1. Introduction

This document is ﬁrmware update procedure manual for YSP-5600 using USB package.

2. Procedure

1. Unplug the cable of YSP-5600

2. Put USB package for YSP-5600 in USB ﬂash memory

3. Connect USB ﬂash memory to YSP-5600

4. Press-and-hold "volume -" button and plug in the cable

5. "FW Update" indication is appeared on FL

6. Wait for ﬁrmware updating process is ﬁnished

7. If "Success!" was displayed on FL, the ﬁrmware updating was completed. Please power off

YSP-5600. If some error was occurred, please check the meaning of the error referencing "3.

Indication and Meaning".

Note : If some progress was stopped more than 3 minutes, some problem might be occurred.

Please power off YSP-5600 and try again.

3. Indication and Meaning

Some informations are displayed on FL. The following table is informations and meanings.

YSP-5600 Firmware Update Procedure Manual

Page

Page 1 6. Wait for ﬁrmware updating process is ﬁnished 7. If “Success!” was displayed on FL, the ﬁrmware updating was completed. Please power off YSP-5600. If some error was occurred, please check the meaning of the error referencing “3. Indication and Meaning”.
Page 2 YSP-5600 Firmware Update Procedure Manual FL Indication Meaning Firmware update process was started The progress of network module. If there is new network module ﬁrmware in USB package, network module is updated on this process. (xx : 0 - 31, yyy : 0 - 100) OSD ﬁrmware update was started...
Page 3 YSP-5600 Firmware Update Procedure Manual FL Indication Meaning DSP2 Boot ﬁrmware update was ﬁnished correctly DSP2 Boot veriﬁcation was failed DSP2 Data ﬁrmware update was started The progress of DSP2 Data ﬁrmware update (xxx : 0 - 100) DSP2 Data ﬁrmware update was ﬁnished correctly DSP2 Data veriﬁcation was failed...
