F u j i t s u A m e r i c a , I n c .

LifeBook T5010 Rubber Base Cover

I N S T R U C T I O N S

This rubber base cover is designed so that you can use your

system either in notebook configuration or in tablet configu-

ration.

Figure 1. Rubber Base Cover (top, empty)

Installing a system in the cover

To install your system into the rubber base cover:

1. Press the latch button in and open the display so that it is

in notebook configuration.

2. Position the system so that the two front corners are

aligned with the two front corners of the base cover.

3. Gently pull the base cover backwards until the front cor-

ners of the system fit snugly into the corners of the cover.

(Figure 2)

Rear of Cover

Front of Cover

Page 1 F u j i t s u A m e r i c a , I n c . LifeBook T5010 Rubber Base Cover I N S T R U C T I O N S This rubber base cover is designed so that you can use your system either in notebook configuration or in tablet configu- ration.
Page 2 4. Turn the display so that it doesn’t obstruct access to the two rear corners of the system (Figure 2). Front corners Figure 2. Inserting LifeBook into front of base cover 5. Pull the flexible rear corners of the rubber base cover enough that they fit over their respective corners of the system (Figure 3).
Page 3 PLEASE NOTE: It is very important that you always press the latch button to unlatch the display before opening it. Failure to do so could result in damage to the latch and/or system. To open the display, press the latch button, located directly below the latch (Figure 4).
Page 4 For technical support call:1-800-8fujitsu (1-800-838-5487) or e-mail us at: 8fujitsu@us.fujitsu.com Fujitsu, the Fujitsu logo, and LifeBook are registered trademarks of Fujitsu, Ltd. All other trademarks mentioned herein are the prop- erty of their respective owners. Fujitsu America, Inc. has made every effort to ensure the accuracy and completeness of this document.
