- Page 1 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 1 ENGLISH DEUTSCH DVR 9511 C SLOVENIA MAGYAR P/NO : MFL46897330...
- Page 2 Should the unit require maintenance, contact European representative: an authorized service center. LG Electronics Service Europe B.V. Use of controls, adjustments or the performance of procedures other than those Veluwezoom 15, 1327 AE Almere, The specified herein may result in hazardous radiation exposure.
- Page 3 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 3 Copyrights Recording equipment should be used only for lawful copying and you are advised to check carefully what is lawful copying in the area in which you are making a copy. Copying of copyright material such as films or music is unlaw- ful unless permitted by a legal exception or consented to by the rights owner.
-
Page 4: Table Of Contents
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 4 Contents Before you start ........5-6 Remote control . -
Page 5: Before You Start
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 5 Before you start Recordable and Playable discs This unit can play and record all widely-used DVD types. The table below shows some specific compatibility differences depending on the disc types. DVD-R DVD-RW DVD-RAM DVD+R DVD+R(DL) DVD+RW Symbol used in... - Page 6 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 6 Notes on discs Restrictions on copying Depending on the conditions of the recording equipment or the CD-R/RW (or Some video material is copy-once protected: Such material cannot be copied to DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be Video tape or DVD.
-
Page 7: Remote Control
Title List-Original and Title List-Playlist menu. setting. DISPLAY: Accesses On-Screen Display. Manufacturer Code Number RETURN (O): Removes the on-screen displays. DUBBING LG / GoldStar 1 (Default), 2 b / B / v / V (left/right/up/down): Zenith 1, 3, 4 Used to navigate on-screen displays. Samsung... -
Page 8: Main Unit
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 8 Main Unit j k l a 1 1 / I (POWER button) j N / X (PLAY / PAUSE) Switches the unit ON or OFF. Starts playback. Pause playback or recording temporarily, press again to exit pause mode. b Disc Tray k x (STOP) Insert a disc here. -
Page 9: Hooking Up The Unit
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 9 Hooking up the unit c SCART connection Connect one end of the scart cable into the AV1 SCART jack on the unit and other end to the corresponding in a Antenna connection jack on your TV. Connect the Terrestrial You can get Audio and Video TV antenna to the... - Page 10 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 10 Hooking up the unit - more you can do Component connection Connect one end of the component(Y PB PR) cable to the COMPONENT OUT- PUT jack on the unit and other end to the COMPONENT INPUT jack on your Connect one ends of the audio cables (red and white) to the analog AUDIO OUTPUT jack on the unit and other ends to the AUDIO INPUT jack on your TV.
- Page 11 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 11 HDMI connection If your TV is not equipped with DTS decoder, set the [DTS] options to [OFF] on the setup menu (See page 17). To enjoy DTS multi channel Connect one end of the HDMI cable to the HDMI OUTPUT jack on the unit and surround, you must connect this unit to a DTS compatible receiver via other end to the HDMI INPUT jack on your TV.
- Page 12 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 12 Connecting a cable box or satellite receiver Pictures containing copy protection signals that prohibit any copying cannot be recorded. You can watch or record satellite/cable box if you connect a decoder (not sup- If you pass the unit signals via the VCR, you may not receive a clear image plied) to the unit.
-
Page 13: Operating Usb Flash Drive
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 13 Connecting to the AV IN 3 Jacks Operating USB Flash Drive Connect the input jacks (AV IN 3) on the unit to the audio/video out jacks on your accessory component using audio/video cables. ON REMOTE 1. -
Page 14: Auto Setup
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 14 [Program Edit]: Change the settings of a channel manually. Auto setup [Station Rename]: Change a name of the selected channel. [Move]: Change the order of the channels and which numerical button they When the first time to turn on the unit, the initial setup correspond to. -
Page 15: Adjust The Setup Settings
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 15 Using the Home Menu - more you can do Adjust the SETUP settings Setup ON REMOTE Start – Displays SETUP menu. (page 15-19) 1 Displays the HOME menu: HOME MOVIE 2 Select the [Setup] option: b b B B VCR –... - Page 16 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 16 Adjust the SETUP settings - more you can do VCR Play System – Your video recorder uses triple colour standards, PAL, MESECAM and Auto. During play your video recorder should select the colour Adjust the general settings system automatically, however if you experience problems you may need to do it manually.
- Page 17 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 17 Adjust the language settings Sampling Freq. (Frequency) – Selects the sampling frequency of the audio signal. [48 kHz]: In case of DVD with 96KHz sampling, Output is converted to 48kHz. If your receiver or amplifier is NOT capable of handling 96 kHz sig- nals, select [48 kHz].
- Page 18 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 18 Adjust the recording settings Auto Chapter – When DVD recording, chapter markers are added automatical- ly in every specified interval (5 or 10 min.). If you select None, switch off automatic chapter marking altogether with the No Separation setting.
-
Page 19: Displaying Disc Information
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 19 Before finalizing, check the characteristics between the disc type in the table Displaying disc information below. The finalized DVD-RW discs can be unfinalized ON REMOTE so that the disc can edit or record again. 1 Play the disc loaded on the unit PLAY Once you finalize a disc, you can not edit or... - Page 20 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 20 Displaying information while watching TV Moving to another title/track/file DVD ALL DivX During viewing the TV, Press DISPLAY to display the information displayed When a disc has more than one title, you can move to another title. on-screen.
-
Page 21: Play A Tape
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 21 Hearing a different audio TAPE Play a Tape Press AUDIO then sets tape audio to HIFI, LEFT, RIGHT or NORMAL. ON REMOTE Use b/B buttons to select tape audio you want. 1 Press VCR to control the VCR deck: Counter Memory Function TAPE 2 Insert a prerecorded video tape:... - Page 22 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 22 Skip to the next/previous chapter/track/file DVD ALL Watching a enlarged video image DVD ALL DivX During playback or pause mode, press ZOOM repeatedly to select zoom mode. You can move through the zoomed picture using vVb B buttons. Press CLEAR Press SKIP (>) to move to the next chapter/track/file.
-
Page 23: Playing A Divx Movie Files
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 23 Notice for displaying DivX ® subtitle Playing DivX ® movie files If the subtitle does not display properly, press PAUSE/STEP when the subtitle appears. Then press and hold SUBTITLE about 3 seconds to display the ON REMOTE language code menu. -
Page 24: Listening To A Music
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 24 Displaying MP3/WMA file information Listening to a music Press DISPLAY while the file you want to show the file information is selected. The unit shows the ID3-Tag information of the file. If the file does not have ON REMOTE ID3-Tag information, [ID3-Tag: None] appears on the screen. -
Page 25: Viewing A Photo
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 25 Viewing photo files as a slide show Viewing a photo To slide show photos in the [Photo list], select the [Slide Show] option on the left side of the screen then press ENTER, The [Slide Show] menu appears on ON REMOTE the screen. -
Page 26: Recording
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 26 Setting a timer record Recording This unit can be programmed to record up to 16 timer recording within a month. The clock must be set correctly before setting a timer record. Follow the instruction below to record a TV channel or ON REMOTE other source. - Page 27 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 27 Timer Recording Troubleshooting Recording From an external inputs Even though the timer is set, the unit will not record when: You can record from an external component, such as a camcorder or VCR, – There is no disc (or tape) loaded. connected to any of the recorder’s external inputs.
-
Page 28: Editing A Title
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 28 Before editing Editing a title This unit offers various edit options for various disc types. Before you edit, check the disc type, and select the option available for your disc. ON REMOTE Using the Title list menu, you can edit video contents. You can enjoy advanced edit functions with VR mode formatted DVD (DVD- 1 Displays a [Title List] menu: DISC MENU/LIST... - Page 29 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 29 Chapter search Time search Video Video You can select the start of a title by searching a chapter. Select a title that you You can select the start of a title by searching time. Select a title that you want want to search and press ENTER.
- Page 30 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 30 Naming a title Protect a title When a title is recorded by this unit, the title name will be named by a number. Use this function to protect a title against accidental recording, editing or delet- You can change a title name by using this function.
-
Page 31: Dubbing
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 31 Overwriting Dubbing You can overwrite a new video recording on a recorded title that is not protect- ed. Select the TV channel or input source you want to record. Press DISC ON REMOTE MENU/LIST to display the Title List menu. Use v V b B to highlights a title you 1 Selects a media that you want to dub: VCR or DVD want to overwrite and then press REC to start overwrite. -
Page 32: Language Codes
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 32 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar 6565 Croatian 7282... -
Page 33: Troubleshooting
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 33 Troubleshooting Cancel the Rating function or change the rating level. Cannot play a disc recorded using this unit on other player. General Finalize the disc. Check the disc compatibility of the player. The power does not turned on. Plug the power cord into the wall outlet securely. - Page 34 RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 34 Stereo Audio Record and/or Playback is not present. Resetting the unit TV is not Stereo-compatible. If you observe any of the following symptoms. Broadcast program is not in stereo format. The unit is plugged in, but the power will not turn on or off. The A/V Output jacks on the unit are not connected to TV A/V In jacks.
-
Page 35: Specifications
RC359H-P.BAUTSSK_ENG_0701 2008.7.1 4:52 PM Page 35 Specifications Playback Frequency response DVD (PCM 48 kHz): 8 Hz to 22 kHz, General CD: 8 Hz to 20 kHz Power requirements AC 200-240V, 50/60 Hz DVD (PCM 96 kHz): 8 Hz to 44 kHz Power consumption Signal-to-noise ratio More than 100 dB (AUDIO OUT connector)
