PN-L862B Dismantle Instruction 1. Scope This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU. 2. Tools for dismantling Below tools are required to dismantle this product. Screw Driver Nipper 3. Dismantle Procedure This product can be dismantled by below steps.
PN-L862B Dismantle Instruction 4. Back covers Big back cover(x1),Middle back cover(x1),Right small back cover(x1) ,Left small back cover(x1) Can be removed by screw driver.
PN-L862B Dismantle Instruction 5. Printed circuit boards All PWBs can be removed by screw driver. Main I/F PWB (1pcs) Power PWB (1pcs) Temperature sensor PWB (1pcs) AC inlet PWB (1pcs) Wi-Fi module PWB (1pcs) T-CON PWB (1pcs) Front Key PWB (1pcs)
PN-L862B Dismantle Instruction 7. LCD Module LCD Dismantle procedure After you have removed the PWB´s and dismantled the LCD Module please take out the cables from the LCD module. Due to direct bonding technology the front glass cannot be removed from the LCD.
PN-L862B Dismantle Instruction 8. Capacitors Electrolyte Capacitors which diameter/height is larger than 25mm is installed on Power PWB, LED driver PWB and 5V Power PWB. These capacitors can be removed by using nipper to cut the leads. On Power PWB...
PN-L862B Dismantle Instruction 9. Parts List Parts described in Annex VII of directive 2012/19/EU are as below. Parts Note 86inch LCD module Printed Circuit Boards Main I/F PWB Power PWB Temperature sensor PWB AC INLET PWB Wi-Fi module PWB T-CON PWB...
