SCION
Preparation
Part Number:
Mounting Kit PT546-52080
Tuner Assy 86180-0W030
Tuner Assy Kit Contents (86180-0W030)
Item #
Quantity Reqd.
1
1
Mounting Kit Contents (PT546-52080)
Item #
Quantity Reqd.
1
1
2
1
3
2
4
2
5
1
6
4
7
1
8
3
9
1
Hardware Bag Contents – 1 (PT546-52080)
Item #
Quantity Reqd.
1
4
2
4
Hardware Bag Contents – 2 (PT546-52080)
Item #
Quantity Reqd.
1
15
2
2
Hardware Bag Contents – 3 (PT546-52080)
Item #
Quantity Reqd.
1
1
2
1
3
1
4
8
5
10
6
1
7
3
Additional Items Required For Installation
Item #
Quantity Reqd.
1
1
Conflicts
Issue: A 02/28/07
xB
Description
Tuner Assy, Stereo Component
Description
Ground Cable
Wire, To Radio Installation
Tuner Bracket
Base Bracket
Template A
(to locate base bracket)
Cushion A (Butyl)
Antenna
Hardware Bags
XM Satellite Radio Brochure
Description
Screw (M5xL8)
Nut (M6)
Description
Lock Tie A (AVC-LAN)
Cushion Tape (50 x 100 mm)
Description
Template B
Connector Housing
Cushion Tape (20 x 100 mm)
Lock Tie B (antenna cable)
Sheet Tape (to fix antenna)
Cord Rail (30 mm)
Protective Sheet (20 x 40 mm)
Description
Satellite Receiver Cover P/N
PT218-52071
Page 1 of 21 pages
2008 -
NOTE: Part number of this accessory may not be the
same as the part number shown.
Recommended Tools
Personal & Vehicle
Protection
Safety Goggles
Seat Covers
Special Tools
Arch (Carpet) Punch
Installation Tools
Ratchet
Extensions
Sockets
Torque Wrench
Screwdriver
Panel Removal Tool
Masking Tape
Mallet
Special Chemicals
Sealant
Cleaner
General Applicability
Recommended Sequence of Application
Item #
Accessory
1
TVIP
2
Satellite Receiver
3
Audio
4
Subwoofer (SB)
Vehicle Service Parts
Item #
Quantity Reqd.
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
XM SATELLITE RADIO
Notes
Notes
5/16 in. Hole Diameter
Notes
10 mm, 12 mm, 14 mm
4.1 N•m (36 lbf•in), 18 N•m (13
lbf•ft), 37 N•m (27 lbf•ft), 42
N•m (31 lbf•ft)
Philips, #2
e.g. Panel Pry Tool #1
Toyota SST # 00002-06001-01
(2 in. wide)
Notes
TM
3M
Ultra-Pro Body
Sealant
TM
3M
Prep Solvent 70
*Mandatory
(may be required for reassembly)
Description
DIO
Advertisement
Related Manuals for Toyota PT546-52080
Summary of Contents for Toyota PT546-52080
- Page 1 Hardware Bags Panel Removal Tool e.g. Panel Pry Tool #1 XM Satellite Radio Brochure Toyota SST # 00002-06001-01 Masking Tape (2 in. wide) Hardware Bag Contents – 1 (PT546-52080) Mallet Special Chemicals Notes Item # Quantity Reqd. Description Screw (M5xL8)
- Page 2 Parts Description of Tuner Assy (86180-0W030) Item # Parts Name Parts No. Tuner 86180-0W030 Parts Description of Mounting Kit (PT546-52080) Item # Parts Name Ground Cable Wire, To Radio Installation Cushion Tape (50 x 100 mm) (0 used for xB)
-
Page 3: Vehicle Disassembly
Safety (eye protection, rechecking torque procedure, etc.). • Vehicle Disassembly/Reassembly (panel removal, part storage, etc.). • Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.). Please see your Toyota dealer for a copy of this document. NOTES 10 mm Socket, Ratchet Removed Parts: Negative... - Page 4 SCION 2008 - XM SATELLITE RADIO Procedure (d) Disengage two (2) claws and four (4) clips, Panel Removal Tool then pull upward and remove the deck trim Claws x2 cover. (Fig. 1-4) Clips x4 Fig. 1-4 (e) Disassemble the rear seat as follows: (1) Disengage the three (3) hooks and remove the rear seat cushion.
- Page 5 SCION 2008 - XM SATELLITE RADIO Procedure (f) Disengage the six (6) claws and remove the Panel Removal Tool Claws B x2 rear passenger side door scuff plates. ② ② (Fig. 1-8) ① ① ① Claws A Claws C Claws A x2 Fig.
- Page 6 SCION 2008 - XM SATELLITE RADIO Procedure (i) Disconnect the connector and remove the 10 mm Socket, Ratchet, Extension three (3) nuts, then detach the right side rear combination light. (Fig. 1-12). Clip x1 Connector Nuts x3 Fig. 1-12 (j) Disengage the seven (7) claws and remove Panel Removal Tool the front passenger side door scuff plates.
- Page 7 SCION 2008 - XM SATELLITE RADIO Procedure (m) Disengage the nine (9) claws and two (2) Claws x3 Panel Removal Tool clips, then remove the passenger side lower center pillar garnish. (Fig. 1-16) Claws x3 Claws x3 Clips x2 Fig. 1-16 2.
- Page 8 SCION 2008 - XM SATELLITE RADIO Procedure (d) Remove the four (4) bolts and remove the 10 mm Socket, Ratchet, Extension head unit (Fig. 2-4). (e) Disconnect the connectors. Bolts x4 Fig. 2-4 3. Remove the Glove Compartment Door Stoppers x2 Damper (a) Disconnect the damper from the glove compartment door.
- Page 9 SCION 2008 - XM SATELLITE RADIO Procedure (e) Remove the two (2) seat front bolts. 14 mm Socket, Ratchet, Extension (Fig. 4-3) (f) Disconnect the wire harness clamp and connectors. (g) Tilt the seat rearwards, exposing the floor Bolts x2 under the front passenger seat, and lay the seat in the rear seat area.
-
Page 10: Install The Antenna
SCION 2008 - XM SATELLITE RADIO Procedure 6. Route the Tuner Ground Cable 10 mm Socket, Ratchet, Extension, Side Cutter (a) Install the end of the tuner ground cable onto Ground Point the bolt located on the cowl side. (Fig. 6-1) Ground Cable Tuner Cable (b) Secure the tuner ground cable and tuner cable... - Page 11 SCION 2008 - XM SATELLITE RADIO Procedure Antenna 8. Route Antenna Cable through Body Opening Insert under the weather strip. (a) The roof and the roof/hatch area where the Sheet Tape x1 sheet tape and cord rail attach must be 5 mm (0.20 in) cleaned with 3M...
- Page 12 SCION 2008 - XM SATELLITE RADIO Procedure (h) Run the antenna cable and insert the Please disregard Antenna the gray marking antenna grommet (attached to cable) into Grommet tapes, as they are the body opening. (Fig. 8-4) used for alignment in other models.
- Page 13 SCION 2008 - XM SATELLITE RADIO Procedure Side Cutter (d) Secure the antenna cable to the vehicle wire Antenna Cable harness using the one (1) lock tie B and vehicle wire harness clamps. (Fig. 9-3) Vehicle Wire Harness Clamps NOTE: Do NOT secure the antenna cable STOP Front to the washer hose.
- Page 14 SCION 2008 - XM SATELLITE RADIO Procedure (d) Push the lock plate in (Fig. 10-4). Push in until it clicks. Fig. 10-4 11. Install the Satellite Tuner (a) Remove the frame number cover. Frame Number Cover (Fig. 11-1) (b) Peel back the carpet and felt. ①Pull upward.
- Page 15 SCION 2008 - XM SATELLITE RADIO Procedure (h) Position template A under the passenger's Base Brackets seat as shown. (Fig. 11-4) (i) Remove the release paper from the four (4) cushion tape A (butyl), and then secure the base brackets over template A as shown. Wire Harness for Seat (j) Remove template A.
- Page 16 SCION 2008 - XM SATELLITE RADIO Procedure (l) Reinstall the carpet and verify the base Carpet Punch, Mallet bracket bolt positions. Transfer each bolt location onto the carpet using carpet punch and mallet to cut four (4) holes in carpet. (Fig.
- Page 17 SCION 2008 - XM SATELLITE RADIO Procedure 12. Reinstall the Radio/Player Head Unit Phillips Screwdriver (a) Connect the satellite tuner cable and the connectors removed in Step 2(b) into the rear of the head unit. (Fig. 12-1) (b) Insert head unit into opening and re-install the bolts.
- Page 18 SCION 2008 - XM SATELLITE RADIO Procedure 14. Installing Receiver Cover (a) Remove the satellite receiver cover (P/N PT218-52071) from the poly bag. (b) Shape the cover so that it forms an open box shape with the Velcro facing down. NOTE: Shipping and storage may have caused the Velcro Backing...
- Page 19 SCION 2008 - XM SATELLITE RADIO Procedure (d) Re-install the passenger side deck trim side Claws x5 panel as follows: (1) Install the deck trim side panel and Clips x3 engage the clips and claws. (Fig. 15-1) (e) Install the rear seatback hinge and bolt B. (Fig.
- Page 20 SCION 2008 - XM SATELLITE RADIO Procedure 16. Reconnect Battery Cable Negative 10 mm Socket, Torque Wrench Battery (a) Reconnect the vehicle’s negative battery Cable cable. (Fig. 16-1) (1) Position the negative terminal to the battery as shown (original factory position).
-
Page 21: Xm Satellite Radio
SCION 2008 - XM SATELLITE RADIO Checklist - these points MUST be checked to ensure a quality installation. Check: Look For: Accessory Function Checks *Verify the proper operation of the Satellite Radio Satellite Radio Tuner Tuner. *Verify the proper operation of the Receiver/player Assembly Receiver/player Assembly *(Refer to the receiver assembly and radio...
