- Page 1 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 1 http://www.LG.ca ENGLISH RH398H-M For questions about this product, please call. 1 1 - - 8 8 8 8 8 8 - - 5 5 4 4 2 2 - - 2 2 6 6 2 2 3 3...
- Page 2 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 2 CAUTION: The apparatus should not be exposed to water (dripping or splash- CAUTION ing) and no objects filled with liquids, such as vases, should be placed on the RISK OF ELECTRIC SHOCK apparatus. DO NOT OPEN...
- Page 3 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 3 IMPORTANT SAFETY 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or...
-
Page 4: Table Of Contents
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 4 Contents Before you start ........5-6 Remote control . -
Page 5: Before You Start
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 5 Before you start Recordable and Playable discs This unit can play and record all widely-used DVD types. The table below shows some specific compatibility differences depending on the disc types. DVD-R DVD-RW DVD-RAM DVD+R... - Page 6 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 6 Notes on discs Restrictions on copying Depending on the conditions of the recording equipment or the CD-R/RW (or Some video material is copy-once protected: Such material cannot be copied to DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be HDD or DVD.
-
Page 7: Remote Control
PR/CH (v/V): Scans up or down through memorized channels. Manufacturer Code Number RETURN (O): Removes the on-screen displays. LG / GoldStar 1 (Default), 2 REC (z): Starts recording. Press repeatedly to set the Zenith 1, 3, 4 recording time. -
Page 8: Main Unit
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 8 Main Unit h i j k a 1 1 / I (POWER button) g Remote Sensor Switches the unit ON or OFF. Point the remote control here. b Disc Tray h N / X (PLAY / PAUSE) Insert a disc here. -
Page 9: Hooking Up The Unit
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 9 Hooking up the unit c Audio/Video connection Connect one end of the video(yellow) cable to the VIDEO OUTPUT jack on the unit and other end to the VIDEO INPUT jack on your a Antenna connection... - Page 10 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 10 Hooking up the unit - More functions Component connection Connect one end of the component(Y PB PR) cable to the COMPONENT OUT- Connecting a Cable Box PUT jack on the unit and other end to the COMPONENT INPUT jack on your...
- Page 11 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 11 S-Video connection Connect one end of the S-Video cable to the S-VIDEO OUTPUT jack on the unit and the other end to the S-Video INPUT jack on your TV. Connect one ends of the audio cables (red and white) to the analog AUDIO OUTPUT jack on the unit and the other ends to the AUDIO INPUT jack on your TV(see component connection on the left).
- Page 12 Some functions of this unit are controlled by TV’s remote control when this plus standard to multi-channel surround-sound audio, HDMI features include unit and LG TV with SIMPLINK are connected through HDMI connection. uncompressed digital video, a bandwidth of up to 5 gigabytes per second, one •...
-
Page 13: Operating Usb Flash Drive
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 13 Connecting to the INPUT 1 or AV IN 2 Jacks Operating USB Flash Drive Connect the input jacks (INPUT1, AV IN 2) on the unit to the audio/video out jacks on your accessory component using audio/video cables. -
Page 14: Auto Setup
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 14 Auto setup Using the Home Menu When the first time to turn on the unit, the initial setup ON REMOTE wizard sets the language, clock and channels ON REMOTE 1 Displays the HOME menu: HOME automatically. -
Page 15: Adjust The Setup Settings
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 15 PHOTO Adjust the SETUP settings HDD – Displays [Photo List] menu, which shows photo files on HDD. (page 25) DISC – Displays [Photo List] menu, which shows photo files on the disc. (page ON REMOTE... - Page 16 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 16 Adjust the SETUP settings - More functions Power Save mode – Selects whether this unit is in power save mode when the power is turned off. This option is not available when a timer recording is set.
- Page 17 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 17 Adjust the audio settings Adjust the lock settings To access the DVD Rating, Password or Area Code options, you must enter the Dolby Digital / DTS / MPEG – Selects the type of digital audio signal when 4-digit password.
- Page 18 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 18 Adjust the recording settings Adjust the disc settings Record Mode Set – Select the picture quality for recording from XP, SP, LP, EP Disc Format – You can Initialize a DVD by pressing ENTER while [Start] is or MLP.
-
Page 19: Displaying Disc Information
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 19 Disc Label – This function allow you to change the default disc name to some- Displaying disc information thing more descriptive. This name appears when you load a disc and when you display disc information on-screen. The keyboard menu appears by pressing ON REMOTE ENTER while [Edit] is selected. -
Page 20: Play A Disc
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 20 Displaying information while watching TV Moving to another title DVD ALL During viewing the TV, Press DISPLAY to display the information displayed When a disc has more than one title, you can move to another title. - Page 21 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 21 Play a disc - More functions Slow down the playing speed DVD ALL While playback is paused, press SCAN (bb or BB) to slow down forward or Playing a disc that contains a menu reverse playback.
-
Page 22: Playing Divx Movie Files
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 22 Divx file requirement Playing DivX ® movie files Available resolution size: 720x480 (W x H) pixel ON REMOTE DivX file extensions: “.avi”, “.divx” Playable DivX subtitle: “.smi”, “.srt”, “.sub (Micro DVD format only)”, 1 Displays the HOME menu: HOME “.txt (Micro DVD format only)”... - Page 23 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 23 Selecting multiple files or folders on the list Copying file(s) or folder(s) to the HDD You can select not only single file but also multiple files using MARKER You can copy file(s) or folder(s) to the HDD.
-
Page 24: Listening To A Music
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 24 Displaying MP3/WMA file information Listening to a music Press DISPLAY while the file you want to show the file information is selected. The unit shows the ID3-Tag information of the file. If the file does not have ON REMOTE ID3-Tag information, [ID3-Tag: None] appears on the screen. -
Page 25: Viewing A Photo
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 25 Rotate a photo Viewing a photo Use vV to rotate the photo while displayed in full screen. ON REMOTE Viewing photo files as a slide show 1 Displays the HOME menu: HOME To slide show photos in the [Photo list], select the [Slide Show] option on the left... -
Page 26: Recording
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 26 Setting a timer record Recording This unit can be programmed to record up to 16 timer recordings within a month. The clock must be set correctly before setting a timer. Follow the instruction below to record a TV channel or other source. - Page 27 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 27 Canceling a timer recording Time Slip You can cancel a timer record before the timer recording actually starts. Select You can watch the title that you are currently recording to HDD with this func- a timer recording that you want to cancel on the [Timer Record List] menu and tion.
-
Page 28: Editing A Title
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 28 Using time shift function Editing a title This feature allow you to pause or rewind live TV, so you do not miss a thing if you were interrupted. Using the Title list menu,you can edit video contents. - Page 29 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 29 Before editing Chapter search Video This unit offers various edit options for various disc types. Before you edit, You can select the start of a title by searching a chapter. Select a title that you check the disc type, and select the option available for your disc.
- Page 30 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 30 Time search Dividing a title Video You can select the start of a title by searching through the time duration. Select Use this function to split a title up into two titles. Select a title that you want to a title that you want to search and press ENTER.
- Page 31 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 31 Naming a title The chapters that you want to combine are created by deleting a part from an Original title. When a title is recorded by this unit, the title name will be named by a number.
-
Page 32: Dubbing A Title
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 32 About ‘Fast’ copying Dubbing a title Copying between DVD and HDD is a complete digital process and therefore involves no loss of quality in the audio or video. This allow for high speed copy- Using the title list menu, you can dub video contents. -
Page 33: Language Codes
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 33 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar... -
Page 34: Troubleshooting
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 34 Troubleshooting Playback The unit does not start playback. General Insert a playable disc. (Check the disc type, color system, and regional code.) The power does not turned on. Place the disc with the playback side down. - Page 35 RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 35 Recording If your TV is not equipped with DTS decoder, set the [DTS] options to [OFF] on the setup menu. To enjoy DTS multi channel surround, you must Cannot record or does not record successfully.
-
Page 36: Specifications
RH398H-M.BCANLLK_ENG 6/11/08 11:08 AM Page 36 Specifications Playback Frequency response DVD (PCM 48 kHz): 8 Hz to 22 kHz, General CD: 8 Hz to 20 kHz Power requirements AC 120V, 60 Hz DVD (PCM 96 kHz): 8 Hz to 44 kHz...
