Manual de instrucciones ィマ・ホサ。ゥ ム For installation and connections, see the supplied installation/connections manual. Para obtener información sobre la instalación y las conexiones, consulte el manual de instalación/conexiones suministrado. テ サセ コヲwクヒ、ホスuク sアオ。Aスミームィ」エ」ィムェコ。ァヲwクヒ。™スuク CDX-4480ESP 1998 by Sony Corporation 3-862-044-21 (1) sアオサ。ゥ ム。ィ。C...
Page 2
Welcome ! Thank you for purchasing the Sony Compact Disc Player. This unit lets you enjoy a variety of features by using either an optional rotary commander (RM-X4S) or a wireless remote (RM-X47).
Location of controls ... 4 Getting Started Resetting the unit ... 6 Detaching the front panel ... 6 Setting the clock ... 7 CD Player Listening to a CD ... 7 Playing a CD in various modes ... 8 Radio Memorizing stations automatically —...
Installation/Connections manual. !§ Frequency Select switch (located on the bottom of the unit) See “Frequency Select switch” in the Installation/Connections manual. !¶ During radio reception: Number buttons 9 !• D-BASS dial 13 DSPL LIST OFF 1 2 D - BASS CDX-4480ESP...
Page 5
Optional wireless remote (RM-X47) The buttons of the wireless remote operate control the same functions as those on this unit. 1 OFF button 2 SEEK/AMS button 3 (–) (+) buttons 4 ATT button 5 SOUND/SEL button 6 DSPL button When the POWER SELECT switch is set to the B position, the unit cannot be operated with the wireless remote unless (SOURCE) on the unit is pressed or a CD is inserted to activate the unit first.
Getting Started Resetting the unit Before operating the unit for the first time or after replacing the car battery, you must reset the unit. Press the reset button with a pointed object, such as a ball-point pen. Reset button Notes •...
If a CD is already inserted, press (SOURCE) repeatedly until “CD” appears. Elapsed playing time TRACK Track number Note To play back an 8 cm CD, use the optional Sony compact disc single adapter (CSA-8). Press Stop playback 6 or (OFF) Eject the CD...
Locating a specific track — Automatic Music Sensor (AMS) During playback, push the SEEK/AMS control up or down momentarily. To locate succeeding tracks To locate preceding tracks Locating a specific point in a track — Manual Search During playback, push the SEEK/AMS control up or down and hold.
Radio Memorizing stations automatically — Best Tuning Memory (BTM) The unit selects the stations with the strongest signals and memorizes them in the order of their frequencies. You can store up to 10 stations on each band (FM1, FM2 and AM). Caution When tuning in a station while driving, use Best Tuning Memory to prevent accidents.
If you cannot tune in a preset station Push the SEEK/AMS control up or down momentarily to search for the station (Automatic Tuning). Scanning stops when the unit receives a station. Push the SEEK/AMS control up or down repeatedly until the desired station is received.
Displaying the station name Press (DSPL) during radio reception. Each time you press (DSPL), the item changes as follows: z Station name* z Frequency MOTION DISPLAY* If the station name of a station is not stored, “NO NAME” appears in the display for one second.
By rotating the control (the SEEK/ AMS control) Rotate the control momentarily and release it to: •Locate a specific track on a disc. Rotate and hold the control until you locate the specific point in a track, then release it to start playback.
Changing the sound and display settings You can set: •CLOCK (page 7). •D.INFO (dual information) to display the clock and the play mode at the same time (ON) or to display the information alternately (OFF). •BEEP to turn the beep tones on or off. •RM (Rotary Commander) to change the operative direction of the controls of the optional rotary commander.
If you have any questions or problems concerning your unit that are not covered in this manual, please consult your nearest Sony dealer. Notes on handling CDs A dirty or defective disc may cause sound dropouts while playing.
If the fuse blows, check the power connection and replace the fuse. If the fuse blows again after replacement, there may be an internal malfunction. In such a case, consult your nearest Sony dealer. Fuse (10 A) Warning Never use a fuse with an amperage rating exceeding the one supplied with the unit as this could damage the unit.
Attaching the label to the rotary commander You can control this unit with the optional rotary commander (RM-X4S). Several labels are supplied with the rotary commander. Attach the label that matches the functions of this unit and the mounting position of the rotary commander. After you mount the rotary commander, attach the label as in the illustration below.
Specifications CD player section System Compact disc digital audio system Signal-to-noise ratio 90 dB Frequency response 10 – 20,000 Hz Wow and flutter Below measurable limit Tuner section Tuning range FM tuning interval: 50 kHz/200 kHz switchable 87.5 – 108.0 MHz (at 50 kHz step) 87.5 –...
Troubleshooting guide The following checklist will help you remedy problems you may encounter with your unit. Before going through the checklist below, check the connection and operating procedures. General Problem No sound The contents of the memory have been erased. Indications do not appear in the display.
Page 19
The CD player cannot be operated RESET because of some problem. If the above-mentioned solutions do not help improve the situation, consult your nearest Sony dealer. Solution Clean or insert the CD correctly. Press the reset button of the this unit.
Page 20
¡Bienvenido! Enhorabuena por la adquisición de este reproductor de discos compactos de Sony. Esta unidad le permitirá disfrutar de varias funciones mediante el uo de un mando rotativo (RM-X4S) o un mando a distancia inalámbrico (RM-X47).
Page 21
Indice Localización de los controles ... 4 Procedimientos iniciales Restauración de la unidad ... 6 Extracción del panel frontal ... 6 Ajuste del reloj ... 7 Reproductor de discos compactos Reproducción de discos compactos ... 7 Reproducción de discos compactos en diversos modos ...
!§ Selector de frecuencia (situado en la base de la unidad) Consulte “Selector de frecuencia” del manual de Instalación/conexiones. !¶ Durante la recepción de radio: Botones numéricos 9 !• Dial D-BASS 13 DSPL LIST OFF 1 2 D - BASS CDX-4480ESP...
Page 23
Mando a distancia inalámbrico opcional (RM-X47) Botones con la misma función a los de la unidad principal. 1 Botón OFF 2 Botón SEEK/AMS 3 Botones (–) (+) 4 Botón ATT 5 Botón SOUND/SEL 6 Botón DSPL Si el interruptor POWER SELECT está ajustado en la posición B, no será posible emplear la unidad con el mando a distancia inalámbrico, a menos que pulse (SOURCE) en dicha unidad o que inserte un CD para que ésta se active en primer lugar.
Procedimientos iniciales Restauración de la unidad Antes de utilizar la unidad por primera vez o después de sustituir la batería del automóvil, es necesario restaurar dicha unidad. Pulse el botón de restauración con un objeto puntiagudo, por ejemplo, un bolígrafo. Botón de restauración Notas •...
Tiempo de reproducción transcurrido TRACK Número de tema Nota Si desea reproducir un CD de 8 cm, utilice el adaptador sencillo opcional de discos compactos Sony (CSA-8). Para Pulse Detener la reproducción 6 o (OFF) Expulsar el CD Cambio de la indicación del visor Cada vez que pulse (DSPL), los elementos cambiarán de la siguiente forma:...
Localización de un tema específico — Sensor de música automático (AMS) Durante la reproducción, desplace el control SEEK/AMS hacia arriba o abajo momentáneamente. Para localizar temas posteriores Para localizar temas anteriores Localización de un punto específico de un tema — Búsqueda manual Durante la reproducción, desplace el control SEEK/AMS hacia arriba o abajo y manténgalo en esta posición.
Radio Memorización automática de emisoras — Memorización de la mejor sintonía (BTM) Esta unidad selecciona las emisoras de señal más intensa y las memoriza por orden de frecuencia. Es posible almacenar hasta 10 emisoras de cada banda (FM1, FM2 y AM). Precaución Durante la conducción, utilice la memorización de la mejor sintonía para evitar accidentes.
Si no puede sintonizar una emisora programada Desplace el control SEEK/AMS hacia arriba o abajo momentáneamente para buscar la emisora (sintonización automática). La exploración se detiene cuando la unidad recibe una emisora. Desplace el control SEEK/AMS hacia arriba o abajo varias veces hasta recibir la emisora que desee.
Visualización del nombre de la emisora Pulse (DSPL) durante la recepción de una emisora. Cada vez que pulse (DSPL), el elemento cambiará de la forma siguiente. z Nombre de la emisora* MOTION DISPLAY* Si el nombre de la emisora no está almacenado, en el visor aparecerá...
Mediante el giro del control SEEK/ Gire el control momentáneamente y suéltelo para: •Localizar un tema específico de un disco. Gire y mantenga girado el control hasta localizar el punto específico de un tema y, a continuación, suéltelo para iniciar la reproducción.
Cambio de los ajustes de sonido y visualización Es posible seleccionar diversos modos: •CLOCK (Reloj) (página 7). •D. INFO (información dual), que permite mostrar simultáneamente el reloj y el modo de reproducción (ON) o la información de forma alternativa (OFF). •BEEP, que permite activar o desactivar los pitidos.
Si desea realizar alguna consulta o solucionar algún problema referentes a la unidad que no aparezcan en este manual, póngase en contacto con el proveedor Sony más próximo. Notas sobre el manejo de discos compactos Si el disco está sucio o es defectuoso, puede producirse pérdida de sonido durante la...
Si una vez sustituido vuelve a fundirse, es posible que exista un funcionamiento defectuoso interno. En este caso, póngase en contacto con el proveedor Sony más próximo. Fusible (10 A) Advertencia No utilice nunca un fusible de amperaje superior al del suministrado con la unidad, ya que ésta podría dañarse.
Adhesión de la etiqueta al mando rotativo Esta unidad puede controlarse con el mando rotativo opcional (RM-X4S). Con el mando rotativo se suministra una serie de etiquetas. Adhiera la etiqueta que corresponda a las funciones de esta unidad y a la posición de montaje del mando rotativo.
Especificaciones Sección del reproductor de discos compactos Sistema Audiodigital de discos compactos Relación señal-ruido 90 dB Respuesta de frecuencia 10 – 20.000 Hz Fluctuación y trémolo Inferior al límite medible Sección del sintonizador Gama de sintonización Intervalo de sintonía de 50 kHz/200 kHz conmutable 87,5 –...
Guía de solución de problemas La siguiente lista de comprobaciones proporciona ayuda para solucionar la mayoría de los problemas que pueden producirse con la unidad. Antes de consultar la lista que aparece a continuación, compruebe los procedimientos de conexión y funcionamiento.
Page 37
El reproductor de CD no funciona RESET debido a algún problema. Si el problema no se soluciona con las sugerencias anteriormente enumeradas, póngase en contacto con el proveedor Sony más próximo. Solución Limpie el CD o insértelo correctamente. Pulse el botón de restauración de la...
