SERVICE MANUAL
This model is classified as a
This Service Manual describes replacement parts for the green product. When repairing this
green product, use the part(s) described in this manual and
For (*1) and (*2), refer to
SOLDER.
© TOSHIBA CORPORATION
file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.628\37H...
LCD Color Television
37HLC56
green product
(*1), as indicated by the underlined serial number.
GREEN PRODUCT PROCUREMENT
Ver. 1.01
lead-free solder
(*2).
and
LEAD-FREE
Стр. 1 из 1
10.05.2015

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 37HLC56

Summary of Contents for Toshiba 37HLC56

  • Page 1 This Service Manual describes replacement parts for the green product. When repairing this green product, use the part(s) described in this manual and lead-free solder (*2). For (*1) and (*2), refer to GREEN PRODUCT PROCUREMENT LEAD-FREE SOLDER. © TOSHIBA CORPORATION file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.628\37H... 10.05.2015...

  • Page 2: Green Product Procurement

    Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.

  • Page 3: Lead-Free Solder

    Стр. 1 из 1 LEAD-FREE SOLDER This product is manufactured using lead-free solder as a part of a movement within the consumer products industry at large to be environmentally responsible. Lead-free solder must be used in the servicing and repair of this product. WARNING: This product is manufactured using lead free solder.

  • Page 4: Important Notice

    Through WEB, ver. 6.5 has been released but with it, the linking function in this manual may not work properly. If ver. 6.5 has been installed, uninstall it and reinstall ver. 6.0. To get ver. 6.0, click the icon, or contact to the nearest Toshiba Service Centre for further assistance. Freezing windows opened (Cannot close the open windows) This may happen occasionally.
  • Page 5 Стр. 2 из 2 Continue to use by operating the windows. Precaution when opening the diagrams While opening the diagrams, the menu in the left frame changes its color to GRAY. This is an indication that the viewer is processing. With this condition, the menu indication color may stick to the GRAY color or Windows may freeze if clicking other menu.
  • Page 6 Стр. 1 из 4 IMPORTANT NOTICE User Guide Autodesk® DWF™ Viewer is necessary to view drawings and to activate the functions of this system. Please download and install. When Windows XP SP2 is used, pop-up windows are limited by the enhanced security function and this sample may not work.

  • Page 7: Operating Environment

    Стр. 2 из 4 Operating Environment : Pentium III or higher recommended Monitor : 1024 x 768 or higher resolution recommended file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.248\37H... 10.05.2015...
  • Page 8 Стр. 3 из 4 Mouse : A mouse with wheel recommended : Microsoft Windows 2000/XP Browser Microsoft Internet Explorer 6.0 or later Drawing viewer : Autodesk DWF Viewer 6.0 * Use the software following respective license terms and conditions. Note: In case of using this service manual with network connection, allocate its folder to the client PCs as network drive to avoid any possible malfunction.
  • Page 9 Стр. 4 из 4 Layer Display Changing Function When any of the color buttons on the toolbar is clicked, it can be selected to display desired layer in its color or not to display each layer. This allows you to see the pattern layer only by setting other layers to "non-display".
  • Page 10 WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.

  • Page 11: Service Mode

    Стр. 1 из 10 ADJUSTMENT Service Mode Entering to Service Mode 1. Set VOLUME to minimum and press MUTE button once on remote control. ↓ ↓ ↓ ↓ 2. Press MUTE button again and hold button down. ↓ ↓ ↓ ↓ Service Mode display 3.
  • Page 12 Стр. 2 из 10 Displaying the Adjustment Menu Press MENU button on TV. Service Mode Press ↑ ↑ ↑ ↑ ↓ ↓ ↓ ↓ Press Adjustment Mode Key Function in the Service Mode The following key entry during display of adjustment menu provides special functions. CAUTION: Never try to perform initialization unless you have changed the memory IC.
  • Page 13 Стр. 3 из 10 Test signal selection Selection of the adjustment items (on TV or remote control) Change of the data value Volume +/- (on TV or remote control) Adjustment menu mode ON/OFF MENU button (on TV) Initialization of the memory (QA02) CALL + CH button on TV ( "RCUT"...
  • Page 14 Стр. 4 из 10 ← BCUT B CUT OFF ← RDRV R DRIVE ← GDRV G DRIVE ← BDRV B DRIVE ← BRTC BRIGHTNESS CENTER FDH ← COLC COLOR CENTER ← UVTT BASE BAND TINT ← CNTX CONTRAST MAX ← VOLUX MAX VOLUME LIMITED ←...

  • Page 15: Test Signal Selection

    Стр. 5 из 10 1. Enter the service mode, then select any register item. 2. Press and hold the CALL button on the remote control, then press the CH button on the TV. The initialization of QA02 has been completed. 3.

  • Page 16: Self-Diagnostic Function

    Стр. 6 из 10 All White Self Diagnostic Function 1. Press "9" button on remote control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC's is executed properly. 2. During diagnosis, the following displays are shown. (1) Firmware : Version information of microprocessor In case of file name : HCL56 and Version : 0459 indicates [HLC56_0459].
  • Page 17 Стр. 7 из 10 (5) Block V1 - V4 : VIDEO 1-4 input mode : PC mode HLC56 Video1/ ColorStreamHD1 (Composite/Component) Video2 (Composite/S-VIDEO) ColorStreamHD2 (Component) HDMI Version Check Mode 1. Press "9" button twice on remote control during display of adjustment menu in the service mode.
  • Page 18 Стр. 8 из 10 (1) MAIN MPU : Version information of microprocessor In case of file name : HLC56, Version 4569 for Code Program Version and (U01) for OSD Version indicates [HLC56_0459(U01)] (2) EEPROM : Version information of EEPROM : Display 1 byte data. (3) SUB MPU : Version information of SUB MPU : Display 1 byte data.
  • Page 19 Стр. 9 из 10 Panel Vender Screen Size (Inch) Example : AUO-32 indicates that Vender is AUO and Screen Size is 32 inch. Status Check Mode 1. Press "9" button thrice on remote control during display of adjustment menu in the service mode.

  • Page 20: Led Indication

    Стр. 10 из 10 TheaterWide 2 TheaterWide 3 FULL NATURAL 4:3 HD (4) OTHER STATUS : Other status information : Display three numbers of 2 byte data. LED Indication Red LEDs on the TV (at the bottom center of the TV) indicate the TV's status, as described below.
  • Page 21 Стр. 1 из 2 FUNCTION AND OPERATION Front and Side Panel Control and Connection file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.555\37H... 10.05.2015...
  • Page 22 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.555\37H... 10.05.2015...

  • Page 23: Function And Operation

    Стр. 1 из 3 FUNCTION AND OPERATION Learning about the Remote Control file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.495\37H... 10.05.2015...
  • Page 24 Стр. 2 из 3 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.495\37H... 10.05.2015...
  • Page 25 Стр. 3 из 3 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.495\37H... 10.05.2015...
  • Page 26 Стр. 1 из 2 FUNCTION AND OPERATION Using the Remote Control to Operate Your Other Device file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.734\37H... 10.05.2015...
  • Page 27 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.734\37H... 10.05.2015...

  • Page 28: Safety Instruction

    Handling the LCD Module Стр. 1 из 4 SAFETY INSTRUCTION Handling the LCD Module Safety Precaution In the event that the screen is damaged or the liquid crystal (fluid) leaks, do not breathe in or drink this fluid. Also, never touch this fluid. Such actions could cause toxicity or skin irritation. If this fluid should enter the mouth, rinse the mouth thoroughly with water.
  • Page 29 Handling the LCD Module Стр. 2 из 4 3. If the panel surface becomes soiled, wipe with cotton or a soft cloth. If this does not remove the soiling, breathe on the surface and then wipe again. If the panel surface is extremely solied, use a CRT cleaner as a cleaner. Wipe off the panel surface by drop the cleaner on the cloth.
  • Page 30 Handling the LCD Module Стр. 3 из 4 6. CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static electricity. When handling the module, use a wrist ground or anchor ground. 7. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for an extended period of time.
  • Page 31 Handling the LCD Module Стр. 4 из 4 10. When transporting the LCD module, do not use packing containing epoxy resin (amine) or silicon resin (alcohol or oxim). The gas generated by these materials can cause loss of polarity. file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.679\37H... 10.05.2015...

  • Page 33: Safety Precaution

    SAFETY INSTRUCTION [LCD] USA Стр. 1 из 3 SAFETY INSTRUCTION WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" INSTRUCTIONS BELOW. Safety Precaution WARNING: SERVICING SHOULD NOT BE ATTEMPTED BY ANYONE UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER. THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED BEFORE SERVICING THIS CHASSIS.
  • Page 34 SAFETY INSTRUCTION [LCD] USA Стр. 2 из 3 inflammability, voltage resistance, etc. therefore, use only replacement parts that have these same characteristics. Use only the specified parts when the mark is indicated in the circuit diagram or parts list. 7. Parts mounting and routing dressing of wirings should be the same as that used originally.

  • Page 35: Product Safety Notice

    SAFETY INSTRUCTION [LCD] USA Стр. 3 из 3 limit constitutes a potential shock hazard and must be corrected immediately. Product Safety Notice Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.

  • Page 36: Specification

    Стр. 1 из 2 SPECIFICATION file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.754\37H... 10.05.2015...
  • Page 37 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.754\37H... 10.05.2015...
  • Page 50 SIGNAL BOARD AV BOARD PANEL DDR RAM FLI8538 CORTEZ Plus VBI Data Processor PANEL I/F DCDi Video Input Analog MADi Decoder Front Terminal Scaling (Audio) (16port) LVDS CVBS(L/R) S-VIDEO(L/R) YCbCr(L/R) Channel Standby Process uCON Digital Input A EEPROM PC_IN(L/R) Digital Input B Micro- processor...

  • Page 51: Schematic Diagram

    Стр. 1 из 2 SCHEMATIC DIAGRAM Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit...
  • Page 52 Стр. 2 из 2 All capacitors are ceramic 50 V, unless otherwise noted as the following marks. = Electrolytic capacitor = Mylar capacitor 3. The parts indicated with " " have special characteristics, and should be replaced with identical parts only. 4.
  • Page 106 Accessory Стр. 1 из 1 Accessory Location Parts No. Description Y101 75002949 MANUAL ENG/FRE, OM Y109 23945015 BAG, POLYETHYLENE COVER 250X400 Y130 75002548 REMOCON HAND UNIT, CT-90262 Y170 23845800 HOLDER, WIRE, NYLON66 D6.8 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.413\37H... 10.05.2015...
  • Page 107 Cabinet Стр. 1 из 1 Cabinet Location Parts No. Description A201 75002988 CESE/COVER/LID FRONT BEZEL ASSY A315 75002076 PIECE, C COVER ASSY A320 75002550 PIECE, FRONT AV ASSY A340 75001920 PIECE, BUTTON 7 KEY A380 23717240 SCREW, BITTB3X10SZN A401 75002987 CESE/COVER/LID BACK COVER ASSY A410 23717219...
  • Page 108 Miscellaneous Стр. 1 из 1 Miscellaneous Location Parts No. Description B001 75001858 DISPLAY, G6AUO37 V2 P801 75002678 POWER CORD, INQ2682(1) PJ22B 75001874 CONNECTOR, B-B PLUG PP01 23845859 HOLDER, WIRE, PVC-C0AT, L=70MM PP08 23974994 BAND, KESSOKU W661 23351292 SPEAKER, SPK1410AM, 60X120 8-OHM 10W Z601 23103841 FERRITE CORE, TFE1014...
  • Page 109 Packing Стр. 1 из 1 Packing Location Parts No. Description A701 75002989 CARTON TOP CASE A701B 75002571 CARTON BOX, BOTTOM A702A 75002572 PACKING, TOP PAD A702B 75002573 PACKING, BOTTOM PAD A703 23945216 BAG, LAMIFILM BAG A705 23518043 PACKING, JOINT A709 75002346 PACKING, CENTER PAD file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.489\37H...

  • Page 110: Parts List

    Стр. 1 из 2 PARTS LIST Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit...
  • Page 111 Стр. 2 из 2 : Electrolytic : Metal Film : Fusible Resistor All CD and PF capacitors are ±5 %, 50 V and all resistor, ±5 %, 1/6 W unless otherwise noted. file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.092\37H... 10.05.2015...
  • Page 112 U01 SIGNAL (PE0081) Стр. 1 из 7 Loading ... Location Parts No. Description 75004725 PC BOARD ASSY, PE0081E1, SIGNAL C301 V01GD0000896 CHIP RESISTOR (1608) C302 V01GD0000896 CHIP RESISTOR (1608) C303 V01GD0000896 CHIP RESISTOR (1608) C304 V01GD0000896 CHIP RESISTOR (1608) C305 V01GD0000896 CHIP RESISTOR (1608) C306 V01GD0000896 CHIP RESISTOR (1608)
  • Page 113 U01 SIGNAL (PE0081) Стр. 2 из 7 C375 V03GD0000578 CHIP CERAMIC CAPACITOR (1608) C376 V03GD0000541 CHIP CERAMIC CAPACITOR (1608) C377 V03GD0000541 CHIP CERAMIC CAPACITOR (1608) C378 V03GD0000741 CHIP CERAMIC CAPACITOR (3216) C379 V03GD0000741 CHIP CERAMIC CAPACITOR (3216) C380 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C381 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C401...
  • Page 114 U01 SIGNAL (PE0081) Стр. 3 из 7 C491 V03A000003Q0 CAPACITOR C492 V03A000003Q0 CAPACITOR C493 V03A000003Q0 CAPACITOR C494 V03A000004Q0 CAPACITOR CHIP CERA 25V 104S 3 C495 V03GD0000585 CHIP CERAMIC CAPACITOR (1608) C496 V03GD0000585 CHIP CERAMIC CAPACITOR (1608) C773 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C774 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C775...
  • Page 115 U01 SIGNAL (PE0081) Стр. 4 из 7 C947 V03A000003Q0 CAPACITOR C948 V03A000003Q0 CAPACITOR C949 V03A000003Q0 CAPACITOR C950 V03A000003Q0 CAPACITOR C951 V03GD0001192 CHIP CERAMIC CAPACITOR (1005) C953 V03GD0001126 CHIP CERAMIC CAPACITOR (1608) C2000 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C2001 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C2002 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C2003...
  • Page 116 U01 SIGNAL (PE0081) Стр. 5 из 7 C3414 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3415 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3416 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3417 V03GD0000589 CHIP CERAMIC CAPACITOR (1608) C3418 V03GD0000589 CHIP CERAMIC CAPACITOR (1608) C3419 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3420 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3421...
  • Page 117 U01 SIGNAL (PE0081) Стр. 6 из 7 C7909 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7910 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7911 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7912 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7913 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C7914 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C7915 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C7916...
  • Page 118 U01 SIGNAL (PE0081) Стр. 7 из 7 C7950 V03GD0000827 CHIP CERAMIC CAPACITOR (1608) C7951 V03GD0000827 CHIP CERAMIC CAPACITOR (1608) C7952 V03GD0000827 CHIP CERAMIC CAPACITOR (1608) C7953 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7954 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7955 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7956 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7957...
  • Page 119 U01A POWER (PE0103) Стр. 1 из 4 U01A POWER (PE0103) Location Parts No. Description U01A 75002985 PWB, POWER, B910PE0103E1 C801 76503507 PLASTIC FILM, AC275V 0.22UF K C802 76503507 PLASTIC FILM, AC275V 0.22UF K C803 76168103 PLASTIC FILM, 400V 0.22UF J C804 76214103 CERAMIC DISC, 500V B 0.01UF K...
  • Page 120 U01A POWER (PE0103) Стр. 2 из 4 CE43 76503041 PLASTIC FILM, 63V 0.1UF J CE85 76073178 ELECTROLYTIC, 25V 3300UF M D801 23362200 DIODE, D5SB60, 7009F07 D801B 23717240 SCREW, BITTB3X10SZN D805 23357627 DIODE, ZENER, RD9.1ESA B1 D806 23357666 DIODE, ZENER, RD27ESA B3 D809 23357654 DIODE, ZENER, RD36ESA B3...
  • Page 121 U01A POWER (PE0103) Стр. 3 из 4 L801 23217834 TRANSFORMER, CHOKE, TPW2078AS L802 23217792 TRANSFORMER, CHOKE, TPW2072AS L806 23248417 COIL, CHOKE, TLN3481AH L807 23248417 COIL, CHOKE, TLN3481AH L874 23103302 FERRITE CHOKE, TEM2011AH L875 23103302 FERRITE CHOKE, TEM2011AH L876 23103302 FERRITE CHOKE, TEM2011AH L878 23103302 FERRITE CHOKE, TEM2011AH...
  • Page 122 U01A POWER (PE0103) Стр. 4 из 4 R821 76553680 OXIDE METAL FILM, 1W 68 OHM J R827 76383103 OXIDE METAL FILM, 2W 10K OHM J R853 76011103 CHIP, 1/20W 10K OHM J R854 76011102 CHIP, 1/20W 1K OHM J R869 76011472 CHIP, 1/20W 4.7K OHM J R873...
  • Page 123 U01B LOWB (PE0103) Стр. 1 из 2 U01B LOWB (PE0103) Location Parts No. Description U01B 75002986 PWB, LOWB, B910PE0103E2 C851 76092538 CERAMIC CHIP, 10V F 1UF Z C852 76109102 CERAMIC CHIP, 50V B 1000PF K CE40 76073183 ELECTROLYTIC, 35V 220UF M CE42 76539104 PLASTIC FILM, 50V 0.1UF J...
  • Page 124 U01B LOWB (PE0103) Стр. 2 из 2 QE53 23205330 TRANSISTOR, RN1403(F) QE64 23085415 IC, BD4746G QE71 75001881 IC, CE-1059 QE74 23205330 TRANSISTOR, RN1403(F) QE82 23205446 TRANSISTOR, 2SC2412K, Q T146 QE90 23085423 IC, KIA7809API-U/P QE90B 23717240 SCREW, BITTB3X10SZN QE95 23205330 TRANSISTOR, RN1403(F) QE96 75001876 TRANSISTOR, TPC8111(TE12L, Q)
  • Page 125 U02A AV TERM (PE0102) Стр. 1 из 7 Loading ... Location Parts No. Description U02A 75002972 PWB, AV THERM, B910PE0102C1 C192 76109103 CERAMIC CHIP, 50V B 0.01UF K C414 76794470 ELECTROLYTIC, 16V 47UF M C415 76100104 CERAMIC CHIP, 25V F 0.1UF Z C416 76092731 CERAMIC CHIP, 16V B 1UF K...
  • Page 126 U02A AV TERM (PE0102) Стр. 2 из 7 C665 76669339 ELECTROLYTIC, 50V 3.3UF M C666 76669339 ELECTROLYTIC, 50V 3.3UF M C677 76109391 CERAMIC CHIP, 50V B 390PF K C678 76109391 CERAMIC CHIP, 50V B 390PF K C685 76669010 ELECTROLYTIC, 50V 1UF M C685A 23960136 ADHESIVE, SILICONE, TSE3843-W...
  • Page 127 U02A AV TERM (PE0102) Стр. 3 из 7 CG22 76669100 ELECTROLYTIC, 50V 10UF M CG23 76109103 CERAMIC CHIP, 50V B 0.01UF K CG24 76797339 ELECTROLYTIO, 50V 3.3UF M CG25 76092730 CERAMIC CHIP, 16V B 0.1UF K CG26 76092726 CERAMIC CHIP, 10V B 2.2UF K CG27 76092726 CERAMIC CHIP, 10V B 2.2UF K...
  • Page 128 U02A AV TERM (PE0102) Стр. 4 из 7 D625 23362140 DIODE, KDS160-RTK D626 23362214 DIODE, SCHOTTKY, RSX301L-30 TE25 D627 23362214 DIODE, SCHOTTKY, RSX301L-30 TE25 D628 23362140 DIODE, KDS160-RTK D640 23362140 DIODE, KDS160-RTK D642 23362140 DIODE, KDS160-RTK D650 23357778 DIODE, ZENER, MA8150-M D652 23357747 DIODE, ZENER, MA8062-L...
  • Page 129 U02A AV TERM (PE0102) Стр. 5 из 7 LG01 23103825 INDUCTOR, BEAD, TEM2118M LG02 23103825 INDUCTOR, BEAD, TEM2118M P601 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 PJ22A 75001873 CONNECTOR, B-B RECEPTACLE PJ80A 23023384 PLUG, TWG-P13P-A1 PV011 75001871 JACK PIN 6/6P+OS ST PV021 75001872 JACK PIN 10/10P ST...
  • Page 130 U02A AV TERM (PE0102) Стр. 6 из 7 QG05 23085576 IC, OP AMP, BA4558F QS01 23009614 IC, CD4053BNSR QS04 23205329 TRANSISTOR, RN1404(F) QS24 23205302 TRANSISTOR, 2SC3326-B(F) QS25 23205302 TRANSISTOR, 2SC3326-B(F) QS26 23205325 TRANSISTOR, RN2404(F) QV16 23085823 IC, MM1508XNRE R459 76011101 CHIP, 1/20W 100 OHM J R460 76011222...
  • Page 131 U02A AV TERM (PE0102) Стр. 7 из 7 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.333\37H... 10.05.2015...
  • Page 132 U02B FRONT AV-1 (PE0102) Стр. 1 из 1 U02B FRONT AV-1 (PE0102) Location Parts No. Description U02B 75002973 PWB, FRONT AV-1, B910PE0102C2 CC11 76109102 CERAMIC CHIP, 50V B 1000PF K CC12 76109102 CERAMIC CHIP, 50V B 1000PF K CV12 76109103 CERAMIC CHIP, 50V B 0.01UF K CV13 76105101...
  • Page 133 U02C LED (PE0102) Стр. 1 из 1 U02C LED (PE0102) Location Parts No. Description U02C 75002974 PWB, LED, B910PE0102C3 CB02 76202221 ELECTROLYTIC, 10V 220UF M CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z CB05 76202221 ELECTROLYTIC, 10V 220UF M...
  • Page 134 U02D KEY (PE0102) Стр. 1 из 1 U02D KEY (PE0102) Location Parts No. Description U02D 75002975 PWU, KEY, B910PE0102C4 DA01 23362042 DIODE, ZENER, UDZS6.8B DA06 23362042 DIODE, ZENER, UDZS6.8B DA07 23362042 DIODE, ZENER, UDZS6.8B PJ42A 23713948 CONNECTOR, S6B-PH-K-S(LF) RA71 76011683 CHIP, 1/20W 68K OHM J RA72 76011223...
