SERVICE MANUAL
COMPACT COMPONENT SYSTEM
SOUND
VOCAL
MODE
MASKING
ECHO
SLEEP
FM MODE
STILL
V.INTRO
HIGHLIGHT
SUBTITLE
TAPE
A/B
REC
START/STOP
ON SCREEN
PREV
NEXT
KEY CONTROL
SELECT
FADE
MUTING
RM–SMXJ770V REMOTE CONTROL
Each difference point
Model
CD/DECK/RECEIVER
MX-J770V
CA-MXJ770V
MX-J880V
CA-MXJ880V
Contents
Safety precautions
Important for laser products
Preventing static electricity
Precautions at disassembly
and parts replacement
Disassembly method
Adjustment method
MX-J770V
MX-J880V
This illustration is MX-J770V
SPEAKER
Tray fitting
SP-MXJ770V
Silver
SP-MXJ880V
1-2
1-3
1-4
1-5
1-6
1-31
COPYRIGHT
2000 VICTOR COMPANY OF JAPAN, LTD.
US
UX
Color
Panel
Light blue
Silver & blue
Champagne-gold
Diagnosis which uses
extension wire method
Flow of functional operation
until TOC read
Maintenance of laser pickup
Replacement of laser pickup
Description of major ICs
MX-J770V
MX-J880V
Area Suffix
Singapore
Saudi Arabia
COMPACT
SUPER VIDEO
COMPACT
DIGITAL VIDEO
COMPACT
DIGITAL AUDIO
Net
Front
Silver
Champagne-gold
Gray
1-35
1-36
1-37
1-37
1-38
No.20861
Jul. 2000
