A-CY3-100-11 (1)
HD 3CMOS
Color Video Camera
Command List
Version 1.00
BRC-Z700
© 2008 Sony Corporation

Advertisement

Table of Contents
loading

Related Manuals for Sony HD 3CMOS BRC-Z700

Summary of Contents for Sony HD 3CMOS BRC-Z700

  • Page 1 A-CY3-100-11 (1) HD 3CMOS Color Video Camera Command List Version 1.00 BRC-Z700 © 2008 Sony Corporation...

  • Page 2: Table Of Contents

    Table of Contents VISCA RS-232C/RS-422 Commands ... 3 Overview of VISCA ... 3 VISCA Communication Specifications ... 4 VISCA Device Setting Command ... 6 VISCA Command/ACK Protocol ... 7 VISCA Camera-Issued Messages ... 8 BRC-Z700 Commands ... 9 BRC-Z700 Command List (1/5) ... 9 BRC-Z700 Command List (2/5) ...

  • Page 3: Visca Rs-232C/Rs-422 Commands

    0 is used, set the camera address selectors on the connected BRC-Z700 cameras to different numbers. 1) VISCA is a protocol developed by Sony for controlling a consumer’s camcorder. “VISCA” is a trademark of Sony Corporation. Note In the same network, all the camera address selectors should be set to “0”...

  • Page 4: Visca Communication Specifications

    VISCA Communication Specifications VISCA packet structure The basic unit of VISCA communication is called a packet (Fig. 2). The first byte of the packet is called the header and comprises the sender’s and receiver’s addresses. For example, the header of the packet sent to the BRC-Z700 assigned address 1 from the controller (address 0) is 81H in hexadecimal.
  • Page 5 Command and inquiry • Command Sends operational commands to the BRC-Z700. • Inquiry Used for inquiring about the current state of the BRC- Z700. Command Packet Note Inquiry 8X QQ RR ... FF = Command/Inquiry, = category code QQ = 01 (Command), 09 (Inquiry) RR = 00 (Interface), 04 (camera 1), 06 (Pan/Tilter) X = 1 to 7: BRC-Z700 address For actual values to be sent, see Command Lists or...

  • Page 6: Visca Device Setting Command

    X = 9 to F: BRC-Z700 address +8 (For reply packet) Reply Packet Note X0 50 FF 88 01 00 01 FF Description (0001: Sony) HHHH = Model ID 0501: BRC-H700 0502: BRU-H700 0505: BRC-Z700 JJJJ = ROM revision KK = Maximum socket # (02)

  • Page 7: Visca Command/Ack Protocol

    VISCA Command/ACK Protocol Command Command Message Reply Message General Command 81 01 04 38 02 FF (Example) 81 01 04 38 FF (Example) 81 01 04 38 02 FF (Example) 81 01 04 08 02 FF (Example) Inquiry Command 81 09 04 38 FF (Example) 81 09 05 38 FF (Example)

  • Page 8: Visca Camera-Issued Messages

    VISCA Camera-Issued Messages ACK/Completion Messages Command Command Message z0 4y FF (y: Socket No.) Completion z0 5y FF (y: Socket No.) z = Device address + 8 Error Messages Command Command Message Syntax Error z0 60 02 FF Command Buffer Full z0 60 03 FF Command Canceled z0 6y 04 FF...

  • Page 9: Brc-Z700 Commands

    BRC-Z700 Commands BRC-Z700 Command List (1/5) Command Set Command AddressSet Broadcast IF_Clear Broadcast CommandCancel CAM_Power CAM_Zoom Stop Tele(Standard) Wide(Standard) Tele(Variable) Wide(Variable) Direct Direct(VariableSpeed) CAM_Focus Stop Far(Standard) Near(Standard) Far(Variable) Near(Variable) Direct Direct(VariableSpeed) AutoFocus ManualFocus Auto/Manual One Push Trigger Infinity CAM_AF_ASSIST** CAM_F_NearLimit CAM_WB Auto1 Auto2...

  • Page 10: Brc-Z700 Command List (2/5)

    BRC-Z700 Command List (2/5) Command Set Command CAM_RGain Reset Down Direct CAM_BGain Reset Down Direct CAM_COLOR_GAIN Up Down Reset Direct CAM_WB_Sens Middle High CAN_ColorMatrix R.ENHANCE G.ENHANCE B.ENHANCE YL.ENHANCE CY.ENHANCE MG.ENHANCE CAM_AE Full Auto Manual Shutter Priority Iris Priority Gain Priority CAM_AE_Speed Middle High...

  • Page 11: Brc-Z700 Command List (3/5)

    BRC-Z700 Command List (3/5) Command Set Command CAM_BackLight CAM_SpotLight Flicker Reduction CAM_Aperture Reset Down Direct CAM_ColorDetail COLOR DETAIL COLOR DETAIL PHASE CAM_Gamma Normal Cinema CAM_PictureEffect B&W CAM_Steady_Shot SOFT STANDARD HARD CAM_H_Phase Down CAM_Memory Reset Recall CAM_Menu CAM_Title Title Set 1 Title Set 2 Title Set 3 Title Clear...

  • Page 12: Brc-Z700 Command List (4/5)

    BRC-Z700 Command List (4/5) Command Set Command Pan-tiltDrive Down Left Right UpLeft UpRight DownLeft DownRight Stop AbsolutePosition RelativePosition Home Reset Pan-tiltLimitSet LimitSet LimitClear RAMP_CURVE MODE1 MODE2 MODE3 D-SUB 15Pin Output 1 RGB OUTPUT Output 1 YPbPr RGB SYNC OFF RGB SYNC RGB D-SUB 15Pin SYNC 3-STATE EXT_SYNC...

  • Page 13: Brc-Z700 Command List (5/5)

    BRC-Z700 Command List (5/5) Command Set Command CAM_SD_VideoOutput_ ON (7.5IRE) Setup* OFF (0IRE) * Available only for 59.94i output signal. Command Set Command CARD_SD- 4:3 [Squeeze] SDI_PictureSize 16:9 [Letter] 4:3 [Crop] Command Set Command CARD_Picture_size VGA [Crop] HFBK-XG1 WXGA Only XGA [Crop] VGA [Letter] XGA [Letter]...

  • Page 14: Brc-Z700 Inquiry Command List (1/4)

    BRC-Z700 Inquiry Command List (1/4) Inquiry Command Command Packet CAM_PowerInq 8x 09 04 00 FF CAM_ZoomPosInq 8x 09 04 47 FF CAM_FocusModeInq 8x 09 04 38 FF CAM_FocusNearLimitInq 8x 09 7E 01 41 FF CAM_FocusPosInq 8x 09 04 48 FF CAM_WBModeInq 8x 09 04 35 FF CAM_RGainInq...

  • Page 15: Brc-Z700 Inquiry Command List (2/4)

    BRC-Z700 Inquiry Command List (2/4) Inquiry Command Command Packet CAM_ExpCompModeInq 8x 09 04 3E FF CAM_ExpCompPosInq 8x 09 04 4E FF CAM_BackLightModeInq 8x 09 04 33 FF CAM_SpotLightModeInq 8x 09 04 3A FF CAM_ApertureInq 8x 09 04 42 FF CAM_ColorDetail ModeInq 8x 09 7E 01 4C FF CAM_ColorDetail PhaseInq 8x 09 7E 01 4D FF...

  • Page 16: Brc-Z700 Inquiry Command List (3/4)

    BRC-Z700 Inquiry Command List (3/4) Inquiry Command Command Packet PanTilt_Max_Speed 8x 09 06 11 FF PanTilt_Position 8x 09 06 12 FF Tally 8x 09 7E 01 0A FF PanTilt_Memory_Speed 8x 09 7E 01 0B 0p FF Pantilt_RampCurveInq 8x 09 06 31 FF CAM_Dzoom_LimitInq 8x 09 7E 01 1E FF Block_inq...

  • Page 17: Brc-Z700 Inquiry Command List (4/4)

    BRC-Z700 Inquiry Command List (4/4) Inquiry Command CARD_D-SUB_OUT1Inq HFBK-SD1 Only CARD_D-SUB_OUT2Inq CARD_RGBSYNC Inq CARD_Picture_SizeInq CARD_7.5IRE_SetupInq* CARD_Analog_OUTSEL_Inq 8x 09 7E 01 28 0p FF y0 50 00 FF HFBK-HD1 Only CARD_Analog_RGB_SYNC Inq 8x 09 7E 01 29 0p FF y0 50 00 FF CARD_SYNC_SEL Inq Audio Delay HFBK-TS1...

  • Page 18: Brc-Z700 Block Inquiry Command List

    BRC-Z700 Block Inquiry Command List Lens control system inquiry commands…..Command Packet 8x 09 7E 7E 00 FF Byte Comments Destination Address Source Address 0 Completion Message(50h) Zoom Position (HH) Zoom Position (HL) Zoom Position (LH) Zoom Position (LL) Byte Comments Focus Position (HH) Focus Position (HL) Focus Position (LH)
  • Page 19 Camera control system inquiry commands (1/2)…..Command Packet 8x 09 7E 7E 01 FF Byte Comments Destination Address Source Address 0 Completion Message(50h) WB R-Gain (H) WB R-Gain (L) WB B-Gain (H) WB B-Gain (L) Byte Comments AWB Sens (1: Low, 2: Mid, 3: High) WB Mode (0: Auto1, 1: Indoor, 2: Outdoor, 3: OnePush,...
  • Page 20 Camera control system inquiry commands (2/2)…..Command Packet 8x 09 7E 7E 02 FF Byte Comments Destination Address Source Address 0 Completion Message(50h) (1: 59.94i, 0: 50i) Power On (1: On, 0: Off) YL.ENHANCE Color Gain Steady Shot (1: On, 0: Off) indefinite Flicker Cancel (1: On, 0: Off) 0B &...
  • Page 21 Other enlargement inquiry commands (1/2) ... Command Packet 8x 09 7E 7E 03 FF Byte Comments Destination Address Source Address 0 Completion Message(50h) D-Zoom Position (H) D-Zoom Position (L) WB R.SHIFT WB B.SHIFT Byte Comments R.ENHANCE G.ENHANCE B.ENHANCE COLOR DETAIL MODE Shutter Pri Position Iris Pri Position Byte...
  • Page 22 Other enlargement inquiry commands (2/2) ... Command Packet 8x 09 7E 7E 04 FF Byte Comments Destination Address Source Address 0 Completion Message(50h) Current WB R-GAIN (H) Current WB R-GAIN (L) Current WB B-GAIN (H) Current WB B-GAIN (L) Byte Comments prism temp (H) prism temp (L)

  • Page 23: Visca Command Setting Values

    VISCA Command Setting Values Exposure control Iris IRIS (F1.6) Parameter F No. F1.6 F1.7 F1.8 F2.0 F2.2 F2.4 F2.6 F2.8 F3.1 F3.4 F3.7 F4.0 F4.4 F4.8 F5.2 F5.6 F6.2 F6.8 F7.3 F8.0 F8.7 F9.6 CLOSE Gain Parameter GAIN (dB) HYPER Iris Limit Parameter F No.
  • Page 24 Shutter Speed 59.94i SHUTTER (sec) 1/10000 1/6000 1/4000 1/3000 1/2000 1/1500 1/1000 1/725 1/500 1/350 1/250 1/180 1/125 1/100 1/90 1/60 Exposure Compensation EXPOSURE Comp Value COMP. (dB) +10.5 +7.5 +4.5 +1.5 –1.5 –3 –4.5 –6 –7.5 –9 –10.5 Gain Limit GAIN Parameter (dB)
  • Page 25 Focus Ratio and Focus Position (for reference) Focus Ratio Focus Distance 1000 Over Inf 2000 3000 1.8 m 4000 1.0 m 5000 65 cm 6000 30 cm 7000 20 cm 8000 13 cm 9000 7 cm A000 4 cm B000 2 cm C000 1 cm...

  • Page 26: Pan/Tilt Status Code List

    Pan/Tilt Status Code List – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –...

  • Page 27: Memory Function (Inquiry Commands)

    Memory Function (Inquiry Commands) Preset No. pp: Memory number last operated last operated – Comments While no Recall commands are used after the power has been tuned on ≠ 00 (or =00 for Reset, Set and Recall commands)

  • Page 28: Revision History

    Revision History Version Item 1.00 Description New edition...
