Power Supply And Connecting Cable Connection - Toshiba RAS-10 Installation Manual

Po er l and Connectin Cable Connection
EN
75 mm
10 mm
1(L) 2(N) Earth line
10 mm
65 mm
CAU I N
1. T e power supply must be same as t e rated of air conditioner.
2. Prepare t e power source for exclusive use wit air conditioner.
3. Circuit breaker must be used for t e power supply line of t is air conditioner.
4. Be sure to comply power supply and connecting cable for si e and wiring met od.
5. Every wire must be connected fi rmly.
6. Perform wiring works so as to allow a general wiring capacity.
7. Wrong wiring connection may cause some electrical part burn out.
8. Incorrect or incomplete wiring is carried out it will cause an ignition or smoke.
9. T is product can be connected to main power supply.
Connection to fi xed wiring A switc w ic disconnects all poles and as a contact separation at least 3 mm must be incorporated in t e fi xed wiring.
