DLP Cinema
Model No.
NP-NC3541L NP-NC2041L
Projector
®
User's Manual
DLP Cinema
NC3541L
NC2041L
Projector
®

Advertisement

Table of Contents
loading

Related Manuals for NEC NC2041L

Summary of Contents for NEC NC2041L

  • Page 1 DLP Cinema Projector ® User’s Manual DLP Cinema Projector ® NC3541L NC2041L Model No. NP-NC3541L NP-NC2041L...

  • Page 2: Important Information

    Maximum power: Red 219 W (NC3541L), 110 W • Other product names and logos mentioned in the user’s (NC2041L), Blue 1028 W (NC3541L), 514 W (NC2041L) manual may be the trademarks or registered trademarks • Radiation pattern from the protective housing: of their respective holders.
  • Page 3 MODIFY THE PRODUCT. NO USER SERVICEABLE PARTS. MAINTENANCE AND SERVICE OF THE PRODUCT IS ONLY TO BE HANDLED BY NEC AUTHORIZED It is possible to vertically set up this device at 360 degrees. TECHNICIANS. However, please do not set up the main part of the device...
  • Page 4 Important Information 2. The power cable is not included with the projector. Ask Cleaning your dealer for the power cable to select and purchase. 1. Shut down AC power by using a circuit breaker before Use a power cable that meets the standards and power cleaning.
  • Page 5 Email Address: contact@goldenduckgroup.com questions relating to unclear points, malfunctions and repairs of the product. In Europe Company Name: Sharp NEC Display Solutions Europe GmbH Address: Landshuter Allee 12-14, D-80637 Munich, Germany Telephone: +49 89 99699 0 Fax Line: +49 89 99699 500 Email Address: infomail@nec-displays.com...
  • Page 6 Important Information Label Information • NC3541L • NC2041L Label A Label A Label F Label F Label A: Risk Group /Lamp Safety Label 3262160500...
  • Page 7 Important Information Label C Label D Label E Label B • Label B Laser Explanatory Label • Label C: NC3541L...
  • Page 8 Important Information • Label C: NC2041L • Label D • Label E • Label F Aperture label...
  • Page 9 Important Information Laser radiation range/No entry range (HD: Hazard distance) • The below table describes the radiation range of emitted light by the projector that is classified as Risk Group 3 (RG3) of IEC 62471-5 First edition 2015. • The below table describes the radiation range of emitted light by the projector that is classified as Risk Group 3 (RG3) of IEC 62471:2006.(for USA).
  • Page 10 Important Information NC2041L (IEC 62471-5 First edition 2015) (IEC 62471:2006 (for USA)) Screen size(m) Screen size(m) Lens Lens HD(m) HD(m) Wide 0.75 0.39 Wide 0.75 0.39 NC-50LS12Z NC-50LS12Z Tele 0.74 0.39 Tele 0.74 0.39 Wide 0.68 0.36 Wide 0.68 0.36...
  • Page 11 Important Information CAUTION Please heed all precaution for safety. To install the projector • For planning the layout of the projector, make sure to take safety measures instructed on the installation manual. • In order to refuse danger, install either a wall outlet within easy reach for pulling out the power plug in emergency or a device as a breaker to shut down the power supply to the projector.

  • Page 12: Table Of Contents

    Table of Contents Important Information ..............2 1. What’s in the Box? and the Names of the Projector Parts ..13 1-1. Features ..................................13 1-2. What’s in the Box? ..............................15 1-3. Names of the Projector Parts ..........................16 2.

  • Page 13: What's In The Box? And The Names Of The Projector Parts

    ® Complies with the strict projection standards defined by the Digital Cinema Initiatives (DCI) industry group in the United States using leading imaging technology of NEC. It also supports 3D projection and high frame rates (HFR). • Employs a long life laser light source The projector employs a newly developed laser light source offering excellent reliability and redundancy. Since the laser light source has a long life, this delivers low cost operation by removing the need for maintenance such as replacing and adjusting the light module over extended periods of time.
  • Page 14 1. What’s in the Box? and the Names of the Projector Parts • Equipped with easy to use functions (1) Lens memory function and light memory function that can be operated with one touch. The projector is equipped with a lens memory function that can save the zoom position and shift position of the lens and a light memory function that can save the brightness setting separately for each input signal.

  • Page 15: What's In The Box

    1. What’s in the Box? and the Names of the Projector Parts 1-2. What’s in the Box? Check the content of the accessories.  Projector  Power cable stopper  Lens hole cap  Important Information  Service keys x 2 ...

  • Page 16: Names Of The Projector Parts

    1. What’s in the Box? and the Names of the Projector Parts 1-3. Names of the Projector Parts 1-3-1. Front of the projector NC3541L...
  • Page 17 1. What’s in the Box? and the Names of the Projector Parts NC2041L 1. Light status indicator Displays the status of the light source. The indicators turn on when the light source is on and turn off when the light source is off.
  • Page 18 1. What’s in the Box? and the Names of the Projector Parts 8. Remote interlock connector (inside side of projector) This port is for safely using this device. It is used to externally control the projector. Consult with your dealer/distributor about using this. 9.
  • Page 19 1. What’s in the Box? and the Names of the Projector Parts 1-3-2. Rear of the projector NC3541L NC2041L 1. Air inlet / Air filter The air inlet for cooling inside the projector. Do not cover. Two filters are attached over the air inlet to prevent dust. Refer to “5-3. Cleaning the Air Filters” (page 58) on how to clean the air filters.
  • Page 20 1. What’s in the Box? and the Names of the Projector Parts 1-3-3. Bottom of the projector 1. Handle (4 locations) Handles for moving the projector. 2. Level adjusters (in 4 positions) In the ordinary installation, you can adjust the projector inclination at 4 positions. 3.
  • Page 21 1. What’s in the Box? and the Names of the Projector Parts 1-3-4. Connection terminals 1. Service terminal (REMOTE) (Stereo mini) This terminal is used for service purpose only. 2. Ethernet port (LAN) (RJ-45) The port for interfacing with an image signal server or controlling the projector from a PC via a network. Connect the projector and the PC with a commercially available Ethernet cable (10/100Base-T).
  • Page 22 1. What’s in the Box? and the Names of the Projector Parts 1-3-5. Control panel 2 3 4 5 6 1. Light button Toggles ON and OFF the light on the control panel of the projector and the backlight on the LCD screen. 2.
  • Page 23 1. What’s in the Box? and the Names of the Projector Parts 10. ENTER button Press this button to select the menu item. 11. EXIT button Press this button to return to the previous menu item. 12. KEY LOCK button Press this button to lock (KEY LOCK) the buttons on the control panel.

  • Page 24: Installation And Connection

    Installation and Connection 2-1. Steps for setting up and connecting Use the following steps for setting up your projector: • Step 1 Setup the screen and projector. (Contact your dealer to carry out the setup.) • Step 2 Connect the power cable to the projector. (See page 25) • Step 3 Connect cables to the image input terminals.

  • Page 25: Connecting The Power Cable

    2. Installation and Connection 2-2. Connecting the Power Cable Consult your dealer for installing the power cable to the projector. If AC power is supplied to the projector and light with one power cable (C1 connection), it is not necessary to connect the cable to the projector power supply.
  • Page 26 2. Installation and Connection Connect the AC power supply cable. Connect the AC power supply cable to the projector. AC input Connect the power plug to the electrical outlet. This completes the connection of the AC power supply cable.
  • Page 27 2. Installation and Connection Attaching the power cable stopper To prevent the power cable from accidently removing from the AC IN of the projector, attach the supplied power cable stopper to clamp the power cable. CAUTION • To prevent the power cable from coming loose, make sure that all the prongs of the power cable are fully inserted into the AC IN terminal of the projector before using the power cable stopper to fix the power cable.
  • Page 28 2. Installation and Connection Slide the clamper to the hilt of the power cable. Pulling the knob in the arrow direction allows you to adjust the clamper position. Once the clamper position is adjusted, release the knob to lock the clamper. knob Pull the band to hold the power cable.
  • Page 29 2. Installation and Connection Removing the power cable from the power cable stopper Pull the knob of the clamper and loosen the band. Pull the knob and slide the clamper away from the power plug. CAUTION The projector may become hot temporarily when the power is turned off or if the AC power is disconnected while the projector is projecting.

  • Page 30: Connecting The Image Input Terminals

    2. Installation and Connection 2-3. Connecting the image input terminals The video input ports that can be used with the IMB are as follows. Refer to the instruction manual of the IMB for details on con- necting the video input ports with external equipment. NP-90MS02 HDMI input port SDI input port...

  • Page 31: Projection Of Images (Basic Operation)

    Projection of Images (Basic Operation) 3-1. Steps of projecting images • Step 1 Turn on the power to the projector. (See page 32) • Step 2 Select the title of input signal. (See page 35) • Step 3 Adjust the position and size of the projected screen. (See page 36) • Step 4 Turn off the power to the projector.

  • Page 32: Turning Your Projector On

    3. Projection of Images (Basic Operation) 3-2. Turning your projector on Please contact your dealer/distributor to connect the power cable. Preparation: • Connect the power cable to the projector. (See page 25) • Supply AC power to the projector. • Turn off the projector power switch and light power switch to the projector when supplying or cutting AC power to NOTE the projector.
  • Page 33 3. Projection of Images (Basic Operation) Turn on the light power switch ([1]) then the projector power switch ([2]) on the side of the projector. A buzzer sounds and the software begins to start. While the software is starting, the POWER indicator is changed from lighting in blue to blinking in blue.
  • Page 34 3. Projection of Images (Basic Operation) If KEY LOCK is on, press the KEY LOCK button for one second or longer. KEY LOCK becomes off. The KEY LOCK button indicator turns off and buttons on the control panel become operable. (See page 40) Press the POWER button on the control panel of your projector three seconds or longer.

  • Page 35: Selecting The Title Of Input Signal

    3. Projection of Images (Basic Operation) 3-3. Selecting the title of input signal This projector allows you to select pre-registered title (input signal) using the preset buttons on the control panel (up to 16 titles). Request your dealer/distributor for details on registering and changing titles. This section explains the steps for selecting registered titles.

  • Page 36: Adjusting The Position And The Size Of Projected Screen

    3. Projection of Images (Basic Operation) 3-4. Adjusting the position and the size of projected screen 3-4-1. Displaying the test pattern Press the MENU button, or select a test pattern from preset buttons (button <1> to <10>). If you register the test patterns to the preset buttons (<1> to <10> buttons), select the test pattern according to “3-3. Selecting the title of input signal (See page 35)”.
  • Page 37 3. Projection of Images (Basic Operation) Display on the LCD the name of the test pattern to be projected, then press the ENTER button. The test pattern is displayed. To cancel the test pattern display, select the title of the signal to project or select the “OFF” test pattern. 3-4-2.
  • Page 38 3. Projection of Images (Basic Operation) 3-4-3. Adjustment of the size (zoom) and focus of the projected screen Press the MENU button. Press the LEFT/RIGHT button to display “Configuration” on the LCD screen. Press the DOWN button. Press the LEFT/RIGHT button to display “Lens Control” on the LCD screen. Press the DOWN button.
  • Page 39 3. Projection of Images (Basic Operation) 3-4-4. Adjusting the brightness of the projected screen (Light output) If the internal temperature within the projector rises due to the temperature in the room being high, the light output NOTE may be automatically reduced. This is called “Thermal Protection Mode (Down Light Power)”. When the projector is in the Thermal Protection Mode, the picture brightness decreases slightly.

  • Page 40: Preventing Misoperations

    3. Projection of Images (Basic Operation) 3-5. Preventing misoperations Buttons on the control panel can be locked (KEY LOCK) to prevent misoperations. Buttons on the control panel do not function while KEY LOCK is on. KEY LOCK must be off to operate these buttons. • KEY LOCK is automatically turned on in the following cases.

  • Page 41: Turning On/Off The Light Source With The Projector Turned On

    3. Projection of Images (Basic Operation) 3-6. Turning on/off the light source with the projector turned on 3-6-1. Turning off the light source • Press the LIGHT ON/OFF button on the control panel for three seconds or longer. 3-6-2. Turning on the light source • Press the LIGHT ON/OFF button on the control panel for three seconds or longer.

  • Page 42: Turning Your Projector Off

    3. Projection of Images (Basic Operation) 3-7. Turning your projector off Press the POWER button on the projector control panel for three seconds or longer. The light source is turned off, the POWER indicator blinks green, and the STATUS and SYSTEM status indicators blink orange (cooling state).
  • Page 43 3. Projection of Images (Basic Operation) Return the administrator switch to the OFF position, then remove the administrator key. Turn off the AC power to the projector. In the following instances, do not turn off the projector power switch and light power switch or disconnect the AC NOTE power.

  • Page 44: Basic Operation With Adjustment Menus

    Using Menus 4-1. Basic operation with adjustment menus To adjust the projector, display the menu on the LCD screen of the projector control panel. 4-1-1. Screen display The menu display screen is composed of a menu display field (the upper two lines) and a setting item display field (the bottom two lines).
  • Page 45 4. Using Menus When not displaying menus, the following screen is normally displayed. When in standby When the projector is in a standby state (the projector power switch and light power switch in on), the following is displayed. When power is turned on When the power is turned on, the following is displayed.
  • Page 46 4. Using Menus 4-1-2. Operating menus Preparation: Turn your projector on. (See page 32) Press the MENU button on the control panel of your projector. The menu is displayed in the LCD screen. Press the LEFT/RIGHT buttons to display “Information.” At each press of the LEFT/RIGHT buttons, the display will cycle as “Title Select”...
  • Page 47 4. Using Menus Press the DOWN button. The submenu “Model” another rank lower than “System” is displayed. Press the LEFT/RIGHT button to select the submenu “Kernel.” At each press of the LEFT/RIGHT button, the display will cycle as “Model” ←→ “Serial No.” ←→ “Kernel” ←→ “U-Boot” ←→...
  • Page 48 4. Using Menus 4-1-3. How to enter alphanumeric characters Alphanumeric characters are entered for items, such as the log file of the specified period is written to USB memory. (See page Characters can be entered by pressing numeric buttons on the control panel on this projector. Move right and left Delete entered characters Enter characters...

  • Page 49: Table Of Adjustment Menus

    4. Using Menus 4-2. Table of adjustment menus Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used. Reference Main menu Submenu Description page Title Select “Title Memory Name” Selects the title of the signal to be projected. TEST Pattern Selects the test pattern to be projected.

  • Page 50: Title Select

    4. Using Menus 4-3. Title Select 4-3-1. Title select (Title Memory) Selects the title of the signal to be projected. You can register up to 100 titles. You can also assign registered titles to the preset buttons (<1> to <10> buttons) on the projector’s control panel and call them up directly using those buttons.

  • Page 51: Configuration

    4. Using Menus 4-4. Configuration Please request your dealer/distributor to perform the settings. 4-4-1. Light Setup Adjust Adjusts the light source brightness (output). This setting is the fraction based on taking the maximum value of light source brightness as 100%. ←...
  • Page 52 4. Using Menus 4-4-3. Reset This is used to reset usage time for the air filter, etc. Filter Cleaning Resets the air filter usage time (for confirming the filter cleaning time). Select the filter. Press the ENTER button, then select “Yes” in the displayed confirmation screen, and then press the ENTER button to reset the air filter usage time (for confirming the filter cleaning time).

  • Page 53: Title Setup

    4. Using Menus 4-5. Title Setup Sets the title to be assigned to the preset buttons (<1> to <10> buttons) (up to 20 titles). Request your dealer/distributor to perform the settings. 4-6. Information Displays information relating to the light source, the usage time of the projector, the version information and error codes. 4-6-1.
  • Page 54 4. Using Menus 4-6-4. Usage Displays information related to the projector usage, such as the usage time of the projector, light source, air filters, and fan, and information about the light source replacement cycle. ← Selects the item to display. ←...
  • Page 55 4. Using Menus 4-6-6. Version Displays version information about the projector, optional boards, and IMB. System Displays the version information of the projector. ← Selects the item to display. ← Displays the version information. Display items are as follows. • Model • Serial No.
  • Page 56 4. Using Menus 4-6-8. Setup Date Displays the date when the projector was set up (starting date of the warranty period). ← Displays the date when the projector was set up (starting date of the warranty period). 4-6-9. Option Status Displays the link status of the device mounted in slot on the projector.

  • Page 57: Maintenance Of Your Projector

    Maintenance of Your Projector Please request your dealer to perform cleaning of the projector inside. NOTE 5-1. Cleaning the Cabinet WARNING Please do not use a spray containing flammable gas to remove dust attached to the cabinet, etc. Doing so may result in fires. Be sure to always check that the AC power supply of the projector is disconnected before carrying out maintenance of the projector.

  • Page 58: Cleaning The Lens

    5. Maintenance of Your Projector 5-2. Cleaning the Lens Clean the lens the same way as with camera lens (using a commercially available camera blower or cleaning paper for glasses). Take care not to damage the lens when cleaning. WARNING • Do not look into the light source while the projector is ON.
  • Page 59 When cleaning the air filter, clean it all at the same time. NC3541L Air inlet (Filter cover / Filter) Air outlet Air outlet Air outlet Air inlet (Filter cover / Filter) NC2041L Air inlet (Filter cover / Filter) Air outlet Air outlet Air outlet Air inlet (Filter cover / Filter)
  • Page 60 5. Maintenance of Your Projector 5-3-1. Cleaning the Air Filter Remove the front filter cover. Pull the front filter cover in the direction of the arrow to remove. Handle Remove the air filter. 1. Press the stopper button (2 places).
  • Page 61 5. Maintenance of Your Projector 2. Pull the top part of the air filter towards you. Once you have freed the upper half of the air filter, remove the filter by pulling it diagonally upwards. Lift the air filter in the direction of the arrow and remove it. Remove the air filters.
  • Page 62 5. Maintenance of Your Projector Do not apply a high degree of force or attempt to pry it open. This could deform the flange making it impossible NOTE to reattach the filter cover. Clean all the dust from the filters using a vacuum cleaner. Carefully remove the dust from the filter covers as well as from both sides of all the filters.
  • Page 63 5. Maintenance of Your Projector Fix the filter inside the projector unit. 1. Snap the filter cover tabs into the cutout portion of the projector unit to secure it. 2. Seat the air filter aligned with the air inlet. Cut out portion Attach the front filter cover.
  • Page 64 5. Maintenance of Your Projector 5-3-2. Resetting the Air Filter Usage Time Turn on the power to the projector. Reset the displayed message by selecting “Configuration” → “Reset” . Select “Configuration” → “Reset” → “Filter Cleaning” in the adjustment menu. “FilterCleaning Time” message on the LCD screen is turned off.

  • Page 65: Appendix

    Appendix 6-1. Troubleshooting Before asking for repair, please check your connection, settings and operation once again. If the trouble cannot be corrected, please contact your dealer/distributor for instructions or repair. 6-1-1. Problems and where to check Problem Check these items The projector cannot be turned on.
  • Page 66 6. Appendix Problem Check these items The SYSTEM status indicator blinks Your projector may have trouble. Please contact your dealer/distributor for instructions. in red. An error code is displayed. Please contact your dealer/distributor for instructions.

  • Page 67: Indicator Display List

    6. Appendix 6-2. Indicator display list See the descriptions below when the buttons on the control panel or the indicators on the rear of the projector is lit or blinking. The projector also has a warning function that uses a buzzer. LIGHT indicator DOUSER indicator POWER indicator...
  • Page 68 6. Appendix 6-2-4. TEMP. indicator Indicator condition Projector condition Note Blinking light The projector temperature rises close to the operating An error message is displayed in temperature limit. the LCD screen. Check the content of the error. Steady light The projector temperature exceeded the operating An error message is displayed in temperature.
  • Page 69 6. Appendix 6-2-8. STATUS indicator LIGHT status indicator SYSTEM status indicator SYSTEM status indicator Indicator condition Projector condition Note Main power is off. Blinking light Orange State from turning the power off to entering standby mode. Wait for a moment. Green (cycle of 1 The projector is getting ready to turn on.

  • Page 70: Operation Using An Http Browser

    6. Appendix 6-3. Operation using an HTTP browser 6-3-1. Overview The use of HTTP server functions will allow control of the projector from a web browser. Please be sure to use “Microsoft Internet Explorer 4.x” or a higher version for the web browser. This device uses “JavaScript”...
  • Page 71 • The IP address and host name of the projector have been added to the “HOSTS” file on the PC (Example 1) When the host name of the projector has been set to “pj.nec.co.jp” http://pj.nec.co.jp/index.html is specified for the address or the entry column of the URL to access HTTP server functions.
  • Page 72 6. Appendix Power Controls the power to your projector. • On: Turns the power on. • Off: Turns the power off. Light Turn the light source on/off. • On: Turns the light source on. • Off: Turns the light source off. Title List Displays titles set in the projector (such as input port, screen type, and title). Check, and the title will be changed.

  • Page 73: Writing Of The Log File (Save Pj Log)

    6. Appendix 6-4. Writing of the log file (Save PJ Log) Log files saved on the main unit can be written to USB memory connected to the USB port of the main unit. To perform the writing of the log file, use the following procedure. Connect the USB memory to the USB port of the main unit.
  • Page 74 6. Appendix When “Manual” is selected, specify the log file writing period. For how to enter numerals, refer to “4-1-3. How to enter alphanumeric characters” (See page 48). If you press the ENTER button, the display advances to the following screen. ←...
  • Page 75 6. Appendix 6-4-1. Names of log files Written log files are saved with the following file names. (Model name)_(Serial Number)_YYMMDDHHmm.txt (Model name) This shows the model of projector. (Serial Number) This shows the serial number of projector. YYMMDDHHmm Shows the date/time when written. YY: Year (lower 2 digits) MM: Month (2 digits) DD: Date (2 digits)

  • Page 76: Outline Drawing

    6. Appendix 6-5. Outline Drawing NC3541L 244.5 Units: mm...
  • Page 77 6. Appendix NC2041L 244.5 Units: mm...

  • Page 78: Specifications

    6. Appendix 6-6. Specifications Model name NC3541L Projection method 3 chip DLP Cinema® method 1.38-inch DC4K chip Panel resolution 4096 x 2160 Light source Laser Diode Screen sizes Max. 32 m @14ft-L / Screen Gain 2.6 (Depends on setup conditions) Contrast ratio 2000:1 with DCI specified color representation Lens adjustment function...
  • Page 79 6. Appendix Model name NC2041L Projection method 3 chip DLP Cinema® method 1.38-inch DC4K chip Panel resolution 4096 x 2160 Light source Laser Diode Screen sizes Max. 20 m @14ft-L / Screen Gain 1.8 (Depends on setup conditions) Contrast ratio...

  • Page 80: Pin Assignment And Functions Of Terminal

    6. Appendix 6-7. Pin Assignment and Functions of Terminal 6-7-1. PC CONTROL terminal (RS-232) (D-sub 9 pin) This is an RS-232C interface for controlling the projector from a PC. The projector operates as a DCE (Data Communication Equipment), so use a straight cable when connecting to a PC. Pin No.
  • Page 81 6. Appendix 6-7-2. External control terminal (GP I/O) (D-sub 37 pin) It is possible to control the projector with an external device and to control the external device from the projector using an external control terminal (GPIO: General Purpose I/O Ports). Each pin is electrically separated from the projector internal circuits by a photo- coupler.
  • Page 82 6. Appendix Input terminal GP I/O terminal Inside Projector Resist = 360 Ω Ext_GPIN_P Pin No.: Voltage applied across the pins of Ext_GPIN_P and Ext_GPIN_N should be in the range from 3.3 Vdc to 10 Vdc. Recommended Operating Current: Absolute Maximum Rating: 23mA Ext_GPIN_N Pin No.: 20 21 23 23 24 25 26 27...
  • Page 83 6. Appendix • Timing chart of GPIO control Example of Select Preset Button Off at least 500 ms at least 500 ms approx. 200 ms 8-27 5-24/6-25/7-26 time Execute Select Preset Button Example for turning the image douser (Douser) on Off at least 500 ms at least 500 ms approx.
  • Page 84 6. Appendix Example of Light source On Off at least 500 ms at least 500 ms approx. 200 ms 5-24/6-25 7-26/8-27 time Execute Light source On Example for turning the power off Off at least 500 ms at least 500 ms approx.
  • Page 85 6. Appendix Output terminal GP I/O terminal Inside Projector Ext_GPOUT_P Ext_PROJ_GOOD_P Pin No.: 9 10 11 12 13 14 15 16 Absolute Maximum Rating: 50 mA Ext_GPOUT_N Ext_PROJ_GOOD_N Pin No.: 28 29 30 31 32 33 34 35 Photo-coupler • Using GPIO Control You can use GPIO control for the projector’s health check and error check.
  • Page 86 6. Appendix 6-7-3. 3D terminal (D-sub 15 pin) This is used to connect a 3D image system to the projector. Pin view of a female connector Pin No. Signal Name Function +12V Supplies power (+12V) to the 3D image system GNDC Ground GNDC...

  • Page 87: Related Products List

    6. Appendix 6-8. Related products list Product name Model name Lens Zoom lens 1.13 to 1.66 NC-50LS12Z Zoom lens 1.30 to 1.85 NC-50LS14Z Zoom lens 1.45 to 2.17 NC-50LS16Z Zoom lens 1.63 to 2.71 NC-50LS18Z Zoom lens 1.95 to 3.26 NC-50LS21Z Zoom lens 2.71 to 3.89 L2K-30ZM...
