- Page 1 Security Level: U9200E training course www.huawei.com HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
- Page 2 • The main purpose of this course is to conduct a comprehensive production training for our customers about U9200E mobile phone, including the following contents: Hardware/Software specifications Introduction of features Useful Operation skills Common Trouble shooting methods ...
- Page 3 Content Chapter 1 U9200E Product Introduction Chapter 2 U9200E Main Features Chapter 3 Operation skills Chapter 4 Trouble Shooting Chapter 5 About Technical Support HUAWEI TECHNOLOGIES CO., LTD. Page 3...
- Page 4 U9200E ID 4.3’ QHD AMOLED PU Cover capacitive touchscreen 10.7 mm Touch key pad Page 4 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
- Page 5 Introduction HUAWEI U9200E is a smart phone developed by HUAWEI. It is based on Google AndroidTM 4.0 Operating System. They give you an excellent browsing with the Operating System from Google™, all in a beautiful thin touch screen phone. •Android 4.0 (Ice Cream Sandwich) •Dual core 1.5 GHz CPU TI OMAP4460+IMC XMM6260...
- Page 6 Content Chapter 1 U9200E Product Introduction Chapter 2 U9200E Main Features Chapter 3 Operation skills Chapter 4 Trouble Shooting Chapter 5 About Technical Support HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential Page 6...
-
Page 7: Hardware Specifications
GSM 850 MHz: 824–849 MHz (UL), 869–894 MHz (DL) GSM 900 MHz: 880–915 MHz (UL), 925–960 MHz (DL) GSM 1800 MHz: 1710–1785 MHz (UL), 1805–1880 MHz (DL) GSM 1900 MHz: 1850–1910 MHz (UL), 1930–1990 MHz (DL) Page 7 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential... - Page 8 Talking time (Depends on the user operation and network condition): Up to 800 mins (3G) Charging Time: 4.5 hours from supplied charger Relative humidity Working: 5% - 95% Camera Main camera：8 MP AF Camera Front camera：1.3 MP HD Page 8 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
- Page 9 •GSM 850 MHz: better than -109 dBm •GSM 900MHz: better than -109 dBm •DCS 1800MHz: better than -109 dBm •PCS 1900MHz: better than -108 dBm •Power supply •90 V–264 V, 50/60 Hz, 1A •Certification •FCC, CE, WIFI, BT Page 9 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
-
Page 10: Software Specifications
Image file format: *.jpeg, *.png, *.gif, *.bmp •Streaming media • Audio Codec: AMR-NB, AAC, AAC+, eAAC+ • Video Codec: H.263, H.264, MPEG4 • File Format: *.mp4, *.3gp •Ringtone •MIDI，MP3, AMR-NB, WAV, OGG, AAC •Software update •HOTA Page 10 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential... - Page 11 Video: 1080P, 720P, QHD, VGA , QVGA, QCIF • Second camera: • Photo(4:3 Non-widescreen) : 1.3M: 1280×960, 0.3M: 640×480 • Photo(16:9 widescreen) : 1.3M: 1280×720, 0.3M: 640×360 • Video: 1280×720, VGA, QVGA, QCIF Page 11 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
- Page 12 Content Chapter 1 U9200E Product Introduction Chapter 2 U9200E Main Features Chapter 3 Operation skills Chapter 4 Trouble Shooting Chapter 5 About Technical Support HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential Page 12...
-
Page 13: Power Saving Tips
• Turn off Wi-Fi when you are not using it. • Turn off your phone’s GPS receiver when you are not using it. • Lower the volume. • Close power-draining programs, when you do not need them. • Turn off the data service. HUAWEI TECHNOLOGIES CO., LTD. Page 13... -
Page 14: Restoring Factory Data
1. On the Settings screen, touch Privacy > Factory data reset. 2. When prompted, touch Reset phone, and then touch Erase everything. The mobile phone resets the settings to the original factory settings, and then restarts. HUAWEI TECHNOLOGIES CO., LTD. Page 14... - Page 15 3. Your mobile phone will record the pattern. Touch Continue. 4. When prompted, draw the screen unlock pattern again, and then touch Confirm. To change your unlock screen pattern, touch Location & security > Change screen lock. HUAWEI TECHNOLOGIES CO., LTD. Page 15...
- Page 16 Installing SIM and TF Cards Page 16 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
-
Page 17: Using The Microsd Card As A Usb Mass Storage
When your microSD card acts as a USB mass storage, your mobile phone will not use this memory space. Ensure that you follow the correct procedures to disconnect the USB mass storage device (your mobile phone) from the PC when you have finished transferring files. HUAWEI TECHNOLOGIES CO., LTD. Page 17... -
Page 18: Using The Android Keyboard
Using the Android Keyboard > > > On the Home screen, touch Settings Language & keyboard Android > keyboard Voice input to turn on or turn off voice input. HUAWEI TECHNOLOGIES CO., LTD. Page 18... - Page 19 Using the Swype Keyboard(Optional) HUAWEI TECHNOLOGIES CO., LTD. Page 19...
-
Page 20: Locking And Unlocking The Screen
2. Drag the lock icon from left to right to unlock the screen. If you have set up a screen unlock pattern, you will be prompted to draw pattern on the screen to unlock it. HUAWEI TECHNOLOGIES CO., LTD. Page 20... -
Page 21: Service Shortcuts
Service Shortcuts 1. Open the notification bar. 2. Touch at the top of the screen to switch data services on or off. You can also touch turn the corresponding services on or off. HUAWEI TECHNOLOGIES CO., LTD. Page 21... - Page 22 Pressing the VOLUME UP key and VOLUME DOWN key, and then press the POWER key to power on the phone and enter the Software Upgrade Mode. 2 Enter to Settings->Privacy>Factory data reset->Reset phone->Erase everything，to reset to factory settings to recovery the operation system. HUAWEI TECHNOLOGIES CO., LTD.
- Page 23 Content Chapter 1 U9200E Product Introduction Chapter 2 U9200E Main Features Chapter 3 Operation skills Chapter 4 Trouble Shooting Chapter 5 About Technical Support HUAWEI TECHNOLOGIES CO., LTD. Page 23...
- Page 24 U9200E Trouble Shooting Page 24 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential...
- Page 25 Content Chapter 1 U9200E Product Introduction Chapter 2 U9200E Main Features Chapter 3 Operation skills Chapter 4 Trouble Shooting Chapter 5 About Technical Support HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential Page 25...
-
Page 26: Technical Support
Technical Support • Huawei Device Official Website http://www.huaweidevice.com • Huawei Device E-mail E-mail： mobile@huawei.com • Huawei Device Forum http://www.huaweidevice.com/cn/technicaIndex.do Page 26 HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential... - Page 27 Thank you www.huawei.com...
