Preface Fujitsu would like to thank you for purchasing our FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library (hereinafter referred to as "LT20 S2/LT40 S2/LT60 S2" or "this product"). Before using the LT20 S2/LT40 S2/LT60 S2, read this manual and the manuals that are provided with the server and backup software to ensure correct usage of the LT20 S2/LT40 S2/LT60 S2.
Page 4
Fujitsu pays careful attention for the safe use of our products to prevent injury to users and bystanders and/or material damage. To use the LT20 S2/LT40 S2/LT60 S2 properly, please follow the instructions in the manuals.
Page 5
SCDPM 2012 SCDPM ■ Abbreviations Used in This Manual • "LT20 S2/LT40 S2/LT60 S2" and "this product" refer to "FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library". • Trademark symbols such as and ® are omitted in this document.
Page 6
This symbol indicates prohibition of disassembly or modification of the LT20 S2/LT40 S2/LT60 S2. This indicates prohibition of contact to the LT20 S2/LT40 S2/LT60 S2. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 7
This symbol indicates the instruction to disconnect the power plug from the outlet and to turn off the circuit breaker on the power distribution board. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 8
Then, contact your sales representative or a Fujitsu maintenance service center. Continued use of the LT20 S2/LT40 S2/LT60 S2 could cause a fire and/or electric shock. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 9
Important Information on Handling Maintenance Do not attempt to repair the LT20 S2/LT40 S2/LT60 S2 by yourself. Ask Fujitsu to dispatch one of our maintenance engineers or a maintenance engineer authorized by Fujitsu for maintenance work. Note that our maintenance engineer may connect maintenance equipment (such as PCs) in order to diagnose the LT20 S2/LT40 S2/LT60 S2.
Page 10
LT20 S2/LT40 S2/LT60 S2 when it is malfunctioning or operating abnormally could cause a fire and/or electric shock. If the LT20 S2/LT40 S2/LT60 S2 needs to be repaired, contact your sales representative or a Fujitsu maintenance service center to perform such work.
Page 11
Yanking on the power cable may cause the core of the power cable to be exposed or broken, causing a fire and/or electric shock. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 12
Connectable Equipment Only connect the equipment specified by Fujitsu to the LT20 S2/LT40 S2/LT60 S2. Connecting other equipment to the LT20 S2/LT40 S2/LT60 S2 may result in injury to users and bystanders, or property damage.
Page 13
Important Information on Handling Moving or Relocating the LT20 S2/LT40 S2/LT60 S2 Before moving or relocating the LT20 S2/LT40 S2/LT60 S2, consult with your sales representative or a Fujitsu maintenance service center. LCD Unit (Operator Panel) The LCD unit (operator panel) in the LT20 S2/LT40 S2/LT60 S2 contains mercury. To ensure safety, observe the precautions: •...
For HBA information, refer to our web site or contact a Fujitsu sales representative. 1.1.4 Fibre Channel Switches For Fibre Channel switch information, refer to our web site or contact a Fujitsu sales representative. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Check the environment (operating system, backup software, and HBAs) of the server to be connected to the LT20 S2/LT40 S2/LT60 S2. Refer "1.1 Operating Environment" (page 17) FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
For the link speed of a drive path, 2Gbit/s, 4Gbit/s, or 8Gbit/s can be selected. For more details about the settings, refer to "FUJITSU Storage ETERNUS LT20 S2 LTO Library Installing, Starting Up and Maintaining" or "FUJITSU Storage ETERNUS LT40 S2/LT60 S2 LTO Library Installing, Starting Up and Maintaining".
Though "Automatic" can be selected for Topology, Addressing mode, and Loop ID, set the fixed values shown above. For more details about the settings, refer to "FUJITSU Storage ETERNUS LT20 S2 LTO Library Installing, Starting Up and Maintaining" or "FUJITSU Storage ETERNUS LT40 S2/LT60 S2 LTO Library Installing, Starting Up and Maintaining".
The LT20 S2/LT40 S2/LT60 S2 has Mailslots that allow tape cartridges to be inserted into or ejected from the library while the library is online. For more details about how to enable the Mailslot, refer to "FUJITSU Storage ETERNUS LT20 S2 LTO Library Installing, Starting Up and Maintaining" or "FUJITSU Storage ETERNUS LT40 S2/LT60 S2 LTO Library Installing, Starting Up and Maintaining".
Special setting for the LT20 S2/LT40 S2/LT60 S2 is not required for the operating system unless it is noted in this manual. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
For 6Gbit/s SAS Cards When the LT20 S2/LT40 S2/LT60 S2 is used with a Fujitsu 6Gbit/s SAS card, Oracle 6Gbit/s SAS card, or LSI Logic 6Gbit/s SAS card, the OS needs to be made aware of the changer device by executing the following command after the OS starts up: # update_drv -a -i '"scsiclass,08"' sgen...
Always perform zoning that is appropriate for the operating mode. For more details about how to edit the driver setting file, refer to the manuals of the HBAs. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
For more details about how to install and set up the driver, refer to the relevant software manuals. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 38
Reconfigure and restart the server to make the server recognize the registered device. Execute the following command: # touch /reconfigure # /usr/sbin/shutdown -y -g0 -i6 FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
If performance is reduced, set an appropriate value for the "zfs_arc_max" parameter in order to increase the performance. Refer to "Oracle Solaris ZFS Tunable Parameters" in "Oracle Solaris Tunable Parameters Reference Manual" for details. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
NetBackup, NetVault, or IBM Spectrum Protect. For information on whether the backup software supports associations and for version information, contact the person in charge of the backup software. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
If no problem is found with the installation of the HBA driver, a powered-off LT20 S2/LT40 S2/ LT60 S2 or loose connection can be assumed. Check the settings and reboot the server before considering the contents. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
If no problem is found with the installation of the HBA driver, a powered-off LT20 S2/LT40 S2/ LT60 S2 or loose connection can be assumed. Check the settings and reboot the server before considering the contents. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Because the RSM service is not supported in Windows 7 and later, or in Windows Server 2008 R2 and later, the setting to stop the RSM is not necessary. Procedure Open [Services] and double-click [Removable Storage Manager]. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 44
Set [Startup type] to [Manual]. Click the [Stop] button in [Service status] to stop the service. Click the [Apply] button to enable the setting. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 45
Chapter 3 Setting the Operating System 3.3 Windows Close the window after checking that [Manual] is displayed for [Startup Type]. End of procedure FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Click the [Next] button and then click the [Yes] button for [Update Driver Warning]. Close the driver installation completion window. End of procedure FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
When NetBackup is installed on a Solaris OS server, system IPC resources must be added for NetBackup interprocess communication. For details, refer to the manual supplied with your backup software. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Setting a media mount timeout value that is based upon the configuration is recommended. Although the media mount timeout value is in seconds, there are cases when it is in minutes for Windows. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
120 (in seconds). To set the interval, use the sleep operation or another operation. In addition, perform the settings that are described in "4.1.5 Setting the Media Mount Timeout" (page 49). FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
LT40SSN1, LT60SSN1, LT20SFN1, LT40SFN1, LT60SFN1) Download and install the driver that corresponds to the Windows OS version and CPU from the IBM Fix Cen- tral website. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 52
LT20 S2/LT40 S2/LT60 S2 has multiple tape drives, it is unable to use the LT20 S2/LT40 S2/LT60 S2 after the Windows OS is restarted. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
LT20 S2/LT40 S2/LT60 S2. In case that the Solaris 11 OS is used, only IBM Spectrum Protect agent can connect to the LT20 S2/LT40 S2/LT60 S2. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
LLC is required. Windows Server 2012 or later does not require a driver. To download the latest tape device driver, contact the seller of the software. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
The following shows an example configuration in which "Issue a load command to start cleaning cycle" is set to "off" and "Use Generic Cleaning" is set to "on". FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 56
Barcode Prefix(es) of cleaning media: Set with the character string that is on the label of the cleaning cartridge. • Cleaning Slots: Slot number where a cleaning cartridge is stored. End of procedure FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 57
The Drive Configuration screen appears. Enter "6" and then press the [Enter] key. "6) Generic Cleaning..." is selected. The Generic Cleaning screen appears. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 58
The Device Configuration screen appears again. Enter "2" and then press the [Enter] key. "2) Configuration..." is selected. The Configuration screen appears. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 59
Execute the following command to perform the library cleaning settings. deviceconfig.exe –username <user_name_for_NetVault> -password <password> -librarymachine <NetVault_machine name_where_the_library_is_connected> -libraryname <library_name> The Changer Configuration screen appears. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 60
Reboot the library by clicking the [Restart] button at the lower right. The new settings are applied after the library is rebooted. End of procedure FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 61
Select [Tree View] to switch the view to the tree view mode. Click the name of the drive and select [Configure] from the menu that appears. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Page 62
Use Generic Cleaning: on (the default setting is "off") The following is an example setting for an LTO6, LTO7, or LTO8 drive. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 63
[Modify] from the menu that appears. Click the library name that appears under [Library Configuration] and click [Configure] from the menu that appears. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
Page 64
Reboot the LT20 S2/LT40 S2/LT60 S2 by clicking the [Restart] button at the bottom right of the page. The new settings are applied after the LT20 S2/LT40 S2/LT60 S2 is rebooted. End of procedure FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
When Arcserve Backup is used as the backup software, do not use an HP tape driver or IBM tape driver. Use a dedicated driver instead (this driver is automatically installed during installation of Arcserve Backup). FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED...
Install the Windows Server 2016 device driver (w2k16) in Windows Server 2019. For the download and the installation procedure of the Tape Library Driver, refer to the following website. https://www.fujitsu.com/global/support/products/computing/storage/download/ FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
For details on the procedure for changing the block size and any additional notes that are required, contact the person in charge of the backup software. The upper limit of the block size must be 128KB. FUJITSU Storage ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library User’s Guide -Server Connection- Copyright 2021 FUJITSU LIMITED P3AM-5322-12ENZ0...
The LTFS option has a command used to clean the tape drives. When cleaning tape drives, use the LT20 S2/ LT40 S2/LT60 S2's automatic cleaning function (Auto Cleaning) or the LTFS option's cleaning command. For more details, refer to "3.8 Cleaning the Tape Drive" in "FUJITSU Storage ETERNUS LT series Tape Libraries LTFS Option User's Guide".
Page 69
However, Fujitsu shall assume no responsibility for any operational problems as the result of errors, omissions, or the use of information in this manual. • Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual.
