SERIES MODEL
MR-508EK, MR-508EKL,
MR-560EK, MR-560EKL
OPERATING INSTRUCTIONS
Non-Freon Refrigerators
This refrigerator uses non-Freon refrigerant (isobutane) and non-Freon foam insulation (cyclopentane).
These materials are harmless to the environment and do not affect the ozone layer and global warming.
Please read this manual carefully and follow the information contained within. In particular, be sure to read the safety precautions before using this refrigerator.
Be sure to receive your copy of the warranty from the retailer and confirm that the purchase date and retailer name are written on the warranty.
Store this operating instructions manual and the warranty in a safe place.
This refrigerator was manufactured for refrigerating and freezing of foods in general households. For commercial use, please use a commercial refrigerator-freezer.
The principal plastic components indicate the material name to facilitate recycling.
Cleaning Instruction - Important!
It is strongly recommended to use only lukewarm water and a soft cloth when cleaning.
Cleaning agents can cause cracking to the plastic components of your refrigerator.
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric MR-508EK Series
Summary of Contents for Mitsubishi Electric MR-508EK Series
- Page 1 SERIES MODEL MR-508EK, MR-508EKL, MR-560EK, MR-560EKL OPERATING INSTRUCTIONS Non-Freon Refrigerators This refrigerator uses non-Freon refrigerant (isobutane) and non-Freon foam insulation (cyclopentane). These materials are harmless to the environment and do not affect the ozone layer and global warming. Please read this manual carefully and follow the information contained within. In particular, be sure to read the safety precautions before using this refrigerator. Be sure to receive your copy of the warranty from the retailer and confirm that the purchase date and retailer name are written on the warranty.
-
Page 2: Safety Precautions
Caution If the power cord is damaged call on the door-l i n er of the refri g erator compartment. ) Mitsubishi Electric Service Centre Using an extension cord or plugging for a technician to replace power cord. in too many power cords into the... - Page 3 Warning About using your refrigerator Do not put any vessels, jars, etc. that Do not use electrical products inside Do not store volatile products that contain water on top of the refrigerator. the refrigerator unit. can easily ignite. If water gets onto If the refrigerant (gas) is leaking Benzine, cosmetics and electrical parts, it...
- Page 4 1. Components Freezer Compartment Shelf (Small) Freezer Compartment Shelf (Large) Ice Tray Freezer Pocket Ice Cube Box Door Gasket Sliding case Egg Rack Temperature Control (refrigerator compartment) Free Pocket (MR-508EK : 2 PCS.) (MR-560EK : 3 PCS.) Temperature Control (freezer compartment) Elevating Shelf LED Light Flexible Glass Shelf...
-
Page 5: Installation
2. Installation Install on a completely flat and rigid surface. Using the two front adjustable feet, ensure that the Toe Grille refrigerator is positioned firmly and level on the floor. Now open the doors approximately half way, and extend the front adjustable feet equally until Leveling Leg the doors close by themselves. -
Page 6: Operation
4. Operation 1. Temperature Control Both the freezer compartment and the refrigerator Temperature Control of compartment have a temperature control. the Freezer Compartment “MID” is recommended for normal usage. Turn the dial to “COLDER” when storing a large quantity of frozen foods, ice cream etc., in the freezer compartment. Turn the dial to “FREEZER”... - Page 7 Bottle Pocket Even large bottles may be stored in this pocket. Some types of commercial water cooler bottles may touch the shelf or foodstuffs when placed in the door pocket, preventing the door from closing firmly. 6. How to Remove the Pockets Remove the door racks as shown in the illustration in order to proceed with cleaning.
-
Page 8: Maintenance
8. Elevating shelf Move the lever on the front of the shelf left or right to adjust the shelf to the desired position. Move the lever to the right to raise the shelf. Move the lever to the left to lower the shelf. The lever will be difficult to move when heavy items are placed on the shelf. - Page 9 How to Replace the LED Light In the event that the LED light is damaged or malfunctions, please refrain from adjusting or repairing it by yourself. Please contact the service center instead. How to remove the elevating shelf 1 Move the lever completely to the right. 2 Push up each support, one at a time, with a strong effort.
-
Page 10: Troubleshooting
6. What to do in these situations When there’s a power failure. Minimize opening/closing of doors and avoid putting in more food. Water discharge outlet When not in use for a long time. Clean the Ice cube box and Ice tray, clean the interior after unplugging the refrigerator, and keep the door open for 2 - 3 days to let it get dry. - Page 11 When the refrigerator is not cooling sufficiently The food may be packed too tightly together, which blocks the flow of cool air. You may have put hot or too many items into the refrigerator. The door may not have been closed properly. The door gasket may be damaged.
- Page 12 ● The refrigerant quantity contained in this appliance is noted on the Rating Label of the appliance. If your Mitsubishi Electric Refrigerator should require service, please contact Mitsubishi Electric Australia ● Pty Ltd see back page of this user manual for contact details.
