OWNER’S MANUAL GAS RANGE Please read this manual carefully before operating your range and retain it for future reference. LRG3085ST LRG3081SB LRG3081BD LRG3083ST LRG3081SW LRG3081ST LSRG307ST www.lg.com MFL33029619 (REV.07 150715)
TABLE OF CONTENTS TABLE OF CONTENTS Cook Time (Timed Cook) PRODUCT FEATURES Start Time (Delayed Timed Cook) Convection Bake IMPORTANT SAFETY INSTRUCTIONS Convection Roast Warm Proof BEFORE USE Accessories CARE AND CLEANING Componen ts Gas Surface Burner - Removing and Replacing the Gas Surface HOW TO USE Burner How to Use Gas Surface Burners...
PRODUCT FEATURES PRODUCT FEATURES MULTIPLE GAS BURNER SIZES Choose a burner to fit the size of your cookware. Cooking multiple items at once is possible by using different burners at the same time. SAFE AND CONVENIENT GAS RANGE Provides safety and convenience for cooking. Superboil can quickly bring a pot of water to a boil.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and to ensure the peak performance of your product. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Page 5
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY NOTICE Enforcement Act requires the Governor of California to publish a list of substances known to the state to cause birth defects or other reproductive harm, and requires businesses to warn customers of potential exposure to such substances. Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon monoxide, formaldehyde and soot, caused primarily by the imperfect combustion of natural or LP gas.
Page 6
IMPORTANT SAFETY INSTRUCTIONS WARNING y This product contains chemicals known to the State of California to cause cancer. Wash hands after handling. WARNING y NEVER use your range as a space heater to heat or warm the room. Doing so may result in carbon monoxide poisoning and overheating of the oven.
Page 7
IMPORTANT SAFETY INSTRUCTIONS SURFACE BURNERS WARNING y Even if the top burner flame goes out, gas is still flowing to the burner until the knob is turned to the “OFF” position. If you smell gas, immediately open a window and ventilate the area for five minutes prior to using the burner. Do not leave the burners turned “ON“...
Page 8
Important Safety InStructIonS BROILER Always use a broiler pan and a grid for excess fat and grease drainage. This will help to reduce splatter, smoke, and flare-ups. The igniter for the broil burner on the ceiling of the oven will glow orange periodically during normal broil operation. WarnInG When using your broiler, the temperature inside the oven will be extremely high.
Page 9
IMPORTANT SAFETY INSTRUCTIONS OVEN When opening the door of a hot oven, stand away from the range. The hot air and steam that escape can cause burns to hands, face and eyes. WARNING NEVER block any slots, holes or passages in the oven bottom or cover an entire rack with materials such as aluminum foil.
For Model: LRG3085 / LRG3083 / LRG3081 / LSRG307 NOTE y Contact LG Customer Service at 1-800-243-0000 (U.S.) if any accessories are missing For Panama Customer Service call at 507-260-0000. y For your safety and extended product life, only use authorized components.
BEFORE USE Components Make sure to understand the names and function of each part. * Throughout this manual, the features and appearance may vary depending on your model. For model: LRG3085 / LSRG307 Control panel Grates Oven vent Oval burner Small burner Medium burner Extra large burner...
HOW TO USE HOW TO USE How to Use Gas Surface Burners Before Use Read all instructions before using. Make sure that all burners are properly placed. Make sure that all grates are properly placed before using the burner. CAUTION DO NOT operate the burner for an extended period of time without cookware on the grate.
HOW TO USE Gas Burners Your gas range cooktop has five or four sealed gas burners. These can be assembled and separated. Follow the guide below. side grate center grate side grate 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 LRG3085/LRG3083/LSRG307...
HOW TO USE Using the Gas Surface Burners In Case of Power Failure In case of a power failure, you can light the gas surface Be sure that all of the surface burners are placed in the burners on your range with a match. correct positions.
HOW TO USE How to Place the Griddle: Using a Wok: The griddle can only be used with the center burner. The griddle must be properly placed If using a wok, it is recommended that you use a 14-inch or on the center grate, as shown in the below illustration.
HOW TO USE How to Use the Oven Before Use Read all instructions before using. Make sure the electrical power Do not block, touch or place cord and the gas valve are items around the oven vent properly connected. during cooking. Check them for safety.
HOW TO USE Using the Control Panel For model: LRG3085/LRG3083/LSRG307 Display Name Description Conv. Bake Press the button to select baking with the Convection function. Bake Press the button to enter the normal bake function. – Press this button to keep food warm in the oven. –...
Page 18
HOW TO USE Using the Control Panel (Continued) For model: LRG3081 Display Name Description Conv. Bake Press the button to select baking with the Convection function. Bake Press the button to enter the normal bake function. – Press and then use the + and – buttons to set the amount of time you want your food to cook. Cook Time/Clock The oven will shut off when the cooking time has run out.
HOW TO USE Operating Instructions (For model: LRG3081 / LRG3091 / LRG3021) Press and hold the Bake button for 3 seconds. How to Set the Convection Auto Using the + button, enter the amount you wish to Conversion Function increase the temperature. (For model: LRG3085/LRG3083/LSRG307) Press the START button to accept the increased temperature.
Page 20
HOW TO USE How to Set the Preheating Alarm Light How to select Fahrenheit or Celsius On/Off (For model: LRG3085/LRG3083/LSRG307) Your oven control is set to use the Fahrenheit temperature The interior oven light automatically turns on when the oven selections but you may change this to use the Celsius door is opened.
HOW TO USE How to Set the Clock Time How to Use the Timer (For model: LRG3085/LRG3083/LSRG307) (For model: LRG3085/LRG3083/LSRG307) The clock must be set to the correct time of day in order for The timer does not control oven operations. the automatic oven timing functions to work properly.
HOW TO USE How to Use the Oven Lockout Feature Replacing the racks The oven lockout feature automatically locks the oven door and prevents most oven controls from being turned on. It 1. While wearing oven mitts, place the end of the rack on does not disable the clock, timer or the interior oven light.
HOW TO USE Power Outage When cooking is complete, press the CLEAR OFF button. Remove the food from the oven. The oven or broiler can not be used during a power outage. If the oven is in use when a power failure occurs, the oven (For model: LRG3081 / LRG3091 / LRG3021) burner shuts off and cannot be re-lit until power is restored.
HOW TO USE Broil Serve the food immediately, and place the pan outside the Your oven is designed for CLOSED DOOR broiling. oven to cool during the meal for easiest cleaning. Place the food on the grid of the broiler pan. Use LO Broil to cook foods such as poultry or thick cuts of meat thoroughly without over-browning them.
HOW TO USE Broiling Chart Broiling times will be affected by the size, weight, thickness, starting temperature and your preference of doneness. This guide is based on meats at refrigerated temperatures. Your oven has 7 rack positions. Quantity and/or Rack First Side Second Side Food...
HOW TO USE Cook Time (Timed Cook) NOTE The TIMED COOK feature allows you to set the oven to cook for a specific length of time. This feature can only be used You can set the cooking time from 1 minute up to 11 hours with the BAKE, CONVECTION BAKE and CONVECTION and 59 minutes.
HOW TO USE Start Time (Delayed Timed Cook) Convection Bake Convection baking allows for even cooking and excellent The automatic timer of the DELAYED TIMED COOK function results when using multiple racks at the same time. It could will turn the oven ON and OFF at the time you select. This also shorten cooking time.
Page 28
HOW TO USE Cookware for Convection Cooking NOTE When cooking using the convection cycle, the oven temperature is automatically reduced by 25°F. The display Check to see if your cookware leaves room for air circulation in will show the changed temperature. the oven before using your convection oven.
HOW TO USE Convection Roast Multi-Rack Convection Baking (For model: LRG3085/LRG3083/LSRG307) You can bake foods with excellent results using multiple racks The CONVECTION ROAST feature is designed to give because heated air is circulated evenly throughout the oven. optimum roasting performance. CONVECTION ROAST Multi-rack baking may increase cook times slightly for some combines cooking with the convection fan with roasting foods but the overall result is time saved.
HOW TO USE Warm Proof (For model: LRG3085/LRG3083/LSRG307) (For model: LRG3085/LRG3083/LSRG307) The WARM function will keep cooked food warm for serving Setting the PROOF function: up to 3 hours after cooking has finished. The Warm function This feature maintains a warm oven for rising yeast leavened may be used without any other cooking operations or can products before baking.
CARE AND CLEANING CARE AND CLEANING Gas Surface Burner CAUTION Electrode y DO NOT clean this appliance with bleach. y To prevent burns, wait until the cooktop has cooled down before touching any of its parts. y Always wear gloves when cleaning the cooktop. y Use care when cleaning the cooktop.
CAUTION call our toll-free customer service number: 1-800-243-0000 (U,S) or Visit our website at: www.lg.com, DO NOT put the grate in the oven during self cleaning for panama please call 507-260-0000.
CARE AND CLEANING Oven Air Vents NOTE Air openings are located at the rear of the cooktop, at the top To prevent scratching, do not use abrasive cleaners on any and bottom of the oven door, and at the bottom of the range. of these materials.
CARE AND CLEANING Removing and Replacing the Replacing the Oven Door Oven Door and Drawer 1. Firmly grasp both sides of the door at the top. CAUTION • The door is very heavy. Be careful when removing and lifting the door. •...
Page 35
CARE AND CLEANING Removing the Drawer Replacing the Drawer 1. Pull the bearing glides to the front of the chassis glide. WARNING 2. Align the glide on each side of the drawer with the glide Disconnect the electrical power to the range at the main slots on the range.
CARE AND CLEANING SELF CLEAN During the self clean cycle, the cooktop elements and The self clean cycle uses extremely hot temperatures to clean the oven cavity. While running the Self Clean cycle, warming drawer cannot be used. you may notice smoking or an odor. This is normal; NOTE especially if the oven is heavily soiled.
CARE AND CLEANING Setting Self Clean (Continued) During Self Clean • The self clean cycle uses extremely hot temperatures (For model: LRG3081 / LRG3091 / LRG3021) to clean the oven cavity. While running the Self Clean cycle, you may notice smoking or an odor. This is Press the Self Clean button once for a 3 hour cycle, twice normal;...
LG’s EasyClean™ enamel in your new oven provides flexibility while cleaning the inside of your range. The EasyClean™ feature works with LG’s new enamel to help lift LIGHT soils such as drops of cheese from pizzas or LIGHT grease splatter from small roasts without harsh chemicals for safer and faster hand-cleaning.
Page 39
CARE AND CLEANING EasyClean™ INSTRUCTION GUIDE STEP EasyClean™ INSTRUCTION GUIDE NOTES Remove oven racks and accessories from the oven. Scrape off any burnt-on debris with a plastic scraper. Suggested plastic scrapers: • Hard plastic spatula • Plastic pan scraper • Plastic paint scraper •...
CARE AND CLEANING Changing the Oven Light Oven Racks The oven light is a standard 40-watt appliance bulb. It will Remove the oven racks before operating the self clean cycle. turn on when the oven door is open. When the oven door is Food spilled into the tracks could cause the racks to closed, press the Oven Light button to turn the light on or off.
BEFORE REQUESTING SERVICE BEFORE REQUESTING SERVICE Symptoms and Questions Possible Cause/Solution Top burners do not light or do not burn evenly y The plug on the range is not completely inserted in the electrical outlet. y Make sure the electrical plug is inserted into a live, properly grounded outlet. y Burner slits on the side of the burner may be clogged.
Page 42
BEFORE REQUESTING SERVICE Symptoms and Questions Possible Cause/Solution Oven light does not work y The light bulb is loose or defective. y Tighten or replace the bulb. y The plug on the range is not completely inserted in the electrical outlet. y Make sure the electrical plug is inserted into a live, properly grounded outlet.
Page 43
BEFORE REQUESTING SERVICE Symptoms and Questions Possible Cause/Solution Strong odor y An odor from the insulation around the inside of the oven is normal for the first few times the oven is used. y This is temporary. Fan noise y The convection fan may turn on and off automatically. y This is normal.
WARRANTY (ONLY USA) LG Electronics Inc. will repair or replace your product, at LG’s option, if it proves to be defective in material or workmanship under normal use, during the warranty period set forth below, effective from the date of original consumer purchase of the product.
Page 45
LG Customer Information Center 1-800-243-0000 USA, Consumer User 1-888-542-2623 CANADA 507-260-0000 PANAMA Register your product Online! www.lg.com Printed in Mexico...
