About this manual The instructions in this manual are for the CFD- G70 and CFD-G70L. Before you start reading, check your model number. The CFD-G70L is the model used for illustration purpose. Note The name of the switch to turn on/off this player is indicated as below: “OPERATE”: CFD-G70L...
Table of contents Basic Operations Playing a CD ... 4 Listening to the radio ... 6 Playing a tape ... 8 Recording on a tape ... 10 The CD Player Using the display ... 12 Locating a specific track ... 12 Playing tracks repeatedly (Repeat Play) ...
Basic Operations Playing a CD Connect the supplied mains lead (see page 20). Press ZPUSH OPEN/CLOSE down to open the CD compartment and place the CD on the CD compartment. Close the lid of the CD compartment. Press u (N on the remote). The player turns on (direct power- on) and plays all the tracks once.
Page 5
Use these buttons for additional operations OPERATE (or POWER) ., > Press adjust the volume VOLUME +, – (VOL +, – on the remote) stop playback u (X on the remote) pause playback Press the button again to resume play after pause. >...
Each time you press the button, the band changes as follows: CFD-G70: “FM” t “AM” CFD-G70L: “FM” t “MW” t “LW” Hold down TUNE + or – until the frequency digits begin to change in the display. The player automatically scans the radio frequencies and stops when it finds a clear station.
Page 7
Tips • If the FM broadcast is noisy, press MODE until “Mono” appears in the display and the radio will play in monaural. • If you need to change the AM/MW tuning interval, see page 20. Use these buttons for additional operations OPERATE (or POWER) MODE...
Playing a tape Connect the supplied mains lead (see page 20). Press xZ to open the tape compartment and insert a recorded tape. Use TYPE I (normal) tape only. Close the compartment. Press N. The player turns on (direct power-on) and starts playing.
Page 9
Use these buttons for additional operations OPERATE (or POWER) m, M adjust the volume stop playback fast-forward or rewind the tape pause playback eject the cassette turn on/off the player VOLUME –, + Press VOLUME +, – (VOL +, – on the remote) M or m Press the button again to...
Recording on a tape Connect the supplied mains lead (see page 20). Press xZ to open the tape compartment and insert a blank tape. Use TYPE I (normal) tape only. Select the program source you want to record. To record from the CD player, insert a CD (see page 4) and press x on the CD section.
Page 11
• Adjusting the volume or the audio emphasis (see page 18) will not affect the recording level. • CFD-G70L only: If the MW/LW programme makes a whistling sound after you've pressed z in step 3, press MODE to select the...
The CD Player Using the display You can check information about the CD using the display. DISPLAY ENT MEMORY Checking the total track number and playing time Press DISPLAY ENT•MEMORY in stop mode. Total playing time Total track number Checking the remaining time Press DISPLAY ENT•MEMORY while playing a CD.
Note You cannot locate a specific track if “SHUF” or “PGM” is lit in the display. Turn off the indication by pressing x. When you locate a track numbered over 10, press >10 first, then the corresponding number buttons. Example: To play track number 23, press >10 first, then 2 and 3.
Playing tracks repeatedly (Repeat Play) (continued) To cancel Repeat Play Press MODE until “REP” disappears from the display. On the remote • Use N instead of u. • When you’ve selected “REP 1”, select the track by pressing the number buttons. Playing tracks in random order (Shuffle Play)
Creating your own programme (Programme Play) You can arrange the playing order of up to 20 tracks on a CD. ., > DISPLAY ENT MODE MEMORY Press x. “Cd” appears in the display. Press MODE until “PGM” appears in the display. Press the .
You can preset up to 30 radio stations (CFD-G70), 20 for FM and 10 for AM in any order or 40 radio stations (CFD- G70L), 20 for FM and 10 for MW and LW in any order. DISPLAY ENT...
Playing preset radio stations Once you've preset the stations, use PRESET + or – on the player or the number buttons on the remote to tune in to your favourite stations. PRESET –, + RADIO BAND AUTO PRESET Press RADIO BAND•AUTO PRESET to select the band.
The Audio Emphasis Selecting the audio emphasis (SOUND/POWER DRIVE WOOFER/GAME Xpand) You can adjust the audio emphasis of the sound you are listening to. You can also enjoy the live presence sound from a game machine, etc., using the GAME Xpand button.
The Timer Falling asleep to music You can set the player to turn off automatically after 10, 20, 30, 60, 90, and 120 minutes, allowing you to fall asleep while listening to music. SLEEP Play the music source you want. Press SLEEP to display “SLEEP.”...
Setting Up Choosing the power sources You can use the AC power or batteries as a power source. 3 Battery compartment Connecting the mains lead Insert one end of the supplied mains lead to the AC IN socket located at the rear of the player, and the other end to the mains.
Page 21
Inserting batteries into the remote Insert two R6 (size AA) batteries (not supplied) Replacing batteries With normal use, the batteries should last for about six months. When the remote no longer operates the player, replace all the batteries with new ones. Using the player on batteries Insert eight R20 (size D) batteries (not supplied) into the battery compartment.
Connecting a game machine or other optional components You can enjoy the sound from a game machine or TV, etc. through the speakers of this player. Be sure to turn off the power of each component before making connections. For details, refer to the instructions of the component to be connected.
Page 23
Connecting a TV or a VCR Audio Front panel of connecting this player cord* (not supplied) VCR, etc. to line out jack Audio connecting cord (supplied) VCR, etc. to headphones jack * A cord with a stereo-mini plug on one end and two phono plugs on the other end.
• If the player has not been used for a long time, set it in the playback mode to warm it up for a few minutes before inserting a cassette. If you have any questions or problems concerning your player, please consult your nearest Sony dealer.
Notes on CDs • Before playing, clean the CD with a cleaning cloth. Wipe the CD from the center out. • Do not use solvents such as benzine, thinner, commercially available cleaners or anti-static spray intended for vinyl LPs. • Do not expose the CD to direct sunlight or heat sources such as hot air ducts, nor leave it in a car parked in direct sunlight as there can be a considerable rise in...
• Move the player away from the TV. • If you are using the remote while listening to AM (CFD-G70) or MW/LW (CFD-G70L) radio, noise may be heard. This is unavoidable. The picture of your TV becomes unstable.
Page 27
After trying the above remedies, if you still have problems, unplug the mains lead and remove all the batteries. After all the indications in the display disappear, plug the mains lead and insert the batteries again. If the problem persists, please consult your nearest Sony dealer.
Maintenance Cleaning the lens If the lens becomes dirty, it may cause a skipping of sound during CD operation. Clean with a commercially available blower. Cleaning the tape heads and tape path Wipe the heads, the pinch roller and the capstan with a cleaning swab slightly moistened with cleaning fluid or alcohol after every 10 hours of operation for...
AM/MW/LW: Built-in ferrite bar aerial Cassette-corder section Recording system 4-track 2 channel stereo Fast winding time Approx. 120 sec. with Sony cassette C-60 Frequency response TYPE I (normal): 70 - 13 000 Hz General Speakers Main speaker: 10 cm (4 in.) dia., 3.2 , cone type (2) Subwoofer: 8 cm (3 ⁄...
Index AM/MW tuning interval 20 Audio emphasis 18 Batteries for player 21 for remote 21 CD player 12 Choosing power sources 20 Cleaning cabinet 28 tape heads and tape path Connecting mains lead 20 optional components 22 Creating your own programme D, E, F Demagnetizing the tape heads Display 12...
Page 32
Acerca de este manual Las instrucciones de este manual hacen referencia a los modelos CFD-G70 y CFD-G70L. Antes de comenzar a leerlas, compruebe el número de modelo. Se ha utilizado el modelo CFD-G70L para las ilustraciones.
Page 33
Índice Procedimientos básicos Reproducción de un CD ... 4 Radiorecepción ... 6 Reproducción de cintas ... 8 Grabación en una cinta ... 10 Reproductor de discos compactos (CD) Utilización del visor ... 12 Localización de una pista específica ... 12 Reproducción repetida de las pistas (Reproducción repetida) ...
Procedimientos básicos Reproducción de un CD Conecte el cable de alimentación de CA suministrado (consulte la página 20). Presione ZPUSH OPEN/CLOSE para abrir el compartimiento de discos y coloque el CD. Cierre la tapa del compartimiento de discos. Presione u (N en el mando a distancia).
Page 35
Utilice estos botones para realizar procedimientos adicionales OPERATE (o POWER) ., > Para Presione ajustar el volumen VOLUME +, – (VOL +, – en el mando a distancia) detener la reproducción realizar una pausa u (X en el mando a distancia) Vuelva a presionar el botón para reanudar la reproducción después de la pausa.
Page 36
Cada vez que presione el botón, la banda cambiará de la siguiente forma: CFD-G70: “FM” t “AM” CFD-G70L: “FM” t “MW” t “LW” Mantenga presionado TUNE + o – hasta que los dígitos de frecuencia comiencen a cambiar en el visor.
Page 37
Sugerencias • Si la emisión en FM presenta ruido, presione MODE hasta que aparezca “Mono” en el visor; la radio sintonizará la emisión en modo monofónico. • Si es preciso cambiar el intervalo de sintonización de AM/MW, consulte la página 20. Utilice estos botones para realizar procedimientos adicionales OPERATE...
Reproducción de cintas Conecte el cable de alimentación de CA suministrado (consulte la página 20). Presione xZ para abrir el compartimiento de la cinta e inserte una cinta grabada. Emplee sólo cintas TYPE I (normal). Cierre el compartimiento. Presione N. El reproductor se enciende (activación directa) e inicia la reproducción.
Page 39
Utilice estos botones para realizar procedimientos adicionales OPERATE (o POWER) m, M Para Presione ajustar el volumen VOLUME +, – (VOL +, – en el mando a distancia) cesar la reproducción avanzar rápidamente o M o m rebobinar la cinta realizar una pausa Vuelva a presionar el botón para reanudar la reproducción...
Grabación en una cinta Conecte el cable de alimentación de CA suministrado (consulte la página 20). Presione xZ para abrir el compartimiento de cintas e inserte una cinta virgen. Emplee sólo cintas TYPE I (normal). Seleccione la fuente de programa que desee grabar.
Page 41
• El ajustes del volumen o del énfasis de sonido (consulte la página 18) no afectarán al nivel de grabación. • Sólo CFD-G70L: Si el programa de MW/LW se recibe con un sonido silbante después de pulsar z en el paso 3, presione MODE para seleccionar la posición de ISS (Interruptor...
Reproductor de discos compactos (CD) Utilización del visor Puede comprobar la información sobre el disco en el visor. DISPLAY ENT MEMORY Comprobación del número total de pistas y del tiempo de reproducción Presione DISPLAY ENT•MEMORY en modo de parada. Tiempo total de reproducción Número total de pistas...
Nota No será posible localizar pistas específicas si “SHUF” o “PGM” está iluminado en el visor. Desactive la indicación presionando x. Sugerencia Para localizar una pista de número superior a 10, presione >10 primero y, a continuación, los botones numéricos correspondientes. Ejemplo: Para reproducir la pista número 23, presione >10 primero y, a continuación, 2 y 3.
Reproducción repetida de las pistas (Reproducción repetida)(continuación) Para cancelar la reproducción repetida Presione MODE hasta que “REP” desaparezca del visor. En el mando a distancia • Utilice N en lugar de u. • Si ha elegido “REP 1”, seleccione la pista pulsando los botones numéricos.
Page 45
Creación de su propio programa (Reproducción programada) Puede crear un programa compuesto por un máximo de 20 pistas en el orden que desee reproducirlas. ., > DISPLAY ENT MODE MEMORY Presione x. La indicación “Cd” aparece en el visor. Presione MODE hasta que la indicación “PGM”...
Page 46
30 emisoras de radio (CFD- G70), 20 para FM y 10 para AM en cualquier orden o 40 emisoras de radio (CFD-G70L), 20 para FM y 10 para MW y LW respectivamente en cualquier orden. DISPLAY ENT MEMORY...
Page 47
Sintonía de emisoras almacenadas Una vez memorizadas las emisoras, utilice PRESET + o – del reproductor o los botones numéricos del mando a distancia para sintonizar las emisoras que desee. PRESET –, + RADIO BAND AUTO PRESET Presione RADIO BAND•AUTO PRESET para seleccionar la banda.
Énfasis de sonido Selección del énfasis de audio (SOUND/POWER DRIVE WOOFER/GAME Xpand) Es posible ajustar el énfasis del sonido que escuche. También puede disfrutar del sonido de una consola de juegos, etc., con el botón GAME Xpand. POWER DRIVE WOOFER GAME Xpand Selección de las características de sonido...
Page 49
Temporizador Desactivación automática de la unidad Es posible ajustar el reproductor para que se desactive automáticamente transcurridos 10, 20, 30, 60, 90 y 120 minutos, de forma que pueda dormirse mientras escucha música. SLEEP Reproduzca la fuente musical que desee. Presione SLEEP para que aparezca “SLEEP”.
Preparativos Selección de la fuente de alimentación Puede utilizar la alimentación de CA o las pilas como fuente de alimentación. Conexión del cable de alimentación de Inserte un extremo del cable de alimentación de CA suministrado en la clavija AC IN situada en la parte posterior del reproductor, y el otro extremo en la toma mural.
Page 51
Inserción de las pilas en el mando a distancia Inserte dos pilas R6 (tamaño AA) (no suministradas). Sustitución de las pilas Con un uso normal, las pilas deben durar aproximadamente seis meses. Cuando el reproductor no responda al mando a distancia, sustituya todas las pilas por unas nuevas.
Page 52
Conexión de una consola de juegos u otros componentes opcionales Puede disfrutar del sonido de una consola de juegos o TV, etc. a través de los altavoces de este reproductor. Asegúrese de desactivar la alimentación de todos los componentes antes de realizar las conexiones.
Page 53
Conexión de un TV o una videograbadora Cable de conexión de audio* (no suministrado) TV, video- grabadora, etc. a toma de salida de línea Cable de conexión de audio TV, video- (suministrado) grabadora, etc. a toma de auriculares * Un cable con un miniconector estéreo en un extremo y dos conectores fonográficos en el otro.
Notas sobre discos compactos • Antes de la reproducción, limpie el CD con un paño de limpieza desde el centro hacia los bordes. • No utilice disolventes como bencina, diluyentes, limpiadores comercialmente disponibles o rociadores antiestáticos para discos analógicos. • No exponga el CD a la luz solar directa ni a fuentes térmicas como conductos de aire caliente;...
• Aleje el reproductor del televisor. • Si emplea el mando a distancia mientras escucha una emisión de AM (CFD-G70) o MW/LW (CFD-G70L), es posible que se oiga ruido. Esto es inevitable. La imagen del televisor no es estable. • Si escucha un programa en FM cerca del televisor con una antena interior, aleje el reproductor del televisor.
CA y extraiga todas las pilas. Una vez que desaparezcan todas las indicaciones del visor, enchufe el cable de alimentación y vuelva a insertar las pilas. Si el problema no se soluciona, póngase en contacto con el proveedor Sony más próximo.
Page 58
Mantenimiento Limpieza de la lente Si la lente se ensucia, pueden producirse pérdidas de sonido durante la reproducción del CD. Límpiela con un soplador disponible en las tiendas del ramo. Limpieza de las cabezas y la trayectoria de la cinta Para obtener una calidad de reproducción y grabación óptima, limpie las cabezas, el rodillo compresor y el eje de arrastre con una escobilla...
Page 59
AM/MW/LW: Barra de ferrita incorporada Sección de la grabadora de casetes Sistema de grabación 4 pistas, 2 canales estéreo Tiempo de bobinado rápido 120 seg. aprox. con casetes Sony C-60 Respuesta de frecuencia TYPE I (normal): 70 - 13 000 Hz General Altavoces Altavoz principal: 10 cm de diámetro, 3,2 , tipo...
Page 60
Fuentes de alimentación 20 G, H GAME Xpand 18 Grabación en una cinta 10 I, J, K Intervalo de sintonización de AM/MW 20 Sony Corporation Limpieza cabezas y recorrido de cinta 28 exterior 28 Localización de una pista específica 12 M, N, O Mejora de la recepción de...
