PS/2 Keyboard Model
Enables a certain keyboard layout. You can choose between "Generic 101-Key
PC" for a standard keyboard layout, "Generic 104-Key PC" for a standard keyboard
layout extended by three additional Windows keys, "Generic 106-Key PC" for a
Japanese keyboard, and "Apple Macintosh" for the Apple Macintosh.
If a keyboard timout is required the according option can be enabled. Additionally,
set the desired time value in the input field below.
USB Mouse Type
Enables the USB mouse type. Choose an appropriate option from the selection
box. For a detailed description about the mouse type and recommended options
for the different operating systems see the Section: Recommended Mouse Settings
in Chapter 3.
Mouse Speed
Auto mouse speed
Use this option if the mouse settings on the host use an additional
acceleration setting. The ARMC/3P tries to detect the acceleration and speed
of the mouse during the mouse sync process.
Fixed mouse speed
Use a direct translation of mouse movements between the local and the
remote pointer.
You may also set a fixed scaling which determines the amount the remote
mouse pointer is moved when the local mouse pointer is moved by one pixel.
This option only works when the mouse settings on the host are linear. This
means that there is no mouse acceleration involved.
To set the options click Apply.
Host Monitor Settings
Using this option (see Figure 77) it is possible to add video modes to the ARMC/3P
which are not recognized using the factory settings. This may be useful when using
special modelines in a X-Window configuration on the host or with uncommon
hosts or operating systems. From the selection box you may choose the desired
screen resolution for the local monitor.
The maximum number of the custom video resolution is 4. Using the option Custom
Modes Handling custom modes may be either disabled (Off), additionally used to
