the head restraint angle lever to fold the head restraint. ITY13C040 ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Front seats Pull the head restraint up while pressing the lock release button. Lock release button ITO13C143 Second seats Pull the head restraint up while pressing the lock release button. Lock release button Third center seat (if equipped) Pull the head restraint up while pressing...
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) Third outboard seats Push a flathead screwdriver into the slot. STEP The slot is located on the left side of the left head restraint anchor. ITY13C035 While pressing in the screwdriver, pull up the head restraint. STEP ■...
Page 70: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Fastening and releasing the third center seat belt (if equipped) Pull out the tab STEP ITY13C120 Push tab B into buckle B until STEP a clicking sound is heard Tab B Buckle B Push tab A into buckle A until STEP a clicking sound is heard...
Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Releasing and storing the third center seat belt (if equipped) Push the release button on STEP buckle A Buckle A Push either the mechanical STEP key or tab A into buckle B When releasing and storing the seat belt, hold the belt while winding it back gently.
Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front and second outboard seats) Down Move the height adjuster up and down as needed until you hear a click. ITY13C054 Seat belt pretensioners (front and second outboard seats [if equipped]) The pretensioner helps the seat belt to quickly restrain the occu-...
Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 75 ■ Seat belt regulations If seat belt regulations exist in the country where you reside, please contact your Toyota dealer for seat belt replacement or installation.
Page 76 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 77 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ For Australian owners Observe the following additional WARNINGS. WARNING: Seatbelts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable;...
Page 79: Steering Wheel
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel Manual tilt & telescopic steering wheel The steering wheel can be adjusted to a comfortable position. ■ To change the angle Hold steering STEP wheel and pull the lock release lever toward you.
Page 80 1-3. Adjustable components (seats, mirrors, steering wheel) Power tilt & telescopic steering wheel The steering wheel can be adjusted to a comfortable position while the “ENGINE START STOP” switch is in ACCESSORY or IGNI- TION ON mode. Down Toward the driver Away from the driver Auto tilt away (vehicles with power tilt &...
Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Automatic adjustment of the steering position A desired steering position can be entered to memory and recalled automat- ically by the driving position memory. (→P. 60) CAUTION ■ While driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and an accident, resulting in death or serious injury.
Page 82: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In auto mode, sensors are used to detect the headlights of vehi- cles behind and automatically reduce the reflected light.
Page 83 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the rear view mirror Adjust the height of the rear view mirror by moving it up and down. ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 84: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Select a mirror to adjust STEP Left Right Adjust the mirror STEP Right...
Page 85 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Manual type Push backward to fold the mir- rors. Power type Press the switch Pressing again will extend the mirror. ■ When the mirrors are fogged up (vehicles with outside rear view mirror defoggers) Turn on the outside rear view mirror defogger to defog the mirrors.
Page 86 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Linked mirror function when reversing (if equipped) The outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground. However, this function will not operate when the mirror select switch is in the neutral position (between “L”...
Page 87: Opening And Closing The Windows And Moon Roof
1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing Opening One-touch opening : Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 88 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Door lock linked window operation (if equipped) The following functions can be used if customized at your Toyota dealer. ● The power windows can be opened and closed using the wireless remote control or mechanical key.
Page 89 If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■ Customization that can be configured at Toyota dealer Settings (e.g. linked door lock operation) can be changed. (Customizable features →P. 424)
Page 90 1-4. Opening and closing the windows and moon roof CAUTION ■ Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 91: Moon Roof
1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
Page 92 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Door lock linked moon roof operation (if equipped) The following functions can be used if customized at your Toyota dealer. ● The moon roof can be opened and closed using the wireless remote con- trol or mechanical key.
Page 93 An alarm will sound when the driver’s door is opened with the moon roof not fully closed and the “ENGINE START STOP” switch OFF. ■ Customization that can be configured at Toyota dealer Setting (e.g. linked door lock operation) can be changed. (Customizable features →P. 424) CAUTION ■...
Page 94: Refueling Opening The Fuel Tank Cap
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the “ENGINE START STOP” switch OFF and ensure that all the doors and windows are closed. ■ Opening the fuel tank cap Pull the lever.
Page 95 ■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol con- tent is up to 10 %. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 96 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.
Page 97 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Failure to do so may damage the vehicle, such as causing the exhaust sys- tems to operate abnormally or damaging fuel system components or the vehicle’s painted surface.
Page 98: Theft Deterrent System
1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with navigation system The indicator light flashes after the “ENGINE START STOP”...
Page 99 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle NOTICE ■...
Page 100: Alarm
1-6. Theft deterrent system ∗ Alarm The system sounds the alarm and flashes lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than by using the entry function, the wireless remote control or using the mechanical key.
Page 101 1-6. Theft deterrent system Vehicles without navigation system ■ Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. ● Unlock the doors using the entry function or the wireless remote control. ● Start the engine. (The alarm will be deactivated or stopped after a few seconds.) ■...
Page 102 1-6. Theft deterrent system ■ Triggering of the alarm The alarm may be triggered in the following situations. (Stopping the alarm deactivates the alarm system.) ● door unlocked using mechanical key. ● A person inside the vehicle opens a door or hood. ●...
Page 103 1-6. Theft deterrent system ■ When the battery is disconnected Be sure to cancel the alarm system. If the battery is disconnected before canceling the alarm, the system may be triggered when the battery is reconnected. ■ Alarm-operated door lock ●...
Page 104: Safety Information
1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (→P. 47) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 105 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 106: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 107 1-7. Safety information Side and curtain shield airbags Side airbags Can help protect the torso of the front seat occupants. Side airbags (if equipped) Can help protect the torso of the second outboard seat occu- pants. Curtain shield airbags Can help protect primarily the head of front, second outboard, third outboard seat occupants.
Page 108 1-7. Safety information Airbag system components Side airbags (if equipped Side and curtain shield air- on second outboard seats) bag sensors Curtain shield airbag sen- Knee airbags (if equipped) sors Front passenger airbag Side airbags (front seats) Front airbag sensors Curtain shield airbags Airbag sensor assembly Driver’s seat belt buckle...
Page 109 1-7. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
Page 110 1-7. Safety information ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbag will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 20 - 30 km/h [12 - 18 mph] frontal collision with a fixed wall that does not move or deform).
Page 111 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front, side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 112 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (vehicles with side airbags and curtain shield airbags) The SRS side airbag (if equipped) and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 113 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 114 1-7. Safety information ● Vehicles with knee airbags: The pad section of the steering wheel, dash- board near the front passenger airbag or lower portion of the instrument panel is scratched, cracked, or otherwise damaged. ● Vehicles without knee airbags: The pad section of the steering wheel, dash- board near the front passenger airbag is scratched, cracked, or otherwise...
Page 115 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 116 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 117 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not lean against the door, the roof side rail or the front, center and rear pil- lars. ● Do not allow anyone to kneel on the passenger seats toward the door or put their head or hands outside the vehicle.
Page 118 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front, center and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 119 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 120 1-7. Safety information Deactivating the curtain shield airbags in a vehicle rollover On/off (Hold for a few seconds) The “RSCA OFF” (roll sensing of curtain shield airbags off) indica- tor light turns on. (Only when the “ENGINE START STOP” switch is in IGNITION ON mode.) ■...
Page 121: Child Restraint Systems
General installation instructions are provided in this manual. (→P. 129) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem information. ● Toyota recommends that you use a child restraint system which conforms to the regulation “ECE No.44”.
Page 122 1-7. Safety information Baby seat (Infant seat) Equal to Group 0 and 0 of “ECE No.44” Child seat (Convertible seat) Equal to Group 0 and I of “ECE No.44” Junior seat (Booster seat) Equal to Group II and III of “ECE No.44”...
Page 123 1-7. Safety information Child restraint system suitability for various seating positions Provided information in the table shows your child restraint system suitability for various seating positions. Seating Second seat Third seat Front position passenger Center (if Mass Outside Center Outside seat equipped) groups...
Page 124 UF: Suitable for forward-facing “universal” category child restraint system approved for the use in this mass group. L1: Suitable for “TOYOTA BABY SAFE (0 to 13 kg [0 to 28 lb.])” approved for the use in this mass group L2: Suitable for “TOYOTA DUO (9 to 18 kg [20 to 39 lb.])” approved for the use in this mass group L3: Suitable for “TOYOTA KID (15 to 36 kg [34 to 79 lb.])”...
Page 125 1-7. Safety information Child restraint system suitability for various seating positions (with ISOFIX rigid anchor) Provided information in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Second seat Outside ISO/L1 Carrycot...
Page 126 1-7. Safety information (1) For the child restraint system which do not carry the ISO/XX size class identification (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraint systems of uni- versal category approved for use in this mass group...
Page 127 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 128 1-7. Safety information CAUTION ■ Child restraint precautions ● Never install a rear-facing child restraint system on the front passenger seat. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear- facing child restraint system is installed on the front passenger seat.
Page 129 1-7. Safety information CAUTION ■ Child restraint lock function belt precaution Do not allow children to play with the child restraint lock function belt. If the belt becomes twisted around a child’s neck, it will not be possible to pull the belt out leading to choking or other serious injuries that could result in death.
Page 130: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using a seat belt or ISOFIX rigid anchor (ISOFIX child restraint system). Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except driver’s seat belt)
Page 131 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position.
Page 132 1-7. Safety information Fully extended the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system down into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 133 1-7. Safety information Forward-facing  Child seat (convertible seat) ■ Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (→P. 47) Place the child restraint system STEP on the second or third seat fac- ing the front of the vehicle.
Page 134 1-7. Safety information Fully extend the shoulder strap STEP and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 135 1-7. Safety information ■ Junior seat (booster seat) Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. Place the child restraint system STEP on the seat facing the front of the vehicle.
Page 136 1-7. Safety information Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. Installation with ISOFIX rigid anchor (ISOFIX child restraint sys- tem) Fold the seatback forward and STEP then back to the 1st lock position (most upright position) until it locks into place.
Page 137 1-7. Safety information Check the positions of the exclu- STEP sive fixing bars, and install the child restraint system to the seat. The bars are installed in the clearance between the seat cush- ion and seatback. If the child restraint system has a top strap, the top strap should be latched onto the anchors.
Page 138 1-7. Safety information Child restraint systems with a top strap Secure the child restraint system using a seat belt or ISOFIX STEP rigid anchors, and do the following. Outside Adjust the head restraint to the upmost position. ITY17C080 Center (Type A) Lower the head restraint to the lowest position.
Page 139 Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer. Locking clip for child restraint system (Part No. 73119-22010)
Page 140 1-7. Safety information CAUTION ■ When installing a junior (booster) seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 72) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 141 ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint system informa- tion. ● When a junior (booster) seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder.
Page 142 1-7. Safety information CAUTION ■ To correctly attach a child restraint system to the anchors When using the ISOFIX rigid anchors, be sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system.
Page 143 1-7. Safety information...
Page 144: When Driving
185 Gauges and meters ..167 Indicators and warning 2-4. Using other driving systems lights ....... 171 Cruise control....186 Multi-information Toyota parking display ......175 assist-sensor ....189 Four-wheel drive system ......198 Rear differential lock system ......203 Crawl Control ....
Page 145: Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine (→P. 155) ■ Driving With the brake pedal depressed, shift the shift lever to “D”. STEP (→P. 159) Release the parking brake. (→P.
Page 146 Drum-in-disc type parking brake system Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down.
Page 147 2-1. Driving procedures ■ Idling time before engine stop (diesel engine) To prevent damage to the turbocharger, allow the engine to idle immediately after high-speed driving or hill climbing. Driving condition Idling time Normal city driving Not necessary Constant speed of approx. Approximately 20 80 km/h (50 mph) seconds...
Page 148 If the smell of exhaust is noticed inside the vehicle, open the windows and check that the back door is closed. Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately.
Page 149 2-1. Driving procedures CAUTION ● Do not shift the shift lever to “P” while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to “R” while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control.
Page 150 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ● Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
Page 151 2-1. Driving procedures CAUTION ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Failure to do so may result in the following: •...
Page 152 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 153 2-1. Driving procedures CAUTION ■ When braking the vehicle ● When the brakes are wet, drive more cautiously. Braking distance increases when the brakes are wet, and may cause one side of the vehicle to brake differently than the other side. Also the parking brake may not securely hold the vehicle.
Page 154 2-1. Driving procedures NOTICE ■ When driving the vehicle Do not use the accelerator pedal or depress accelerator and brake pedals together to hold the vehicle on a hill. ■ When parking the vehicle Always put the shift lever in “P”. Failure to do so may cause the vehicle to move or the vehicle may accelerate suddenly if the accelerator pedal is acci- dentally depressed.
Page 155 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
Page 156: Engine (Ignition) Switch
2-1. Driving procedures Engine (ignition) switch Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine Check that the parking brake is set. STEP Check that the shift lever is set in “P”.
Page 157 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can...
Page 158 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power off function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in “P”, the “ENGINE START STOP”...
Page 159 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 160: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever.
Page 161 2-1. Driving procedures ■ Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving “S” mode driving (→P. 161) : For optimal balance between performance, fuel economy and quiet operation, set the shift lever to “D” position for normal driving. : By selecting shift ranges using “S”...
Page 162 2-1. Driving procedures Changing shift ranges in “S” mode Shift the shift lever to the “S” position and operate the shift lever. Upshifting Downshifting Optitron type meters Non-Optitron type meters The initial shift range in “S” mode is automatically set to “5” or “4” according to the vehicle’s speed (6-speed models) or “4”...
Page 163 2-1. Driving procedures ■ Shift ranges and their functions Shift range Function Automatically selecting gears between 1 and 6 (6-speed models according to vehicle speed and driving conditions. only) Automatically selecting gears between 1 and 5 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 4 according to vehicle speed and driving conditions.
Page 164 If the “S” indicator does not come on even after shifting the shift lever to “S” This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in “D”.) ■...
Page 165: Turn Signal Lever
2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 166: Parking Brake
2-1. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while press- ing the button. ■ Usage in winter time See “Winter driving tips”...
Page 167: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel (vehicles with manual tilt & tele- scopic steering wheel) Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 168: Instrument Cluster Gauges And Meters
2-2. Instrument cluster Gauges and meters Optitron type meters Non-Optitron type meters The following gauges, meters and displays illuminate when the “ENGINE START STOP” switch is in IGNITION ON mode.
Page 169 2-2. Instrument cluster Tachometer Displays the engine speed in revolutions per minute. Engine coolant temperature gauge Displays the engine coolant temperature. Fuel gauge Displays the quantity of fuel remaining in the tank. Speedometer Displays the vehicle speed. Odometer/trip meter/instrument cluster light control and trip meter reset button →P.
Page 170 2-2. Instrument cluster Odometer, trip meter and instrument cluster light control display button Optitron type meters Pressing this button switches between odometer and trip meter. Odometer Trip meter A Trip meter B : Pushing and holding the button will reset the trip meter. Non-Optitron type meters Pressing this button switches between odometer, trip meter and instrument cluster light control displays (when the headlight switch...
Page 171 While driving ● When the voltmeter indicates more than 19 V or less than 9 V, the battery may be malfunctioning. Have your vehicle checked at your Toyota dealer. ● When the engine oil pressure gauge does not work properly, immediately...
Page 172: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster (Optitron type meters) Instrument cluster (non-Optitron type meters)
Page 173 2-2. Instrument cluster Center panel (vehicles with navigation system) Center panel (vehicles without navigation system)
Page 174 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator “PWR” mode indicator (→P. 164) (→P. 160) Automatic transmission Headlight high beam second start indicator indicator (→P. 178) (→P.
Page 175 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 176: Multi-Information Display
The multi-information display presents the driver with a variety of driving-related data. ● Trip information (→P. 176) Displays driving range, fuel consumption and other cruis- ing-related information. ● Toyota parking assist-sen- sor display (→P. 189) Automatically displayed when using Toyota parking assist- sensor. ● Crawl Control display (→P.
Page 177 2-2. Instrument cluster Switch the display Display items can be switched by pressing the “DISP” switch. ITY22C030 Trip information ■ Current fuel consumption Displays the current rate of fuel consumption. ■ Average fuel consumption Displays the average fuel consumption since the vehicle was last refueled.
Page 178 2-2. Instrument cluster ■ Average vehicle speed Displays the average vehicle speed since the engine was started. ■ Driving distance Displays the driving distance since the engine was started. ■ System check display After switching the “ENGINE START STOP” switch to IGNITION ON mode, “LAND CRUISER”...
Page 179: Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. parking, tail, license plate instrument panel lights turn on. The headlights and all lights listed above turn ITY23C004 Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams.
Page 180 To turn the lights on again, turn the “ENGINE START STOP” switch to IGNI- TION ON mode, or turn the headlight switch off once and then back to the position. ■ Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be changed. (Customizable features →P. 424) NOTICE ■...
Page 181: Fog Light Switch
2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. The fog lights can be used when the headlights or parking lights are turned on. ITY23C017 ∗...
Page 182: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation (when “INT” is selected). Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation ITY23C023 Washer/wiper dual opera- tion Wipers operate automatically.
Page 183 2-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. ■ “INT” mode (if equipped) Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency ITY23C031 ■...
Page 184 2-3. Operating the lights and wipers NOTICE ■ When the windshield is dry Do not use the wipers, as they may damage the windshield. ■ When there is no washer fluid spray from the nozzle Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.
Page 185: Rear Window Wiper And Washer
2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer operation ■ The rear window wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. NOTICE ■...
Page 186: Headlight Cleaner Switch
2-3. Operating the lights and wipers ∗ Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ITY23C040 ■ The headlight cleaner can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode and the head- light switch is turned on.
Page 187: Using Other Driving Systems
2-4. Using other driving systems ∗ Cruise control Use the cruise control to maintain a set speed without using the accelerator. ■ Set the vehicle speed STEP Press the “ON-OFF” button to operate the cruise control. Press the switch once more to deactivate the cruise control.
Page 188 2-4. Using other driving systems ■ Canceling and resuming regular acceleration Cancel Pull the lever towards you to cancel cruise control. The speed setting is also can- celed when the brakes are applied. Resume To resume cruise control and return to the set speed, push the lever up.
Page 189 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected. CAUTION ■...
Page 190: Toyota Parking Assist-Sensor
2-4. Using other driving systems ∗ Toyota parking assist-sensor Toyota parking assist-sensor uses sensors in the corners and rear of the vehicle to detect the distance between the vehicle and any obsta- cles, and informs the driver of this distance using the multi-informa- tion display, the touch screen, and warning beeps.
Page 191 2-4. Using other driving systems ■ Multi-information display Front corner sensor detec- tion Rear corner sensor detec- tion Back sensor detection ITY24C017 ■ Touch screen (with navigation system) When the vehicle is moving forward The graphic is automatically displayed when an obstacle is detected.
Page 192 2-4. Using other driving systems Sensor detection display, obstacle distance ■ Corner sensors Multi- Touch screen Approximate information distance to obstacle Insert display display Front: 60 cm (2.0 ft.) to 47.5 cm (1.6 ft.) Rear: 60 cm (2.0 ft.) to (continuous) (continuous) (blinking)
Page 193 2-4. Using other driving systems ■ Back sensors Approximate distance Multi-information Touch screen to obstacle display (insert display) 150 cm (4.9 ft.) to 60 cm (2.0 ft.) (continuous) (blinking slowly) 60 cm (2.0 ft.) to 45 cm (1.5 ft.) (continuous) (blinking) 45 cm (1.5 ft.) to 35 cm (1.1 ft.)
Page 194 2-4. Using other driving systems Beeps and obstacle distance A beep sounds when the corner sensors and back sensors are oper- ating. ● The beep sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obsta- cle, the beep sounds continuously.
Page 195 Warning beep volume and touch screen settings (vehicles with navigation system only) You can change the warning beep volume and touch screen operat- ing conditions. Press “SETUP” to display the “Setup” screen. STEP Touch “Vehicle”. STEP Touch “TOYOTA park assist”. STEP...
Page 196 Touch “Rear” to change the distance for the back sensors dis- STEP play and tone indication, then touch “OK”. ■ The Toyota parking assist-sensor can be operated when ● Front corner sensors: • The “ENGINE START STOP” switch is in IGNITION ON mode.
Page 197 • If towing eyelet is installed on your vehicle. • The bumper or sensor receives a strong impact. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. In addition to the examples above, there are instances in which, because of their shapes, signs and other objects may be judged by the sensor to be closer than they are.
Page 198 If a message is displayed on the multi-information display → P. 369 CAUTION ■ When using the Toyota parking assist-sensor Observe the following precautions. Failing to do so may result in the vehicle being unable to be driven safely and possibly cause an accident. ●...
Page 199: Four-Wheel Drive System
2-4. Using other driving systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/ unlock switch to select the following transfer and center differential modes. ■ Four-wheel drive control switch “H4” (high speed position) Normal driving on all types of roads.
Page 200 2-4. Using other driving systems Shifting between “H4” and “L4” ■ Shifting from “H4” to “L4” Stop the vehicle completely. STEP Shift the shift lever to “N”. STEP Push and turn the four-wheel drive control switch fully clock- STEP wise. Maintain this condition until the low speed four-wheel drive indicator light turns on.
Page 201 2-4. Using other driving systems ■ Advice for driving on slippery roads ● If you shift the four-wheel drive control switch to “L4” and the shift lever to the “2” range of “S” while driving in steep off-road areas, the output of the brake can be controlled effectively by the Active TRC, which assists the driver to control the driving power of 4 wheels.
Page 202 In this case, you may not be able to shift between “H4” and “L4”, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately.
Page 203 2-4. Using other driving systems CAUTION ■ While driving Never move the four-wheel drive control switch if the wheels have lost trac- tion. Doing so may cause an accident resulting in death or serious injury. ■ When the vehicle is parked If the shift lever is moved before the low speed four-wheel drive indicator turns on/off, the transfer mode may not be shifted completely.
Page 204: Rear Differential Lock System
2-4. Using other driving systems ∗ Rear differential lock system Use the rear differential lock system only when wheel spinning occurs in a ditch or on a slippery or ragged surface. This system is effective in case one of the rear wheels is spinning. ■...
Page 205 2-4. Using other driving systems ■ For easy unlocking Slightly turn the steering wheel in either direction while the vehicle is in motion. ■ Automatic unlocking feature The rear differential will also unlock if you turn the four-wheel drive control switch to “H4”...
Page 206: Crawl Control
2-4. Using other driving systems ∗ Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road sur- faces, allowing for stable driving.
Page 207 2-4. Using other driving systems When the system is turned off If the system is turned off when Crawl Control is operating, the slip indicator turns off, and the Crawl Control indicator flashes until the system has turned off completely. When turning off Crawl Control while traveling, stop the vehicle before the Crawl Control indicator turns off, or drive extremely carefully.
Page 208 2-4. Using other driving systems ■ Function limitations ● In the following situations, brake control can be used to drive downhill at a constant speed. However, engine control is not available when driving uphill at a constant speed. • When switched to second start mode •...
Page 209 2-4. Using other driving systems CAUTION ■ When using Crawl Control Do not rely solely on the Crawl Control. This function does not extend the vehicle’s performance limitations. Always thoroughly check the road condi- tions, and drive safely. ■ These conditions may cause the system not to operate properly When driving on the following surfaces, the system may not be able to main- tain a fixed low speed, which may result in an accident: ●...
Page 210: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 211 2-4. Using other driving systems When the VSC/Active TRC/hill-start assist control systems are operating Optitron type meters If the vehicle is in danger of slip- ping, rolling backwards when starting on an incline, or if the rear wheels spin, the slip indica- tor light flashes to indicate that VSC/Active TRC/hill-start...
Page 212 2-4. Using other driving systems To disable Active TRC and/or VSC system If the vehicle gets stuck in fresh snow or mud, Active TRC and VSC system may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 213 2-4. Using other driving systems ■ Active TRC can be turned off when The four-wheel drive control switch is in “H4” and the center differential is unlocked. ■ Automatic reactivation of Active TRC and VSC Turning the “ENGINE START STOP” switch off after turning off the Active TRC and VSC systems will automatically re-enable them.
Page 214 2-4. Using other driving systems CAUTION Any of the following conditions may result in an accident which could cause death or serious injury: ■ The Multi Terrain ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded. ●...
Page 215 In the following situations, there is the possibility that a system malfunction has occurred, and drive comfort and the vehicle’s ability to travel on poor road surfaces may be reduced. Take the vehicle to your Toyota dealer imme- diately. ●...
Page 216: Driving Information
2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
Page 217 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 218 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 219 2-5. Driving information NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 220: Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 221 2-5. Driving information CAUTION ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury. ● Stow cargo and luggage in the luggage compartment whenever possible. ● Do not stack anything in the luggage compartment higher than the seat- backs.
Page 222: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 223 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions. ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 224 2-5. Driving information Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain (5 mm [0.20 in.] in diameter) Cross chain (6.3 mm [0.25 in.] in diameter) ITY25C045 Regulations on the use of tire chains ●...
Page 225 2-5. Driving information CAUTION ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the size specified for your vehicle. ●...
Page 226: Trailer Towing
For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. For towing purposes, we recommend use of the following parts: ●...
Page 227 2-5. Driving information ■ Gross axle weight The load on either the front or rear axle resulting from distribu- tion on the gross vehicle weight on both axles must not exceed the following. Front: 1630 kg (3594 lb.) Rear: 1950 kg (4299 lb.) ■...
Page 228 ITY25C047 Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kits, etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer. Even though the vehicle may be rated for towing a higher weight, the operator must never exceed the maxi- mum weight rating specified for the trailer hitch.
Page 229 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 800 km (500 miles) of driving.
Page 230 2-5. Driving information CAUTION ■ To avoid accident or injury ● The total trailer weight (trailer weight plus the weight of cargo) must not exceed 3500 kg (7716 lb.). ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue load capacities.
Page 231 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
Page 232 2-5. Driving information ● As stopping distance is increased when towing a trailer, vehicle-to- vehicle distance should be increased. For each 10 km/h (6 mph) of speed, allow at least one vehicle and trailer length. ● Avoid sudden braking as you may skid, resulting in jackknifing and loss of control.
Page 233 2-5. Driving information ● Due to the added load of the trailer, your vehicle’s engine may overheat on hot days (at temperatures over 30°C [85°F]) when driving up a long or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air condition- ing (if in use), pull your vehicle off the road and stop in a safe spot.
Page 234 2-5. Driving information CAUTION ■ To avoid an accident ● Observe the legal maximum speeds for trailer towing. ● Slow down and downshift before descending steep or long downhill grades. Do not make sudden downshifts while descending steep or long downhill grades.
Page 235 2-5. Driving information...
Page 236: Interior Features
Interior features 3-1. Using the air conditioning 3-3. Using the storage features system and defogger List of storage features ..260 • Glove box ....... 261 Front air conditioning • Console box....262 system ......236 • Overhead console ..263 Rear air conditioning •...
Page 237: Using The Air Conditioning System And Defogger
3-1. Using the air conditioning system and defogger Front air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system and rear air conditioning system Passenger’s side temperature control Driver’s side temperature control...
Page 238 3-1. Using the air conditioning system and defogger Others Passenger’s side temperature control Driver’s side temperature control Fan speed Fan speed display Airflow display Airflow display Driver’s side Passenger’s side temperature temperature setting display setting display Outside air mode Changes the air outlets used Changes the air outlets used Recirculated Automatic...
Page 239 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting (with rear air conditioning system) Press “∧” to increase the temperature and “∨” to decrease the tem- perature on The air conditioning system switches between individual and simulta- neous modes each time is pressed.
Page 240 3-1. Using the air conditioning system and defogger ■ Adjusting the temperature setting (without rear air condition- ing system) Press “∧” to increase the temperature and “∨” to decrease the tem- perature on The air conditioning system switches between dual and simultaneous modes each time is pressed.
Page 241 3-1. Using the air conditioning system and defogger ■ Changing the air outlets With rear air conditioning system Press For front passenger’s seat For driver’s seat The air outlets switch each time the button is pressed. Different air outlets for the driver’s and front passenger’s seats can be chosen.
Page 242 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. : Depending on the rear air con- ditioning setting. Air flows to the feet. : Depending on the rear air con- ditioning setting. Air flows to the feet and the windshield defogger operates.
Page 243 3-1. Using the air conditioning system and defogger ■ Switching between outside air and recirculated air modes Press to switch to recirculated air mode and press to switch to outside air mode. Changing the rear seat settings from the front seat (with rear air conditioning system) ■...
Page 244 3-1. Using the air conditioning system and defogger ■ Adjusting the fan speed Press STEP Press “>” (increase) or “<” (decrease) on STEP The fan speed is shown on the display. (7 levels) Press to turn the fan off. ■ Changing the air outlets Press STEP...
Page 245 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air REAR REAR FRONT mode. ITY31C024 Pollen removal mode Press Outside air mode switches to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body.
Page 246 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. ITY31C032 Front side outlets Direct air flow to the left or...
Page 247 3-1. Using the air conditioning system and defogger ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
Page 248 3-1. Using the air conditioning system and defogger ■ Customization that can be configured at Toyota dealer Settings can be changed. (Customizable features →P. 424) CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather.
Page 249: Rear Air Conditioning System
3-1. Using the air conditioning system and defogger ∗ Rear air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Fan speed display Airflow display Left side temperature setting display Right side temperature setting display Left side temperature control Right side temperature control Automatic mode...
Page 250 3-1. Using the air conditioning system and defogger Adjusting the setting ■ Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on The temperature for the right-hand and left-hand rear seats can be set separately.
Page 251 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press The air outlets switch each time the button is pressed. Air flows to the upper body. ITY31C020 Air flows to the upper body and feet. ITY31C021 Air flows to the feet.
Page 252 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Rear center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Roof side outlets Direct air flow to the left or right, up or down.
Page 253: Rear Cooler System
3-1. Using the air conditioning system and defogger ∗ Rear cooler system REAR COOLER REAR ITY31C037 Fan speed control knob Rear cooler on/off switch Adjusting the fan speed Press to turn on the system. STEP REAR COOLER to adjust the desired fan speed. STEP REAR COOLER Press...
Page 254 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Direct air flow to the left or right, up or down. Turn the knob fully to the back of the vehicle to close the vent.
Page 255: Heater Idle Up Switch
3-1. Using the air conditioning system and defogger ∗ Heater idle up switch This feature is used to boost heating effect in extremely cold condi- tions when the vehicle is not moving. Press the switch to increase engine speed. Press the switch again to IDLE return the engine to the normal idle speed.
Page 256: Rear Window And Outside Rear View Mirror Defoggers
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers Clear the rear window using the defogger. (For vehicles with outside rear view mirror defoggers, turning the rear window defogger on will turn the outside rear view mirror defoggers on. The outside rear view mirror is used to remove raindrops, dew and frost from the outside rear view mirrors.) With navigation system...
Page 257 3-1. Using the air conditioning system and defogger ■ The rear window and outside rear view mirror defoggers can be oper- ated when The “ENGINE START STOP” switch is in IGNITION ON mode. CAUTION ■ When the outside rear view mirror defoggers are on Do not touch the rear view mirror surfaces, as they can become very hot and burn you.
Page 258: Using The Interior Lights
3-2. Using the interior lights Interior lights list Your Toyota is equipped with an illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off accord-...
Page 259: Interior Lights
TION ON when the door is not fully closed and the interior light switch is in the door position, the lights will go off automatically after 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features →P. 424)
Page 260: Personal Lights
3-2. Using the interior lights Personal lights Personal lights Front On/off SPOT DOOR ON OFF SPOT ITY33C011 Rear (type A) On/off Rear (type B) On/off ITY33C014...
Page 261: Using The Storage Features List Of Storage Features
3-3. Using the storage features List of storage features ITY34C002 Bottle holders Card holder Door pockets Cup holders Glove box Console box/cool box Overhead console Auxiliary box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 262: Glove Box
3-3. Using the storage features Glove box Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical ITY34C004 ■ Glove box light The glove box light turns on when the tail lights are on. CAUTION ■ While driving Keep the glove box closed.
Page 263: Console Box
3-3. Using the storage features Console box Console box Your vehicle is equipped with either a lower console box or cool box. For vehicles with the cool box, refer to page 268. Upper console box Press the tab to open. ITY34C007 Lower console box (if equipped) Lift the lever to open.
Page 264: Overhead Console
3-3. Using the storage features Console box and overhead console CAUTION ■ While driving Keep the console box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. Overhead console (if equipped) Press the button. The overhead console is useful temporarily storing...
Page 265: Cup Holders
3-3. Using the storage features Cup holders Cup holders Front Press down and release the lid. You can adjust or remove the separator inside. ITY34C012 Second seats (if equipped) Pull the armrest down. (→P. 280) STEP Press the button. STEP ITY34C015 Third seats (if equipped)
Page 266: Bottle Holders
3-3. Using the storage features Cup holders and bottle holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 267 3-3. Using the storage features Bottle holders For second seats ITY34C024 For third seats NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
Page 268: Card Holder
3-3. Using the storage features Card holder and auxiliary box Card holder Auxiliary box Type A ITY34C023 Type B (if equipped)
Page 269: Other Interior Features Cool Box
3-4. Other interior features ∗ Cool box While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Lift the lever to open. STEP ITY34C029 On/off STEP COOL When on, the indicator light comes on.
Page 270 3-4. Other interior features CAUTION ■ While driving Keep the cool box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. NOTICE ■ To prevent battery discharge Do not leave the cool box on longer than necessary when the engine is stopped.
Page 271: Sun Visors
3-4. Other interior features Sun visors Main sun visor Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide backwards. Sub-sun visor Flip down with the main sun visor in position...
Page 272: Vanity Mirror
3-4. Other interior features Vanity mirror Slide the cover. The light turns on when the cover is opened.
Page 273: Clock
3-4. Other interior features Clock With navigation system Refer to “Navigation System Owner’s Manual”. Without navigation system Adjust hours. Adjust minutes. Round the nearest hour. :e.g. 1:00 to 1:29→1:00 1:30 to 1:59→2:00 ITY35C004 ■ The clock is displayed when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 274: Outside Temperature Display
The “ENGINE START STOP” switch is in IGNITION ON mode. ■ When --- is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
Page 275: Ashtray
3-4. Other interior features Ashtray Front Press in and release the lid to open. Press down on the lock spring plate to remove. Push the lid to close. ITY35C008 Rear Pull the ashtray lid to open. Pull the ashtray upwards to remove.
Page 276: Cigarette Lighter
3-4. Other interior features Cigarette lighter Push the cigarette lighter in. The cigarette lighter will pop up when ready for use. ITY35C011 ■ The cigarette lighter can be used when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 277: Power Outlet
3-4. Other interior features Power outlet The power outlet can be used for 12 V accessories that run on less than 10 A. Instrument panel ITY35C013 Luggage compartment ■ The power outlet can be used when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 278 3-4. Other interior features NOTICE ■ To avoid damaging the power outlet Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. ■ To prevent the fuse from being blown Do not use an accessory that uses more than 12 V/10 A.
Page 279: Seat Heaters
3-4. Other interior features ∗ Seat heaters For front seats For driver’s seat Pops the switch out. For front passenger’s seat Pops the switch out. The indicator light comes on. Adjusts the seat tempera- ture The further you turn the knob clockwise, the warmer the seat becomes.
Page 280 3-4. Other interior features ■ The seat heaters can be used when The “ENGINE START STOP” switch is in IGNITION ON mode. CAUTION ■ Burns ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: •...
Page 281: Armrest
3-4. Other interior features ∗ Armrest Pull the armrest down for use. ITY35C019 NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. ∗ : If equipped...
Page 282: Floor Mats
When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 283 3-4. Other interior features CAUTION ■ Before driving ● Check that the floor mat is securely fixed in the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor. ● With the engine stopped and the shift lever in “P”, fully depress each pedal to the floor to make sure it does not inter-...
Page 284: Luggage Compartment Features
3-4. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ITY35C022 ■ Storage compartment Open the storage compart- ment as shown. ITY35C024 ■ Warning reflector holder Hold the warning reflector with a band. The warning reflector itself is not included as an original equipment.
Page 285 3-4. Other interior features ■ First-aid kit holder (if equipped) Hold the first-aid kit with a band. The first-aid kit itself is not included as an original equip- ment. ITY35C026 CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their positions when they are not in use.
Page 286: Maintenance And Care
Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..286 Cleaning and protecting the vehicle interior ..289 4-2. Maintenance Maintenance requirements....292 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ..... 295 Hood ......... 298 Engine compartment..299 Tires........
Page 287: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 288 4-1. Maintenance and care ■ Touch-up paint (if equipped) Touch-up paint may be used to cover small chips or scratches. Apply the paint soon after the damage occurs or corrosion may set in. To apply the touch-up paint so it is hardly noticeable, the trick is to apply it only to the bare spots.
Page 289 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 290: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 291 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 292 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
Page 293: Maintenance
These are best performed by qualified technicians. Even if you’re an experienced do-it-yourself mechanic, we recommend that repairs and maintenance be conducted by your Toyota dealer who will keep a record of maintenance on your Toyota. This record could be helpful should you ever require Warranty Service.
Page 294 4-2. Maintenance ■ Where to go for service? It makes good sense to take your vehicle to your local Toyota dealer for ser- vice. Toyota technicians are well-trained specialists. And they are receiving the latest service information through technical bulletins, service tips, and in dealership training programs.
Page 295 4-2. Maintenance CAUTION ■ If your vehicle is not properly maintained It could result in serious damage to the vehicle and possible serious injury or death. ■ Warning in handling of the battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 296: Do-It-Yourself Maintenance
• Baking soda Battery condition (→P. 308) • Grease • Conventional wrench (for terminal clamp bolts) • Toyota Super Long Life Coolant or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (→P.
Page 297 4-3. Do-it-yourself maintenance Items Parts and tools • Tire pressure gauge Tire inflation pressure (→P. 316) • Compressed air source • Water or washer fluid containing Washer fluid (→P. 312) antifreeze (for winter use) • Funnel CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized.
Page 298 4-3. Do-it-yourself maintenance CAUTION ■ When working near the electric cooling fan or radiator grille Be sure the “ENGINE START STOP” switch is off. With the “ENGINE START STOP” switch in IGNITION ON mode, the electric cooling fan may automatically start to run if the air conditioning is on and/or the coolant temperature is high.
Page 299: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION ■ Pre-driving check Check that the hood is fully closed and locked.
Page 300: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment 2UZ-FE engine Engine oil level dipstick Fuse box (→P. 326) (→P. 302) Washer fluid tank (→P. 312) Engine coolant reservoir Battery (→P. 308) (→P. 306) Condenser (→P. 308) Cooling fans Radiator (→P. 308) Engine oil filler cap (→P.
Page 301 4-3. Do-it-yourself maintenance 1VD-FTV engine Engine coolant reservoir Cooling fans (→P. 306) Fuel filter (→P. 401) Engine oil level dipstick Fuse box (→P. 326) (→P. 302) Washer fluid tank (→P. 312) Engine oil filler cap Battery (→P. 308) (→P. 303) Condenser (→P.
Page 302 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips Push up center portion Insert Press...
Page 303 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, STEP wait more than 5 minutes for the oil to drain back into the bot- tom of the engine.
Page 304 4-3. Do-it-yourself maintenance Diesel engine Full ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. (→P. 411) ITY43C115 Make sure to check the oil type and prepare the items needed before adding oil.
Page 305 ● Oil consumption: Max. 1.0 L per 1000 km (1.1 qt./600 miles, 0.9 lmp. qt./ 600 miles) ● If you consume more than 1.0 L (1.1 qt., 0.9 lmp. qt.) every 1000 km (600 miles), contact your Toyota dealer.
Page 306 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 307 4-3. Do-it-yourself maintenance Engine coolant Gasoline engine The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir when the engine is cold. Reservoir cap “F” “L” If the level is on or below the “L” line, add coolant up to the “F”...
Page 308 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. ■...
Page 309 Check the radiator, condenser and intercooler and clear any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■ When the engine is hot Do not touch the radiator, condenser or intercooler, as they may be hot and may cause serious injuries, such as burns.
Page 310 Check the battery condition using the indicator color. Good condition Type A Type B Charging is necessary. Have Green Blue the vehicle inspected by your Toyota dealer. Not working properly, add dis- Dark White tilled water. Clear or light yellow ITY43C101 ■...
Page 311 4-3. Do-it-yourself maintenance ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: ● If recharging with the battery installed on the vehicle, be sure to discon- nect the ground cable. ● Make sure the power switch on the charger is off when connecting and disconnecting the charger cables to the battery.
Page 312 4-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 313 4-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display (vehicles with Optitron type meters) or the warning indicator light comes on (vehicles with non-Optitron type meters), the washer tank may be empty. Add washer fluid.
Page 314: Tires
Check spare tire condition and inflation pressure if not rotated. ■ Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate your Front tires approximately every 5000 km (3000 miles).
Page 315 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Tire life Any tire over 6 years old must be checked by a qualified technician even if they have seldom or never been used or damage is not obvious.
Page 316 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 317: Tire Inflation Pressure
Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 318 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
Page 319: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 320 4-3. Do-it-yourself maintenance CAUTION ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.
Page 321: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the “ENGINE START STOP” switch IGNITION ON STEP mode and switch to recirculated air mode, then turn the “ENGINE START STOP”...
Page 322 2 minutes at or bar, 72 500 kPa (5.0 kgf/cm psi). If it is not available, have the filter cleaned by your Toyota dealer. ■ Replacement method Remove the air conditioning filter and replace it with a new one.
Page 323 4-3. Do-it-yourself maintenance ■ Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, please refer to the “Warranty and Service Book- let”.) ■...
Page 324: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) ●...
Page 325 ● The operational range is reduced. ■ Use a CR1632 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer. ●...
Page 326 4-3. Do-it-yourself maintenance CAUTION ■ Removed battery and other parts Keep away from children. These parts are small and if swallowed by a child, they can cause choking. Failure to do so could result in death or serious injury. NOTICE ■...
Page 327: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “ENGINE START STOP” switch OFF. STEP The fuses are located in the following places. To check the STEP fuses, follow the instructions below.
Page 328 4-3. Do-it-yourself maintenance Driver’s side instrument panel (if equipped) Remove the lid. ITY42C028 After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 330) for details about which fuse to check. Remove the fuse with the pull- STEP out tool.
Page 329 4-3. Do-it-yourself maintenance Check if the fuse has blown. STEP Type A and B Normal fuse Type A Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. ITY42C012 Type B ITY42C013...
Page 330 4-3. Do-it-yourself maintenance Type C and D Normal fuse Type C Blown fuse Contact your Toyota dealer. ITY42C014 Type D ITY42C015...
Page 331 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment 6 7 8 9 10 11 12 13 14 15 16 17 36 37 3839 4041 4243 5556575859 4445 46 47 4849 50 51 525354 60616263 ITY43C035 Fuse Ampere Circuit 15 A A/F heater...
Page 332 4-3. Do-it-yourself maintenance Fuse Ampere Circuit ALT-CDS 10 A No circuit FR FOG 15 A Front fog lights SECURITY SECURITY SEAT-A/C RH 25 A No circuit Stoplights, high mounted stoplight, STOP 15 A ABS, VSC, main body ECU, EFI, trailer TOW BRK 30 A No circuit...
Page 333 4-3. Do-it-yourself maintenance Fuse Ampere Circuit A/PUMP NO.2 50 A No circuit GLOW2 80 A Engine glow system Headlight, HEAD LL, HEAD RL, MAIN 40 A HEAD LH, HEAD RH ABS1 50 A ABS2 30 A 30 A Starter system ID code box, smart entry &...
Page 334 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Navigation system, audio system, RAD NO.1 10 A parking assist system Smart entry & start system, over- head module, tilt and telescopic ECU-B1 steering, meter, cool box, gateway ECU, steering sensor DOME1 Illuminated entry system, clock HEAD LH 15 A Headlight high beam (left)
Page 335 4-3. Do-it-yourself maintenance ■ Passenger’s side instrument panel Fuse Ampere Circuit 15 A Cigarette lighter BK/UP LP 10 A Back-up lights, trailer Audio system, parking assist sys- tem, multi-display assembly, main 7.5 A body ECU mirror ECU, smart entry & start system, clock Four-wheel drive system, ashtray, cigarette lighter, cool box, cruise control, center differential lock,...
Page 336 4-3. Do-it-yourself maintenance Fuse Ampere Circuit WINCH No circuit Cool box, condenser fan, cooler compressor, rear window and out- A/C IG 10 A side rear view mirror defoggers, air conditioning system Tail lights, license plate lights, front TAIL 15 A fog lights, trailer, parking lights WIPER 30 A...
Page 337 4-3. Do-it-yourself maintenance Fuse Ampere Circuit No circuit TI & TE 15 A Tilt and telescopic steering FR P/SEAT RH 30 A Power seat PWR OUTLET 15 A Power outlet 7.5 A On-Board diagnosis 30 A No circuit DOOR NO.1 25 A Main body ECU FR P/SEAT LH...
Page 338 4-3. Do-it-yourself maintenance ■ Driver’s side instrument panel (if equipped) Fuse Ampere Circuit RSF LH 30 A No circuit B/DR CLSR RH 30 A No circuit B/DR CLSR LH 30 A No circuit RSF RH 30 A No circuit DOOR DL 15 A No circuit AHC-B...
Page 339 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 340: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 341 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal light Back-up light License plate lights ITY43C106 Replacing light bulbs ■ Headlight low beams Turn the bulb base counterclock- STEP wise. ITY43C038 Unplug connector while STEP depressing the lock release. ITY43C039...
Page 342 4-3. Do-it-yourself maintenance ■ Headlight high beams Turn the bulb base counterclock- STEP wise. ITY43C040 Unplug connector while STEP depressing the lock release. ITY43C041...
Page 343 4-3. Do-it-yourself maintenance ■ Front fog lights (if equipped) Remove the fender liner bolts, STEP loose the fender liner nut and remove the fender liner. Fender liner nut Fender liner bolts Turn the bulb base counterclock- STEP wise. Unplug connector while STEP depressing the lock release.
Page 344 4-3. Do-it-yourself maintenance ■ Front position light Turn the bulb base counterclock- STEP wise. ITY43C046 Remove the light bulb. STEP ITY43C047...
Page 345 4-3. Do-it-yourself maintenance ■ Front turn signal lights For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. ITY43C044 Remove the light bulb. STEP ITY43C045...
Page 346 4-3. Do-it-yourself maintenance ■ Side turn signal lights Push it to the front of the vehicle STEP as shown. ITY43C055 Turn the bulb base counterclock- STEP wise. ITY43C056 Remove the light bulb. STEP ITY43C057...
Page 347 4-3. Do-it-yourself maintenance ■ Back-up lights Open the back door and remove STEP the nuts and lamp assembly. ITY43C052 Turn the bulb bases counter- STEP clockwise. ITY43C053 Remove the light bulb. STEP ITY43C054...
Page 348 4-3. Do-it-yourself maintenance ■ Rear turn signal lights Open the back door and remove STEP the bolts and lamp assembly. ITY43C058 Turn the bulb bases counter- STEP clockwise. ITY43C059 Remove the light bulb. STEP ITY43C060...
Page 349 4-3. Do-it-yourself maintenance ■ License plate lights Open the back door and remove STEP the license plate light unit. Turn the bulb base counterclock- STEP wise. ITY43C067 Remove the light bulb. STEP ITY43C068...
Page 350 Water has built up inside the headlight. ■ LED lights The stop/tail, tail lights and high mounted stoplight consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 351 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
Page 352: When Trouble Arises
When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers..352 If a warning light turns on If your vehicle needs to be or a warning buzzer towed ......353 sounds......361 If you think something If a warning message is wrong ......
Page 353: Essential Information Emergency Flashers
5-1. Essential information Emergency flashers Use the emergency flashers if vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 354: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 355 5-1. Essential information Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the towing hook. This should only be attempted on hard, surfaced roads for short dis- tances at low speeds.
Page 356: If Your Vehicle Needs To Be
5-1. Essential information CAUTION ■ While towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing hook and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
Page 357 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels.
Page 358 5-1. Essential information From rear Use a towing dolly under the front wheels. NOTICE ■ To prevent causing serious damage to the transmission Never tow this vehicle wheels on the ground. ■ To prevent damaging the vehicle ● Do not tow the vehicle with the “ENGINE START STOP” switch OFF. The steering lock mechanism is not strong enough to hold the front wheel straight.
Page 359 5-1. Essential information Using a flat bed truck If your Toyota is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. When attaching the hooks to the rear of the vehi- cle, make sure to attach them to the inside of the vehicle.
Page 360: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 361: Fuel Pump Shut Off System (Gasoline Engine Only)
5-1. Essential information Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 362: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds
Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light...
Page 363 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
Page 364 5-2. Steps to take in an emergency Warning light Warning light/Details Fuel system warning light (vehicles with non-Optitron type meters) (warning buzzer) Indicates: • The amount of accumulated water in the fuel filter has reached the specified level if the light comes on. •...
Page 365 15.0 L (4.0 gal., 3.3 Imp. gal.) or less. (vehicles without sub fuel tank) Indicates a malfunction in the fuel tank system if the Have the system checked light flashes. (vehicles with by your Toyota dealer. 1VD-FTV engine only)
Page 366 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Driver’s seat belt reminder light (warning buzzer) Fasten the seat belt. Warns the driver to fasten his/her seat belt. (On the center panel without Front passenger’s seat navigation belt reminder light system)
Page 367 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Unengaged “Park” warn- ing light Shift four-wheel drive con- Indicates that the trans- trol to “H4” or “L4”. mission “Park” mecha- (→P. 198) nism is not engaged. Master warning light (If equipped) A buzzer sounds and the...
Page 368 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible. ■...
Page 369 5-2. Steps to take in an emergency Follow the correction procedures. (smart entry & start system) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Correction Warning light Warning light/Details buzzer buzzer procedure...
Page 370: If A Warning Message Is Displayed
Multi-information display If any of the warning messages is shown again after its correction procedure has been performed, contact your Toyota dealer. Messages and warnings The warning lights and warning buzzers operate as follows depend- ing on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected immediately by your Toyota dealer.
Page 371: Or A Warning Buzzer
5-2. Steps to take in an emergency System Warning warning Warning buzzer light Indicates an important situation, such as when a system related to  Comes on Sounds driving is malfunctioning or that danger may result if the correction procedure is not performed. Indicates an important situation, Comes such as when the system shown...
Page 372 5-2. Steps to take in an emergency ■ System warning lights The master warning light does not come on or flash in the following cases. Instead, a separate system warning light will come on or flash along with the message shown on the multi-information display. ●...
Page 373: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 374 5-2. Steps to take in an emergency Taking out the jack Remove the cover. STEP Loosen STEP Tighten Loosen and remove the jack.
Page 375 5-2. Steps to take in an emergency Taking out the tool box Remove the cover. STEP Take out the tool box. STEP...
Page 376 5-2. Steps to take in an emergency Taking out the spare tire Assembling the jack handle. STEP Remove the jack handle and the jack extension bar from the tool box and assemble by following these steps. Loosen the screw using a screwdriver.
Page 377 5-2. Steps to take in an emergency Insert the jack handle extension STEP into the lowering screw. Lower Raise ITY52C050 Lower the spare tire completely STEP to the ground. ITY51C031 Pull out the spare tire and STEP remove the holding bracket. ITY52C032...
Page 378 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side...
Page 379 5-2. Steps to take in an emergency Pry off the wheel ornament, STEP using the beveled end of the wheel ornament remover as shown. Slightly loosen the wheel nuts STEP (one turn).
Page 380 5-2. Steps to take in an emergency Assembling the jack handle. STEP Remove the jack handle, jack extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 381 5-2. Steps to take in an emergency Position the jack at the jack STEP points as shown. Front - Under the chassis frame side rail Rear - Under the rear axle hous- Raise the vehicle until the tire is STEP slightly raised off the ground.
Page 382 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 383 5-2. Steps to take in an emergency Lower the vehicle. STEP Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque Aluminum wheels: 131 N•m (13.4 kgf•m, 97 ft•lbf) Steel wheels: 209 N•m (21.3 kgf•m, 154 ft•lbf) Reinstall the wheel ornament.
Page 384 5-2. Steps to take in an emergency Stowing the flat/spare tire, jack and tools Lay down the tire with the outer STEP side facing up, and install the holding bracket. ITY52C033 Raise the tire. STEP Vehicles with kinetic dynamic suspension: Pull the tire towards the rear of the vehicle when raising.
Page 385 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 386 5-2. Steps to take in an emergency CAUTION ■ Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury. ● Lower the spare tire completely to the ground before removing it from under the vehicle. ●...
Page 387: If The Engine Will Not Start
5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 155) or releasing the steering lock (→P. 157), confirm the following points. ■ The engine will not start even when the starter motor oper- ates normally One of the following may be the cause of the problem.
Page 388 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 394) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
Page 389: If The Shift Lever Cannot Be Shifted From P
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 390: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the other keys and the key number stamped on your key num- ber plate.
Page 391: If You Cannot Operate Back Door Opener
If the back door opener does not operate, there may be a problem with the back door opener system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the back door can be opened from the inside.
Page 392: If The Electronic Key Does Not Operate Properly
Using mechanical (→P. 22) in order to perform the following operations. Locks all doors Closes windows/moon roof (turn and hold) Unlocks all doors Opens windows/moon roof (turn and hold) : This setting must be custom- ized at your Toyota dealer.
Page 393 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine Shift the shift lever to “P” and apply the brakes. STEP Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate...
Page 394 5-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to “P” and press the “ENGINE START STOP” switch as you normally do when stopping the engine. ■ Replacing the key battery As this above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery depletes.
Page 395: If The Battery Is Discharged
You can also call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below.
Page 396 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible.
Page 397 5-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting. ■ Avoiding a discharged battery ● Turn off the headlights and the audio system while the engine is turned off.
Page 398 5-2. Steps to take in an emergency CAUTION ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery. ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 399: If Your Vehicle Overheats
Wait until the engine coolant temperature gauge begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your Toyota dealer. After the engine has cooled STEP down sufficiently, check the...
Page 400 Water can be used in an emer- gency if engine coolant is (→ unavailable. P. 416 TY51C047 Have the vehicle checked at the nearest Toyota dealer as soon as possible. ■ Overheating If you observe the following, your vehicle may be overheating. ●...
Page 401 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.
Page 402: If You Run Out Of Fuel And The Engine Stalls (Diesel Engine Only)
If the engine does not start after the above steps have been per- formed, wait for 10 seconds and try step 2 and 3 again. If the engine still does not start, contact your Toyota dealer. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.
Page 403: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift STEP lever in “P”.
Page 404: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
Page 405 5-2. Steps to take in an emergency CAUTION ■ If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 406: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..406 Fuel information ....423 6-2. Customization Customizable features ..424...
Page 407: Specifications Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 4950 mm (194.9 in.) Overall width 1970 mm (77.6 in.) Overall height 1905 mm (75.0 in.) Wheelbase 2850 mm (112.2 in.) Front 1640 mm (64.6 in.) Tread Rear 1635 mm (64.4 in.) : Unladen vehicles...
Page 408 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel or on the front right frame.
Page 409 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 2UZ-FE engine 1VD-FTV engine...
Page 410 6-1. Specifications Engine Gasoline engine Model 2UZ-FE Type 8-cylinder V type, 4-cycle, gasoline Bore and stroke 94.0 x 84.0 mm (3.70 x 3.31 in.) Displacement 4664 cm (284.5 cu. in.) Intake: 0.15  0.25 mm (0.006  0.010 in.) Valve clearance Exhaust: 0.25 ...
Page 411 6-1. Specifications Fuel Gasoline engine Fuel type Unleaded gasoline only Research octane 91 or higher number Fuel tank capacity 138 L (36.5 gal., 30.4 lmp. gal.) (Reference) Diesel engine Fuel type Diesel fuel only Cetane number 48 or higher Vehicles with sub fuel tank 138 L (36.5 gal., 30.4 Imp.
Page 412 Without filter 8.2 L (8.7 qt., 7.2 Imp. qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Gasoline engine...
Page 413 6-1. Specifications Recommended viscosity (SAE): If you use SAE10W-30 or a higher viscosity engine oil in extremely low temperatures, the engine may become difficult to start, so SAE 5W-30 engine oil is recommended. Temperature range anticipated before next oil change The 10W portion of the oil viscosity rating indicates the characteristic of the oil which allows cold startability.
Page 414 6-1. Specifications How to read oil container labels: Either or both API registered marks are added to some oil containers help you select the oil you should use. API Service Symbol portion: quality designation by API (American Petroleum Institute) (SM) Center portion: The SAE viscosity grade (SAE 10W-30) Lower...
Page 415 6-1. Specifications Diesel engine Oil grade: G-DLD-1, API CF-4, CF or ACEA B1 (You may also use API CE or CD.) Recommended viscosity (SAE): SAE 5W-30 is the best choice for good fuel economy and good Preferred starting in cold weather. If you use SAE 10W-30 or a higher viscosity engine oil in extremely low temperatures, the...
Page 416 6-1. Specifications DLD logo mark: The Global DLD-1 logo mark, attached on some oil containers to help in selecting the oil you should use, indicates that the oil meets the guidelines recom- mended by the following associ- ations: ● ACEA (Association des Con- structeurs Europeens d’Auto- mobiles) ●...
Page 417 17.6 L (18.6 qt., 15.5 Imp.qt.) engine Without rear heater 14.8 L (15.6 qt., 13.0 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 418 6-1. Specifications Ignition system (gasoline engine only) Spark plug Make DENSO SK20R11 NGK IFR6A11 DENSO 1.1 mm (0.043 in.) NGK 1.1 mm (0.043 in.) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine. Electrical system Battery 1.250 ...
Page 419 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota...
Page 420 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please con-...
Page 421 6-1. Specifications Brakes Pedal clearance 93 mm (3.66 in.) Min. 1  6 mm (0.04  0.24 in.) Pedal free play 5  7 clicks Parking brake lever travel Fluid type SAE J1703 or FMVSS No. 116 DOT 3 : Minimum pedal clearance when depressed with a force of 490 N (50 kgf, 110 lbf) while the engine is running : Parking brake lever travel when pulled up with a force of 200 N (20.4 kgf, 45.0 lbf)
Page 422 6-1. Specifications Tires and wheels Tire size 285/60R18 116V, 285/65R17 116H Front wheel Rear wheel Tire inflation pressure kPa (kgf/cm kPa (kgf/cm (Recommended cold tire or bar, psi) or bar, psi) inflation pressure) 230 (2.3, 33) 230 (2.3, 33) 18 × 8 J, 17 × 8 J Wheel size Aluminum wheels Steel wheels...
Page 423 6-1. Specifications Light bulbs Light Bulbs Type Headlights Low beam High beam Front turn signal lights Front position lights Exterior Front fog lights Side turn signal lights Rear turn signal lights Back-up lights License plate lights Front interior light Rear interior lights With rear personal lights Without rear personal lights Front personal lights...
Page 424: Fuel Information
■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■ If you plan to drive in foreign countries Low sulfur diesel fuel may not be available, so please confirm the availability with your distributor.
Page 425: Customization
Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 426 6-2. Customization Customized Item Function Default setting setting Linked door key opera- tion (close) Linked door key opera- tion (open) Power win- dows Wireless remote control (→P. 86) linked operation (close) Wireless remote control linked operation (open) Linked entry function Time elapsed before Automatic headlights automati-...
Page 427 6-2. Customization Customized Item Function Default setting setting Mechanical key linked operation Open only Mechanical key linked Open and close operation Close only Linked operation of components when door Slide only Tilt only key is used Moon roof Wireless remote control (→P.
Page 428 6-2. Customization Multi-information display (→P. 175) English (U.S.A.), English (UK), French, Available languages German, Spanish, Italian, Japanese, Sim- plified Chinese and Traditional Chinese...
Page 429 6-2. Customization...
Page 430: Index
Index Abbreviation list ...... 430 Alphabetical index....431 What to do if......440 For details of equipment related to the navigation sys- tem and touch screen, such as the air conditioning and audio systems, refer to the “Navigation System Owner’s Manual”.
Page 431: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air conditioning Anti-lock Brake System Automatic Locking Retractor Child Restraint System DIFF Differential DISP Display Emergency Locking Retractor Intermittent KDSS Kinetic Dynamic Suspension System Light Emitting Diode Limited Slip Differential Power RSCA Roll Sensing of Curtain Shield Airbag Supplemental Restraint System TEMP Temperature...
Page 432: Alphabetical Index
Alphabetical index Alphabetical index Automatic transmission Air conditioning filter....320 Automatic transmission..159 Automatic air conditioning..236 If the shift lever cannot be ABS ........... 209 shifted from P ..... 388 Active traction control..... 209 S mode ......... 161 Air conditioning filter ....320 Automatic light control Air conditioning system system........
Page 433 Display Installing CRS with top Crawl Control display.... 205 strap........137 Trip information..... 176 Junior seats, definition ..120 Toyota parking assist-sensor Junior seats, installation..129 display ........ 189 Child safety Shift position and shift Airbag precautions ....114 range ........159 Battery precautions ..
Page 434 Alphabetical index Electronic key Engine If your electronic key battery Compartment ......299 Engine switch......155 is discharged ....323, 394 Emergency flashers Hood ........298 Switch ........352 How to start the engine..155 Emergency, in case of Identification number .... 407 If the electronic key does not If the engine will not start ..
Page 435 Alphabetical index Fog lights Gas station information ..444 Replacing light bulbs..... 339 Gauges ........167 Glove box ......... 261 Switch ........180 Wattage......... 422 Glove box light......261 Four-wheel drive system..198 Front fog lights Hazard lights Replacing light bulbs..... 339 Switch ........
Page 436 Alphabetical index Illuminated entry system..257 Language Indicator lights ......171 Multi-information display ......175, 427 Inside rear view mirror ....81 Instrument cluster light License plate lights control ........169 Replacing light bulbs..... 339 Intercooler ........ 308 Wattage ........ 422 Interior lights Light bulbs Interior lights ......
Page 437 Alphabetical index Odometer........167 Replacing Off road precautions ....215 Key battery......323 Fuses ........326 Engine oil ......302 Light bulbs ......339 Opener Tires........372 Fuel filler door ......93 Roll sensing of curtain shield Hood ........298 airbags off switch....
Page 438 Alphabetical index Shift lever Switch Automatic transmission..159 ECT switch......160 Emergency flasher switch..352 If the shift lever cannot be shifted from P ....388 Engine switch......155 Side airbags ......105 Fog light switch ..... 180 Side mirror Hazard light switch....
Page 439 Anti-lock brake system ..362 Automatic transmission fluid Emergency towing ....354 Trailer towing ......225 temperature ....... 363 Toyota parking assist-sensor 189 Brake system ......361 Traction control ....... 209 Charging system....361 TRC ........... 209 Fuel system ......363 Trip information Fuel level ......
Page 440 Alphabetical index...
Page 441: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 372 P. 386 If the engine will not start If you run out of fuel and the P. 401 engine stalls The engine does not start P.
Page 442 What to do if... The warning light or indicator If a warning light turns on P. 361 light comes on Vehicles with Optitron type meters Vehicles with non-Optitron type meters...
Page 443 What to do if... ■Warning lights Brake system warning Open door warning light light P. 361 P. 364 Charging system warn- Low fuel level warning ing light light P. 361 P. 364 Automatic transmission Driver’s seat belt fluid temperature warn- reminder light ing light P.
Page 444 What to do if...
Page 445 GAS STATION INFORMATION Fuel filler door Auxiliary catch lever P. 93 P. 298 Tire inflation pressure Fuel filler door opener Hood lock release lever P. 421 P. 93 P. 298 Vehicles with sub fuel tank 138 L (36.5 gal.,30.4 Imp. gal.) Fuel tank system capacity...

This manual is also suitable for:

Land cruiser station wagon 2008 Land cruiser station wagon 2009 Land cruiser station wagon 2010 Land cruiser station wagon 2011

Toyota LAND CRUISER STATION WAGON 2007 Owner's Manual

Quick Links

Related Manuals for Toyota LAND CRUISER STATION WAGON 2007

Summary of Contents for Toyota LAND CRUISER STATION WAGON 2007

This manual is also suitable for:

Table of Contents
