PRODUCT FEATURES PRODUCT FEATURES Depending on the model, some of the following functions may not be available. FILTERED WATER AND ICE DISPENSER The water dispenser dispenses fresh, chilled water. The ice dispenser dispenses cubed and crushed ice. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer drawer remains open.
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. This is the safety alert symbol.
Page 5
SAFETY INSTRUCTIONS Keep packing materials out of the reach of children. Packaging material can be dangerous for children. There is a risk of suffocation. Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may deteriorate. Do not place the refrigerator in direct sunlight or expose it to the heat from heating appliances such as stoves or heaters.
Page 6
SAFETY INSTRUCTIONS Do not put animals inside the appliance. (such as candles and lamps) on the appliance. Avoid contact with any moving parts of the ejector mechanism or with the heater that releases the ice When dispensing ice from the dispenser, do not use a fragile container. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
Page 7
SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with CAUTION to the product or property when using this product, follow basic precautions, including the following: INSTALLATION Do not install the refrigerator where there may be a danger of the unit falling. The refrigerator must be properly installed in accordance with the Installation Instructions.
PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS Electrical requirements: 115 V, 60 Hz Min. / Max. water pressure: 20 - 120 psi (138 - 827 kPa) Model LFXS28968* Description Standard-depth, French door refrigerator, bottom freezer Net weight 305 lb (138 kg) Model LMXS28626* Description Standard-depth, French door refrigerator, bottom freezer Net weight...
PRODUCT SPECIFICATIONS PRODUCT OVERVIEW The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Exterior Control Panel Door button (On Some Models) Sets the refrigerator and freezer temperatures, Opens the Door-in-Door Compartment.
Page 12
12 PRODUCT SPECIFICATIONS LED interior lamps Cheese & Butter and Condiment Bins Light up the inside of the refrigerator. Cheese & Butter and Condiment bins are specially designed for these items, making spreading butter and slicing cheese easier. NOTE The refrigerator shelves are adjustable to meet individual storage needs.
INSTALLATION INSTALLATION Installation Overview location. Unpacking the Choosing the Proper Disassembling/ Refrigerator Location Assembling Leveling and Door Connecting the Water Alignment Line CAUTION Connect to potable water supply only.
14 INSTALLATION Unpacking the Refrigerator Choosing the Proper Location WARNING Water Water supply must be easily connected for the Use two or more people to move and install the automatic icemaker. refrigerator. Failure to do so can result in back injury or other injury.
16 INSTALLATION Removing/Assembling Removing the Refrigerator Handles Handles Loosen the set screws (1) with a 3/32 in. Allen wrench and remove the handle. When moving the refrigerator through a narrow opening, removing the doors is preferred. The appearance of the handles may vary from what Loosen the mounting fasteners (2) that connect is shown.
INSTALLATION Removing/Assembling the Removing the Freezer Drawer Handle Doors and Drawers Loosen the set screws (1) located on the lower side of the handle with a 1/8 in. Allen wrench and If the entrance door is too narrow for the refrigerator remove the handle.
Page 18
18 INSTALLATION Remove the screw (1) from the hinge cover at the Lift the door from the middle hinge pin and top of the refrigerator. Lift the hook (not visible), remove the door. located at the bottom of the front side of the cover CAUTION Place the door, inside facing up, on a nonscratching surface.
Page 19
INSTALLATION Assembling the Right Refrigerator Detach the wire harness (1). Door Make sure that the plastic sleeve is inserted in the bottom of the door. Lower the door onto the Rotate the hinge lever (1) clockwise. Lift the top hinge (2) free of the hinge lever latch. Hinge Lever Latch Fit the hinge (1) over the hinge lever latch and slot it into place.
Page 20
20 INSTALLATION Assembling the Left Refrigerator Hold the water supply connection and gently push Door in the collet (1) to connect the water supply line (2) as shown. Insert the tube at least 5/8 inch (15 Install the left refrigerator door after the right door is mm) into the connector.
Page 21
INSTALLATION Removing the Freezer Drawers Lift the front of the drawer up, then pull it straight out. For models with two freezer drawers, remove both drawers in the same way. The Pullout Drawer located above the freezer drawer is not shown for clarity. WARNING persons, and death, follow basic precautions, including the following:...
Page 22
22 INSTALLATION Hold both rails and push them in simultaneously. the screws located on both sides. Assembling the Freezer Drawer Push the drawer back until it clicks into place. Pull out both rails simultaneously, until they are fully extended. Replace the ice bin in the drawer. Insert the Durabase basket in the rail assembly.
INSTALLATION Connecting the Water Line If the water pressure from the reverse osmosis system is less than 20 psi or 138 kPa or 1.4 kgf/ cm Before Beginning 198 cc capacity): This water line installation is not covered by the refrigerator warranty.
Page 24
24 INSTALLATION Shutoff valve to connect to the cold water line. Drill the hole for the valve. The shutoff valve should have a water inlet with a Drill a ¼ in. hole in the water pipe using a sharp minimum inside diameter of 5/32 in. at the point of bit.
Page 25
INSTALLATION Route the tubing. Connect the tubing to the refrigerator. Route the tubing between the cold water line and the refrigerator. NOTE Route the tubing through a hole drilled in the wall Before making the connection to the refrigerator, be sure that the refrigerator power cord is not plugged cabinet) as close to the wall as possible.
26 INSTALLATION Leveling and Door Alignment Door Alignment Standard Door Leveling Both the left and right refrigerator doors have an The refrigerator has two front leveling legs. Adjust the adjustable nut, located on the bottom hinge, to raise legs to alter the tilt from front-to-back or side-to side. and lower them to align properly.
INSTALLATION Turning on the Power The right refrigerator door does not have an adjustable nut. After installing, plug the refrigerator’s power cord If the space between the doors is uneven, follow the into a 3-prong grounded outlet and push the instructions below to align the right door: With one hand, lift up both the inner and outer door sections of the right door to raise them at the...
28 OPERATION OPERATION Before Use Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains the refrigerator. Remove adhesive residue by wiping it off with your thumb or dish detergent.
OPERATION Control Panel Depending on the model, some of the following functions may not be available. Control Panel Features NOTE When the refrigerator is in the Power Saving Mode, the display remains off until a door is opened or a button is pressed.
Page 30
The actual refrigerator temperature depends on the food inside the refrigerator. * Wi-Fi The Wi-Fi button, when used with the LG Fresh Air Filter Smart Refrigerator smart phone app, allows the refrigerator to connect to a home Wi-Fi network.
If ice or water dispenses unexpectedly, turn off the water supply and contact an LG Electronics Customer Information Center. Never use a glass that is exceptionally narrow or deep. Ice may jam in the ice passage and...
If the problem continues, contact compartment. This could also cause the icemaker to an LG Electronics Customer Information Center. stop producing ice. Do not use the water or ice until the problem is corrected.
Page 33
OPERATION Detaching the In-Door Ice Bin CAUTION Gently pull the handle to open the ice compartment. When handling the ice bin, keep hands away from the icemaker tray area to avoid personal injury. Avoid touching the auto shutoff (feeler arm) when replacing the ice bin.
34 OPERATION Automatic Icemaker Turning the Automatic Icemaker On To turn the automatic icemaker On/Off, press and Icemaker hold the Ice On/Off button on the control panel for three seconds. Normal Sounds You May Hear Power Switch Keeping the power turned on to the icemaker before the water line is connected can damage the Ice-detecting Sensor icemaker.
OPERATION Storing Food Where to Store Food Each compartment inside the refrigerator is designed to store different types of food. Store food in the optimal space to enjoy the freshest taste. Standard Door Door-in-Door...
Page 36
36 OPERATION Vegetable Storage (Crisper) Preserves vegetables and fruit. Removable Ice storage bin If a large amount of ice is needed, transfer the ice in the in-door ice bin to an ice storage bin in the freezer. Durabase ® Largest storage space in the freezer. Dairy Product Bin Stores milk products such as butter and cheese.
Page 37
OPERATION Food Storage Tips CAUTION Wrap or store food in the refrigerator in airtight and moisture-proof material unless otherwise noted. This prevents food odor and taste transfer throughout the bins. Doing so may cause damage to the bin refrigerator. For dated products, check date code to or personal injury if items are removed with ensure freshness.
38 OPERATION Storing Frozen Food Do not use Bread wrappers Check a freezer guide or a reliable cookbook for further information about preparing food for freezing Non-polyethylene plastic containers or food storage times. Containers without tight lids Wax paper or wax-coated freezer wrap Freezing Thin, semi-permeable wrap Your freezer will not quick-freeze a large quantity of...
OPERATION Glide‘N’Serve Detaching/Assembling the Storage Bins The Glide’N’Serve provides storage space with a variable temperature control that can keep the compartment at a slightly different temperature than one location. the refrigerator section. This drawer can be used for large party trays, deli items and beverages. (This drawer should not be used to store vegetables that Glide'N'Serve and Crispers require high humidity.)
40 OPERATION Door-in-Door (On Some Crisper Cover Models) To remove, lift the front of the cover up until it detaches from the back wall of the cabinet, then pull The Door-in-Door compartment allows for easy it out. access to commonly used food items. The outer Door-In-Door door includes two door bins, the Cheese &...
Page 41
OPERATION Door-in-Door Case CAUTION To open the Door-in-Door case, pull evenly on the marked area. The Door-in-Door Case is removable Do not overcrowd door bins or close doors with for easy cleaning and adjustment. excessive force. The inner door-in-door may not close properly or may be pushed open by falling items, resulting in product or property damage or personal injury.
Page 42
42 OPERATION Shelves CAUTION The shelves in the refrigerator are adjustable to meet Make sure that shelves are level from one side individual storage needs. Your model may have full or to the other. Failure to do so may result in the split shelves.
To verify the Wi-Fi connection, check that the Wi-Fi icon on the control panel is lit. Smart ThinQ Application LG Smart ThinQ is not responsible for any network connection problems or any faults, malfunctions, or The Smart ThinQ application allows you to communicate with the appliance using a smartphone.
2) This device must accept any interference received, available for download. including interference that may cause undesired LG Electronics will also provide open source code operation of the device. to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of...
Page 45
(TALR) mode. LG Open API Delay Appliance Load (DAL) You can manage Smart Grid features for the LG The refrigerator responds to a DAL signal by Smart Refrigerator. providing a moderate load reduction for the duration of the delay period.
LG Customer Information Center. NFC or Wi-Fi equipped models can also transmit data to a smartphone using the LG Smart ThinQ application. Smart Diagnosis™ through the Customer Information Center...
MAINTENANCE MAINTENANCE For products with a standard stainless steel exterior, of the grain. Dry with a paper towel to avoid streaks. Cleaning of liquid dish soap in water, and rinse with hot water before drying. Do not use abrasive or harsh cleaners. WARNING Inside Walls Allow freezer to warm up so the cloth will not stick.
48 MAINTENANCE Replacing the Fresh Air Filter Replacing the Water Filter Replace the Fresh Air Filter: Replace the Water Filter : Approximately every six months. Approximately every six months. When the Replace Filter icon turns on. When the Replace Filter icon turns on.
Page 49
MAINTENANCE Water Filter button for three seconds to reset the indicator light. counterclockwise. NOTE Visit your local dealer or distributor lg.com Use replacement cartridge: LT1000P (ADQ74793501) LT1000PC (ADQ74793504) LT1000PCS (ADQ74793505) remove the protective cover from the o-rings. For further assistance, call: turn it clockwise.
Page 50
50 MAINTENANCE Performance Data Sheet Model: LT1000P/PC/PCS NSF System Trade Name Code : MDJ64844601 The concentration of the indicated substances in water entering the system was reduced to a concentration less Standard 53. and Standard 401 for the reduction of substances listed below. Average Average substance...
Page 52
Do not install where water hammer conditions For further assistance, the LG Electronics Customer may occur. If water hammer conditions exist you Information Center is open 24 hours a day/7 days a must install a water hammer arrester. Contact a week.
TROUBLESHOOTING TROUBLESHOOTING FAQs: Frequently Asked Questions What are the best temperature settings for my refrigerator and freezer? The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). The default setting for the freezer is 0° Fahrenheit (-18° Celsius). Adjust these settings as necessary to keep food at desired temperatures.
54 TROUBLESHOOTING Before Calling for Service Cooling Problem Possible Cause Solutions The refrigerator control is set Turn the control ON. Refer to the Setting the Controls to OFF (some models). section for proper temperature settings. Demo Mode allows the lights and control display to work normally while disabling cooling, to save energy while Refrigerator is set to Demo Mode.
Page 55
TROUBLESHOOTING Cooling Problem Possible Cause Solutions When the doors are opened often or for long periods of time, warm, humid air enters the compartment. This Doors are opened often or for raises the temperature and moisture level within the long periods of time. compartment.
Page 56
56 TROUBLESHOOTING Cooling/Ice & Water Problem Possible Cause Solutions When the doors are opened often or for long periods of time, warm, humid air enters the compartment. This Doors are opened often or for raises the temperature and moisture level within the long periods of time.
Page 57
TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Demand exceeds ice storage The icemaker will produce approximately 70-184 cubes capacity. in a 24 hour period. Connect the refrigerator to a cold water supply with House water supply is not adequate pressure and turn the water shutoff valve fully connected, valve is not turned on open.
Page 58
58 TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Foreign substances or frost on the ice-detecting sensor The ice detecting sensor is can interrupt ice production. Make sure that the sensor obstructed. area is clean at all times for proper operation. The refrigerator is not connected to a water supply or Connect the refrigerator to the water supply and turn the...
Page 59
TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Infrequent use of the ice dispenser will cause the cubes to stick together over time, which will prevent them from Infrequent use of the properly dispensing. Check the ice bin for ice cubes dispenser.
Page 60
60 TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Refrigerator or freezer doors Water will not dispense if any of the refrigerator doors are not closed properly. are left open. trapped air and contaminants from the system. Do not removed or replaced. dispense the entire 2.5 gallon amount continuously.
Page 61
TROUBLESHOOTING Parts & Features Problem Possible Cause Solutions Food packages are blocking Rearrange food containers to clear the door and door the door open. shelves. Ice bin, crisper cover, pans, Push bins all the way in and put crisper cover, pans, shelves, door bins, or baskets shelves and baskets into their correct positions.
Page 62
62 TROUBLESHOOTING Noises Problem Possible Cause Solutions The defrost control will click when the automatic defrost cycle begins and ends. Clicking The thermostat control (or refrigerator Normal Operation control on some models) will also click when cycling on and off. of refrigerant, the water line on the back Normal Operation of the unit, or items stored on top of or...
WARRANTY: Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S.
Page 64
Damage or failure caused by incorrect electrical current, voltage, or plumbing codes, commercial or industrial use, or use of accessories, components, or consumable cleaning products that are not approved by LG. Damage caused by transportation and handling, including scratches, dents, chips, and/or other damage to the within one (1) week of delivery.
(ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
Page 66
Damage or Product failure caused by incorrect electrical current, voltage, or plumbing codes, commercial or industrial use, or use of accessories, components, or cleaning products that are not approved by LG Canada. Damage caused by transportation and handling, including scratches, dents, chips, and/or other damage to the within one (1) week of delivery.
