Page 1
OLED TV Conditions of Use: (1) Please use this information only for the purpose of performing repair and recycling Sony products. Using this information for any purpose other than the purpose described foregoing is forbidden. (2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior written permission of the author.
TOOLS & EQUIPMENTS 1 LIST OF ITEMS TO BRING i. Screwdriver (e.g., #2 Phillips Screwdriver) ii. Multimeter iii. ESD Wrist Straps iv. Metal Washer (Flat) or Coin (for remove Rear Cover) v. Ruler (for remove Rear Cover) vi. Service Manual (Unique) (for remove & replace details) Thickness: approx.
Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operations are identified in this manual.
Page 5
SAFETY NOTES Refer to the panel handling chapter of each Service manual, or the "Transporting" information of 1-2. Caution for OLED Panel. the Reference Guide of each model on how to hold it. 1) Handling. When repairing the TV set, be sure you are grounded by using a wrist band. 2) OLED Screen.
Page 6
SAFETY NOTES Pixel shift. To reduce the risk of image retention: Automatically moves the image on the screen to prevent image retention. • Fill the screen by changing [Wide mode] to eliminate the black bars. Select [Wide mode] other than [Normal]. •...
Page 7
SAFETY NOTES 1-3. Safety Check-Out Stabilized power supply instrument and isolated voltage transformer: Use too much current capacity and isolated voltage transformer does not need to use After correcting the original service problem, perform the following safety checks stabilized power supply equipment. before releasing the set to the customer:- Specification of RMS volt meter: Input resistance >...
Page 8
SAFETY NOTES 1-5. How to Find a Good Earth Ground. 1-6. Lead Free Information 1) A cold-water pipe is a guaranteed earth ground; the cover-plate retaining screw on The circuit boards used in these models have been processed using Lead Free Solder. The most AC outlet boxes is also at earth ground.
Page 9
DIASSEMBLY AND REMOVAL CAUTIONS 42” REAR COVER 1. Remove AC Cover and Under Cover COVER, AC(SM LIO) COVER, UNDER (SM LIO) 2. Remove screws from Rear Cover SCREW M3X3.0 STEP 6 pcs SCREW, ORNAMENTAL M6x12 4 pcs Total screws : 10 pcs...
Page 10
DIASSEMBLY AND REMOVAL CAUTIONS 42” REAR COVER 3. Remove AC Cover (AC COVER (AT)) and Power Supply Cord Then disconnect from Power Board . 4. Hold near Smart Core and pull up Rear Cover. Then release all hooks at under recess area. Total hooks : 4 pcs...
Page 11
DIASSEMBLY AND REMOVAL CAUTIONS 42” REAR COVER 5. Remove hooks at the left side 1. Use gloves is a must to remove the hooks 2. Support at right figure area and hold the hole at the AC Cover Support 3. After that pull the Rear Cover downwards 4.
Page 12
DIASSEMBLY AND REMOVAL CAUTIONS 42” REAR COVER 7. Remove hooks at the top / right side and terminal area 1. Push Rear Cover to the right side 2. Then , release 7 pcs of hooks at top / right side and terminal area as well 3.
EXPLODED VIEW & PART LIST 42” • Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts. (*) Parts are not stocked since they are seldom required for routine service. Some delays should be anticipated when ordering these components.
Page 15
EXPLODED VIEW & PART LIST 42” SET PART LIST REMARKS DESCRIPTION REF. NO PART NO. A-5044-984-A COMPL SVC BM5S22B_FL_EUUK Printed Circuit Board, incl. capacitors 1-014-412-11 G210 - STATIC CONVERTER(TV) Internal Power Supply 1-014-435-11 OLED PANEL (L42EQD1) OLED OTHER PART 1-912-741-11 POWER-SUPPLY CORD (WITH CONN.) Cable 1-912-983-12...
Page 17
DIASSEMBLY AND REMOVAL CAUTIONS 48” REAR COVER 1. Remove screws from the rear cover Ornament Screw M6 4 pcs Step screw M3 6 pcs Total screws is 10 pcs 2. Remove AC Connector 1. Use finger to slot into AC cover screw hole 2.
Page 18
DIASSEMBLY AND REMOVAL CAUTIONS 48” REAR COVER 3. Unhook left side hook 1. Use 1 hand to pull the rear cover, until creating gap between rear cover & back chassis, then slide in the ruler 2. Slide up ruler until hook location, then rotate the ruler to front of TV until hear pop-out sound, that indicate the hook is disassemble...
Page 19
DIASSEMBLY AND REMOVAL CAUTIONS 48” REAR COVER 4. Unhook right side hook 1. Use 1 hand to pull the rear cover a little bit, to create gap between rear cover & back chassis then carefully slide in the ruler 2. Slide up ruler until hook location, then rotate the ruler to front of TV until hear pop-out sound that indicate the hook is disassemble...
Page 20
DIASSEMBLY AND REMOVAL CAUTIONS 48” REAR COVER 5. Unhook top hook 1. Hold bottom side of rear cover using both hand then push up the rear cover gently toward upside 2. Repeat step 1 gently, until top side of rear cover is detached Notes : Refer to page 13 for specific hook location...
Page 22
EXPLODED VIEW & PART LIST 48” • Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts. (*) Parts are not stocked since they are seldom required for routine service. Some delays should be anticipated when ordering these components.
Page 23
EXPLODED VIEW & PART LIST 48” SET PART LIST REMARKS REF. NO PART NO. DESCRIPTION A-5044-984-A COMPL SVC BM5S22B_FL_EUUK Printed Circuit Board, incl. capacitors 1-010-088-21 G93G- STATIC CONVERTER(TV) Internal Power Supply 1-014-957-11 OLED PANEL(L48EAQP1B) OLED OTHER PART 1-912-984-11 POWER-SUPPLY CORD (CONN.) CEI / RU3 Cable 1-912-983-12...
