  • Page 1 User Manual DAP-1360U Wireless N300 Access Point & Router December 2018...

  • Page 2: Table Of Contents

    DAP-1360U Wireless N300 Access Point & Router User Manual Contents Chapter 1. Introduction..........4 Contents and Audience............4 Conventions..............4 Document Structure............4 Chapter 2. Overview..........5 General Information............5 Specifications..............6 Product Appearance............9 Top Panel..............9 Back and Bottom Panels...........10 Delivery Package............11 Chapter 3. Installation and Connection......12 Before You Begin............12...
  • Page 3 DAP-1360U Wireless N300 Access Point & Router User Manual Connections Setup............60 WAN..............60 Creating Dynamic IPv4 or Static IPv4 WAN Connection....62 Creating PPPoE WAN Connection..........66 Creating PPTP or L2TP WAN Connection........71 LAN..............75 Wi-Fi..............79 Basic Settings............79 Client Management............87 WPS..............88 Using WPS Function via Web-based Interface......90 Using WPS Function without Web-based Interface......91...

  • Page 4: Chapter 1. Introduction

    Chapter 2 gives an overview of the device's hardware and software features, describes its appearance and the package contents. Chapter 3 explains how to install the access point DAP-1360U and configure a PC in order to access its web-based interface.

  • Page 5: Chapter 2. Overview

    You are able to connect the wireless access point DAP-1360U switched to the router mode to a cable or DSL modem or to a private Ethernet line and use a high-speed Internet connection to successfully fulfill a wide range of professional tasks.

  • Page 6: Specifications

    DAP-1360U Wireless N300 Access Point & Router Overview User Manual Specifications Hardware Processor · RTL8196D (620MHz) · 32MB, SDRAM Flash · 4MB, SPI Interfaces · 10/100BASE-TX WAN port · 4 10/100BASE-TX LAN ports · LEDs POWER · WLAN · ·...
  • Page 7 Local and remote access to settings through TELNET/WEB (HTTP/HTTPS) · Bilingual web-based interface for configuration and management (Russian/English) · Support of D-Link Assistant application for Android and iPhone smartphones · Firmware update via web-based interface · Automatic notification on new firmware version ·...
  • Page 8 DAP-1360U Wireless N300 Access Point & Router Overview User Manual Wireless Module Parameters · Receiver sensitivity 802.11b (typical at PER = 8% at room temperature 25 °C) -82dBm at 1Mbps -80dBm at 2Mbps -78dBm at 5.5Mbps -76dBm at 11Mbps ·...

  • Page 9: Product Appearance

    DAP-1360U Wireless N300 Access Point & Router Overview User Manual Product Appearance Top Panel Figure 1. Top panel view. Mode Description The device is powered on. Solid green POWER The device is powered off. No light The device's WLAN is on.

  • Page 10: Back And Bottom Panels

    DAP-1360U Wireless N300 Access Point & Router Overview User Manual Back and Bottom Panels Figure 2. Back panel view. Name Description ON/OFF A button to turn the device on/off. 12VDC IN Power connector. A button to set up a wireless connection (the WPS function) and enable/disable the wireless network.

  • Page 11: Delivery Package

    • “Quick Installation Guide” (brochure). • The “User Manual” and “Quick Installation Guide” documents are available on D-Link website (see www.dlink.ru). Using a power supply with a different voltage rating than the one included will cause damage and void the warranty for this product.

  • Page 12: Chapter 3. Installation And Connection

    Operating System Configuration of the access point DAP-1360U supporting the router mode (hereinafter referred to as “the access point”) is performed via the built-in web-based interface. The web-based interface is available from any operating system that supports a web browser.

  • Page 13: Connecting To Pc

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Connecting to PC PC with Ethernet Adapter 1. Connect an Ethernet cable between any of LAN ports located on the back panel of the access point and the Ethernet port of your PC.

  • Page 14: Configuring Ip Address In Os Windows 7

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Configuring IP Address in OS Windows 7 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category...
  • Page 15 DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual 3. In the menu located on the left part of the window, select the Change adapter settings line. Figure 4. The Network and Sharing Center window. Page 15 of 158...
  • Page 16 DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual 4. In the opened window, right-click the relevant Local Area Connection icon and select the Properties line in the menu displayed. Figure 5. The Network Connections window. Page 16 of 158...
  • Page 17 DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual 5. In the Local Area Connection Properties window, on the Networking tab, select the Internet Protocol Version 4 (TCP/IPv4) line. Click the Properties button. Figure 6. The Local Area Connection Properties window.
  • Page 18 7. Click the OK button in the connection properties window. Now you can connect to the web-based interface of DAP-1360U for configuring all needed parameters. To gain access to an external network (to the Internet), you also need to specify the default gateway and the addresses of DNS servers.

  • Page 19: Pc With Wi-Fi Adapter

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual PC with Wi-Fi Adapter 1. Attach the antennas from the delivery package. To do this, remove the antennas from their wrapper, attach them to the relevant connectors on the back panel of the access point, and then screw the antennas in a clockwise direction to the back panel.

  • Page 20: Configuring Wi-Fi Adapter In Os Windows 7

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Configuring Wi-Fi Adapter in OS Windows 7 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category...
  • Page 21 DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual 5. In the Wireless Network Connection Properties window, on the Networking tab, select the Internet Protocol Version 4 (TCP/IPv4) line. Click the Properties button. 6. Select the Use the following IP address radio button and enter the value 192.168.0.51 in the IP address field.
  • Page 22 11. Wait for about 20-30 seconds. After the connection is established, the network icon will be displayed as the signal level scale. Now you can connect to the web-based interface of DAP-1360U for configuring all needed parameters. To gain access to an external network (to the Internet), you also need to specify the default gateway and the addresses of DNS servers.

  • Page 23: Connecting To Web-Based Interface

    Enter key. Also you can enter the IP address of the device (by default, 192.168.0.50). Figure 12. Connecting to the web-based interface of the DAP-1360U device. If the error “ The page cannot be displayed ” (or “ Unable to display the page ”/“ Could not connect to remote server ”) occurs upon connecting to the web-based interface of the access...
  • Page 24 DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual If you configured the device previously, after access to the web-based interface the login page opens. Enter the username (admin) in the Username field and the password you specified in the Password field, then click the LOGIN button.

  • Page 25: Web-Based Interface Structure

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Web-based Interface Structure The operating mode defines available sections and pages of the web-based interface. Summary Page On the Summary page, detailed information on the device state is displayed.
  • Page 26 DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual The Device Information section displays the model and hardware version of the access point, the firmware version, and other data. To contact the technical support group (to send an e-mail), left-click the support e-mail address.

  • Page 27: Home Page

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Home Page This page is available for the Router and WISP Repeater modes. The Home page displays links to the most frequently used pages with device's settings. Figure 16. The Home page.

  • Page 28: Menu Sections

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Menu Sections To configure the access point use the menu in the left part of the page. In the Initial Configuration section you can run the Initial Configuration Wizard. The Wizard...

  • Page 29: Notifications

    DAP-1360U Wireless N300 Access Point & Router Installation and Connection User Manual Notifications The access point's web-based interface displays notifications in the top right part of the page. Figure 17. The web-based interface notifications. Click the icon displaying the number of notifications to view the complete list and click the relevant button.

  • Page 30: Chapter 4. Configuring Via Web-Based Interface

    If you perform initial configuration of the access point via Wi-Fi connection, please make sure that you are connected to the wireless network of DAP-1360U (see the WLAN name (SSID) on the barcode label on the bottom panel of the device) and click the NEXT button.
  • Page 31 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual On the opened page, click YES in order to leave the current language of the web-based interface or click NO to select the other language. Figure 21. Selecting a language.

  • Page 32: Selecting Operation Mode

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Selecting Operation Mode In order to connect your device to a wired router for adding a wireless network to the existing local network, on the Device mode page, from the Connection method list, select the Wired connection value.
  • Page 33 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In order to let wired PCs connected to your device access the network of a wireless router, on the Device mode page, from the Connection method list, select the Wi-Fi value. Then from the Work mode list select the Client value.
  • Page 34 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In order to connect your device to a wired ISP, on the Device mode page, from the Connection method list, select the Wired connection value. Then from the Work mode list select the Router value.

  • Page 35: Configuring Wds Function

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Configuring WDS Function This configuration step is available for the WDS mode. 1. On the WDS page, in the WDS Mode list, select the WDS function mode.

  • Page 36: Changing Lan Ipv4 Address

    If you want to manually assign the LAN IPv4 address for DAP-1360U, do not select the Automatic obtainment of IPv4 address checkbox and fill in the IP address, Netmask, Hostname fields and, if needed, the Gateway IP address field.

  • Page 37: Wi-Fi Client

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Wi-Fi Client This configuration step is available for the WISP Repeater, Repeater, and Client modes. 1. On the Wi-Fi Сlient page, click the WIRELESS NETWORKS button and select the network to which you want to connect in the opened window.
  • Page 38 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Encryption key WEP as Select the checkbox to set a hexadecimal number as a key for encryption. Keys for WEP encryption. The router uses the key selected from the Encryption key Default key ID drop-down list.

  • Page 39: Configuring Wan Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Configuring WAN Connection This configuration step is available for the Router and WISP Repeater modes. You should configure your WAN connection in accordance with data provided by your Internet service provider (ISP).

  • Page 40: Static Ipv4 Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Static IPv4 Connection Figure 32. The page for configuring Static IPv4 WAN connection. Fill in the following fields: IP address, Netmask, Gateway IP address, and DNS IP address.

  • Page 41: Pppoe Or Pppoe + Dynamic Ip (Pppoe Dual Access) Connections

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual PPPoE or PPPoE + Dynamic IP (PPPoE Dual Access) Connections Figure 33. The page for configuring PPPoE WAN connection. In the Username field enter the login and in the Password field enter the password provided your ISP.

  • Page 42: Pppoe + Static Ip (Pppoe Dual Access) Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual PPPoE + Static IP (PPPoE Dual Access) Connection Figure 34. The page for configuring PPPoE + Static IP (PPPoE Dual Access) WAN connection. In the Username field enter the login and in the Password field enter the password provided your ISP.

  • Page 43: Pptp + Dynamic Ip Or L2Tp + Dynamic Ip Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual PPTP + Dynamic IP or L2TP + Dynamic IP Connection Figure 35. The page for configuring PPTP + Dynamic IP WAN connection. In the Username field enter the login and in the Password field enter the password provided by your ISP.

  • Page 44: Pptp + Static Ip Or L2Tp + Static Ip Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual PPTP + Static IP or L2TP + Static IP Connection Figure 36. The page for configuring PPTP + Static IP WAN connection. In the Username field enter the login and in the Password field enter the password provided by Click the Show icon ( your ISP.

  • Page 45: Configuring Wireless Network

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Configuring Wireless Network This configuration step is available for the Router, Access point, WISP Repeater, Repeater, and WDS modes. 1. On the Wireless Network 2.4 GHz page, in the Network name field, specify your own name for the wireless network or leave the value suggested by the access point.
  • Page 46 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual 5. If you want to create an additional wireless network isolated from your LAN, select the Enable guest network checkbox (available for the Router, and WISP Repeater modes only).

  • Page 47: Configuring Lan Ports For Iptv/Voip

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Configuring LAN Ports for IPTV/VoIP This configuration step is available for the Router and WISP Repeater modes. 1. On the IPTV page, select the Is an STB connected to the device checkbox.
  • Page 48 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual 5. On the VoIP page, select the Is an IP phone connected to the device checkbox. Figure 40. The page for selecting a LAN port to connect an VoIP phone.

  • Page 49: Changing Web-Based Interface Password

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Changing Web-based Interface Password On this page, you should change the default administrator password. To do this, enter a new password in the Admin password and Password confirmation fields. You may set any password except admin.
  • Page 50 If problems of connection have not been solved, contact the technical support of your ISP (as a rule, the technical support phone is provided with the agreement) or the D-Link technical support (the phone number is displayed on the Summary page).

  • Page 51: Connection Of Multimedia Devices

    The Multimedia Devices Connection Wizard helps to configure LAN ports or available wireless interfaces of the access point for connecting additional devices, for example, an IPTV set-top box or IP phone. Contact your ISP to clarify if you need to configure DAP-1360U in order to use these devices.
  • Page 52 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual If you need to configure a connection via VLAN, click the ADVANCED MODE button. Figure 44. The Multimedia Devices Connection Wizard. The advanced mode. In the WAN section, click the Add icon ( Figure 45.
  • Page 53 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the opened window, specify a name of the connection for easier identification in the Name field (you can specify any name). Specify the VLAN ID provided by your ISP and click the SAVE button.

  • Page 54: Statistics

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Statistics The pages of this section display data on the current state of the access point: network statistics • IP addresses leased by the DHCP server •...

  • Page 55: Dhcp

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual DHCP The Statistics / DHCP page displays the information on computers that have been identified by hostnames and MAC addresses and have got IP addresses from the DHCP server of the device, as well as the IP address expiration periods (the lease time).

  • Page 56: Routing Table

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Routing Table This page is available for the Router and WISP Repeater modes. The Statistics / Routing Table page displays the information on routes. The table contains destination IP addresses, gateways, subnet masks, and other data.

  • Page 57: Clients And Session

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Clients and Session On the Statistics / Clients and Session page, you can view the list of devices connected to the local network of the access point and information on current sessions of each device.

  • Page 58: Port Statistics

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Port Statistics On the Statistics / Port Statistics page, you can view statistics for traffic passing through ports of the access point. The information shown on the page can be used for diagnosing connection problems.

  • Page 59: Multicast Groups

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Multicast Groups The Statistics / Multicast Groups page displays addresses of active multicast groups (including IPTV channels and groups for transferring service information) to which the device is subscribed, and the interface through which the device is subscribed.

  • Page 60: Connections Setup

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Connections Setup In this menu you can configure basic parameters of the access point's local area network and configure connection to the Internet (a WAN connection). This page is available for the Router and WISP Repeater modes.
  • Page 61 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To use one of existing WAN connections as the default connection, in the Default Gateway section, select the choice of the radio button which corresponds to this connection.

  • Page 62: Creating Dynamic Ipv4 Or Static Ipv4 Wan Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Creating Dynamic IPv4 or Static IPv4 WAN Connection On the connection creation page, go to the All Settings tab. Then select the relevant value from the Connection type drop-down list and specify the needed values.
  • Page 63 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 55. The page for creating a new Static IPv4 connection. The Ethernet section. Parameter Description Ethernet A MAC address assigned to the interface. This parameter is mandatory if your ISP uses MAC address binding.
  • Page 64 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 56. The page for creating a new Static IPv4 connection. The IPv4 section. Parameter Description IPv4 For Static IPv4 type IP address Enter an IP address for this WAN connection.
  • Page 65 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 57. The page for creating a new Static IPv4 connection. The Miscellaneous section. Parameter Description Miscellaneous If the switch is moved to the right, the network address translation function is enabled.

  • Page 66: Creating Pppoe Wan Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Creating PPPoE WAN Connection On the connection creation page, go to the All Settings tab. Then select the relevant value from the Connection type drop-down list and specify the needed values.
  • Page 67 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 59. The page for creating a new PPPoE connection. The Ethernet section. Parameter Description Ethernet A MAC address assigned to the interface. This parameter is mandatory if your ISP uses MAC address binding. In the field, enter the MAC address registered by your ISP upon concluding the agreement.
  • Page 68 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 60. The page for creating a new PPPoE connection. The PPP section. Parameter Description Move the switch to the right if you don't need to enter a username Without authorization and password to access the Internet.
  • Page 69 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Move the switch to the right if you want the access point to establish connection to the Internet on demand. In the Maximum idle time...
  • Page 70 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 61. The page for creating a new PPPoE connection. The Miscellaneous section. Parameter Description Miscellaneous If the switch is moved to the right, the network address translation function is enabled.

  • Page 71: Creating Pptp Or L2Tp Wan Connection

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Creating PPTP or L2TP WAN Connection On the connection creation page, go to the All Settings tab. Then select the relevant value from the Connection type drop-down list and specify the needed values.
  • Page 72 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 63. The page for creating a new PPTP connection. The PPP section. Parameter Description Move the switch to the right if you don't need to enter a username Without authorization and password to access the Internet.
  • Page 73 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Select a method of MPPE encryption. No encryption: MPPE encryption is not applied. • MPPE 40/128 bit: MPPE encryption with a 40-bit or 128- •...
  • Page 74 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 64. The page for creating a new PPTP connection. The Miscellaneous section. Parameter Description Miscellaneous If the switch is moved to the right, the network address translation function is enabled.

  • Page 75: Lan

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To configure the router's local interface, go to the Connections Setup / LAN page. On this page, you can change IPv4 address, configure the built-in DHCP server, or specify MAC address and IP address pairs.
  • Page 76 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 66. Configuring the local interface. The IPv4 tab. The Dynamic IP Addresses section. Parameter Description Dynamic IP Addresses An operating mode of the access point's DHCP server.
  • Page 77 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Move the switch to the right so that the devices connected to the access point obtain the address of the access point as the DNS server address.
  • Page 78 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To remove a MAC-IPv4 pair, select the checkbox located to the left of the relevant line in the table and click the DELETE button ( ). Then click the APPLY button. Also you can remove a MAC-IPv4 pair in the editing window.

  • Page 79: Wi-Fi

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Wi-Fi In this menu you can specify all needed settings for your wireless network. Basic Settings In the Wi-Fi / Basic Settings section, you can change basic parameters for the wireless interface of the access point and configure the basic and additional wireless networks.
  • Page 80 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the General Settings section, the following parameters are available: Parameter Description To enable Wi-Fi connection, move the switch to the right. Enable Wireless To disable Wi-Fi connection, move the switch to the left.
  • Page 81 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To edit the settings of the basic wireless network, in the Wi-Fi Network section, change the needed parameters and click the APPLY button. Also you can create an additional wireless network. To do this, click the ADD WI-FI NETWORK button.
  • Page 82 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Wi-Fi Network A name for the wireless network. The name can consist of digits and Network name (SSID) Latin characters. If the switch is moved to the right, other users cannot see your Wi-Fi Hide SSID network.
  • Page 83 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the Security Settings section, you can change security settings of the wireless network. By default, the WPA2-PSK network authentication type of the wireless network is specified. WPS PIN from the barcode label is used as the network key.
  • Page 84 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual The WPA , WPA2 , and WPA/WPA2 mixed authentication types require a RADIUS server. When the Open or WEP value is selected, the following settings are displayed on the page (unavailable for the wireless network operating modes which support the standard 802.11n):...
  • Page 85 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual When the WPA-PSK, WPA2-PSK, or WPA-PSK/WPA2-PSK mixed value is selected, the following fields are displayed on the page: Figure 72. The WPA2-PSK value is selected from the Network authentication drop-down list.
  • Page 86 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual When the WPA, WPA2, or WPA/WPA2 mixed value is selected, the following settings are displayed on the page: Figure 73. The WPA2 value is selected from the Network authentication drop-down list.

  • Page 87: Client Management

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Client Management On the Wi-Fi / Client Management page, you can view the list of wireless clients connected to the access point. Figure 74. The page for managing the wireless clients.

  • Page 88: Wps

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual On the Wi-Fi / WPS page, you can enable the function for configuration of the WLAN and select a method for connection to the WLAN. The WPS function helps to configure the protected wireless network automatically. Devices connecting to the wireless network via the WPS function must support the WPS function.
  • Page 89 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual When the WPS function is enabled, the Information section is available on the page. Parameter Description The state of the WPS function: Configured (all needed settings are specified; these settings •...

  • Page 90: Using Wps Function Via Web-Based Interface

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Using WPS Function via Web-based Interface To connect to the basic wireless network via the PIN method of the WPS function, follow the next steps: 1. Click the ENABLE WPS button.

  • Page 91: Using Wps Function Without Web-Based Interface

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Using WPS Function without Web-based Interface You can use the WPS function without accessing the web-based interface of the access point. To do this, you need to configure the following access point's settings: 1.

  • Page 92: Wds

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual This page is available for the Access point, Repeater, WDS, and Client modes. On the Wi-Fi / WDS page, you can enable the WDS function and select a mode of this function.
  • Page 93 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description The MAC address of The MAC address of the access point. this point in 2.4 GHz The MAC addresses of devices connected to the access point via the WDS function.

  • Page 94: Wmm

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual On the Wi-Fi / WMM page, you can enable the Wi-Fi Multimedia function. The WMM function implements the QoS features for Wi-Fi networks. It helps to improve the quality of data transfer over Wi-Fi networks by prioritizing different types of traffic.
  • Page 95 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual The WMM function allows assigning priorities for four Access Categories (AC): BK (Background), low priority traffic (print jobs, file downloads, etc.). • BE (Best Effort), traffic from legacy devices or devices/applications that do not support •...
  • Page 96 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Transmission Opportunity. The higher the value, the higher is the TXOP Access Category priority. Admission Control Mandatory. If the switch is moved to the right, the device cannot use the relevant Access Category.

  • Page 97: Client

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Client This page is available for the Router, Access point, WISP Repeater, Repeater, and Client modes. On the Wi-Fi / Client page, you can configure the device as a client to connect to a wireless access point or to a WISP.
  • Page 98 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the Wireless Networks section, the list of available wireless networks is displayed. To view the latest data on available wireless networks, click the UPDATE LIST button.
  • Page 99 An encryption method: TKIP, AES, or TKIP+AES. When you have configured the parameters, click the APPLY button. When connecting to a wireless access point, the wireless channel of DAP-1360U will switch to the channel of the access point to which you have connected.

  • Page 100: Client Shaping

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Client Shaping On the Wi-Fi / Client Shaping page, you can limit the maximum bandwidth of upstream and downstream traffic for each wireless client of the access point by its MAC address.
  • Page 101 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description If the switch is moved to the right, the rule is active. Enabled Move the switch to the left to disable the rule.

  • Page 102: Additional

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Additional On page of the Wi-Fi / Additional section, you can define additional parameters for the WLAN of the access point. Changing parameters presented on this page may negatively affect your WLAN! Figure 82.
  • Page 103 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual The following fields are available on the page: Parameter Description The channel bandwidth for 802.11n standard in the 2.4GHz band. Bandwidth 20 MHz: 802.11n clients operate at 20MHz channels.
  • Page 104 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description The time interval (in milliseconds) between packets sent to Beacon period synchronize the wireless network. The minimum size (in bytes) of a packet for which an RTS frame is RTS threshold transmitted.

  • Page 105: Mac Filter

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual MAC Filter On the Wi-Fi / MAC Filter page, you can define a set of MAC addresses of devices which will be allowed to access the WLAN, or define MAC addresses of devices which will not be allowed to access the WLAN.
  • Page 106 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 84. The window for adding a rule for the MAC filter. You can specify the following parameters: Parameter Description A wireless network to which the rule will be applied. Select the SSID needed value from the drop-down list.

  • Page 107: Roaming

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Roaming On the Wi-Fi / Roaming page, you can enable the function of smart adjustment of Wi-Fi clients. This function is designed for wireless networks based on several access points or routers. If the function is enabled for all access points (routers) which establish a wireless network, then wireless clients will always connect to the device with the highest signal level.
  • Page 108 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Move the switch to the right in order to use multicast traffic for service data exchange between access points (routers). This setting is needed if the devices which support the smart adjustment function are located in different subnets.

  • Page 109: Advanced

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Advanced In this menu you can configure advanced settings of the access point: create groups of ports for VLANs • add name servers • configure a DDNS service •...

  • Page 110: Vlan

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual VLAN This page is available for the Router and WISP Repeater modes. On the Advanced / VLAN page, you can create and edit groups of ports for virtual networks (VLANs).
  • Page 111 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 87. The page for adding a group of ports for VLAN. You can specify the following parameters: Parameter Description Name A name for the port for easier identification.

  • Page 112: Dns

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual On the Advanced / DNS page, you can add DNS servers to the system. Figure 88. The Advanced / DNS page. DNS servers are used to determine the IP address from the name of a server in Intranets or the Internet (as a rule, they are specified by an ISP or assigned by a network administrator).
  • Page 113 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual If needed, you can add your own address resource record. To do this, click the ADD button ( ) in the Hosts section. Figure 89. The window for adding a DNS record.

  • Page 114: Ddns

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual DDNS This page is available for the Router and WISP Repeater modes. On the Advanced / DDNS page, you can define parameters of the DDNS service, which allows associating a domain name with dynamic IP addresses.
  • Page 115 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual After specifying the needed parameters, click the SAVE button. To edit parameters of the existing DDNS service, select the relevant line in the table. On the opened page, change the needed parameters and click the SAVE button.

  • Page 116: Ports Settings

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Ports Settings On the Advanced / Ports Settings page, you can configure or disable autonegotiation of speed and duplex mode or manually configure speed and duplex mode for each Ethernet port of the access point.
  • Page 117 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 93. The window for changing the settings of the access point's port. In the opened window, specify the needed parameters: Parameter Description Data transfer mode. Select the Auto value to enable autonegotiation. When this value is selected, the Autonegotiation Modes and Flow control sections are displayed.
  • Page 118 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Flow control Move the switch to the right to enable the flow control function for the port. Symmetric flow control Move the switch to the left to disable the flow control function for the port.

  • Page 119: Bandwidth Control

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Bandwidth Control On the Advanced / Bandwidth Control page, you can setup the rate limit for traffic transmitted from every port of the access point. Figure 94. The Advanced / Bandwidth Control page.

  • Page 120: Routing

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Routing This page is available for the Router and WISP Repeater modes. On the Advanced / Routing page, you can add static routes (routes for networks that are not connected directly to the device but are available through the interfaces of the device) into the system.
  • Page 121 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description From the drop-down list, select an interface through which the destination network can be accessed. If you have selected the Auto...

  • Page 122: Remote Access

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Remote Access This page is available for the Router and WISP Repeater modes. On the Advanced / Remote Access page, you can configure access to the web-based interface of the access point.
  • Page 123 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description Mask The mask of the subnet. Public port An external port of the access point. You can specify only one port. Protocol The protocol available for remote management of the access point.

  • Page 124: Upnp Igd

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual UPnP IGD This page is available for the Router and WISP Repeater modes. On the Advanced / UPnP IGD page, you can enable the UPnP IGD protocol. The access point uses the UPnP IGD protocol for automatic configuration of its parameters for network applications requiring an incoming connection to the access point.

  • Page 125: Igmp

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual IGMP This page is available for the Router and WISP Repeater modes. On the Advanced / IGMP page, you can allow the access point to use IGMP.

  • Page 126: Alg/Passthrough

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual ALG/Passthrough This page is available for the Router and WISP Repeater modes. On the Advanced / ALG/Passthrough page, you can allow the access point to use RTSP, enable the SIP ALG and PPPoE/PPTP/L2TP/IPsec pass through functions.
  • Page 127 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual The following elements are available on the page: Parameter Description Move the switch to the right to enable SIP. Such a setting allows using the SIP ALG function. This function allows VoIP traffic to pass through the NAT-enabled access point.

  • Page 128: Firewall

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Firewall This section is available for the Router and WISP Repeater modes. In this menu you can configure the firewall of the access point: add rules for IP filtering •...
  • Page 129 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Figure 104. The page for adding a rule for IP filtering. You can specify the following parameters: Parameter Description General settings Move the switch to the right to enable the rule.
  • Page 130 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description A protocol for network packet transmission. Select a value from the Protocol drop-down list. Source IP address Set as Select the needed value from the drop-down list.
  • Page 131 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To edit a rule for IP filtering, select the relevant line in the table. On the opened page, change the needed parameters and click the APPLY button.

  • Page 132: Virtual Servers

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Virtual Servers On the Firewall / Virtual Servers page, you can create virtual servers for redirecting incoming Internet traffic to a specified IP address in the local area network.
  • Page 133 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual You can specify the following parameters: Parameter Description General Settings A name for the virtual server for easier identification. You can Name specify any name. Select a virtual server template from the drop-down list, or select...
  • Page 134 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Parameter Description A port of the IP address specified in the Private IP field to which traffic is directed from the Public port. Specify the start and the Private port (start)/ end value for the port range.

  • Page 135: Dmz

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual A DMZ is a host or network segment located “between” internal (local) and external (global) networks. In the device, the DMZ implements the capability to transfer a request coming to a port of the access point from the external network to a specified host of the internal network.

  • Page 136: Mac Filter

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual MAC Filter On the Firewall / MAC Filter page, you can configure MAC-address-based filtering for computers of the access point's LAN. Figure 108. The Firewall / MAC Filter page.
  • Page 137 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description Move the switch to the right to enable the rule. Enable rule Move the switch to the left to disable the rule.

  • Page 138: Url Filter

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual URL Filter On the Firewall / URL Filter page, you can specify restrictions on access to certain web sites and define devices to which the specified restrictions will be applied.
  • Page 139 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To specify URL addresses to which the selected filtering mode will be applied, in the Addresses section, click the ADD button ( ). In the opened window, you can specify the following...

  • Page 140: System

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual System In this menu you can do the following: change the password used to access the access point's settings • restore the factory default settings • create a backup of the access point's configuration •...

  • Page 141: Configuration

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Configuration On the System / Configuration page, you can change the password for the administrator account used to access the web-based interface of the access point and to access the device settings via...
  • Page 142 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual The following buttons are also available on the page: Control Description Click the button to restore the factory default settings. Also you can Factory restore the factory defaults via the hardware RESET button (see the Back and Bottom Panels section, page 10).

  • Page 143: Firmware Update

    To enable the automatic check for firmware updates, in the Remote Update section, move the Check for updates automatically switch to the right and click the APPLY SETTINGS button. By default, in the Remote server URL field, the D-Link update server address (fwupdate.dlink.ru) is specified.

  • Page 144: Local Update

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Local Update Attention! Do not turn off the access point before the firmware update is completed. This may cause the device breakdown. To update the firmware of the access point locally, follow the next steps: 1.

  • Page 145: Remote Update

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Remote Update Attention! Do not turn off the access point before the firmware update is completed. This may cause the device breakdown. To update the firmware of the access point remotely, follow the next steps: 1.

  • Page 146: Log

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual On the System / Log page, you can set the system log options and configure sending the system log to a remote host. Figure 113. The System / Log page. The Settings tab.
  • Page 147 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To view the system log, go to the Log tab. Figure 114. The System / Log page. The Log tab. To view the latest system events, click the REFRESH button.

  • Page 148: Ping

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Ping On the System / Ping page, you can check availability of a host from the local or global network via the Ping utility. The Ping utility sends echo requests to a specified host and receives echo replies.
  • Page 149 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In the opened window, in the Packet size field, specify the volume of data sent in a request. In the Time to wait for a response field, specify the response waiting period in seconds. To restore the default field values, click the DEFAULT SETTINGS button.

  • Page 150: Traceroute

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Traceroute On the System / Traceroute page, you can determine the route of data transfer to a host via the traceroute utility. Figure 117. The System / Traceroute page.
  • Page 151 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual To specify additional settings, click the MORE SETTINGS button. Figure 118. The System / Traceroute page. The additional settings window. In the opened window, you can specify the following parameters:...

  • Page 152: Telnet

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual Telnet On the System / Telnet page, you can enable or disable access to the device settings via TELNET from your LAN. By default, access is disabled.

  • Page 153: System Time

    DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual System Time On the System / System Time page, you can manually set the time and date of the access point or configure automatic synchronization of the system time with a time server on the Internet.
  • Page 154 DAP-1360U Wireless N300 Access Point & Router Configuring via Web-based Interface User Manual In some cases NTP servers addresses are provided by your ISP. In this case, you need to move the Get NTP server addresses using DHCP switch in the NTP Settings section to the right and click the APPLY button.

  • Page 155: Chapter 5. Operation Guidelines

    DAP-1360U Wireless N300 Access Point & Router Operation Guidelines User Manual CHAPTER 5. OPERATION GUIDELINES Safety Rules and Conditions Please carefully read this section before installation and connection of the device. Make sure that the device is not damaged. The device should be used only as intended in accordance with the documents.

  • Page 156: Wireless Installation Considerations

    RF noise in your home or office. To maximize your wireless range, follow the guidelines below. 1. Keep the number of walls and ceilings between the DAP-1360U device and other network devices to a minimum – each wall or ceiling can reduce your wireless network range by 3- 90 feet (1-30 meters).

  • Page 157: Chapter 6. Abbreviations And Acronyms

    DAP-1360U Wireless N300 Access Point & Router Abbreviations and Acronyms User Manual CHAPTER 6. ABBREVIATIONS AND ACRONYMS Access Category Advanced Encryption Standard Address Resolution Protocol BSSID Basic Service Set Identifier Complementary Code Keying Cyclic Redundancy Check DDNS Dynamic Domain Name System...
  • Page 158 DAP-1360U Wireless N300 Access Point & Router Abbreviations and Acronyms User Manual PPPoE Point-to-point protocol over Ethernet PPTP Point-to-point tunneling protocol Pre-shared key Quality of Service RADIUS Remote Authentication in Dial-In User Service Routing Information Protocol Request To Send RTSP...

Table of Contents
