Adding Detergents and Softeners ..............21 Programme Table ....................24 Drying Programme ..................27 Extra Options and Functions ................29 SMART FUNCTIONS LG ThinQ Application ..................31 Smart Diagnosis ....................31 MAINTENANCE Cleaning After Every Wash................32 Cleaning the Appliance Periodically & Performing an Emergency Water Evacuation......................33 TROUBLESHOOTING Before Calling for Service................36...
global_main.book.book Page 3 Wednesday, December 29, 2021 10:20 AM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.
Page 4
global_main.book.book Page 4 Wednesday, December 29, 2021 10:20 AM SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Page 5
global_main.book.book Page 5 Wednesday, December 29, 2021 10:20 AM SAFETY INSTRUCTIONS • Remove all objects from pockets such as lighters and matches. • The appliance is not to be used if industrial chemicals have been used for cleaning. Installation • This appliance should only be transported by two or more people holding the appliance securely.
Page 6
• Do not touch the door during a high temperature programme. • In case of a water leak from the appliance or flood, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
Page 7
• Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the...
Page 8
global_main.book.book Page 8 Wednesday, December 29, 2021 10:20 AM SAFETY INSTRUCTIONS Disposal • Before discarding an old appliance, unplug it. Cut off the cable directly behind the appliance to prevent misuse. • Dispose of all packaging materials (such as plastic bags and styrofoam) away from children.
global_main.book.book Page 9 Wednesday, December 29, 2021 10:20 AM INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View Control Panel Power Plug Detergent Dispenser Drawer Transit Bolts Drum Drain Hose...
Page 10
global_main.book.book Page 10 Wednesday, December 29, 2021 10:20 AM INSTALLATION Specifications Model F4J3TM(G)(0-9)W / F4J3TM(G)(0-9)P Power Supply 220‒240 V~, 50 Hz Product Weight 65 kg Dimension(mm) D’’ D’ D" 1005...
Page 11
global_main.book.book Page 11 Wednesday, December 29, 2021 10:20 AM INSTALLATION Accessories Cold Supply Hose Anti–slip Sheets*1 Spanner Elbow Bracket for Securing Drain Hose Caps for Covering Transit Bolt Holes Tie Strap*1 *1 The included accessories vary depending on the model you purchased.
global_main.book.book Page 12 Wednesday, December 29, 2021 10:20 AM INSTALLATION Installation Place Index Clearance (mm) Requirements Before installing the appliance, check the following information to make sure that the appliance should be installed in a correct place. WARNING Installation Location •...
INSTALLATION grounded/earthed in accordance with all local NOTE codes and ordinances. • You can purchase rubber cups (part No. 4620ER4002B) from the LG service centre. Unpacking the Appliance Lifting the Appliance Off the Ventilation Foam Base • Make sure that air circulation around the...
global_main.book.book Page 14 Wednesday, December 29, 2021 10:20 AM INSTALLATION Starting with the bottom two transit bolts • If the appliance rocks when pushing the top use the spanner (included) to fully loosen all plate of the appliance diagonally, adjust the feet transit bolts by turning them counterclockwise.
Page 15
Failure to do so may cause vibration or noise. • Do not install the washing machine on a plinth, stand or elevated surface unless it is manufactured by LG Electronics for use with this model. Using Anti-Slip Sheets This feature may vary depending on the model purchased.
Water Tap NOTE Connecting Screw-Type Hose to Tap with Thread • Additional anti-slip sheets are available at LG Screw the supply hose connector onto the water Electronics service centre. supply tap. Hand tighten only with the aid of a soft cloth.
global_main.book.book Page 17 Wednesday, December 29, 2021 10:20 AM INSTALLATION Connecting the Hose to the • Securing the drain hose correctly will protect the floor from damage due to water leakage. Appliance Screw the supply hose to the water inlet valve on the back of the appliance.
global_main.book.book Page 18 Wednesday, December 29, 2021 10:20 AM OPERATION OPERATION Operation Overview • Add the proper amount of detergent to the detergent dispenser. If desired, add bleach or fabric softener to the appropriate areas of Using the Appliance the dispenser. Before the first wash, select the Cotton wash programme and add a half amount of the Turn on the appliance.
global_main.book.book Page 19 Wednesday, December 29, 2021 10:20 AM OPERATION Control Panel The actual control panel may differ from model to model. Control Panel Features Description Power On/Off Button • Press this button to turn the washing machine on or off. Programme Knob •...
Page 20
global_main.book.book Page 20 Wednesday, December 29, 2021 10:20 AM OPERATION Description Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. • While the load weight is sensed automatically, the display on the control panel blinks. Time and Status Display Description Estimated Time Remaining...
global_main.book.book Page 21 Wednesday, December 29, 2021 10:20 AM OPERATION Preparing the Wash Load NOTE Sort the wash load for best washing results, and • The dashes under the symbol give you then prepare the clothes according to the symbols information about the type of fabric and the on their care labels.
Page 22
global_main.book.book Page 22 Wednesday, December 29, 2021 10:20 AM OPERATION detergents that are suitable for Drum (front • Minimum load: 1/3 of full load. load) type washers. • If too many suds occur, reduce the detergent amount. Using the Dispenser •...
Page 23
global_main.book.book Page 23 Wednesday, December 29, 2021 10:20 AM OPERATION Adding Water Softener • Pour fabric softener to the maximum fill line. Pouring excessive fabric softener over the maximum fill line can cause it to dispense too A water softener, such as anti-limescale can be used to cut down on the use of detergent in areas early, which may stain the clothes.
global_main.book.book Page 24 Wednesday, December 29, 2021 10:20 AM OPERATION Programme Table Washing Programme Cotton 40 ℃ (Cold to 95 ℃) Max. Load: Rating Description Washes normally soiled clothes by combining various drum motions. Cotton+ 60 ℃ (Cold to 60 ℃) Max.
Page 25
global_main.book.book Page 25 Wednesday, December 29, 2021 10:20 AM OPERATION Quick 30 20 ℃ (Cold to 40 ℃) Max. Load 2 kg Description Washes small loads of lightly soiled clothes for approximately 30 minutes. Rinse+Spin Max. Load: Rating Description Rinses and spins clothes. Use fabric softener if needed. NOTE •...
Page 26
global_main.book.book Page 26 Wednesday, December 29, 2021 10:20 AM OPERATION Selectable Maximum Spin Speed Spin Speed Programme Default Available Cotton 1400 rpm Cotton+ 1400 rpm Mixed Fabric 1400 rpm Easy Care 800 rpm Up to 800 rpm Baby Care 800 rpm Up to 800 rpm Normal Dry 1400 rpm...
global_main.book.book Page 27 Wednesday, December 29, 2021 10:20 AM OPERATION Drying Programme Blankets and Duvets Check fabric care labels on blankets and duvets General Tips for Drying before using the drying programme. Some blankets and duvets may shrink by the heated air. Use the automatic programmes to dry most loads.
Page 28
global_main.book.book Page 28 Wednesday, December 29, 2021 10:20 AM OPERATION Select a dry (Normal Dry, Low Temp. Dry or NOTE Time Dry) programme. • The capacity of the machine for washing clothes is twice as much as when drying clothes. If the Press the Start/Pause button.
global_main.book.book Page 29 Wednesday, December 29, 2021 10:20 AM OPERATION Extra Options and Press the Start/Pause button. Functions Only Using a Spin Function You can use the extra options and functions to Prepare the clothes and load the drum. customize the programmes. Customising a Washing Press the Power button.
Page 30
global_main.book.book Page 30 Wednesday, December 29, 2021 10:20 AM OPERATION Select a washing programme. • A beeper will sound, and will appear on the display. Press the Delay End button as necessary. Unlocking the Control Panel Turn on the power. Press the Start/Pause button.
Page 31 Wednesday, December 29, 2021 10:20 AM SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided The LG ThinQ application allows you to in the LG ThinQ application.
global_main.book.book Page 32 Wednesday, December 29, 2021 10:20 AM MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. •...
global_main.book.book Page 33 Wednesday, December 29, 2021 10:20 AM MAINTENANCE Cleaning the Appliance WARNING Periodically & Performing • Leave the door open to dry inside of the an Emergency Water appliance only if the children are supervised at home. Evacuation Tub Clean Cleaning the Water Inlet Filter This is a programme to help clean the inside of the...
Page 34
global_main.book.book Page 34 Wednesday, December 29, 2021 10:20 AM MAINTENANCE Cleaning the Drain Pump Filter and leakage. Reinsert the plug back into the drain tube and place the tube into its holder. and Performing an Emergency Water Evacuation Close the cover cap. The drain filter collects threads and small objects that may have been accidentally left in the clothes.
Page 35
global_main.book.book Page 35 Wednesday, December 29, 2021 10:20 AM MAINTENANCE Wipe any moisture with a dry towel or cloth after cleaning. Reassemble the components of the drawer to the proper compartments and insert the detergent dispenser drawer.
Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to LG Electronics service centre.
Page 37
• Check and clean the drain filter. Door sensor malfunctions. dE dE1 dEz dE4 DOOR ERROR • Please call LG service centre. You can find your local LG service centre phone number in the warranty card. This is a control error. CONTROL ERROR •...
Page 38
global_main.book.book Page 38 Wednesday, December 29, 2021 10:20 AM TROUBLESHOOTING Noises You Might Hear Symptoms Possible Cause & Solution Rattling and clanking Foreign objects, such as keys, coins, or safety pins may be in the drum. noise • Stop the appliance, check the drum for foreign objects. If the noise continues after the appliance is restarted, call for service.
Page 39
global_main.book.book Page 39 Wednesday, December 29, 2021 10:20 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does not Control panel has powered off due to inactivity. operate. • This is normal. Press the Power button to turn the appliance on. Appliance is unplugged.
Page 40
global_main.book.book Page 40 Wednesday, December 29, 2021 10:20 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance is not filling Inlet filter clogged. properly. • Make sure the inlet filters on the fill valves are not clogged. Inlet hoses may be kinked. •...
Page 41
global_main.book.book Page 41 Wednesday, December 29, 2021 10:20 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Staining Bleach or softener is dispensed too soon. • Dispenser compartment is overfilled. It makes bleach or softer dispensed rapidly. Always measure bleach or softener to prevent overfilling. •...
Page 42
global_main.book.book Page 42 Wednesday, December 29, 2021 10:20 AM TROUBLESHOOTING Drying Symptoms Possible Cause & Solution Dry problem Check water supply tap. • Do not overload. Check that the washing machine is draining properly to extract adequate water from the load. When load of laundry is too small to tumble properly.
