  • Page 1 Installation Guide...

  • Page 2: Using The Product Safely

    Using the Product Safely Safety Instructions For your safety, read all the instructions in this guide before using this product. Incorrect handling that ignores instructions in this guide could damage this product or could result in personal injury or property damage. Keep this installation guide at hand for future reference.
  • Page 3 Use M10 nuts and bolts. Nuts and bolts smaller than M10 could cause the setting plate to fall. Epson accepts no responsibility for any damage or injury caused by lack of wall strength or inadequate installation.
  • Page 4 If any abnormalities occur with this product, immediately disconnect the cables from the product, and then contact your local dealer or the nearest Epson service call center. Continuing to use the product in an abnormal condition could cause a fire, electric shock, or visual impairment.

  • Page 5: Notes On Handling The Touch Unit

    The Touch Unit contains a high power laser product that could cause a fire, electric shock, or an accident. Only connect the Touch Unit to the EB-1470Ui. Do not connect it to any other projectors or devices. The device could malfunction, or laser light that is higher than normal intensity could be emitted.
  • Page 6 Using the Product Safely It also describes how to install the Touch Unit, Control Pad, and Pen Stand after mounting the projector on a wall.

  • Page 7: Choosing An Installation Location

    Using the Product Safely Choosing an Installation Location Projector installation location • Carry out power supply wiring work for the installation location of the setting plate in advance. • Install the projector away from other electric devices such as fluorescent lights or air conditioners. Some kinds of fluorescent lights could interfere with the remote control of the projector.

  • Page 8: Touch Unit Installation Location

    Using the Product Safely Touch Unit installation location • When using the Touch Unit, install the projector using one of the following methods. The Touch Unit cannot be used if another installation method is used. • Mount the projector on a wall or suspend it from a ceiling and project images from in front of the screen. •...
  • Page 9 Using the Product Safely • If the distance from the wall to the surface of the screen (f) is more than 50 mm, you cannot install the Touch Unit outside the whiteboard. • If there is a frame around the screen, make sure that the thickness of the top of the frame (e) is less than 3 mm. If the thickness of the top of the screen exceeds 3 mm, the Touch Unit will not operate correctly.

  • Page 10: Table Of Contents

    Contents Laser diffusion port ....23 Using the Product Safely Projection Distance Table ... . 24 Safety Instructions .
  • Page 11 Contents Angle Adjustment ....92 Appendix Installing Multiple Projectors in Parallel (Multi-Projection) ... . 96 Multi-Projection settings .

  • Page 12: Installation Guide

    Installation Guide Installation Work Flow Installing one projector Follow the procedures below to mount the projector on a wall. Installing the Setting Plate and the Projector ( p.33) Adjusting the Position of the Projector ( p.46) Calibrating the Interactive Pen ( p.55) Installing the Control Pad and the Pen Stand ( p.62)

  • Page 13: When Two Or More Projectors Are Installed In Parallel

    Installation Guide When installing the Touch Unit on the whiteboard (without using the Touch Unit Bracket) Installing the Touch Unit ( p.88) Adjusting the Angle of Laser Diffusion ( p.92) Performing Touch Calibration ( p.85) When two or more projectors are installed in parallel When using the multi-projection function (when multiple projectors are installed in parallel to project one, large screen), follow the steps below.

  • Page 14: Package Contents

    Installation Guide Package Contents Setting plate The following supplied items are necessary to mount the projector on a wall. Confirm that you have all items before beginning. Depending on the area in which you purchased the product, the Setting Plate is not supplied.

  • Page 15: Control Pad

    Installation Guide Control Pad The following supplied products are necessary when attaching the Control Pad. Confirm that you have all items before beginning. Control Pad Pen Stand Stereo mini cable Port protection stickers (for connecting the Control Pad (approx. 5m)) When installing the Control Pad on a wall and so on, prepare commercially available M4 screws (20 mm x4).

  • Page 16: Touch Unit

    Installation Guide Touch Unit The following supplied products are necessary when attaching the Touch Unit. Confirm that you have all items before beginning. When installing the Touch Unit outside the whiteboard, use the supplied Touch Unit Bracket. Touch Unit Touch Unit connection cable (approx. 2.8 m) Markers x2 Infrared deflectors (approx.

  • Page 17: Specifications

    Installation Guide Specifications Setting plate Item Specification Remark Reference Page Setting plate weight Approx. 7.9 kg Setting plate, 3-axis adjustment unit, slide plate, wall plate, wall plate covers/end caps Maximum load capacity 13.0 kg Forward/backward slide ad- 0 to 320 mm Adjustment for 3-axis adjustment unit in- See the fig- justment range...

  • Page 18: Wall Plate

    Installation Guide Wall plate The following figure shows two frames connected to one plate (separate when shipped). [Unit: mm] The offset value for the position of the center of the projected image and the center of the wall plate is 27 mm. Cable routing holes When routing cables to connect to the projector through a wall, use positions ( ) and (...

  • Page 19: Horizontal Slide Adjustment Range

    Installation Guide Horizontal slide adjustment range [Unit: mm] Forward/backward slide adjustment range Arm slide adjustment range [Unit: mm] Adjustment range for 3-axis adjustment unit installation position [Unit: mm] Position for installing accessories These screw holes allow you to secure peripheral devices and accessories such as external tuners. Use commercially available M4 screws.

  • Page 20: Control Pad/Pen Stand

    Installation Guide 2 x M4 30.5 49.7 60.8 Control Pad/Pen Stand Control Pad (external dimensions/weight) [Unit: mm] 50.1 63.3 4 x M4 15.5 • Weight: approx. 262 g • Operating temperature: 0 to +50°C (no condensation) • Operating temperature: -20 to +60°C (no condensation)

  • Page 21: Cable Routing Holes

    Installation Guide Cable routing holes When routing cables through a wall, use the position ( ) shown in the followingfigure as the cable routing hole. Otherwise, remove the cable cover ( ) and route the cables from there. Route the printer cable along the groove at the back of the Control Pad.

  • Page 22: Touch Unit

    Installation Guide Touch Unit Touch Unit (external dimensions/weight) [Unit: mm] The Touch Unit weighs approximately 450 g. Touch Unit Bracket (external dimensions/adjustment range/weight) [Unit: mm] 229.8 Front [Unit: mm]...

  • Page 23: Attached Labels

    Installation Guide Installation plate (front) [Unit: mm] Ø4.2 2-5.7 When the Touch Unit is installed (side) [Unit: mm] 100.8 Touch Unit Bracket weights approximately 750 g. Attached labels The Touch Unit is a Class 1 laser product that conforms to the IEC/EN60825-1:2014 standard. There are warning labels affixed to the Touch Unit to indicate that it is a Class 1 laser product.

  • Page 24: Laser Diffusion Port

    Installation Guide • Caution: If this section is opened, class 3B invisible laser radiation will be emitted. • Avoid exposure to the radiation beams. Laser diffusion port The laser beam is diffused from the laser diffusion ports at the back of the Touch Unit. •...

  • Page 25: Projection Distance Table

    Installation Guide Projection Distance Table Figures of Installation Dimensions To find the appropriate projection distance, see the following figures when installing. The values are only rough estimates. The recommended range for the projection distance (a) is 62 to 432 mm. The offset value for the position of the center of the projected image and the center of the wall plate is 27 mm.

  • Page 26: When Installing The Touch Unit

    Installation Guide Aspect ratio for standard projected image When installing the Touch Unit By using the supplied Touch Unit Bracket, you can install the Touch Unit outside the whiteboard. When installing the Touch Unit outside the whiteboard, measure the length from the surface where the Touch Unit is installed to the whiteboard surface ((f) in the following figure).
  • Page 27 Installation Guide When the Touch Unit is installed outside the whiteboard (using the Touch Unit Bracket) [Unit: mm] If there are any obstacles such as a frame or tray at the bottom of the screen, touch operations will not operate correctly. Stick the supplied infrared deflectors along the locations of the obstacles p.52).
  • Page 28 Installation Guide When installing the Touch Unit on the whiteboard (without using the Touch Unit Bracket) You need to leave at least 120 mm distance between the top edge of the projected image and the top edge of the actual screen. [Unit: mm] •...

  • Page 29: When Installing The Control Pad And The Pen Stand

    Installation Guide When installing the Control Pad and the Pen Stand When installing the Control Pad, leave enough space around it to install/remove the cover or to connect/ disconnect cables easily as shown in the following figure. [Unit: mm] When installing the Pen Stand next to the Control Pad, do not install it so that it covers the groove in the front cover as shown in the following figure.

  • Page 30: When Projected Image Is Smaller Than 85 Inches

    Installation Guide When Projected Image is Smaller than 85 Inches Mount the 3-axis adjustment unit at the position marked with a stamp ( The projection distance table provides the figures when mounting the 3-axis adjustment unit at the position marked with a stamp ( The distance from the top of the projected image to the bottom wall plate installation screw hole (c) is the number given when the vertical slide is set to the standard position (...

  • Page 31: 16:10 Projected Image

    Installation Guide 16:10 projected image [Unit: cm] Projected image size Projection Dis- Numbers on Distance to Distance from Height of pro- tance the arm slide the bottom the top of the jected image Minimum scale wall plate in- projected im- (Wide) to Maxi- stallation age to the wall...

  • Page 32: When Projected Image Is 85 Inches Or More

    Installation Guide When Projected Image is 85 inches or more Mount the 3-axis adjustment unit at the position marked with a stamp ( The projection distance table provides the figures when mounting the 3-axis adjustment unit at the position marked with a stamp ( The distance from the top of the projected image to the bottom wall plate installation screw hole (c) is the number given when the vertical slide is set to the standard position (...

  • Page 33: 16:10 Projected Image

    Installation Guide 16:10 projected image [Unit: cm] Projected image size Projection Numbers on Distance to the Distance from Height of pro- Distance the arm slide bottom wall the top of the jected image Minimum scale plate installa- projected im- (Wide) to tion screw hole age to the wall Maximum...

  • Page 34: Installing The Setting Plate

    Installation Guide Installing the Setting Plate Connecting Devices Necessary cables Be sure to prepare the power cord supplied. Additionally, prepare the necessary cables according to the devices being used. • USB connection cable supplied • Touch Unit connection cable supplied •...
  • Page 35 Installation Guide Necessary cables when installing two projectors in parallel and using the Easy Interactive Function When using the interactive function with two projectors installed in parallel, you need the optional remote control cable set (ELPKC28). When connecting one computer to two projectors and using the interactive function, connect a USB cable from the computer to each projector.
  • Page 36 H876x (where x is any letter from A to Z) If you want to connect a different projector or if you have any queries, check the Epson Projector Contact List provided on the Document CD-ROM and contact your local dealer.

  • Page 37: Installation Procedure

    Installation Guide Installation Procedure Make sure to follow the steps below to install the setting plate. If these steps are not followed, the product could fall and cause personal injury or property damage. Warning Do not use adhesives, lubricants, or oils to install or adjust the setting plate. If you use adhesives to prevent the screws from loosening or things such as lubricants or oils on the slide plate fixing part of the projector, the case may crack and cause the projector to fall, resulting in personal injury or property damage.
  • Page 38 Installation Guide Check that the 3-axis adjustment unit is aligned with the slide plate's standard position If the standard position ( ) is not correct, loosen the M4 bolt and adjust the position of the slide plate. When you have finished making adjustments, tighten the bolt. Secure the 3-axis adjustment unit and the slide plate to the base of the projector with the M4 x 12 mm bolts (x4) supplied Bolt installation positions...

  • Page 39: Install The Wall Plate On The Wall

    Installation Guide Install the wall plate on the wall Determine the projection position based on the projected image size See the projection distance table to check the following values. • Projected image size (S) • Distance from the top of the projected image to the bottom wall plate installation screw hole (c) •...
  • Page 40 Installation Guide Attach the template sheet to the wall • Match the center line ( ) checked in step 1 to the Image Center B line on the template sheet. Confirm where the beams are within the wall, and shift the position left or right as necessary. (The position can be shifted horizontally left or right from the center line of the projection surface up to a maximum of 45 mm.) •...

  • Page 41: Determine The Projection Distance, And Then Pass The Cables Through The Setting Plate

    Installation Guide Drill the holes in the wall Drill diameter: 10.5 mm Pilot hole depth: 45 mm Anchor hole depth: 40 mm Remove the template sheet, and clean the concrete dust from the holes with a dust pump Position the wall plate on the wall and insert M10 x 60 mm commercially available anchors into the holes Attach the nut and tap it with a hammer until the core touches the top of the an-...
  • Page 42 Installation Guide Loosen the M4 x 12 mm bolts (x2) and extend the arm slide on the setting plate Align the slider with the combined distances of (b) and (x) that you checked in step 1. Route the necessary cables through the setting plate See the following figure to route the cables so that the ends of the cables that connect to the projector are on the projector's interface side.

  • Page 43: Attaching The Setting Plate To The Wall Plate

    Installation Guide Attaching the setting plate to the wall plate Insert the hexagonal axis into the setting plate Mount the setting plate to the wall plate Insert the top of the hexagonal axis into the wall plate, and then insert it into the slot at the bottom. Caution •...
  • Page 44 Installation Guide Secure the setting plate and the wall plate Secure the supplied M6 screws (x3) with a commercially available No.3 cross-head screwdriver, and then lightly tighten the supplied M6 bolt (x1) with the spanner. Adjust the vertical slide with the open-ended spanner, and align it with the standard position ( •...

  • Page 45: Securing The Projector To The Setting Plate

    Installation Guide Tighten the M6 bolt (x1) to fix the setting plate in position Securing the projector to the setting plate Loosen the screws (x2) and remove the cable cover from the projector...
  • Page 46 Installation Guide Attach the 3-axis adjustment unit to the setting plate with the M4 x 12 mm bolts (x4) supplied • When a projected image is smaller than 85 inches: Mount the unit at the stamp ( • When a projected image is 85 inches or more: Mount the unit at the stamp ( : Smaller than 85 inches : 85 inches or more...

  • Page 47: Adjusting The Position Of The Projector

    Installation Guide Connect the cables to the projector "Connecting Devices" p.33 Connect the power cord last. Use commercially available M4 screws to secure peripheral devices and accessories such as external tuners to the screw holes in the following figure. Install the wireless LAN module supplied in the wireless LAN unit module slot. Adjusting the Position of the Projector •...
  • Page 48 Installation Guide When installing the Touch Unit, if there are any obstacles at the bottom of the whiteboard such as a frame or trays, stick the infrared deflectors along the bottom edge of the whiteboard before adjusting the position of the projector. "Sticking the infrared deflectors"...
  • Page 49 Installation Guide Change the aspect ratio of the projected image (only when necessary) Project images from a connected device, and then press the [Aspect] button on the remote control. Each time you press the button, the aspect name is displayed on the screen and the aspect ratio changes.
  • Page 50 Installation Guide After loosening the adjustment dial at the bottom, adjust the horizontal roll using the adjustment dial at the top. Repeat steps 6 to 11 as necessary. After you finish making adjustments, tighten the adjustment dial at the bottom. Loosen the M4 screw (x1) with the hexagon wrench, and then adjust the horizontal rotation with the adjustment dial After you finish making adjustments, tighten the M4 screws that you loosened.
  • Page 51 Installation Guide After loosening the adjustment dial at the bottom, adjust the vertical tilt using the adjustment dial at the top. After you finish making adjustments, tighten the adjustment dial at the bottom. Loosen the M4 bolt with the hexagon wrench, and then adjust the horizontal slide After you finish making adjustments, tighten the M4 bolt that you loosened.
  • Page 52 Installation Guide Loosen the M4 bolts (x2) with the hexagon wrench, and then adjust the forward/backward slide After you finish making adjustments, tighten the M4 bolts that you loosened. Loosen the M6 bolt (x1) with the open-ended spanner, and then adjust the vertical slide Adjust the vertical slide with the hexagonal axis at the top or the bottom.

  • Page 53: Sticking The Infrared Deflectors

    Installation Guide Make sure that all of the bolts that you loosened in steps 6 to 11 are securely tightened Warning Tighten all bolts and screws firmly. Otherwise, the product may fall and cause personal injury or property damage. Adjust the focus to match the focus in the following figure ( Open the air filter cover, and then adjust the focus.
  • Page 54 Installation Guide • Do not remove an infrared deflector once it has been stuck in place. This can weaken the adhesive strength of the tape. • Do not stick tape or place anything on the infrared deflectors. The infrared deflector will not function correctly.

  • Page 55: Arc Correction

    Installation Guide Arc Correction When fine-tuning the shape of the projected image, perform Arc Correction. Turn on the projector, and then press the [Menu] button Using the Remote Control Using the Control Panel Select Geometry Correction from Settings Select Arc Correction Select Arc Correction...

  • Page 56: Calibrating The Pen

    Installation Guide Select the side you want to correct Correct the selected side If the message "Cannot adjust any further."is displayed while adjusting, you cannot adjust the shape any further in the direction indicated by the gray triangle. Repeat steps 5 and 6 as needed to adjust any remaining sides Calibrating the pen Check that adjusting the position of the projector is complete before you start calibrating the interactive pen.
  • Page 57 Installation Guide Turn on the projector, and then press the [Menu] button Using the Remote Control Using the Control Panel Select Easy Interactive Function from Extended Select Manual Calibration Check that the screen is in focus, and then select Yes A green dot is displayed at the top left of the projection screen.
  • Page 58 Installation Guide Touch the center of the dot with the pen tip of the interactive pen The dot disappears and moves to the next position. Make sure you touch the center of the dot. Otherwise, it may not be positioned correctly.
  • Page 59 Installation Guide Repeat step 5 until all of the dots disappear The dot appears at the top left first and then moves towards the bottom right. When all of the dots disappear, calibration is complete. • Check that there are no obstacles between the interactive pen and the Interactive pen receiver ( •...

  • Page 60: Attaching The Covers

    Installation Guide Attaching the Covers Attach the wall plate covers Install the right cover first. • Depending on the cable configurations, you may need to cut notches ( ) in the wall plate covers to route the cables. Perform deburring on the cut sides to smooth off any sharp edges. Make sure you do not damage the cables when routing them through the cut holes.
  • Page 61 Installation Guide Fit the end cap to the setting plate If you are concerned about the groove in the arm, stick the supplied masking sticker. Attach the cable cover to the projector, and then secure it with the screws (x2)
  • Page 62 Installation Guide Caution Only a specialist should remove or reinstall the projector, including for maintenance and repairs. See the projector's User's Guide for instructions on maintenance and repairs. Warning • Never loosen the bolts and nuts after installation. Confirm that the screws have not become loose on a regular basis.

  • Page 63: Stand

    Installation Guide Installing the Control Pad and the Pen Stand Installing the Control Pad See the following for the installation location of the Control Pad. "When installing the Control Pad and the Pen Stand" p.28 Remove the front cover Check the installation position and secure with commercially available M4 screws (20 mm Warning •...

  • Page 64: Installing The Pen Stand

    Installation Guide Connect the cable that is connected to the projector to the Control Pad For details on connecting cables, see the following. "Necessary cables when installing the Control Pad" p.35 Paste the port protection stickers supplied to the plugs on the Control Pad that are not being used "Control Pad"...
  • Page 65 Installation Guide Check the installation position and secure with commercially available M4 screws (20 mm Warning • Be careful not to tilt the screw to the installation surface when securing. • Make sure that the Pen Stand is secured properly. •...

  • Page 66: Installing The Touch Unit

    Check that the screen is parallel to the surface on which the Touch Unit is installed. Caution Only connect the projector to the EB-1470Ui. Do not connect it to any other Touch Units or devices. Turn on the projector, and then press the [Menu] button...
  • Page 67 Installation Guide Select Touch Unit Setup Select Installation Pattern The installation pattern is displayed on the projected image. Loosen the screw at the bottom of the dial cover using a commercially available No.2 cross- head screwdriver...
  • Page 68 Installation Guide Slide the dial cover down to remove it Determine the installation position for the Touch Unit Bracket We recommend marking the following installation positions (positions of the screw holes) to make installation easier. ): Center line of installation pattern. Align with the center line ( ) of the installation plate.
  • Page 69 Installation Guide Install the installation plate using three M4 commercially available 4 mm wood screws, or three M4 anchor bolts. Attach the securing plate to the rear of the Touch Unit with the two M4 x 25 mm bolts supplied Adjust the position so that the two screw holes of the Touch Unit and the two screw holes of the securing plate are aligned.
  • Page 70 Installation Guide Use the supplied M4 x 10 mm bolts (x2) to install the securing plate on the installation plate Tighten the bolts to the securing plate using the supplied hexagon wrench. Measure the distance from the wall to the surface of the screen (f)
  • Page 71 Installation Guide Adjust the height of the left and right according to the value (f) measured in step 11 Loosen the two screws and move the Touch Unit back and forth to adjust the left and right so that the arrow aligns with the value on the scale the same as (f).

  • Page 72: Angle Adjustment

    Installation Guide Angle Adjustment An infrared laser in the shape of a curtain is emitted from the Touch Unit. The infrared laser reflects off your finger when touched to the whiteboard thereby detecting the finger position allowing the projector's infrared camera to recognize the position being reflected.
  • Page 73 Installation Guide When the laser is not parallel to the screen • • The position of your finger may not be detected The position of your finger detected by the pro- even if you touch the projected image. jector and your actual finger position may not •...
  • Page 74 Installation Guide Select Easy Interactive Function from the projector's Extended menu Select Touch Unit Setup Set Power to On The Touch Unit power turns on and the indicator is lit blue. When Power is set to On, the next time the projector is turned on, the Touch Unit automatically turns on.
  • Page 75 Installation Guide Select Angle Adjustment Select Installing the Touch Unit with the bracket The following screen is displayed.
  • Page 76 Installation Guide Turn the adjustment screw for the Touch Unit fully clockwise using the hexagon wrench supplied with the setting plate Turn the adjustment dials on the Touch Unit counterclockwise until you hear a clicking sound When you hear a clicking sound coming from the adjustment dial, stop turning, and then press the ] button on the remote control.
  • Page 77 Installation Guide Attach the supplied two markers to the marker positions ( ) on the projection screen Match the positions so that the crosses ( ) for the markers overlap with the points ( ) for the • Magnetic screens: Place the bottom of the markers onto the screen. •...
  • Page 78 Installation Guide Turn the adjustment screw on the Touch Unit counterclockwise to display the pointers Adjusting the angle of the Touch Unit using the adjustment screw Before adjustment After adjustment When the pointers overlap in the correct position, the colors become solid (...
  • Page 79 Installation Guide Turn the adjustment screw clockwise to move the pointer down as needed. • When turning the adjustment screw, make sure shadows from your arm or body do not overlap with the markers. • If the pointers are not solid colors ( ), check if the Touch Unit and screen are parallel.
  • Page 80 Installation Guide Turn the adjustment dials on the Touch Unit to move the pointers ( ) so that they overlap with the target ( ) of the same color on either side When you turn the adjustment dial clockwise, the pointer moves diagonally up towards the center of the projected image.
  • Page 81 Installation Guide When the pointers on the left and right become solid colors ( ), press the [ button on the remote control The following screen is displayed. Place the markers at the top marker positions [1] ( When angle adjustment is performed correctly, the upper pointers become solid colors ( If the upper pointers do not become solid colors ( ), start again from step 1.
  • Page 82 Installation Guide Place the markers at the bottom marker positions [2] ( When angle adjustment is performed correctly, the bottom pointers become solid colors ( If the bottom pointers do not become solid colors ( ), start again from step 4. When you have finished checking, remove the markers, and then press the [ ] button on the remote control...
  • Page 83 Installation Guide Trace the dots ( ) with your finger When angle adjustment is performed correctly, the dots you have traced disappear. Touch operations may not perform correctly if you are wearing artificial nails or nail polish, or if your fingers are obstructed by bandages and so on. When all of the dots have disappeared, select Complete and press the [ ] button on the remote control.
  • Page 84 Installation Guide Attach the dial cover, and then tighten the screw at the bottom of the dial cover When you have finished making adjustments, perform a touch calibration. "Touch Calibration" p.85 Make sure you store the markers in a safe place. Additional adjustments Perform additional adjustments if the dots on the left and right remain after adjusting the angle.
  • Page 85 Installation Guide Select Additional Adjustment The following screen is displayed. After this, adjust using the same procedure for angle adjustment from step 11. Follow the on-screen instructions to make adjustments. "Angle Adjustment" p.71 When you have finished making adjustments, perform a touch calibration. "Touch Calibration"...

  • Page 86: Touch Calibration

    Installation Guide Touch Calibration Perform touch calibration so that the projector can recognize touch operations precisely. When two projectors are installed in parallel and you are using the interactive function, check the following before performing touch calibration. • The multi-projection interactive features are set "When two projectors are installed in parallel and you are using the interactive function"...
  • Page 87 Installation Guide Select Touch Calibration The focus adjustment message is displayed. Check that the screen is in focus, and then select Yes A dot is displayed at the top left of the projection screen.
  • Page 88 Installation Guide Touch the center of the dot with your finger When the dot disappears and moves to the next position, remove your finger. • Make sure you touch the center of the dot. Otherwise, it may not be positioned correctly. •...

  • Page 89: When Installing The Touch Unit On The Whiteboard (Without Using The Touch Unit Bracket)

    Install the Touch Unit, and then connect to the projector. Caution Only connect the Touch Unit to the EB-1470Ui. Do not connect it to any other projectors or devices. Turn on the projector, and then press the [Menu] button Using the Remote Control...
  • Page 90 Installation Guide Select Touch Unit Setup Select Installation Pattern The installation pattern is displayed on the projected image. Loosen the screw at the bottom of the dial cover using a commercially available No.2 cross- head screwdriver...
  • Page 91 Installation Guide Slide the dial cover down to remove it Determine the installation position for the Touch Unit We recommend marking the following installation positions to make installation easier. ): Center line of installation pattern. Align with the center line of the Touch Unit ( ): 25 to 100 mm from the top edge of the projected image.
  • Page 92 Installation Guide Secure the Touch Unit • Magnetic screens: Place the back of the Touch Unit on the screen surface, and then secure. Caution When installing the Touch Unit on a magnetic surface, be careful not to trap your fingers or any other part of your body between the magnets and the installation surface.

  • Page 93: Angle Adjustment

    Installation Guide [Unit: mm] Screw hole cross-section Connect the Touch Unit connection cable that is connected to the projector to the TCH port on the Touch Unit Angle Adjustment This section explains how to adjust the angle of the Touch Unit. For details on angle adjustment, see p.71. •...
  • Page 94 Installation Guide Select Easy Interactive Function from the projector's Extended menu Select Touch Unit Setup Set Power to On The Touch Unit power turns on and the indicator is lit blue. When Power is set to On, the next time the projector is turned on, the Touch Unit automatically turns on.
  • Page 95 Installation Guide Select Angle Adjustment...
  • Page 96 Installation Guide Select Installing the Touch Unit without the bracket The following screen is displayed. The next procedures are the same as for adjusting the angle (after step 11) when installing outside the whiteboard using the bracket. "Angle Adjustment" p.71 •...

  • Page 97: Appendix

    Appendix Installing Multiple Projectors in Parallel (Multi- Projection) By installing multiple projectors in parallel, you can project one, large image (Multi-Projection). Check the following when installing multiple projectors in parallel. ( "Installation Work Flow" p.11) When projecting the screen from one computer, you need to make the following preparations. See the documentation provided with your computer to check how to make settings.
  • Page 98 Appendix Select Projector ID Select the ID number for the target projector Press the [Menu] button to close the menu Repeat steps 1 to 5 for the remaining projectors.
  • Page 99 Appendix Point the remote control at the projector you want to operate, and then press the [ID] button The ID set for the projector is displayed on the projected screen. The display turns off after approximately three seconds. While holding down the [ID] button, press the button with the same number as the projector ID for the projector you want to operate Remote control operations for the projector with the selected ID are enabled.

  • Page 100: Adjusting The Image In Multi-Projection

    Appendix Press the [ID] button and check the ID setting The following is displayed. • Remote Control: On is displayed: You can operate the projector currently being operated. • Remote Control: Off is displayed: You cannot operate the projector with the remote control. Repeat the procedure above to enable remote control operations.

  • Page 101: When Two Projectors Are Installed In Parallel And You Are Using The Interactive Function

    Appendix Set Multi-Projection to On Press the [Esc] button to return to the previous screen. Make each setting Set the same item for each projector. Color Mode Color Uniformity Adjust the color balance for the entire screen (only when necessary). Brightness Settings If the brightness of the light source for each projector is different, adjust the brightness of the light source.
  • Page 102 Appendix Connect the SYNC ports for each projector by using the optional remote control cable set (ELPKC28) When the projectors are connected by cable, operations for the interactive pen stabilize. The SYNC port has an IN and OUT socket. When you connect one end of the remote control cable set to an IN socket, connect the other end to an OUT socket.

  • Page 103: Setting Multi-Projection Interactive

    Appendix Select Advanced Set Sync of Projectors to Wired Setting Multi-Projection Interactive Before setting Multi-Projection Interactive, check that you have finished adjusting the image for multi- projection. If you perform image adjustment after setting interactive, the pen position may not be correct. "Adjusting the Image in Multi-Projection"...
  • Page 104 Appendix Press the [Menu] button Using the Remote Control Using the Control Panel Select Easy Interactive Function from Extended Select Advanced from General Select Multi-Projection...
  • Page 105 Appendix Select Left Calibrate the pen ( p.55) Turn off the projector on the left Turn on the projector on the right, and perform steps 2 to 5 Select Right from Multi-Projection Calibrate the pen ( p.55)
  • Page 106 Appendix When using the Touch Unit Turn on the projector on the left and turn off the projector on the right Press the [Menu] button Using the Remote Control Using the Control Panel Select Easy Interactive Function from Extended...
  • Page 107 Appendix Select Advanced from General Select Multi-Projection Select Left Calibrate the pen ( p.55)
  • Page 108 Appendix Installing and adjusting the angle for the Touch Unit The procedure differs depending on where the Touch Unit is installed. When installing the Touch Unit outside the whiteboard (using the Touch Unit Bracket) Installing the Touch Unit ( p.65) Adjusting the Angle of Laser Diffusion ( p.71) When installing the Touch Unit on the whiteboard (without using the Touch Unit Bracket)
  • Page 109 Appendix Performing touch calibration for each projector ( p.85)

  • Page 110: Batch Setup Function

    Appendix Batch Setup Function After making the projector's menu settings for one projector, you can copy the settings to other projectors (batch setup function). The batch setup function is only for projectors with the same model number. Use one of the following methods. •...

  • Page 111: Setup Using A Usb Flash Drive

    Appendix Setup Using a USB flash drive This section explains how to perform batch setup using a USB flash drive. • Use a FAT format USB flash drive. • The batch setup function cannot be used by USB flash drives that incorporate security functions. Use a USB flash drive that does not incorporate security functions.
  • Page 112 Appendix While holding down the [Esc] button on the remote control or the control panel, connect the power cord to the projector The On/Standby indicator and the Status indicator turn blue, and the Laser indicator and the Temp indicator turn orange. When all of the projector's indicators turn on, release the [Esc] button.

  • Page 113: Copying Saved Settings To Other Projectors

    Appendix Copying saved settings to other projectors Disconnect the power cord from the projector, and check that all of the projector's indicators have turned off Connect the USB flash drive containing the saved batch setup file to the projector's USB-A port Do not store any data except for the batch setup file on the USB flash drive.
  • Page 114 Writing the settings may have failed and an error may have occurred tus indicator flashing blue quickly, and the in the projector's firmware. Stop using the projector, remove the Laser indicator and the Temp indicator power plug from the electrical outlet, and contact Epson for help. flashing orange quickly?

  • Page 115: Attaching A Security Cable

    The security slot on this product is compatible with the Microsaver Security System manufactured by Kensington. See the following for more details on the Microsaver Security System. http://www.kensington.com/ Projector Touch Unit (cannot be used when attached to bracket) ©SEIKO EPSON CORPORATION 2017. All rights reserved.
