Page 2 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Air conditioning and audio systems, as well as other Interior features interior features for a comfortable driving experience. Maintenance and Cleaning and protecting your vehicle, performing do-it- care...
Page 3: Table Of Contents
TABLE OF CONTENTS Index 1-7. Safety information Before driving Correct driving posture..101 SRS airbags ....... 103 Child restraint systems..113 1-1. Key information Installing child restraints..121 Keys........42 1-2. Opening, closing and locking When driving the doors Wireless remote control ..44 2-1.
Page 4 2-4. Using other driving systems Interior features Cruise control...... 176 Toyota parking assist-sensor ....180 3-1. Using the air conditioning Rear view monitor system and defogger system ......186 Air conditioning system ..242 Four-wheel drive system ..199 Rear window defogger ..249 Active traction control system ......
Page 5 TABLE OF CONTENTS Index 3-4. Using the hands-free phone Luggage storage box (vehicles without sub system (for mobile phone) woofer) ......372 Hands-free phone system Luggage compartment (for mobile phone) .... 323 features ......373 Using the hands-free Compass ......376 phone system (for mobile phone) ....
Page 6 When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 476 Maintenance data (fuel, oil level, etc.) ... 522 If your vehicle needs to be towed ......477 Fuel information ....535 If you think something is wrong ......483 6-2.
Page 7 Pictorial index Exterior Type A Outside rear view mirror  illumination lights P. 165 Windshield wipers P. 171 Hood P. 407 Antenna P. 304 Outside rear view mirrors P. 85 Headlights P. 165 Front turn signal/front position and front side marker lights P.
Page 8 Stop/tail and rear side  marker lights P. 165 Fuel filler door P. 92 Access doors P. 52 Side doors P. 49 Tires ●Rotation P. 425 ●Replacement P. 495 ●Inflation pressure P. 432 Rear turn signal lights P. 151  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 9 Pictorial index Exterior Glass hatch P. 60  Rear window defogger Rear window wiper P. 249 P. 174 Back door P. 54  Rear view monitor system camera P. 186 License plate lights P. 165 FJCRUISER_OM_General_OM35B53W...
Page 10 Type B Windshield wipers P. 171 Headlights P. 165 Hood P. 407 Antenna P. 304 Outside rear view mirrors P. 85 Side turn signal lights Front position lights P. 165 P. 151 Front turn signal lights P. 151  Front fog lights P.
Page 11 Pictorial index Exterior  Stop/tail lights P. 165 Fuel filler door P. 92 Access doors P. 52 Side doors P. 49 Tires ●Rotation P. 425 P. 495 ●Replacement ●Inflation pressure P. 432 FJCRUISER_OM_General_OM35B53W...
Page 12 Glass hatch P. 60 Rear window wiper Rear window defogger P. 174 P. 249 Back door P. 54 Rear turn signal lights Rear view P. 151 monitor  camera P. 186 Rear fog lights P. 169 License plate lights P. 165 ...
Page 13 Interior Pictorial index (Left-hand drive vehicles) SRS driver airbag Seat belts P. 75 P. 103 Horn P. 155 Head restraints P. 72 Auxiliary box P. 359 SRS front passenger airbag Bottle holders P. 358 P. 103 Floor mats P. 370 Rear seats P.
Page 14 Interior lights Sun visors P. 352 P. 360 Vanity mirrors P. 361  SRS curtain shield airbags P. 103 Anti-glare inside rear view mirror P. 81  Rear view monitor system P. 186  P. 311, 329 Microphone  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 15 Interior Pictorial index (Left-hand drive vehicles) Vehicles without Crawl Control Personal lights P. 353 Vehicles with Crawl Control A-TRAC switch P. 202 Personal lights P. 353 RR DIFF LOCK switch P. 205 Crawl Control switch P. 208 FJCRUISER_OM_General_OM35B53W...
Page 16 Inside door lock button P. 50 Window lock switch P. 90 Door lock switch P. 49 Power window switches P. 89 FJCRUISER_OM_General_OM35B53W...
Page 17 Interior Pictorial index (Left-hand drive vehicles) P. 147 Shift lever Cup holders Front-wheel drive control P. 356 lever P. 199 Parking brake lever Cup holders P. 356 P. 153 Shift lock override button P. 148 FJCRUISER_OM_General_OM35B53W...
Page 18 Instrument panel Pictorial index (Left-hand drive vehicles) Headlight switch P. 165 Front fog light switch P. 168 Turn signal lever P. 151 Gauges and meters P. 156 Windshield wipers and washer switch P. 171 Rear window wiper and  washer switch P.
Page 19 Instrument panel Pictorial index (Left-hand drive vehicles) Clock P. 362  Emergency flasher switch P. 476 Audio system P. 250 Air conditioning system P. 242 Security indicator P. 96 Rear window defogger switch P. 249 FJCRUISER_OM_General_OM35B53W...
Page 20 VSC OFF switch P. 213  RR DIFF LOCK switch P. 205  A-TRAC switch P. 202 Power outlet P. 367  AUX port/USB port P. 276, 285, 299  Toyota parking assist-sensor switch P. 182  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 21 Instrument panel Pictorial index (Left-hand drive vehicles) Engine (ignition) switch P. 144 FJCRUISER_OM_General_OM35B53W...
Page 22  Telephone switch P. 328  Talk switch P. 328  Audio remote control switches P. 301  Cruise control switch P. 176  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 23 Instrument panel Pictorial index (Left-hand drive vehicles)  Instrument cluster light control dial P. 158 Outside rear view Tilt steering lock release lever P. 80  mirror switches P. 85  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 24 Interior Pictorial index (Right-hand drive vehicles) Seat belts P. 75 SRS driver airbag P. 103 Horn P. 155 Head restraints P. 72 Auxiliary box Bottle holders P. 358 P. 359 SRS front passenger airbag P. 103 Rear seats P. 66 Floor mats P.
Page 25 Interior Pictorial index (Right-hand drive vehicles) Interior lights P. 352 Sun visors P. 360 Vanity mirrors P. 361 SRS curtain shield airbags P. 103 Anti-glare inside rear view mirror P. 81  Rear view monitor system P. 186  Microphone P.
Page 26 Vehicles without Crawl Control Personal lights P. 353 Vehicles with Crawl Control A-TRAC switch P. 202 Personal lights P. 353 RR DIFF LOCK switch P. 205 Crawl Control switch P. 208  : NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 27 Interior Pictorial index (Right-hand drive vehicles) Inside door lock button P. 50 Window lock switch P. 90 Door lock switch P. 49 Power window switches P. 89 FJCRUISER_OM_General_OM35B53W...
Page 28 Front-wheel drive control lever P. 199 Cup holders P. 356 P. 147 Shift lever Cup holders Parking brake lever P. 356 P. 153 Shift lock override button P. 148 FJCRUISER_OM_General_OM35B53W...
Page 29 Instrument panel Pictorial index (Right-hand drive vehicles) Headlight switch P. 165 Gauges and meters P. 156 Front fog light switch P. 168 Turn signal lever P. 151 Glove box P. 355 Hood lock release lever P. 407 P. 176 Cruise control switch Fuel filler door opener P.
Page 30 Clock P. 362  Emergency flasher switch P. 476 Audio system P. 250 Air conditioning system P. 242 Security indicator P. 96 Rear window defogger switch P. 249  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 31 Pictorial index (Right-hand drive vehicles)  A-TRAC switch P. 202 RR DIFF LOCK switch P. 205  AUX port/USB port P. 276, 285, 299 VSC OFF switch P. 213 Power outlet P. 367 Toyota parking assist-sensor switch P. 182 FJCRUISER_OM_General_OM35B53W...
Page 32 Windshield wipers and washer switch P. 171 Rear window wiper and washer switch P. 174  Audio remote control switches P. 301 Tilt steering lock release lever P. 80  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 33 Instrument panel Pictorial index (Right-hand drive vehicles) Instrument cluster light control dial P. 158  Telephone switch P. 328 Rear fog light switch P. 169  Talk switch Headlight leveling dial P. 166 P. 328 Engine (ignition) switch P. 144 Outside rear view mirror switches P.
Page 34 Pictorial index Luggage compartment Child restraint anchor brackets P. 121 Tie-down hooks P. 373 FJCRUISER_OM_General_OM35B53W...
Page 35 Pictorial index Luggage compartment Shopping bag hooks P. 375 Cargo net hooks P. 374 Jack Tools P. 495 P. 495  Shopping bag hooks P. 375  Cargo net hooks P. 374 Luggage storage  P. 372  Power outlets P.
Page 36 All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.
Page 37 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is available on request at your Toyota dealer.
Page 38 ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 39 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
Page 40 CAUTION General precautions while driving ■ Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 41 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 42: Before Driving
Before driving 1-1. Key information 1-4. Opening and closing the windows Keys........42 Power windows....89 1-2. Opening, closing and locking the doors 1-5. Refueling Wireless remote control ..44 Opening the fuel tank cap... 92 Side doors ......49 1-6.
Page 43: Keys
Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (P. 508) ■...
Page 44 1-1. Key information NOTICE To prevent key damage ■ ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
Page 45: Opening, Closing And Locking The Doors
1-2. Opening, closing and locking the doors  Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Check that the door is securely locked. Unlocks all doors ■...
Page 46 ● When the wireless key has been left near an electrical appliance such as a personal computer ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features P. 536) ■...
Page 47 1-2. Opening, closing and locking the doors For vehicles sold in Tahiti and the Commonwealth of Dominica The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing address: http://www.globaldenso.com/en/products/oem/index.html FJCRUISER_OM_General_OM35B53W...
Page 48 1-2. Opening, closing and locking the doors FJCRUISER_OM_General_OM35B53W...
Page 49 1-2. Opening, closing and locking the doors FJCRUISER_OM_General_OM35B53W...
Page 50: Side Doors
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked/unlocked using the wireless remote con- trol, key or door lock switch. ■ Wireless remote control (if equipped) P. 44 ■ Locks all doors Unlocks all doors ■...
Page 51 1-2. Opening, closing and locking the doors Driver’s door lock switch (right-hand drive vehicles) Locks all doors Unlocks all doors Passenger’s door lock switch (left-hand drive vehicles only) Locks all doors Unlocks all doors ■ Inside door lock button Locks the door Unlocks the door Pulling the inside handle can open the driver’s door even if...
Page 52 A buzzer sounds if the driver’s door is opened, while the engine switch is in the ACC or LOCK position to remind you to remove the key. ■ Customization that can be configured at Toyota dealer Setting (e.g. unlocking function using a key) can be changed. (Customizable features P. 536)
Page 53: Access Doors
1-2. Opening, closing and locking the doors Access doors The access door (rear door) can be opened using the inside handle. Open the front door widely Pull (from the outside) or push (from the inside) the inside handle of the access door.
Page 54 1-2. Opening, closing and locking the doors NOTICE When opening or closing the front door and access door ■ The front door and access door could be damaged if they hit each other when being opened or closed. FJCRUISER_OM_General_OM35B53W...
Page 55: Back Door
1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked using a key, wireless remote control or door lock switch. ■ Wireless remote control (if equipped) P. 44 ■ Unlocks the back door Locks the back door Opens the back door When you turn the key clock- wise and hold it for about 1...
Page 56 1-2. Opening, closing and locking the doors ■ Back door fixing function The back door can be held in the following positions: Half open position Open the back door to the half open position. It cannot be held in this posi- tion when being closed.
Page 57 1-2. Opening, closing and locking the doors Rear step bumper Type A For rear end protection and eas- ier step-up loading. To get on the rear step bumper, use the shaded area in the illus- tration. Type B For rear end protection and eas- ier step-up loading.
Page 58 1-2. Opening, closing and locking the doors CAUTION Caution while driving ■ ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 59 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. FJCRUISER_OM_General_OM35B53W...
Page 60 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply vertical forces to it.
Page 61: Glass Hatch
1-2. Opening, closing and locking the doors Glass hatch The glass hatch can be opened using the key. Turn the key clockwise and hold it for about 1 second. Raise ■ Opening the glass hatch ● The glass hatch opens slightly, after the back door is locked. ●...
Page 62 1-2. Opening, closing and locking the doors CAUTION Caution while driving ■ ● Keep the glass hatch closed while driving. If the glass hatch is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 63 Doing so may cause hands to be caught or the glass hatch damper stay to break, causing an accident. Do not attach any accessories other than genuine Toyota parts to the ● glass hatch. Such additional weight on the glass hatch may cause the glass hatch to suddenly shut again after it is opened.
Page 64 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other Damper stay rod than genuine Toyota parts to the glass hatch. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 65: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seat cushion angle adjust- ment knob (driver’s side only) Seat height adjustment lever (driver’s side only) Seatback angle adjustment lever Active head restraints (right-hand drive vehicles only) When the occupant’s lower back presses against the seatback during a rear-end collision, the...
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Active head restraints (right-hand drive vehicles only) ■ Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may show the head restraint inner structure.
Page 67: Rear Seats
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks of the rear seats can be folded down. Stow the seat belt buckles and remove the head restraints. Swing the bottom cushion up by pulling the lock release strap. FJCRUISER_OM_General_OM35B53W...
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Push the lock release button and fold down the seatback. Removing rear seat bottom cushions When loading large luggage items, the cushion can be removed. Do not remove the cushion for normal usage. Loosen the bolts with a wrench at first and turn the dials by hand to remove them.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) Separate the bottom cushion from the hinge. Fold the hinge as shown in the illustration. FJCRUISER_OM_General_OM35B53W...
Page 70 1-3. Adjustable components (seats, mirrors, steering wheel) If you cannot raise the seatback ■ Release the seat belt lock by: Pushing on the lower front edge of the seatback to slacken the seat belt. Letting the seat belt retract a little. When the bottom cushion is reinstalled ■...
Page 71 Have the hexagon head bolts tightened with a torque wrench to 17 N·m (1.7 kgf·m, 12.5 ft·lbf), or have them tightened by your Toyota dealer. Failure to do so may cause the dials to be loosened and the bottom cush- ions to be removed.
Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE Before folding down or removing the seats ■ ● The seat belts buckles must be stowed. The head restraints must be removed before you fold down the seatback. ● ■ After returning the seatback and reinstalling the bottom cushion Return the seat belt buckles to their cor- rect position.
Page 73: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. ■ Adjusting the head restraints Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release button.
Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Pull the head restraint up while pushing the lock release button. ■ Installing the head restraints Front seats Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the rear seat head restraints Always raise the head restraint one level from the stowed position when using. CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury.
Page 76: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) Releasing the belt Press the release button. Release button Adjusting the height of the belt (front seats) ■ Move the height adjuster up as needed until you hear a click. Down Push the lock release button and slide the height adjuster down.
Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) ■ The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 79 ● for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ● Do not recline the seat any more than necessary to achieve a proper seat- ing position.
Page 80 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been ●...
Page 81: Steering Wheel
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and pull and hold the lever. Adjust to the ideal position by moving the steering wheel vertically. After adjustment, release the lever to secure the steering wheel.
Page 82: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position FJCRUISER_OM_General_OM35B53W...
Page 83 1-3. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
Page 84 1-3. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error (vehicles with auto anti-glare inside rear view ■ mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. ■ If a sun visor interferes with the mirror Hold and rotate the mirror to adjust the support.
Page 85 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE When adjusting the support ■ Do not push the mirror horizontally from the side. The mirror could fall off. FJCRUISER_OM_General_OM35B53W...
Page 86: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Power-adjustable type (left-hand drive vehicles) Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. FJCRUISER_OM_General_OM35B53W...
Page 87 1-3. Adjustable components (seats, mirrors, steering wheel) Power-adjustable type (right-hand drive vehicles) Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. Manually adjustable type Adjust the mirror up, down, in or out by pushing the mirror surface.
Page 88 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir- rors. STS13AC024 Mirror operating conditions (vehicles with power-adjustable type) ■ The engine switch is in the ACC or ON position. FJCRUISER_OM_General_OM35B53W...
Page 89 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When driving the vehicle ■ Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an acci- dent, resulting in death or serious injury. ●...
Page 90: Opening And Closing The Windows
1-4. Opening and closing the windows Power windows The power windows can be opened/closed using the following switches. Driver’s power window switches Closing Opening One-touch opening (driver’s window only) : To stop the window partway, operate the switch in the oppo- site direction.
Page 91 1-4. Opening and closing the windows Lock switch Left-hand drive vehicles Press the switch down to lock passenger window switches. Use this switch to prevent chil- dren from accidentally opening or closing a passenger window. Right-hand drive vehicles Press the switch down to lock passenger window switches.
Page 92 1-4. Opening and closing the windows CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. ● The driver is responsible for all the power window operations, including the operation for the passengers. In order to prevent accidental operation, especially by a child, do not let a child operate the power windows.
Page 93: Refueling
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the engine switch to the LOCK position and ensure that all the doors, windows and glass hatch are closed. Opening the fuel tank cap ■...
Page 94 1-5. Refueling Right-hand drive vehicles Pull up the opener to open the fuel filler door. Turn the fuel tank cap slowly to open. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction.
Page 95 Fuel types ■ P. 535 ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. CAUTION ■ Refueling the vehicle Observe the following precautions while refueling the vehicle.
Page 96 ● ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 97: Theft Deterrent System
1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
Page 98 1-6. Theft deterrent system ■ Certifications for the engine immobilizer system The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc FJCRUISER_OM_General_OM35B53W...
Page 99 1-6. Theft deterrent system FJCRUISER_OM_General_OM35B53W...
Page 100 1-6. Theft deterrent system FJCRUISER_OM_General_OM35B53W...
Page 101 1-6. Theft deterrent system For vehicles sold in the Dominican Republic FCC ID: MOZRI-20BTY This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 102: Safety Information
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (P. 64) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 103 1-7. Safety information CAUTION While driving ■ ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 104: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 105 1-7. Safety information Airbag system components STS17AC033 Front passenger airbag Side and curtain shield air- bag sensors (if equipped) Curtain shield airbags (if equipped) Driver airbag Side airbags (if equipped) Driver’s seat position sen- SRS warning light Driver’s seat belt buckle Curtain shield airbag sen- switch sors (if equipped)
Page 106 1-7. Safety information SRS warning light ■ This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensor assemblies (if equipped), cur- tain shield airbag sensor assemblies (if equipped), driver’s seat position sen- sor, driver’s seat belt buckle switch, seat belt pretensioner assemblies, interconnecting wiring and power sources.
Page 107 1-7. Safety information ■ Operating conditions (SRS side airbags and SRS curtain shield airbags [if equipped]) The SRS side airbags and SRS curtain shield airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 1500 kg [3307 lb.] vehicle colliding with the vehicle cabin from a direction perpendicu- lar to the vehicle orientation at an approximate speed of 20-30 km/h [12-18...
Page 108 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags [if equipped]) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 109 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. The front of the vehicle is damaged or ●...
Page 110 1-7. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 111 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 112 1-7. Safety information CAUTION SRS airbag precautions ■ ● Vehicles with side airbags and curtain shield airbags: Do not allow anyone to kneel on the passenger seat toward the door or put their head or hands outside the vehicle. ● Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad.
Page 113 ● Vehicles with curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar gar- nishes, are damaged or cracked, have them replaced by your Toyota dealer. ●...
Page 114: Child Restraint Systems
General installation instructions are provided in this manual. (P. 121) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation. ● Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44.
Page 115 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44: Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0 : Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II:...
Page 116 1-7. Safety information Junior seat (booster seat) Equal to Group II and III of ECE No.44 Child restraint system suitability for various seating positions Information provided in the table shows your child restraint system suitability for various seating positions. Seating Rear seat Front position...
Page 117 1-7. Safety information Key of letters inserted in the above table: Suitable for “universal” category child restraint system approved for the use in this mass group. UF: Suitable for forward-facing “universal” category child restraint system approved for the use in this mass group. Not suitable seat position for children in this mass group.
Page 118 1-7. Safety information Child restraint system suitability for various seating positions (with ISOFIX rigid anchor) Information provided in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Rear seat Outside ISO/L1 Carrycot...
Page 119 1-7. Safety information For the child restraint system which do not carry the ISO/XX size class identification (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this mass group.
Page 120 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 121 1-7. Safety information CAUTION Child restraint precautions ■ ● Vehicles with side airbags and curtain shield airbags: Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint system.
Page 122: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts belt requires a locking clip) ISOFIX rigid anchors (ISOFIX...
Page 123 1-7. Safety information Anchor bracket (for top strap) Anchor brackets are provided for all rear seats. FJCRUISER_OM_General_OM35B53W...
Page 124 1-7. Safety information Installing child restraints using a seat belt Rear facing Baby seat (Infant seat)/child seat (Convertible ■ seat) Place the child seat on the rear seat facing the rear of the vehi- cle. Run the seat belt through the child seat and insert the plate into the buckle.
Page 125 1-7. Safety information Forward facing Child seat (convertible seat) ■ Place the child seat on the seat facing the front of the vehicle. Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 126 1-7. Safety information ■ Junior seat (booster seat) Place the junior seat (booster seat) on the seat facing the front of the vehicle. Sit the child in the junior seat (booster seat). Fit the seat belt to the junior seat (booster seat) according to the manufacturer’s instructions and insert the plate into the buckle.
Page 127 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with ISOFIX rigid anchor (ISOFIX child restraint system) Widen the gap between the seat cushion and seatback slightly.
Page 128 1-7. Safety information Child restraint systems with a top strap Secure the child restraint using a seat belt or ISOFIX rigid anchors and remove the head restraint. Raise the anchor bracket, latch the hook onto the anchor bracket and tighten the top strap. Make sure the top strap is securely latched.
Page 129 You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the fol- lowing item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010) ■...
Page 130 1-7. Safety information CAUTION When installing a child restraint system ■ Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
Page 131 1-7. Safety information CAUTION When installing a child restraint system ■ ● Never use a rear-facing child restraint system on the front passenger seat. The force of the rapid inflation of the front passenger airbag can cause death or serous injury to children in the event of an accident.
Page 132 1-7. Safety information CAUTION When installing a child restraint system ■ ● Ensure that the belt and tab are securely locked and the seat belt is not twisted. ● Push and pull the child restraint system in different directions to be sure it is secure.
Page 133 1-7. Safety information FJCRUISER_OM_General_OM35B53W...
Page 134: When Driving
Fog light switch ....168 Trailer towing (left-hand Windshield wipers and drive vehicles and washer ......171 South Africa)....229 Rear window wiper and washer ......174 2-4. Using other driving systems Cruise control ....176 Toyota parking assist-sensor ....180 FJCRUISER_OM_General_OM35B53W...
Page 135: Driving The Vehicle
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine (P. 144) Driving ■ With the brake pedal depressed, shift the shift lever to D. (P. 147) Release the parking brake. (P. 153) Gradually release the brake pedal and gently depress the accelerator pedal to accelerate the vehicle.
Page 136 It does not indicate sudden acceleration. The vehicle is judged to be driving uphill or downhill ● ● When the accelerator pedal is released Breaking in your new Toyota ■ To extend the life of the vehicle, the following precautions are recommended to observe: ●...
Page 137 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down operation.
Page 138 2-1. Driving procedures CAUTION When starting the vehicle ■ Always keep your foot on the brake pedal while stopped with the engine run- ning. This prevents the vehicle from creeping. ■ When driving the vehicle Do not drive if you are unfamiliar with the location of the brake and accel- ●...
Page 139 Have the vehicle inspected by your Toyota dealer immediately. Do not shift the shift lever to P while the vehicle is moving.
Page 140 2-1. Driving procedures CAUTION When driving the vehicle ■ ● Do not adjust the position of the steering wheel, the seat, or the inside or outside rear view mirrors while driving. Doing so may result in a loss of vehicle control that can cause accidents that may result in death or serious injury.
Page 141 2-1. Driving procedures CAUTION When the vehicle is stopped ■ ● In order to prevent accidents due to the vehicle rolling away, always keep depressing the brake pedal while the engine is running, and apply the parking brake as necessary. ●...
Page 142 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 143 2-1. Driving procedures CAUTION When braking the vehicle ■ ● The brake system consists of 2 individual hydraulic systems: If one of the systems fails, the other will still operate. In this case, the brake pedal should be depressed more firmly than usual and braking distance becomes longer.
Page 144 If you hear a squealing or scraping noise while driving (brake pad wear ■ limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 145: Engine (Ignition) Switch
2-1. Driving procedures Engine (ignition) switch ■ Engine switch LOCK The steering wheel is locked and the key can be removed. (The key can be removed only when the shift lever is in P.) Some electrical components such as the audio system can be used.
Page 146 2-1. Driving procedures Turning the key from ACC to LOCK ■ Shift the shift lever to P. (P. 147) Push in the key and turn to the LOCK position. Steering lock release ■ When starting the engine, the engine switch may seem stuck in the LOCK posi- tion.
Page 147 2-1. Driving procedures CAUTION When starting the engine ■ Always start the engine while sitting in the driver’s seat. Do not depress the accelerator while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 148: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the engine switch is on, depress the brake pedal and move the shift lever. Shift position uses ■ Shift position Function Parking the vehicle or starting the engine Reversing...
Page 149 If the shift lever cannot be shifted with your foot on the brake, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 150 2-1. Driving procedures Right-hand drive vehicles Press the shift lock override button. The shift lever can be shifted while the button is pressed. Left-hand drive vehicles Pry the cover up with a flathead screw- driver or equivalent. Press the shift lock override button. The shift lever can be shifted while the button is pressed.
Page 151 2-1. Driving procedures CAUTION To prevent an accident when releasing the shift lock ■ Before pressing the shift lock override button, make sure to set the parking brake and depress the brake pedal. If the accelerator pedal is accidentally depressed instead of the brake pedal when the shift lock override button is pressed and the shift lever is shifted out of P, the vehicle may suddenly start, possibly leading to an accident resulting in death or serious injury.
Page 152: Turn Signal Lever
2-1. Driving procedures Turn signal lever Left-hand drive vehicles Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 153 2-1. Driving procedures Turn signals can be operated when ■ The engine switch is in the ON position. ■ If the indicators flash faster than usual Check that a light bulb in the front or rear turn signal lights has not burned out.
Page 154: Parking Brake
2-1. Driving procedures Parking brake ■ Set the parking brake Fully set the parking brake while depressing the brake pedal. At this time, the indicator will come on. Release the parking brake ■ Slightly raise the lever Press the button Lower it completely FJCRUISER_OM_General_OM35B53W...
Page 155 2-1. Driving procedures Parking the vehicle ■ P. 134 Usage in winter time ■ See “Winter driving tips” for parking brake usage in winter time. P. 223) NOTICE Before driving ■ Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.
Page 156: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
Page 157: Instrument Cluster
2-2. Instrument cluster Gauges and meters The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Voltmeter Displays the charge state. Engine coolant temperature gauge Displays the engine coolant temperature.
Page 158 2-2. Instrument cluster Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ- ent distances independently.
Page 159 2-2. Instrument cluster Instrument cluster light control The brightness of the instrument cluster lights can be adjusted. Left-hand drive vehicles (if equipped) Brighter Darker Right-hand drive vehicles Brighter Darker NOTICE ■ To prevent damage to the engine and its components ●...
Page 160: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel FJCRUISER_OM_General_OM35B53W...
Page 161 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Cruise control indicator (P. 151) (P. 176) (if equipped) Headlight high beam Slip indicator indicator (P. 165) (P. 203, 208, 212) Front fog light indicator VSC OFF indicator (P.
Page 162 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 163 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 164: Accessory Meter
2-2. Instrument cluster  Accessory meter Compass Displays the direction that the vehicle is heading. (P. 376) Outside temperature Displays the outside air temperature. (P. 363) Clinometer Displays the longitudinal and lateral inclination of the vehicle. SET button This button is used to calibrate the compass. (P. 378) E/M button Outside temperature mode: Switch the outside air temperature display between °C (Celsius) and °F...
Page 165 2-2. Instrument cluster CAUTION Caution while driving ■ Do not adjust the display. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. FJCRUISER_OM_General_OM35B53W...
Page 166: Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. The side marker (if equipped), front posi- tion, tail, license plate, outside rear view mir- illumination equipped) and instru- ment panel lights turn The headlights and all lights listed above turn Turning on the high beam headlights With the headlights on, push...
Page 167 2-3. Operating the lights and wipers Headlight leveling dial (right-hand drive vehicles only) The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle. Raises the level of the head- lights Lowers the level of the head- lights...
Page 168 2-3. Operating the lights and wipers Automatic light off system ■ The headlights and tail lights turn off automatically with the engine switch turned to the ACC or LOCK position and the driver’s door is opened. To turn the lights on again, turn the engine switch to the ON position, or turn the headlight switch off once and then back to the position.
Page 169: Fog Light Switch
2-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Front fog light switch (if equipped) ■ Turns the front fog light Turns the front fog light FJCRUISER_OM_General_OM35B53W...
Page 170 2-3. Operating the lights and wipers ■ Rear fog light switch (right-hand drive vehicles) Press the rear fog light switch. The rear fog light indicator will come on. Press the switch again to turn the rear fog lights off. FJCRUISER_OM_General_OM35B53W...
Page 171 2-3. Operating the lights and wipers Rear fog lights (right-hand drive vehicles) ■ The rear fog lights are used to warn other drivers of the presence of your vehicle when visibility is bad, such as in rain or fog. Do not use the rear fog lights when visibility is good because they may dis- turb drivers behind you.
Page 172: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation (when INT is selected). Left-hand drive vehicles Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency...
Page 173 2-3. Operating the lights and wipers Washer/wiper dual opera- tion Wipers will automatically oper- ate a couple of times after the washer squirts. Right-hand drive vehicles Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Decreases the intermittent windshield wiper frequency Increases the intermittent...
Page 174 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. FJCRUISER_OM_General_OM35B53W...
Page 175: Rear Window Wiper And Washer
2-3. Operating the lights and wipers  Rear window wiper and washer Left-hand drive vehicles Intermittent window wiper operation. The wiper operates 3 times at normal speed and then moves to intermittent mode. Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion...
Page 176 2-3. Operating the lights and wipers Right-hand drive vehicles Intermittent window wiper operation. The wiper operates 3 times at normal speed and then moves to intermittent mode. Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The rear window wiper oper- ates while the washer squirts.
Page 177: Using Other Driving Systems
2-4. Using other driving systems  Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch Setting the vehicle speed ■ Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come on.
Page 178 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 179 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. FJCRUISER_OM_General_OM35B53W...
Page 180 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 181: Toyota Parking Assist-Sensor
2-4. Using other driving systems  Toyota parking assist-sensor The Toyota parking assist-sensor assists the driver by communicat- ing the distance to obstacles measured by the sensors via the buzzer when parallel parking or maneuvering into a garage. Always check the surrounding area when using this system.
Page 182 2-4. Using other driving systems Type B These sensors detect obsta- cles behind the vehicle. FJCRUISER_OM_General_OM35B53W...
Page 183 2-4. Using other driving systems ■ Toyota parking assist-sensor switch On/off When on, the buzzer sounds to inform the driver that the system is operational. At this time, the indicator will come Press the switch to switch the on/off mode.
Page 184 2-4. Using other driving systems Sensors that operate and detection range The following diagrams show the sensor detection range. Note that sensors may not be able to detect obstacles that are extremely close to the vehicle. ■ Detection range of the sensors Approx.
Page 185 2-4. Using other driving systems The Toyota parking assist system can be operated when ■ ● The engine switch is at the ON position. ● The shift lever is in R. Sensor detection information ■ ● Certain vehicle conditions and the surrounding environment may affect the ability of a sensor to correctly detect an obstacle.
Page 186 • A person near the vehicle (depending on the type of clothes worn) • When the bumper is damaged. CAUTION Caution when using the Toyota parking assist-sensor ■ Observe the following precautions. Failure to do so may result in the vehicle being unable to be driven safely and possibly cause an accident.
Page 187: Rear View Monitor System
2-4. Using other driving systems  Rear view monitor system The rear view monitor system assists the driver by displaying guide lines and an image of the view behind the vehicle while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 188 2-4. Using other driving systems Switching the screen The rear view monitor display on the inside rear view mirror can be turned on/off. Except for South Africa When the screen is displayed, press on the inside rear view mirror to switch the screen ON/OFF mode.
Page 189 2-4. Using other driving systems Press and hold to turn the display on/off. To leave the “Rear View Monitor Menu”, select “Back to main menu” to return to the starting screen, then either select “Exit” or wait several seconds without pressing Screen description Guide lines are displayed on the screen.
Page 190 2-4. Using other driving systems Distance guide line (red) This line indicates a position on the ground about 0.5 m (1.5 ft.) behind on the ground of the rear bumper of your vehicle. Rear view monitor system precautions Area displayed on screen ■...
Page 191 2-4. Using other driving systems ■ Rear view monitor system camera The camera for the rear view monitor system is located to the spare wheel cover. ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud, etc.) is adhering to the camera, it cannot transmit a clear image.
Page 192 2-4. Using other driving systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual distance. Because of this, objects will appear to be farther away than they actually are.
Page 193 2-4. Using other driving systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of pas- sengers or the distribution of the load, there is a margin of error between the guide lines on the screen and the actual distance/ A margin of error course on the road.
Page 194 2-4. Using other driving systems ● Distance guide lines Visually check the surroundings and the area behind the vehicle. On the screen, it appears that a truck is parking at point B. How- ever, in reality if you back up to point A, you will hit the truck.
Page 195 ■ If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Symptom Likely cause Solution •...
Page 196 Solution The image is The camera or surrounding Have the vehicle out of align- area has received a strong inspected by your Toyota ment impact. dealer. When a bright spot (such as sunlight reflecting off the body of another vehicle) is...
Page 197 2-4. Using other driving systems When using the rear view monitor system ■ The anti-glare function of the inside rear view mirror will be canceled. Rear view monitor system settings ■ The following can be adjusted when the engine switch is in the ON position and the shift position is in R.
Page 198 2-4. Using other driving systems CAUTION When using the rear view monitor system ■ The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding. Observe the following precautions to avoid an accident that could result in death or serious injury.
Page 199 Doing so may result in the camera malfunc- tioning. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. FJCRUISER_OM_General_OM35B53W...
Page 200: Four-Wheel Drive System
2-4. Using other driving systems Four-wheel drive system Use the front-wheel drive control lever to select the following trans- fer modes. The four-wheel drive indicator comes on when the H4, N or L4 mode is selected. H2 (high speed position, two-wheel drive) Use this for normal driving on dry hard-surfaced roads.
Page 201 2-4. Using other driving systems Shifting between H2 and H4 ■ ● Reduce your speed to less than 80 km/h (50 mph) and shift the front- wheel drive control lever from H2 to H4. If you have trouble shifting in cold weather, reduce your speed or stop the vehicle.
Page 202 2-4. Using other driving systems CAUTION Caution while driving ■ ● Never shift the front-wheel drive control lever from H2 to H4 if the wheels are slipping. Stop the slipping or spinning before shifting. ● For normal driving on dry and hard surface roads, use H2 position. Driving on dry and hard surface roads in H4 or L4 position may cause drive com- ponent oil leakage, seizure, or other problems resulting in an accident.
Page 203: Active Traction Control System
2-4. Using other driving systems  Active traction control system The active traction control system automatically helps prevent the spinning of 4 wheels when the vehicle is started or accelerated on slippery road surfaces. System operation ■ Stop the vehicle, shift the shift lever to N and shift the front- wheel drive control lever into L4.
Page 204 2-4. Using other driving systems Vehicles with overhead console Press the A-TRAC switch to activate the system. At this time, the active traction control system indicator will come on. To cancel the system, push the switch again. When the active traction control system is operating If any of the drive wheels spins, the slip indicator flashes to indi- cate that the active traction con-...
Page 205 2-4. Using other driving systems When the rear differential is locked (vehicles with the rear differential ■ lock system) The active traction control system is activated only when the vehicle speed is less than 6 km/h (4 mph). ■ Sounds and vibrations caused by the active traction control system ●...
Page 206: Rear Differential Lock System
2-4. Using other driving systems  Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or rugged surface. The rear differential lock system is effective in case one of the rear wheels is spinning.
Page 207 2-4. Using other driving systems Vehicles with overhead console Press the RR DIFF LOCK switch to lock the rear differen- tial. At this time, the rear differential lock indicator will blink. Wait a few seconds for the system to complete operation. After the rear differential is locked, the indicator will stop blinking and remain on.
Page 208 2-4. Using other driving systems Locking the rear differential ■ ● When the rear differential is locked, VSC is automatically turned off. (The rear differential lock and VSC OFF indicators will come on.) ● The following systems do not operate when the rear differential is locked. It is normal operation for the ABS warning light and VSC OFF indicator to be on at this time.
Page 209: Crawl Control
2-4. Using other driving systems  Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road sur- faces, allowing for stable driving.
Page 210 2-4. Using other driving systems ■ Speed modes The following table shows some typical terrains and the recommended speed modes. Mode Road condition L (Low) Rock, mogul (downhill) and gravel (downhill) Between L and M Mogul (uphill) M (Medium) Snow, mud, gravel (uphill), sand, dirt, Between M and H mogul (uphill) and grass H (High)
Page 211 2-4. Using other driving systems Crawl Control can be operated when ■ ● The engine is running. ● The shift lever is in any position other than P or N. The front-wheel drive control lever is in L4. ● ● The driver’s door is closed.
Page 212 2-4. Using other driving systems CAUTION When using Crawl Control ■ ● Do not overly rely on Crawl Control. This function does not extend the vehicle’s performance limitations. Always check the terrain thoroughly and drive safely. ● The recommended speed modes for the listed terrains (P. 209) are only a reference.
Page 213: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 214 2-4. Using other driving systems To disable TRC and/or VSC If the vehicle gets stuck in fresh snow or mud, TRC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
Page 215 ■ switch has not been pressed TRC and Crawl Control (if equipped) systems cannot be operated. Contact your Toyota dealer. ■ Automatic reactivation of TRC and VSC Turning the engine switch off after turning off the TRC and VSC systems will automatically re-enable them.
Page 216 In addition, make sure that the tires are inflated to the appro- priate tire pressure level. The ABS, VSC and TRC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. FJCRUISER_OM_General_OM35B53W...
Page 217 2-4. Using other driving systems CAUTION Handling of tires and suspension ■ Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction. FJCRUISER_OM_General_OM35B53W...
Page 218: Driving Information
2-5.Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
Page 219 2-5. Driving information CAUTION Off-road vehicle precautions ■ Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 220 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 221 2-5. Driving information CAUTION Off-road driving precautions ■ ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Therefore, the driver and all passengers should fasten their seat belts whenever the vehicle is moving. ●...
Page 222: Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 223 2-5. Driving information CAUTION Storage precautions ■ ● Do not stack anything in the luggage compartment higher than the seat- backs. Such items may be thrown about and possibly injure people in the vehicle during sudden braking or in an accident. ●...
Page 224: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations ■ ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 225 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Regulations on the use of snow chains ●...
Page 226 2-5. Driving information Snow chain installation ■ Observe the following precautions when installing and removing chains. ● Install and remove tire chains in a safe location. Install tire chains on the rear tires only. Do not install tire chains on the ●...
Page 227: Eco-Friendly Driving Tips
2-5. Driving information Eco-friendly driving tips For improved fuel economy and reduced CO2 emissions, pay atten- tion to the following points: ■ Accelerator pedal/brake pedal operation Drive your vehicle smoothly. Avoid abrupt acceleration and decelera- tion. Gradual acceleration and deceleration will help reduce excessive fuel consumption.
Page 228 2-5. Driving information ■ Performing idling stops ● Avoid unnecessary idling. Stop the engine when parking the vehicle to reduce excessive fuel consumption, even it is only for a short period of time. ● Except in severe environment, such as when the outside tem- perature is extremely low, warming up the engine before driv- ing is unnecessary.
Page 229: Trailer Towing (Right-Hand Drive Vehicles Except South Africa)
Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier of a wheelchair, scooter, bicycle, etc. Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 230: Trailer Towing (Left-Hand Drive Vehicles And South Africa)
The vehicle stability and braking performance are affected by trailer stability, brake adjustment and performance, and the hitch. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Ask your local authorized Toyota dealer or repairer, or another duly qualified and equipped professional, for further details before tow- ing, as there are additional legal requirements in some countries.
Page 231 2-5. Driving information Important points regarding trailer loads Total trailer weight and permissible drawbar load ■ Total trailer weight Weight of the trailer itself plus the trailer load should be within the maximum towing capacity. Exceeding this weight is danger- ous.
Page 232 2-5. Driving information ■ Information tag (manufacturer’s label) Gross vehicle mass The combined weight of the driver, passengers, towing hitch, total curb mass and drawbar load should not exceed the gross vehi- cle mass by more than 100 kg (220.5 lb.). Exceeding this weight is dangerous.
Page 233 2-5. Driving information Installation positions for the towing hitch/bracket and hitch ball 78 mm (3.07 in.) 78 mm (3.07 in.) 53 mm (2.09 in.) 53 mm (2.09 in.) 53 mm (2.09 in.) 53 mm (2.09 in.) 1082 mm (42.60 in.) 130.6 mm (5.14 in.) 72.6 mm (2.86 in.) 47.6 mm (1.87 in.)
Page 234 2-5. Driving information Hitch ● If you wish to install a trailer hitch, contact your local authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ● Use only a hitch that conforms to the gross trailer weight require- ment.
Page 235 For the correct safety chain installation procedure, ask your local authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 236 2-5. Driving information ■ Safety checks before towing Check that the maximum load limit for the towing hitch/bracket and tow- ● ing ball is not exceeded. Bear in mind that the coupling weight of the trailer will add to the load exerted on the vehicle. Also make sure that the total load exerted on the vehicle is within the range of the weight limits.
Page 237 2-5. Driving information Guidance Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, by keeping the following in mind when towing: ■ Checking connections between trailer and lights Before starting out, check the trailer lights and all vehicle-trailer connections, and after driving a short distance, stop and recheck the lights and connections.
Page 238 2-5. Driving information ■ Important points regarding turning ● The wheels of the trailer will travel closer to the inside of the curve than the wheels of the vehicle. To make allowance for this, take the turns wider than you would normally. ●...
Page 239 2-5. Driving information ■ When parking the vehicle ● Always place wheel blocks behind both the vehicle wheels and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
Page 240 2-5. Driving information CAUTION Follow all the instructions described in this section. Failure to do so could cause an accident resulting in death or serious injury. ■ Trailer towing precautions ● When towing, make sure that none of the weight limits are exceeded. (P.
Page 241: Using The Air Conditioning
3-1. Using the air conditioning system and defogger Air conditioning system..242 Rear window defogger..249 3-2. Using the audio system Audio system types... 250 Using the radio....253 Using the CD player..259 Playing MP3 and WMA discs...... 267 Operating an iPod.....
Page 242 Interior features ® 3-3. Using the Bluetooth audio 3-5. Using the interior lights system Interior lights list....351 ® • Interior lights ....352 Bluetooth audio • Personal lights ....353 system ......307 ® Using the Bluetooth 3-6. Using the storage features audio system ....
Page 243: Air Conditioning System
3-1. Using the air conditioning system and defogger Air conditioning system Outside air or recirculated Air conditioning air mode switch ON/OFF switch Fan speed control dial Temperature control dial Air outlet selection dial Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 244 3-1. Using the air conditioning system and defogger ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can also be selected for more detailed adjustment. When the dial is set to , air flows to the upper body.
Page 245 3-1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet and the wind- shield defogger operates. When the dial is set to , air flows to the windshield and side windows to defog them.
Page 246 3-1. Using the air conditioning system and defogger Adjusting the position of the air outlets Center outlets Direct air flow to the left or right, up or down. FJCRUISER_OM_General_OM35B53W...
Page 247 3-1. Using the air conditioning system and defogger Right and left side outlets Direct air flow to the left or right, up or down. Opening and closing the right and left side outlets Open the vent. Close the vent. FJCRUISER_OM_General_OM35B53W...
Page 248 There may be a problem in the air conditioning system if the indi- cator continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Ventilation and air conditioning odors To let fresh air in, set the air conditioning system to the outside air mode.
Page 249 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up ■ Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 250: Rear Window Defogger
3-1. Using the air conditioning system and defogger Rear window defogger This feature is used to defog the rear window. On/off Press the button to turn on the rear window defogger. The indicator light will come on. The defogger will automatically turn off after 15 to 240 minutes.
Page 251: Using The Audio System
3-2. Using the audio system  Audio system types Type A: CD player with external CD changer controller and AM/FM radio Type B: CD player with a changer and AM/FM radio Type A Type B  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 252 3-2. Using the audio system Title Page Using the radio P. 253 Using the CD player P. 259 Playing MP3 and WMA discs P. 267 Operating an iPod P. 276 Operating a USB memory P. 285 Optimal use of the audio system P.
Page 253 3-2. Using the audio system CAUTION Certification for the CD player ■ This product is a class 1 laser product. Do not open the cover of the player or attempt to repair the unit yourself. ● Refer servicing to qualified personnel. Laser power: No hazardous ●...
Page 254: Using The Radio
3-2. Using the audio system  Using the radio Type A “PWR·VOL” knob Frequency adjustment knob Preset station buttons Power Volume TA mode button Seek button AF mode button AM/FM mode buttons Auto preset button Program type button  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 255 3-2. Using the audio system Type B “PWR·VOL” knob Frequency adjustment knob Preset station buttons Power Volume Seek button Preset tuning button AM/FM mode buttons Scan button FJCRUISER_OM_General_OM35B53W...
Page 256 3-2. Using the audio system Setting station presets Manually operation ■ Search for the desired stations by turning pressing “” or “” on Press and hold the button (from ) the station is to be set to until you hear a beep. Automatically operation (type A) ■...
Page 257 3-2. Using the audio system RDS (Radio Data System) (type A) This feature allows your radio to receive station and program informa- tion (classical, news, etc.) from radio stations which broadcast this information. ■ Listening to stations of the same network Press “AF-ON”, “REG-OFF”...
Page 258 3-2. Using the audio system ■ Traffic information Press TP mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received. The station returns to the previous one when the traffic information ends. TA mode: Traffic information can be heard only when a signal is received.
Page 259 3-2. Using the audio system EON (Enhanced Other Network) system (for traffic announcement ■ function) (type A) If the RDS station (with EON data) you are listening to is not broadcasting a traffic information program and the audio system is in the TA (traffic announcement) mode, the radio will be switched automatically to a station broadcasting a traffic information program in the EON AF list when traffic information begins.
Page 260: Using The Cd Player
3-2. Using the audio system  Using the CD player Type A “PWR·VOL” knob Eject button Random playback button Power Volume Repeat play button Track selector button Text button Playback button  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 261 3-2. Using the audio system Type B “PWR·VOL” knob Eject button Repeat play button Power Volume Load button CD selector Track selector buttons button Text button Scan button Random playback button Playback button Playback/Pause button Loading a CD Loading a CD ■...
Page 262 3-2. Using the audio system ■ Loading multiple CDs (type B) Press and hold until you hear a beep. “WAIT” is shown on the display. When the indicator on the slot turns from amber to green, insert a CD. The display changes from “WAIT” to “LOAD”. The indicator on the slot turns to amber when the CD is being inserted.
Page 263 3-2. Using the audio system Selecting, fast-forwarding, reversing and scanning tracks Selecting a track ■ Press “” to move up or “” to move down using until the desired track number is displayed. Fast-forwarding and reversing tracks ■ To fast-forward or reverse, press and hold “” or “” on until you hear a beep.
Page 264 3-2. Using the audio system Random playback Current CD ■ Press (RAND). Songs are played in random order. To cancel, press (RAND) again. All CDs (type B) ■ Press and hold (RAND) until you hear a beep. Tracks on all loaded CDs are played in random order. To cancel, press (RAND) again.
Page 265 “WAIT”: This indicates that operation is stopped due to a high tempera- ture inside the player. Wait for a while and then press . If the CD still cannot be played back, contact your Toyota dealer. ■ Discs that can be used Discs with the marks shown below can be used.
Page 266 3-2. Using the audio system NOTICE CDs and adapters that cannot be used ■ Do not use the following types of CDs. Also, do not use 8 cm (3 in.) CD adapters, DualDiscs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function. CDs that have a diameter that is not ●...
Page 267 3-2. Using the audio system NOTICE CD player precautions ■ Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. Do not apply oil to the CD player.
Page 268: Playing Mp3 And Wma Discs
3-2. Using the audio system  Playing MP3 and WMA discs Type A “PWR·VOL” knob Eject button Random playback button Power Volume Folder selector buttons File selector knob File selector button Text button Playback button Repeat play button  : If equipped FJCRUISER_OM_General_OM35B53W...
Page 269 3-2. Using the audio system Type B “PWR·VOL” knob Eject button Load button Repeat play button Power Volume Folder selector buttons File selector knob File selector button Disc selector button Search playback button Random playback button Playback button Text button Playback/Pause button Loading MP3 and WMA discs P.
Page 270 3-2. Using the audio system Selecting and scanning a folder Selecting a folder one at a time ■ Press () or () or “” or “” on the to select the desired folder. Returning to the first folder ■ Press and hold () or “”...
Page 271 3-2. Using the audio system ■ Scanning the files in a folder (type B) Press The first 10 seconds of each file will be played. To cancel, press again. When the desired file is reached, press again. Playing and pausing files (type B) To play or pause a file, press Random playback ■...
Page 272 Wait for a while and then press . If the CD still cannot be played back, con- tact your Toyota dealer. “NO MUSIC”: This indicates that an MP3/WMA file is not included in the CD. FJCRUISER_OM_General_OM35B53W...
Page 273 3-2. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used.
Page 274 3-2. Using the audio system ● WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
Page 275 3-2. Using the audio system ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 276 3-2. Using the audio system NOTICE CDs and adapters that cannot be used (P. 265) ■ ■ CD player precautions (P. 266) FJCRUISER_OM_General_OM35B53W...
Page 277: Operating An Ipod
3-2. Using the audio system  Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect an iPod using an iPod cable. Left-hand drive vehicles Turn on the power of the iPod if it is not turned on.
Page 278 3-2. Using the audio system Right-hand drive vehicles Turn on the power of the iPod if it is not turned on. Press FJCRUISER_OM_General_OM35B53W...
Page 279 3-2. Using the audio system ■ Control panel Type A “PWR·VOL” knob Shuffle playback button Playback/Pause button Power Volume iPod menu/Song selector knob Song selector button Text button Go back button Repeat play button Playback button FJCRUISER_OM_General_OM35B53W...
Page 280 3-2. Using the audio system Type B “PWR·VOL” knob Shuffle playback button Playback/Pause button Power Volume iPod menu/Song selector knob Song selector button Playback button Repeat play button Text button Go back button Selecting a play mode Press to select iPod menu mode. Turning changes the play mode in the follow- ing order:...
Page 281 3-2. Using the audio system ■ Play mode list First Second Third Fourth Play mode selection selection selection selection Playlists “PLAYLISTS” Songs select select “ARTISTS” Artists select Albums select Songs select “ALBUMS” Albums select Songs select “SONGS” Songs select “PODCASTS” Albums select Songs select “GENRES”...
Page 282 3-2. Using the audio system Selecting songs Turn or press “” or “” on to select the desired song. Playing and pausing songs To play or pause a song, press Fast-forwarding and reversing songs To fast-forward or reverse, press and hold “” or “” on until you hear a beep.
Page 283 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Album title  Track title  Artist name Adjusting sound quality and volume balance Press to enter iPod menu mode.
Page 284 3-2. Using the audio system ■ Error messages “ERROR”: This indicates a problem in the iPod or its connection. “NO MUSIC”: This indicates that there is no music data in the iPod. “EMPTY”: This indicates that an empty playlist is selected. “UPDATE”: This indicates that the version of the iPod is not compatible.
Page 285 3-2. Using the audio system CAUTION Caution while driving ■ Do not connect iPod or operate the controls. NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. ●...
Page 286: Operating A Usb Memory
3-2. Using the audio system  Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a USB memory Left-hand drive vehicles Turn on the power of the USB memory if it is not turned on.
Page 287 3-2. Using the audio system Right-hand drive vehicles Turn on the power of the USB memory if it is not turned on. Press FJCRUISER_OM_General_OM35B53W...
Page 288 3-2. Using the audio system ■ Control panel Type A “PWR·VOL” knob Random playback button Repeat play button Power Volume Folder selector buttons File selector knob File selector button Text button Playback button Playback/Pause button FJCRUISER_OM_General_OM35B53W...
Page 289 3-2. Using the audio system Type B “PWR·VOL” knob Random playback button Repeat play button Power Volume Folder selector buttons File selector knob File selector button Search playback button Playback button Playback/Pause button Text button Selecting and scanning a folder Selecting folders one at a time ■...
Page 290 3-2. Using the audio system When the desired folder is reached, press again. Selecting and scanning files Selecting a file ■ Turn or press “” or “” on to select the desired file. Scanning the files in a folder (type B) ■...
Page 291 3-2. Using the audio system Repeat play Repeating a file ■ Press (RPT). To cancel, press (RPT) again. ■ Repeating all the files in a folder Press and hold (RPT) until you hear a beep. To cancel, press (RPT) again. Switching the display Press Each time the button is pressed, the display changes in the following...
Page 292 3-2. Using the audio system ■ Error messages “ERROR”: This indicates a problem in the USB memory or its connection. “NO MUSIC”: This indicates that no MP3/WMA files are included in the USB memory. ■ USB memory Compatible devices ● USB memory that can be used for MP3 and WMA playback.
Page 293 3-2. Using the audio system ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
Page 294 3-2. Using the audio system ● MP3 and WMA playback • When a device containing MP3 or WMA files is connected, all files in the USB memory device are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders.
Page 295 3-2. Using the audio system CAUTION Caution while driving ■ Do not connect USB memory or operate the controls. NOTICE ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player.
Page 296: Optimal Use Of The Audio System
3-2. Using the audio system  Optimal use of the audio system Type A Displays the current mode Changes the following set- ting • Sound quality and vol- ume balance (P. 296) The sound quality and bal- ance setting changed to produce the best sound.
Page 297 3-2. Using the audio system Adjusting sound quality and volume balance Changing sound quality modes ■ Pressing Pressing the button changes sound modes in the following order: “BAS”  “TRE”  “FAD”  “BAL” (type A)  “FIX-EQ” (type A)  “ASL”...
Page 298 3-2. Using the audio system Turning the Automatic Sound Levelizer (ASL) on/off Type A When “ASL” is selected, turning to the right changes the “ASL” level in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to the vehicle speed.
Page 299 3-2. Using the audio system Trademark owned by SRS Labs, Inc. (type A) ■   The audio systems utilize SRS FOCUS and SRS TruBass audio enhancement technologies, under license from SRS Labs, Inc., in all mode except AM radio mode. FOCUS, TruBass, SRS and symbols are trademarks of SRS Labs, Inc.
Page 300: Using The Aux Port/Usb Port
3-2. Using the audio system  Using the AUX port/USB port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect the portable audio device. Left-hand drive vehicles ...
Page 301 3-2. Using the audio system Right-hand drive vehicles Press ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All the other adjustments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet ■...
Page 302: Using The Steering Wheel Audio Switches
3-2. Using the audio system  Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Increases/decreases vol- Radio mode: Selects radio station CD mode: Selects a track, file (MP3 WMA) and disc ®...
Page 303 3-2. Using the audio system Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the button is pressed. If no discs are inserted in the player, that mode will be skipped. FM1FM2 ...
Page 304 3-2. Using the audio system Selecting a folder Press to select USB memory mode. Press and hold “” or “” on until you hear a beep. Selecting a disc in the CD player (type B) Press to select CD mode. Press and hold “”...
Page 305: Antenna
3-2. Using the audio system Antenna The antenna can be removed. ■ Removing the antenna Place the included wrench around the antenna. When not in use, the wrench is stored in glove box. Loosen the antenna with the wrench and remove it. FJCRUISER_OM_General_OM35B53W...
Page 306 3-2. Using the audio system ■ Installing the antenna Tighten the antenna by one hand until it will not turn any more. Using the wrench, tighten the antenna an additional 1/8th turn (20 to 45 degrees) to secure it in place. After tightening the antenna, remove the wrench.
Page 307 3-2. Using the audio system NOTICE To avoid damage to the antenna ■ Remove the antenna in the following situations. When using an automatic carwash. ● ● When the antenna will touch the ceiling of a garage, etc. When covering the vehicle with a car cover. ●...
Page 308: Using The Bluetooth ® Audio
® 3-3. Using the Bluetooth audio system  ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable player from the vehicle speakers via wireless communica- tion. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 309 ® 3-3. Using the Bluetooth audio system ® ■ About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models ® ● Bluetooth specifications: Ver. 1.2, or higher (Recommended: Ver. 2.0+EDR or higher) Following Profiles: ● • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher •...
Page 310 ® 3-3. Using the Bluetooth audio system CAUTION Caution while driving ■ Do not connect portable players or operate the controls. Caution regarding interference with electronic devices ■ ® ● Your audio unit is fitted with Bluetooth antennas. People with implanted pacemakers or cardiac defibrillators should maintain a reasonable dis- ®...
Page 311: Using The Bluetooth ® Audio System
® 3-3. Using the Bluetooth audio system  ® Using the Bluetooth audio system ■ Audio unit Display A message, name, number etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
Page 312 ® 3-3. Using the Bluetooth audio system ■ Microphone FJCRUISER_OM_General_OM35B53W...
Page 313 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press and select “Setup (BT·A Setup)”...
Page 314 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system Second First menu Third menu Operation detail menu Registering a portable audio “Pair Audio” player Selecting a portable audio “Select Audio” player to be used “BT A Changing the registered “Change Name”...
Page 315: Operating A Bluetooth
® 3-3. Using the Bluetooth audio system  ® Operating a Bluetooth enabled portable player Type A “PWR·VOL” knob Random playback button Playback/Pause button Power Volume Album selector buttons BT A menu knob Track selector button Text button Repeat play button Playback button ...
Page 316 ® 3-3. Using the Bluetooth audio system Type B “PWR·VOL” knob Random playback button Playback/Pause button Power Volume Album selector buttons BT A menu knob Track selector button Text button Repeat play button Playback button Selecting an album To select the desired album, press () or () or “”...
Page 317 ® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press and hold “  ” or “” on until you hear a beep. Random playback Press (RAND). To cancel, press (RAND) again. Repeat play Press (RPT).
Page 318 ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system functions ■ Depending on the portable player that is connected to the system, certain functions may not be available. ■ Display Up to 12 characters can be displayed at a time. If there are 13 or more characters, pressing and holding 1 second or more enables to display the remaining characters.
Page 319: Setting Up A Bluetooth ® Enabled Portable Player
® 3-3. Using the Bluetooth audio system  ® Setting up a Bluetooth enabled portable player ® Registering a portable audio player in the Bluetooth audio system allows the system to function. The following functions can be used for registered portable players: Functions and operation procedures ■...
Page 320 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio” using , and perform the procedure for registering a portable player. (P. 312) Selecting a portable player to be used Select “Select Audio” using Select the portable player to be used using Select “From Car”...
Page 321 ® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audios” using The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT A Setup (BT·A Setup)”. Changing the passkey Select “Set Passkey”...
Page 322 ® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio” using Select the desired portable player to be deleted using ® If the portable player to be deleted is paired as a Bluetooth phone, the registration of the mobile phone can be deleted at the same time. When “Del Phone?”...
Page 323: Bluetooth Audio System Setup
® 3-3. Using the Bluetooth audio system  ® Bluetooth audio system setup ■ System setup items and operation procedures To enter the menu of each setting, follow the steps below. Press to select “Setup (BT·A Setup)” or press the off-hook switch (P. 328) and select “Setup (BT·A Setup)”...
Page 324: Using The Hands-Free Phone System (For Mobile Phone)
3-4. Using the hands-free phone system (for mobile phone)  Hands-free phone system (for mobile phone) The hands-free phone system is a function that allows you to use your mobile phone without touching it. ® ® This system supports Bluetooth mobile phones.
Page 325 3-4. Using the hands-free phone system (for mobile phone) Title Page Security and system setup ■ Security setting items and operation procedures P. 341 ■ System setup items and operation procedures Using the phone book ■ Adding a new phone number ■...
Page 326 3-4. Using the hands-free phone system (for mobile phone) ■ When using the hands-free phone system The audio system and voice guidance are muted when making a call. ● ● If both parties speak at the same time, it may be difficult to hear. If the incoming call volume is overly loud, an echo may be heard.
Page 327 3-4. Using the hands-free phone system (for mobile phone) CAUTION Caution while driving ■ ® Do not use a mobile phone or connect the Bluetooth phone. Caution regarding interference with electronic devices ■ ® ● Your audio unit is fitted with Bluetooth antennas.
Page 328: Using The Hands-Free Phone System (For Mobile Phone)
3-4. Using the hands-free phone system (for mobile phone)  Using the hands-free phone system (for mobile phone) ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Selects speed dials Displays information that is too long to be displayed at one time on the display...
Page 329 3-4. Using the hands-free phone system (for mobile phone) ■ Steering wheel switches Volume The voice guidance volume cannot be adjusted using this button. Off-hook switch Turns the hands-free sys- tem on/starts a call On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Talk switch...
Page 330 3-4. Using the hands-free phone system (for mobile phone) ■ Microphone FJCRUISER_OM_General_OM35B53W...
Page 331 3-4. Using the hands-free phone system (for mobile phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a mobile phone in the system. The system will enter phone registra- tion mode automatically when starting the system with no mobile phone registered.
Page 332 3-4. Using the hands-free phone system (for mobile phone) Menu list of the hands-free phone system Second First menu Third menu Operation detail menu Dialing a number stored in “CallBack” the incoming call history memory Dialing a number stored in “Redial”...
Page 333 3-4. Using the hands-free phone system (for mobile phone) Second First menu Third menu Operation detail menu “Set PIN” Setting a PIN code “Security” “Phbk Lock” Locking the phone book “Phbk Unlock” Unlocking the phone book “Pair Phone” Registering a mobile phone Selecting a mobile phone to “Select Phone”...
Page 334 3-4. Using the hands-free phone system (for mobile phone) Automatic volume adjustment ■ When vehicle speed reaches 80 km/h (50 mph) or more, the volume auto- matically increases. The volume returns to the previous volume setting when vehicle speed drops to 70 km/h (43 mph) or less. ■...
Page 335: Making A Phone Call
3-4. Using the hands-free phone system (for mobile phone)  Making a phone call ■ Making a phone call ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 336 3-4. Using the hands-free phone system (for mobile phone) Dialing by inputting a name Press the talk switch and say a registered name. The desired name or number is displayed. Dial by one of the following methods: a. Press the off-hook switch. b.
Page 337 3-4. Using the hands-free phone system (for mobile phone) Transferring a call A call can be transferred between the mobile phone and system while dialing, receiving a call, or during a call. Use one of the following methods: a. Operate the mobile phone. Refer to the manual that comes with the mobile phone for the opera- tion of the phone.
Page 338 3-4. Using the hands-free phone system (for mobile phone) Using a call history memory Follow the procedure below to use a number stored in call history memory: Press the off-hook switch and select “Redial” (when using a number stored in the outgoing call history memory) or “Call back”...
Page 339: Setting A Mobile Phone
3-4. Using the hands-free phone system (for mobile phone)  Setting a mobile phone Registering a mobile phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered mobile phones: Functions and operation procedures ■...
Page 340 3-4. Using the hands-free phone system (for mobile phone) Registering a mobile phone Select “Pair Phone” using , and perform the proce- dure for registering a mobile phone. (P. 330) Selecting a mobile phone to be used Select “Select Phone” using Select the mobile phone to be used using Changing a registered name of a mobile phone Select “Change Name”...
Page 341 3-4. Using the hands-free phone system (for mobile phone) Changing the passkey Select “Set Passkey” using Select a 4 to 8-digit number using The number should be input 1 digit at a time. When the entire number to be registered as a passkey has been input, press again.
Page 342: Security And System Setup
3-4. Using the hands-free phone system (for mobile phone)  Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedures Press the off-hook switch and select “Setup” using Select “Security”...
Page 343 3-4. Using the hands-free phone system (for mobile phone) ■ System setup items and operation procedures Press the off-hook switch and select “Setup” using Select “System Setup” using Select one of the following items using ● Setting voice tag playback volume (Setting voice guidance volume) “Playback Vol (Guidance Vol)”...
Page 344 3-4. Using the hands-free phone system (for mobile phone) Setting or changing the PIN Setting a PIN ■ Select “Set PIN” using Enter a PIN using Input the code 1 digit at a time. ■ Changing the PIN Select “Set PIN” using Enter the registered PIN using Enter a new PIN using Input the code 1 digit at a time.
Page 345 3-4. Using the hands-free phone system (for mobile phone) Setting voice tag playback (guidance) volume Select “Playback Vol (Guidance Vol)” using Change the voice tag playback (guidance) volume. To decrease the volume: Turn counterclock- wise. To increase the volume: Turn clockwise.
Page 346 3-4. Using the hands-free phone system (for mobile phone) Initialization ■ ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered mobile phone data • Security code ®...
Page 347: Using The Phone Book
3-4. Using the hands-free phone system (for mobile phone)  Using the phone book To enter the menu of each setting, follow the steps below. Press the off-hook switch and select “Phonebook” using Select one of the following items using ●...
Page 348 3-4. Using the hands-free phone system (for mobile phone) Adding a new phone number The following methods can be used to add a new phone number: ● Transferring data from the mobile phone ● Inputting a phone number using ● Selecting a phone number from outgoing or incoming call history Adding procedure ■...
Page 349 3-4. Using the hands-free phone system (for mobile phone) Inputting a phone number using STEP2-1 Select “Manual Input” using STEP2-2 Input a phone number using , and press again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history: STEP2-1 Select “Call History”...
Page 350 3-4. Using the hands-free phone system (for mobile phone) Changing the registered name in the phone book Select “Change Name” using Select the desired name to be changed using Select “Record Name” with , and say the new name after the beep. The name to be registered will be repeated aloud.
Page 351 3-4. Using the hands-free phone system (for mobile phone) Setting speed dials Select “Speed Dial” using Select the desired data using Select the desired preset button, and register the data into speed dial by either of the following methods: a. Press the desired preset button, and select “Confirm” using b.
Page 352: Using The Interior Lights
3-5. Using the interior lights Interior lights list Rear interior light (P. 352) Center interior light (P. 352) Personal lights (P. 353) Engine switch light FJCRUISER_OM_General_OM35B53W...
Page 353: Interior Lights
DOOR position, the light will go off automatically after 30 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features P. 536)
Page 354: Personal Lights
3-5. Using the interior lights Personal lights Personal lights Type A On/off Type B On/off To prevent the battery from being discharged ■ The personal lights will automatically turn off in about 30 minutes after the key is removed from the engine switch. FJCRUISER_OM_General_OM35B53W...
Page 355: Using The Storage Features
3-6. Using the storage features List of storage features Auxiliary box Glove box Bottle holders Cup holders CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may result in the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact ●...
Page 356: Glove Box
3-6. Using the storage features Glove box Glove box Pull up the lever. CAUTION ■ Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.
Page 357: Cup Holders (Front)
3-6. Using the storage features Cup holders (front) Cup holders (front) Holding large cups ■ The adapter can be removed. FJCRUISER_OM_General_OM35B53W...
Page 358: Cup Holders (Rear)
3-6. Using the storage features Cup holders (front) and cup holders (rear) CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 359: Bottle Holders
3-6. Using the storage features Cup holders (rear) and bottle holders CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 360: Auxiliary Box
3-6. Using the storage features Auxiliary box Auxiliary box Push the button. Pull up the lid. CAUTION Caution while driving ■ Keep the auxiliary box closed. Items may fall out and cause death or serious injury in case of an accident or sudden stop.
Page 361: Other Interior Features
3-7. Other interior features Sun visors Front Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side Flip down. FJCRUISER_OM_General_OM35B53W...
Page 362: Vanity Mirrors
3-7. Other interior features Vanity mirrors Open the cover. FJCRUISER_OM_General_OM35B53W...
Page 363: Clock
3-7. Other interior features Clock Adjusts the hours Adjusts the minutes Pressing and holding the but- ton will adjust the hours or min- utes. The clock is displayed when ■ The engine switch is in the ACC or ON position. When disconnecting and reconnecting battery terminals ■...
Page 364: Outside Temperature Display
3-7. Other interior features  Outside temperature display The temperature display shows temperatures within the ranges of -40°C (-40°F) and 50°C (122°F). ■ Outside temperature display Type A Displays the outside air temperature. Switches the outside air temperature display between °C (Celsius) and °F (Fahrenheit).
Page 365 3-7. Other interior features ■ Ice advisory indicator (Type B) If the outside temperature low- ers to 3°C (37°F) or below when the engine switch is in the ON position, the indicator will come on to warn the driver that roads may be icy. Check the road surface and drive carefully.
Page 366 3-7. Other interior features To leave the “Temperature Settings Menu”, select “Back to main menu” to return to the starting screen, then either select “Exit” or wait several seconds without pressing Setting the ice advisory indicator (Type B) The ice advisory indicator on the inside rear view mirror can be turned on/off.
Page 367 ■ When “– –” or “– – –” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. Customization that can be configured for the inside rear view mirror ■ display (Type B) Settings (e.g.
Page 368: Power Outlets
3-7. Other interior features Power outlets The power outlet can be used for 12V accessories that run on less than 10A. Front (left-hand drive vehicles) Front (right-hand drive vehicles) Rear (if equipped) FJCRUISER_OM_General_OM35B53W...
Page 369 3-7. Other interior features The power outlet can be used when ■ The engine switch is in the ACC or ON position. NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit.
Page 370: Armrest
3-7. Other interior features Armrest Adjusting to the desired angle: Lower the armrest from the highest position to the lowest position. Raise the armrest to the desired angle. Unlock the armrest: Lift the armrest to raise it to the highest position. NOTICE ■...
Page 371: Floor Mat
3-7. Other interior features Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eye- lets.
Page 372 ■ Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 373: Luggage Storage Box (Vehicles Without Sub Woofer)
3-7. Other interior features Luggage storage box (vehicles without sub woofer) Push the lid down and pull it towards you. CAUTION Caution while driving ■ Keep the luggage storage box closed. Injuries may result in the event of an accident or sudden braking. FJCRUISER_OM_General_OM35B53W...
Page 374: Luggage Compartment Features
3-7. Other interior features Luggage compartment features ■ Tie-down hooks Tie-down hooks are provided for securing loose items. FJCRUISER_OM_General_OM35B53W...
Page 375 3-7. Other interior features ■ Cargo net hooks To hang the cargo net, use the cargo net hooks and tie-down hooks. The cargo net itself is not included as an original equip- ment. FJCRUISER_OM_General_OM35B53W...
Page 376 3-7. Other interior features ■ Shopping bag hooks To hang the shopping bag, use the cargo net hooks. CAUTION ■ When the tie-down hooks and cargo net hooks are not in use To avoid injury, always return the tie-down hooks and cargo net hooks to their positions when they are not in use.
Page 377: Compass
3-7. Other interior features  Compass The compass indicates the direction that the vehicle is heading. ■ Operation The compass points north for about 3 seconds after the engine switch is turned to the ON position, and then indi- cates the actual direction the vehicle facing.
Page 378 3-7. Other interior features Calibrating the compass Central and South America Except Central and South America The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 379 3-7. Other interior features ■ Deviation calibration Stop the vehicle where it is safe to drive in a circle. Press the SET button until a number (1 to 15) appears on the outside temperature display. Press the E/M button, and referring to the map above, select the num- ber of the zone where you are.
Page 380 3-7. Other interior features Drive the vehicle in a cir- cle, completing at least full circle within 20-120 seconds. Con- tinue until the outside temperature display returns. If there is not enough space to drive in a circle, drive around the block until the direction is displayed.
Page 381 3-7. Other interior features Conditions unfavorable to correct operation ■ The compass may not show the correct direction in the following conditions: ● The vehicle is stopped immediately after turning. The compass does not adjust while the vehicle is stopped. ●...
Page 382 3-7. Other interior features NOTICE To avoid the compass malfunctions ■ Do not place magnets or any metal objects on or near the accessory meter. Doing this may cause a malfunction of the compass sensor. ■ To ensure normal operation of the compass Do not perform circling calibration of the compass in a place where the ●...
Page 383 3-7. Other interior features FJCRUISER_OM_General_OM35B53W...
Page 384: Maintenance And Care
Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..384 Cleaning and protecting the vehicle interior ..387 4-2. Maintenance Maintenance requirements....390 Scheduled maintenance (except South Africa) ..393 4-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 385: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 386 4-1. Maintenance and care ■ Aluminum wheels Remove any dirt immediately by using a neutral detergent. ● ● Wash detergent off with water immediately after use. To protect the paint from damage, make sure to observe the following ● precautions. •...
Page 387 4-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 388: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 389 4-1. Maintenance and care Caring for leather areas ■ Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 390 4-1. Maintenance and care NOTICE Cleaning detergents ■ ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
Page 391: Maintenance
Maintenance beyond the last period should be performed at the same intervals. ● Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for maintenance service as well as other inspections and repairs.
Page 392 ● Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Toyota dealer, as soon as possible. Your vehicle may need adjustment or repair. FJCRUISER_OM_General_OM35B53W...
Page 393 4-2. Maintenance CAUTION If your vehicle is not properly maintained ■ It could result in serious damage to the vehicle and possible serious injury or death. ■ Warning in handling of battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 394: Scheduled Maintenance (Except South Africa)
Your Toyota needs to be serviced in accordance with the normal maintenance schedule. (See “Maintenance schedule”.) If you mainly operate your Toyota under one or more of the special operating conditions below, some of the maintenance schedule items need to be serviced more frequently in order to keep your vehicle in good condition.
Page 395 4-2. Maintenance Maintenance schedule Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: 1000 (Odometer reading or MONTHS months, whichever 1000 comes miles first.) BASIC ENGINE COMPONENTS Drive belts Engine oil Engine oil filter Cooling and...
Page 396 4-2. Maintenance Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: 1000 (Odometer reading or MONTHS months, whichever 1000 comes miles first.) FUEL AND EMISSION CONTROL SYSTEMS Fuel filter (including the filter in fuel tank)
Page 397 4-2. Maintenance Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate; L = Lubricate SERVICE ODOMETER READING INTERVAL: 1000 (Odometer reading or MONTHS months, whichever 1000 comes miles first.) CHASSIS AND BODY Brake pedal and parking brake...
Page 398 4-2. Maintenance Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate T = Tighten to specified torque; SERVICE ODOMETER READING INTERVAL: 1000 (Odometer reading or MONTHS months, whichever 1000 comes miles first.) CHASSIS AND BODY Propeller shaft bolts...
Page 399 4-2. Maintenance Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: 1000 (Odometer reading or MONTHS months, whichever 1000 comes miles first.) CHASSIS AND BODY Air condition- — ing filter Refrigerant amount for air con-...
Page 400 4-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requiring more frequent service specific to the type of severe conditions. (For outline, see “Maintenance schedule requirements”.) A-1: Operating on rough or muddy roads, or roads with melted snow. Inspection* of brake linings and Every 10000 km (6000 miles) or 6 drums (include parking brake lin-...
Page 401 4-2. Maintenance A-2: Operating on dusty roads. (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.) Every 5000 km (3000 miles) or 6 Replacement of engine oil months Every 5000 km (3000 miles) or 6 Replacement of engine oil filter months...
Page 402 4-2. Maintenance B-1: Heavily loaded vehicle. (Example: Towing a trailer, using a camper, using a car top carrier, etc.) Every 5000 km (3000 miles) or 6 Replacement of engine oil months Every 5000 km (3000 miles) or 6 Replacement of engine oil filter months Inspection* of brake linings and Every 10000 km (6000 miles) or 6...
Page 403 4-2. Maintenance B-2: Repeated short trips less than 8 km (5 miles) and outside tempera- tures remain below freezing. (Engine temperature will not reach to normal temperature.) Every 5000 km (3000 miles) or 6 Replacement of engine oil months Every 5000 km (3000 miles) or 6 Replacement of engine oil filter months B-3: Extensive idling and/or low speed driving for a long distance such...
Page 404 4-2. Maintenance NOTE: 1.Lubricate within 24 hours after submerging. 2.For seat mounting bolts, suspension member retaining bolts. FJCRUISER_OM_General_OM35B53W...
Page 405: Do-It-Yourself Maintenance
Battery condition (P. 415) • Conventional wrench (for terminal clamp bolts) • Distilled water • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (P.
Page 406 4-3. Do-it-yourself maintenance Items Parts and tools • Water Washer fluid (P. 419) • Washer fluid containing antifreeze (for winter use) CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions.
Page 407 4-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner ■ Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. ■ If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 408: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Left-hand drive vehicles Pull the hood release lever. The hood will pop up slightly. FJCRUISER_OM_General_OM35B53W...
Page 409 4-3. Do-it-yourself maintenance Right-hand drive vehicles Pull the hood release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury.
Page 410: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Dust cup (P. 423) Fuse box (P. 442) Air cleaner (P. 421) Battery (P. 415) Engine oil level dipstick Radiator (P. 415) (P. 410) Condenser (P. 415) Engine coolant reservoir Radiator cap (P. 413) Washer fluid tank (P. 419) Engine oil filler cap (P.
Page 411 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 412 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 413 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 414 4-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage ■ Check the oil level on regular basis. When replacing the engine oil ■ ● Be careful not to spill engine oil on the vehicle components. Avoid overfilling, as the engine could be damaged. ●...
Page 415 ■ Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection ■...
Page 416 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 417 4-3. Do-it-yourself maintenance ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Checking battery fluid Check that the level is between the upper line and the lower line. Upper line Lower line If the fluid level is at or below the...
Page 418 4-3. Do-it-yourself maintenance ■ Adding distilled water O.K. Remove the vent plug. Add distilled water. If the upper line cannot be seen, check the fluid level by looking directly at the cell. Put the vent plug back on and close securely. Before recharging ■...
Page 419 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery ■ A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: ●...
Page 420 4-3. Do-it-yourself maintenance NOTICE When recharging the battery ■ Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. ■ When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
Page 421 4-3. Do-it-yourself maintenance CAUTION When refilling the washer fluid ■ Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■...
Page 422 4-3. Do-it-yourself maintenance Air cleaner filter Check the air cleaner filter as follows. Release the clips. Lift the cover and take out the air cleaner filter. Inspect the outer surface of the filter, and replace the filter if it is extremely dirty.
Page 423 4-3. Do-it-yourself maintenance If the filter is just moderately dusty, use compressed air to blow dust out of the filter. CAUTION ■ To prevent inhaling dust Wear a respirator when using compressed air to clean the air cleaner filter. NOTICE ■...
Page 424 4-3. Do-it-yourself maintenance Dust cup Remove the dust cup. If the dust cup is dusty, remove the dust. NOTICE ■ When removing the dust cup To prevent the dust cup from being damaged, do not use any tool to remove FJCRUISER_OM_General_OM35B53W...
Page 425: Tires
4-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance schedules and treadwear. ■ Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 426 4-3. Do-it-yourself maintenance ■ Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate your Front tires approximately every 10000 km (6000 miles). ■ The tire pressure warning system (if equipped)
Page 427 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 427) Initializing the tire pressure warning system (vehicles with a tire pressure warning system) ■...
Page 428 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. FJCRUISER_OM_General_OM35B53W...
Page 429 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels (vehicles with a tire pressure warning sys- ■...
Page 430 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 431 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. Do not mix differently constructed tires ● (radial, bias-belted or bias-ply tires).
Page 432 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replac- ing the tire.
Page 433: Tire Inflation Pressure
Reduced safety ● ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 434 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: ●...
Page 435: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 436 4-3. Do-it-yourself maintenance When replacing wheels (vehicles with a tire pressure warning system) ■ The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valves and transmitters must be installed.
Page 437 ● Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 438: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the engine switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the upper claws.
Page 439 4-3. Do-it-yourself maintenance Remove the filter case. Replacement method ■ Remove the air conditioning filter and replace it with a new one. The“UP” marks shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 440: Key Battery
4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Small Phillips-head screwdriver ● Lithium battery Vehicles sold in Republic of Panama: CR2016 Vehicles except sold in Republic of Panama: CR1616 ■...
Page 441 The wireless remote control will not function properly. ● The operational range is reduced. ■ Use a CR1616 or CR2016 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera ● stores. ● Replace only with the same or equivalent type recommended by the manufacturer.
Page 442 4-3. Do-it-yourself maintenance CAUTION Removed battery and other parts ■ These parts are small and if swallowed by a child, they can cause choking. Keep away from children. Failure to do so could result in death or serious injury. NOTICE ■...
Page 443: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
Page 444 4-3. Do-it-yourself maintenance Right-hand drive vehicles Remove the lid. After a system failure, see “Fuse layout and amperage ratings” (P. 446) for details about which fuse to check. FJCRUISER_OM_General_OM35B53W...
Page 445 4-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool. Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. FJCRUISER_OM_General_OM35B53W...
Page 446 4-3. Do-it-yourself maintenance Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 447 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment ■ Fuse Ampere Circuit SPARE 10 A Spare fuse SPARE 15 A Spare fuse RR FOG 10 A Rear fog lights Stop lights, high mounted stop- light, anti-lock brake system, trac- tion control system, active traction control system, vehicle stability STOP...
Page 448 4-3. Do-it-yourself maintenance Fuse Ampere Circuit HEAD (HI RH) 10 A No circuit HEAD (HI LH) 10 A No circuit Multiport fuel injection system/ EFI NO.2 10 A sequential multiport fuel injection system Multiport fuel injection system/ 10 A sequential multiport fuel injection system DEFOG 30 A...
Page 449 4-3. Do-it-yourself maintenance Fuse Ampere Circuit EFI NO.2, multiport fuel injection 20 A system/sequential multiport fuel injection system TOWING NO.2 30 A Towing connector Door lock system, multiplex com- DR/LCK 20 A munication system FR FOG 10 A Front fog lights RADIO NO.2 20 A Audio system...
Page 450 4-3. Do-it-yourself maintenance ■ Under the instrument panel Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, anti-lock brake system, 10 A vehicle stability control system, traction control system, active trac- tion control system, SRS airbag system GAUGE 7.5 A Meter and gauge...
Page 451 Turn signal lights, charging system, anti-lock brake system, traction 15 A control system, active traction con- trol system, vehicle stability control system, back-up lights, Toyota parking assist-sensor, rear differen- tial lock system, accessory meter, 10 A meter and gauge, rear view moni- tor system 7.5 A...
Page 452 Never use a fuse of a higher amperage rating than indicated, or use any ● other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. ● Never replace a fuse with a wire, even as a temporary fix.
Page 453: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 454 4-3. Do-it-yourself maintenance Type B Side turn signal lights Front fog lights (if equipped) Headlights Front position Front turn signal lights lights STS43AC022 Rear bulb locations ■ Type A Stop/tail and rear side marker lights Back-up lights License plate lights Rear turn signal lights FJCRUISER_OM_General_OM35B53W...
Page 455 4-3. Do-it-yourself maintenance Type B Stop/tail lights Rear turn signal lights License plate lights Rear fog lights Back-up lights Replacing light bulbs (type A) Headlights ■ Unplug the connector. FJCRUISER_OM_General_OM35B53W...
Page 456 4-3. Do-it-yourself maintenance Remove the rubber cover. Release bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 457 4-3. Do-it-yourself maintenance ■ Front turn signal/front position and front side marker lights Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 458 4-3. Do-it-yourself maintenance ■ Front fog lights (if equipped) Remove the bolts and partly remove the fender liner. Unplug connector while depressing the lock release. Turn the bulb counterclockwise. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 459 4-3. Do-it-yourself maintenance ■ Outside rear view mirror illumination lights (if equipped) Depress the mirror. Remove the mirror. To prevent damaging the vehicle, wrap the screwdriver with a tape. FJCRUISER_OM_General_OM35B53W...
Page 460 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 461 4-3. Do-it-yourself maintenance ■ Back-up lights, stop/tail and rear side marker lights and rear turn signal lights ● Removing the sub woofer speaker (vehicles with sub woofer) Remove the speaker cover. Remove the cover. Installing the sub woofer speaker. (P. 472) Remove the sub woofer speaker.
Page 462 4-3. Do-it-yourself maintenance ● Removing the back-up, stop/tail and rear side marker and rear turn signal light bulbs Open the back door and remove the cover. Using a flathead screwdriver or equivalent which is wrapped with a cloth. Turn the bulb bases counter- clockwise.
Page 463 4-3. Do-it-yourself maintenance Remove the light bulb. Back-up light Stop/tail and rear side marker lights Rear turn signal light When installing, reverse the steps listed. ■ License plate lights Remove the screws and cover. FJCRUISER_OM_General_OM35B53W...
Page 464 Remove the light bulb. When installing, reverse the steps listed. ■ Lights other than the above If the high mounted stoplight has burnt out, have it replaced by your Toyota dealer. Replacing light bulbs (type B) ■ Headlights Unplug the connector.
Page 465 4-3. Do-it-yourself maintenance Remove the rubber cover. Release bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 466 4-3. Do-it-yourself maintenance ■ Front position lights Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 467 4-3. Do-it-yourself maintenance ■ Front turn signal lights Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 468 4-3. Do-it-yourself maintenance ■ Side turn signal lights Remove the side turn lens. Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 469 4-3. Do-it-yourself maintenance ■ Front fog lights (if equipped) Remove the bolts and partly remove the fender liner. Unplug connector while depressing the lock release. Turn the bulb counterclockwise. When installing, reverse the steps listed. FJCRUISER_OM_General_OM35B53W...
Page 470 4-3. Do-it-yourself maintenance ■ Back-up and stop/tail lights Open the back door and remove the cover. Using a flathead screwdriver or equivalent which is wrapped with a cloth. Turn the bulb bases counter- clockwise. Stop/tail lights Back-up light Remove the light bulb. Stop/tail lights Back-up light When installing, reverse the steps listed.
Page 471 4-3. Do-it-yourself maintenance ■ Rear turn signal and rear fog lights Remove the bolts. Open the cover. Turn the bulb base counter- clockwise. FJCRUISER_OM_General_OM35B53W...
Page 472 4-3. Do-it-yourself maintenance Remove the light bulb. Rear turn signal light Rear fog light When installing, reverse the steps listed. ■ License plate lights Remove the screws and cover. FJCRUISER_OM_General_OM35B53W...
Page 473 ■ The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Installing the sub woofer speaker (vehicles with sub woofer) Install the rubber inside the panel as shown in the illustration.
Page 474 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 475 4-3. Do-it-yourself maintenance FJCRUISER_OM_General_OM35B53W...
Page 476: When Trouble Arises
When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers..476 If a warning light turns on If your vehicle needs to or a warning buzzer be towed ......477 sounds......485 If you think something is If you have a flat tire ..
Page 477: Essential Information
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 478: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 479 5-1. Essential information Towing with a wheel-lift type truck From the front Use a towing dolly under the rear wheels. From the rear Use a towing dolly under the front wheels. FJCRUISER_OM_General_OM35B53W...
Page 480 5-1. Essential information Using flatbed truck If your vehicle is transported by a Front flatbed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 481 5-1. Essential information Emergency towing procedure Securely attach cables or chains to the towing hooks. Take care not to damage the vehicle body. STS51AC002 Enter the vehicle being towed and starting the engine. If the engine does not start, turn the engine switch to the ON position.
Page 482 5-1. Essential information CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with all four wheels raised off the ground. If the vehicle is towed with the tires contacting the ground, the drivetrain or related parts may be damaged, the vehicle may fly off...
Page 483 5-1. Essential information NOTICE To prevent damage to the vehicle when towing using a wheel-lift type ■ truck ● Do not tow the vehicle from the rear when the engine switch is in the LOCK position or the key is removed. The steering lock mechanism is not strong enough to hold the front wheels straight.
Page 484: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ■ ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 485: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 486: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds
Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging sys-...
Page 487 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
Page 488 5-2. Steps to take in an emergency Warning light Warning light/Details Cruise control indicator light (if equipped) Indicates a malfunction in the cruise control system. (Flashes) Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off.
Page 489 If the light does not go off, contact your Toyota dealer. When the light flashes: Have the system Indicates a malfunction in checked by your Toyota the automatic transmis- dealer. sion system. Low fuel level warning light Refuel the vehicle.
Page 490 Toyota dealer. When the light comes on Have the system after blinking for 1 min- checked by your Toyota ute: dealer. Malfunction in the tire pressure warning sys-  tem ( P.
Page 491 5-2. Steps to take in an emergency : Driver’s seat belt reminder (except for South Africa): The driver’s seat belt reminder sounds to alert the driver that his or her seat belt is not fastened. Once the engine switch is turned to the ON or START position, the buzzer sounds for 6 seconds.
Page 492 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Speed warning buzzer (for G.C.C. countries , Republic of Yemen, ■...
Page 493 5-2. Steps to take in an emergency ■ The tire pressure warning light may turn on due to natural causes (vehicles with a tire pressure warning system) The tire pressure warning light may come on due to natural causes such as natural air leaks and tire inflation pressure changes caused by temperature.
Page 494 5-2. Steps to take in an emergency ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ● If tire chains are used.
Page 495 5-2. Steps to take in an emergency NOTICE To ensure the tire pressure warning system operates properly (vehi- ■ cles with a tire pressure warning system) Do not install tires with different specifications or makers, as the tire pres- sure warning system may not operate properly. FJCRUISER_OM_General_OM35B53W...
Page 496: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. ■ Before jacking up the vehicle ● Stop the vehicle in a safe place on a hard, flat surface. ●...
Page 497 5-2. Steps to take in an emergency Taking out the jack and tool bag Remove the cover and loosen the strap. Loosen and remove the jack. Tighten Loosen Taking out the spare tire (vehicles without rear view monitor system) Unlocking the spare tire lock sys- tem.
Page 498 5-2. Steps to take in an emergency Turn the hold-down nuts counter- clockwise with the wheel nut wrench and remove them. Taking out the spare tire (vehicles with rear view monitor system) Remove the bolt cover. Bolt cover Remove the bolt which fixes the spare wheel cover using the wrench in the tool bag (P.
Page 499 5-2. Steps to take in an emergency Remove the spare wheel cover. Unlocking the spare tire lock sys- tem. Insert the key into the cylinder. Remove the key and cylinder. Turn the hold-down nuts counter- clockwise with the wheel nut wrench and remove them.
Page 500 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Wheel chock Flat tire positions Left- Behind the rear hand right-hand side side tire Front Right- Behind the rear STS52AC026 hand left-hand side side tire Left- In front of the hand front right-hand...
Page 501 5-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Assembling the jack handle. Remove the jack handle, jack handle extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 502 5-2. Steps to take in an emergency Assemble the jack handle extension bar and the jack handle and tighten the screw. Check that the screw is firmly tightened. Position the jack at the correct jack point as shown. Front Rear Make sure the jack is positioned on a level and solid place.
Page 503 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 504 5-2. Steps to take in an emergency Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 103 N·m (10.5 kgf·m, 76 ft·lbf) Reinstall the wheel ornament. Stowing the flat tire, jack and all tools Install the flat tire in the reverse order of removal.
Page 505 5-2. Steps to take in an emergency Vehicles with rear view monitor system: Install the spare wheel cover in the reverse order of removal. Tighten the bolt. Tightening torque: 14 N·m (1.4 kgf·m, 10 ft·lbf) Stow the tools and jack securely. CAUTION Using the jack ■...
Page 506 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 507 5-2. Steps to take in an emergency NOTICE Do not drive the vehicle with a flat tire ■ Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 508: If The Engine Will Not Start
One of the following may be the cause of the problem. ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 509) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. FJCRUISER_OM_General_OM35B53W...
Page 509: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the master keys and the key number stamped on your key number plate. (P. 42) ■...
Page 510: If The Vehicle Battery Is Discharged
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connecting the jumper cables...
Page 511 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 512 5-2. Steps to take in an emergency CAUTION To avoid battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 513 5-2. Steps to take in an emergency NOTICE When handling jumper cables ■ Be careful that the jumper cables do not become tangled in the cooling fan or any of the belts when connecting or disconnecting them. FJCRUISER_OM_General_OM35B53W...
Page 514: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the F (Full) and L (Low) lines on the reservoir.
Page 515 If the fan is not operating: Stop the engine immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer. CAUTION To prevent an accident or injury when inspecting under the hood of ■...
Page 516 5-2. Steps to take in an emergency NOTICE When adding engine coolant ■ Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. ■...
Page 517: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P.
Page 518 5-2. Steps to take in an emergency CAUTION When attempting to free a stuck vehicle ■ If you choose to rock the vehicle back and forth to free it, make sure the sur- rounding area is clear, to avoid striking other vehicles, objects or persons. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 519: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly depress it.
Page 520 5-2. Steps to take in an emergency CAUTION If the engine has to be turned off while driving ■ ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 521 5-2. Steps to take in an emergency FJCRUISER_OM_General_OM35B53W...
Page 522: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..522 Fuel information ....535 6-2. Customization Customizable features ..536 6-3. Items to initialize Items to initialize ....539 FJCRUISER_OM_General_OM35B53W...
Page 523: Specifications
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 4670 mm (183.9 in.) Overall width 1905 mm (75.0 in.) Overall height 1830 mm (72.0 in.) Wheelbase 2690 mm (105.9 in.) Front tread 1605 mm (63.2 in.) Rear tread 1605 mm (63.2 in.) Gross vehicle mass...
Page 524 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. It is forbidden to cover, paint, weld, drill, alter or remove the vehicle identi- fication number (VIN).
Page 525 6-1. Specifications This number is also on the manufacturer’s label (except G.C.C. countries , Republic of Yemen, Jordan and Lebanon) or the Certification Regulation label (G.C.C. countries , Republic of Yemen, Jordan and Lebanon). : Saudi Arabia, Sultanate of Oman, Bahrain, United Arab Emirates, Qatar, Kuwait ■...
Page 526 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 1GR-FE Type 6-cylinder V type, 4-cycle, gasoline 94.0  95.0 mm (3.70  3.74 in.) Bore and stroke Displacement 3956 cm (241.4 cu.in.) Drive belt tension Automatic adjustment Valve clearance...
Page 527 6-1. Specifications Fuel Fuel type Premium unleaded gasoline only Research Octane Number 95 (Octane rating 91) or higher Vehicles without 72.0 L (19.0 gal., 15.8 lmp.gal.) Fuel tank sub fuel tank capacity Vehicles with (Reference) 159.0 L (42.0 gal., 35.0 lmp.gal.) sub fuel tank Lubrication system Oil capacity...
Page 528 6-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving” or SN “Resource-Conserving”;...
Page 529 6-1. Specifications Oil viscosity (5W-30 is explained here as an example): ● The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. ●...
Page 530 6-1. Specifications Cooling system Capacity 9.8 L (10.4 qt., 8.6 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 531 Rear 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please con- tact your Toyota dealer for further details.
Page 532 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please con- tact your Toyota dealer for further details.
Page 533 6-1. Specifications Steering Free play Less than 30 mm (1.2 in.) ® Automatic transmission fluid DEXRON II or Power steering fluid type Tires and wheels Tire size 265/70R17 115S Front tires: Tire inflation pressure 220 kPa (2.2 kgf/cm or bar, 32 psi) (Recommended cold tire Rear tires: inflation pressure)
Page 534 6-1. Specifications Light bulbs Type A Light Bulbs Type Headlights 60/55 Front fog lights (if equipped) Front turn signal/front position and 21/5 front side marker lights Outside rear view mirror illumination Exterior lights (if equipped) Rear turn signal lights Stop/tail and rear side marker lights 21/5 Back-up lights License plate lights...
Page 535 6-1. Specifications Type B Light Bulbs Type Headlights 60/55 Front fog lights (if equipped) Front position lights Front turn signal lights 21/5 Side turn signal lights Exterior Rear turn signal lights Stop/tail lights 21/5 Rear fog lights Back-up lights License plate lights Personal lights Vehicles with overhead console Vehicles without overhead console...
Page 536: Fuel Information
■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 537: Customization
Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customizing inside rear view mirror features (for South Africa) For information displayed on the inside rear view mirror, it is possible to change the color of the display and the displayed language.
Page 538 6-2. Customization To leave the “Custom Settings Menu”, select “Back to main menu” to return to the starting screen, then either select “Exit” or wait several seconds without pressing To change the display language ■ Press and hold to display the “Custom Settings Menu”. Press and select “Dis- play”,...
Page 539 6-2. Customization Customizable features Customized Item Function Default setting setting Wireless remote control Time elapsed before 60 seconds automatic door lock function is activated if 30 seconds door is not opened after 120 seconds Wireless being unlocked remote control Operation signal ...
Page 540: Items To Initialize
6-3. Items to initialize Items to initialize The following item must be initialized for normal system operation after such cases as the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference • When adjusting the tire inflation pressure Tire pressure warn- •...
Page 541 6-3. Items to initialize FJCRUISER_OM_General_OM35B53W...
Page 542: Appendix
Appendix Abbreviation list ...... 542 What to do if......543 FJCRUISER_OM_General_OM35B53W...
Page 543: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Anti-Lock Brake System Accessory AI-SHIFT Artificial Intelligence Shifting A-TRAC Active Traction Control Child Restraint System English/U.S. Customary System and metric Emergency Locking Retractor Gross Vehicle Mass Intermittent Light Emitting Diode MPAC Maximum Permissible Axle Capacity RR DIFF LOCK Rear Differential Lock Supplemental Restraint System...
Page 544: What To Do If
What to do if... What to 4do if... If you have a flat tire A tire punctures P. 495 P. 507 If the engine will not start The engine does not start Engine immobilizer system P. 96 P. 509 If the vehicle battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 545 What to do if... Instrument cluster ■ Center panel ■ FJCRUISER_OM_General_OM35B53W...
Page 546 What to do if... ■Warning lights Cruise control indicator Brake system warning light light P. 485 P. 487 Charging system warning Open door warning light light P. 485 P. 487 Low engine oil pressure Driver’s seat belt reminder warning light P.

Toyota FJ CRUISER Owner's Manual

1 Before Driving

2 When Driving

4 Maintenance and Care

5 When Trouble Arises

6 Vehicle Specifications

Appendix

Quick Links

Related Manuals for Toyota FJ CRUISER

Summary of Contents for Toyota FJ CRUISER

Table of Contents
