Version 1.00 | 07/27/2018
User Manual
Wireless N Exterior Access Point
DAP-3315

Advertisement

Table of Contents
loading

Related Manuals for D-Link DAP-3315

Summary of Contents for D-Link DAP-3315

  • Page 1 Version 1.00 | 07/27/2018 User Manual Wireless N Exterior Access Point DAP-3315...

  • Page 2: Table Of Contents

    Time and Date ..............52 Performance .................25 Status ....................53 Wireless Resource ...............28 Device Information ............53 Multi-SSID ................30 Client Information ..............54 VLAN ..................31 Ethernet Information ............55 Port List ................32 WLAN Information .............56 Add/Edit VLAN ..............33 Configuration ................57 PVID Settings ..............34 D-Link DAP-3315 User Manual...
  • Page 3 Table of Contents Save and Activate ............57 Discard Changes ............58 System ....................59 Help ....................60 Troubleshooting ..............61 Technical Specifications ..........64 Antenna Pattern ..............67 D-Link DAP-3315 User Manual...

  • Page 4: Product Overview

    Power cord Wall Mount Quick Installation Guide Note: Using a PoE Injector with a different voltage rating or PoE injector than the one included with the DAP-3315 will cause damage and void the warranty for this product. D-Link DAP-3315 User Manual...

  • Page 5: System Requirements

    • Mozilla Firefox 28 and higher • Google™ Chrome 33 and higher • Apple Safari 7 and higher Windows Users: Make sure you have the latest version of Java installed. ® Visit www.java.com to download the latest version. D-Link DAP-3315 User Manual...

  • Page 6: Introduction

    Section 1 - Product Overview Introduction D-Link, an industry leader in networking, introduces the new D-Link DAP-3315 Wireless N Exterior Access Point. With the ability to transfer files with a maximum wireless signal rate of up to 300 Mbps , the DAP-3315 gives you ability to add high-speed wireless network access to places outside of your internal networking environment.
  • Page 7 Section 1 - Product Overview Ultimate Performance The D-Link Wireless N Exterior Access Point (DAP-3315) is an 802.11n compliant device that delivers real world performance of up to 300 Mbps , much faster than an 802.11g wireless connection (also faster than a 100 Mbps wired Ethernet connection). Create a secure wireless network to share photos, files, music, video, printers, and network storage outside of your normal internal networking environment.

  • Page 8: Features

    • Compatible with IEEE802.11g Devices - The DAP-3315 is still fully compatible with the 802.11g standards, so it can connect with existing 802.11g adapters. • Built-in High Gain Sector Antenna - The DAP-3315 comes equipped with a high powered 12 dBi antenna that helps to provide better wireless coverage and increases signal strength.

  • Page 9: Hardware Overview

    Note: The DAP-3315 uses a proprietary PoE injector which is needed to function correctly. Only use the included PoE injector as other power sources such as 3rd party PoE injectors or PoE switches or hubs may damage the DAP-3315 or cause it to operate unreliably, and will also void the warranty.

  • Page 10: Leds

    A solid green light indicates the LAN port (PoE) connection is OK. A blinking green light LAN LED (PoE) indicates that the unit is transmitting data over that port. D-Link DAP-3315 User Manual...

  • Page 11: Installation

    Installation First, you will need to configure the DAP-3315 with a computer connected directly to the unit. The following pages explains how to set up the DAP-3315 in order to be properly configured and then tested to work as desired.
  • Page 12 B. Connect an Ethernet cable from a router, switch, or PC to the LAN port on the PoE Injector. C. Attach the power cord to connect PoE injector, and plug it into an electrical outlet. This product uses a proprietary PoE design and can only be used with the included PoE injector. D-Link DAP-3315 User Manual...

  • Page 13: Wireless Installation Considerations

    1. Keep the number of walls and ceilings between the D-Link access point and other network devices to a minimum. Each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters). Position your devices so that the number of walls or ceilings is minimized.

  • Page 14: Configuration

    Section 3 - Configuration Configuration This section will show you how to configure your new D-Link Wireless N Exterior Access Point using the web-based configuration utility. Web-based Configuration Utility If you wish to change the default settings or optimise the performance of the DAP-3315, you may use the web-based configuration utility.

  • Page 15: Operating Modes

    Wireless AP devices that are in WDS mode. Wireless Client: As a wireless client the DAP-3315 can connect to an existing AP and expand the network physically with the two built-in 10/100 Ethernet ports.

  • Page 16: Basic Settings

    AP is currently in, please see “Operating Modes” on page 15. Note: The DAP-3315 has different configuration options depending on the current operating mode. Please be aware that some screens and menus will not be present unless the AP is operating in an applicable operating mode.

  • Page 17: Wireless Settings

    Section 3 - Configuration Wireless Settings This page will allow you to configure the wireless connection for the DAP-3315. Please be aware that some menu options will change depending on which type of security setting is used. Network Name Enter a name for your wireless network (SSID). For...
  • Page 18 Click Save to commit your changes. Note: Hexadecimal (HEX) digits consist of the numbers 0-9 and the letters A-F. ASCII (American Standard Code for Information Interchange) is a code that represents English letters using numbers ranging from 0-127. D-Link DAP-3315 User Manual...
  • Page 19 Select the interval during which the group Update: key will be valid. The default value of 1800 is recommended. Select Manual to enter your key (Passphrase). Passphrase When you select WPA-Personal, please enter / Confirm a Passphrase in the corresponding fields. Passphrase: D-Link DAP-3315 User Manual...
  • Page 20 The recommended value is 1800. Interval: A lower interval may reduce data transfer rates. RADIUS Server: Enter the IP address of your RADIUS server. RADIUS Port: Enter the RADIUS port. RADIUS Secret: Enter the RADIUS secret. D-Link DAP-3315 User Manual...
  • Page 21 Section 3 - Configuration 802.1x Authentication RADIUS Server: Enter the IP address of your RADIUS server. RADIUS Port: Enter the RADIUS port. RADIUS Secret: Enter the RADIUS secret. D-Link DAP-3315 User Manual...

  • Page 22: Wds

    Section 3 - Configuration Wireless Band: 2.4GHz(DAP-3315 is 2.4GHz Access Point WDS (Wireless This feature will be enabled automatically Distribution when select WDS or WDS with AP mode in System): operation page.For other operation mode it is disabled. Network Name Input the name for WDS connection.

  • Page 23: Wireless Lan Settings(Repeater Mode)

    DAP-3315 will be connecting to. Local Wi-Fi This option can either be set to rebroadcast Network Name: the wireless network that the DAP-3315 is connected to, or it can broadcast a different SSID. Authentication: The wireless LAN security can be Open System, WPA-Personal, WPA-Enterprise, or 802.1x.

  • Page 24: Lan Settings

    Section 3 - Configuration LAN Settings This section will allow you to change the local network settings of the DAP-3315. After making your changes, click the Save button. Get IP From: Select an option to choose how the AP will obtain an IP address to use on the local network.

  • Page 25: Advanced Settings

    The default (100) is recommended. Setting a higher beacon interval can help to save the power of wireless clients, while setting a lower one can help a wireless client connect to an access point faster. D-Link DAP-3315 User Manual...
  • Page 26 Short GI: Select Enable or Disable. Enabling a short guard interval can increase throughput. However, be aware that it can also increase the error rate in some installations due to increased sensitivity to radio-frequency installations. D-Link DAP-3315 User Manual...
  • Page 27 20MHz. Transfer DHCP Enable to transfer the DHCP Offer to Unicast Offer to from LAN to WLAN, suggest to enable this Unicast : function if stations number is larger than 30. D-Link DAP-3315 User Manual...

  • Page 28: Wireless Resource

    AP exceeds the percentage that has been specified, the DAP-3315 will not allow clients to associate with the AP. User Limit: Set the maximum amount of users that are allowed access (zero to 64 users) to the device using the specified wireless band.
  • Page 29 Use the drop-down menu to Enable the function. When enabled, the device denies the connection request from the wireless clients with the RSSI lower than the specified threshold below. ACL RSSI Set the ACL RSSI Threshold. Threshold: D-Link DAP-3315 User Manual...

  • Page 30: Multi-Ssid

    (WLAN). Enable Multi- Check to enable support for multiple SSIDs. SSID: 2.4GHz(DAP-3315 is 2.4GHz Access Point Wireless Band: You can select up to seven multi-SSIDs. With Index: the Primary SSID, you have a total of eight multi-SSIDs.

  • Page 31: Vlan

    Section 3 - Configuration VLAN The DAP-3315 supports VLANs. VLANs can be created with a Name and VID. Mgmt (TCP stack), LAN, Primary/Multiple SSID, and WDS connection can be assigned to VLANs as they are physical ports. Any packet which enters the DAP-3315 without a VLAN tag will have a VLAN tag inserted with a PVID.

  • Page 32: Port List

    The name of the port is displayed in this column. Tag VID: The Tagged VID is displayed in this column. Untag VID: The Untagged VID is displayed in this column. PVID: The Port VLAN Identifier is displayed in this column. D-Link DAP-3315 User Manual...

  • Page 33: Add/Edit Vlan

    Save button to let your changes take effect. VLAN Status: Use the radio button to toggle to Enable. VLAN ID: Provide a number between 1 and 4094 for the Internal VLAN. VLAN Name: Enter the VLAN to add or modify. D-Link DAP-3315 User Manual...

  • Page 34: Pvid Settings

    PVID settings. Click the Save button to let your changes take effect. VLAN Status: Use the radio button to toggle between Enable and Disable. PVID Auto Use the radio button to toggle PVID auto assign Assign Status: status to Enable. D-Link DAP-3315 User Manual...

  • Page 35: Intrusion

    All, Valid, Neighborhood, Rogue, and New. Click the Save button to let your changes take effect. Wireless Band: 2.4GHz. AP List: The choices include All, Valid, Neighbor, Rogue, and New. Detect: Click this button to initiate a scan of the network. D-Link DAP-3315 User Manual...

  • Page 36: Schedule

    Check this box to have your settings apply 24 hours a day. Start Time: Enter the beginning hour and minute, using a 24-hour clock. End Time: Enter the ending hour and minute, using a 24-hour clock. D-Link DAP-3315 User Manual...

  • Page 37: Dhcp Server

    A Dynamic Pool allows wireless stations to receive an available IP with lease time control. If needed or required in the network, the DAP-3315 is capable of acting as a DHCP server.

  • Page 38: Static Pool Settings

    After you have assigned a static IP address to a device via its MAC address, click Save; the device will appear in the Assigned Static Pool at the bottom of the screen. You can edit or delete the device in this list. D-Link DAP-3315 User Manual...

  • Page 39: Current Ip Mapping List

    IP address from the DHCP dynamic pool. Assigned IP The current corresponding DHCP-assigned IP Address: address of the device. Lease Time: The length of time that the dynamic IP address will be valid. D-Link DAP-3315 User Manual...

  • Page 40: Filter

    Apply. When you enter a MAC address, it appears in this list. Highlight a MAC address and click Delete to remove it from this list. Current Client This table displays information about all the Information: current connected stations. D-Link DAP-3315 User Manual...

  • Page 41: Wlan Partition

    Guest Mode: Select this option to disallow communication between wireless clients connected to the same SSID and between wireless clients connected to different SSIDs configured on the access point. D-Link DAP-3315 User Manual...

  • Page 42: View Log

    The log information includes but is not limited to the following items: cold start AP, upgrading firmware, client associate and disassociate with AP, and web login. The web page holds up to 500 logs. D-Link DAP-3315 User Manual...

  • Page 43: Log Settings

    Notification: schedule and periodical change key. It can not support Gmail SMTP port 465. Please set to Gmail SMTP port 25 or 587. E-mail Log Use the drop-down menu to set the e-mail log Schedule: schedule. D-Link DAP-3315 User Manual...

  • Page 44: Dmz

    If the Multiple DMZ option is selected, this Address: field will be available. This should be set to the internal IP address of a computer or device that will be assigned to an external IP address. D-Link DAP-3315 User Manual...

  • Page 45: Virtual Server

    Note: The private and public ports are usually the same. The public port is the port seen from the Internet side, and the private port is the port being used by the application on the computer or device within your local network. D-Link DAP-3315 User Manual...

  • Page 46: Port Forwarding

    Enter the TCP and/or UDP port or ports that you want to open. Port Range: Enter a single port or a range of ports. Example: 24,1009,3000-4000 Click Add to add this rule or Reset to clear settings. D-Link DAP-3315 User Manual...

  • Page 47: Parental Control

    Protocol: Specify which protocol to filter. Local Port: Enter the specific port to filter on the local network. Destination Enter the specific port to filter on the destination Port: network. D-Link DAP-3315 User Manual...

  • Page 48: Ip Routing

    Select whether the static route will be controlled by an existing gateway, or if the interface on the AP should route the traffic. Gateway: This option becomes available if Gateway is selected. Enter the gateway IP address. D-Link DAP-3315 User Manual...

  • Page 49: Maintenance

    The password is case-sensitive and should be between 0 and 12 characters. Country Settings: You can change country domain here. (For some countries such as Unitied States, Japan, Isael and Korea, this selection is grayed out due to regulation limitation. D-Link DAP-3315 User Manual...

  • Page 50: Firmware And Ssl Certification Upload

    This is a useful feature that prevents future bugs and allows for new features to be added to this product. Please go to your local D-Link website to see if there is a newer version firmware available.

  • Page 51: Configuration File

    Section 3 - Configuration Configuration File This page will allow you to upload or download a configuration file for the DAP-3315. Upload File: Use this option to load a previously saved configuration. Click Browse to find a previously saved configuration file. Then, click the Upload Settings button to transfer those settings to the access point.

  • Page 52: Time And Date

    Save. To avoid having to manually set the time, you can also click the Copy Your Computer’s Time Settings button at the bottom of the page to have the DAP-3315 automatically set the time based on the system clock of the computer being used to configure the DAP-3315.

  • Page 53: Status

    Section 3 - Configuration Status Device Information This page displays the current LAN, wireless LAN and important device information for the DAP-3315. Firmware Displays the access point’s time and firmware Version: version. Also displays the current operating mode and hardware address (MAC), which may be needed by a network administrator.

  • Page 54: Client Information

    Section 3 - Configuration Client Information This window displays the wireless client information for clients currently connected to the DAP-3315. Client This window displays the wireless client Information: information for clients currently connected to the DAP-3315. SSID: Displays the SSID of the client.

  • Page 55: Ethernet Information

    Section 3 - Configuration Ethernet Information The DAP-3315 keeps statistics of the traffic that passes through it. You can view the amount of packets that pass through the LAN and wireless portions of the network. The traffic counter will reset if the access point is rebooted.

  • Page 56: Wlan Information

    Section 3 - Configuration WLAN Information This window displays wireless network statistics for data throughput, transmitted and received frames, and frame errors. The traffic counter will reset if the access point is rebooted. D-Link DAP-3315 User Manual...

  • Page 57: Configuration

    You may change settings to multiple pages before activating. Once you are finished, click the Configuration button located at the top of the page and then click Save and Activate. You can then click Activate here to enable your changes. D-Link DAP-3315 User Manual...

  • Page 58: Discard Changes

    Save button at the bottom of each screen to save (not activate) your configuration changes. If you wish to discard all of the changes you have made, and not yet activated, you may click the Discard button. D-Link DAP-3315 User Manual...

  • Page 59: System

    Click the Restore button to reset all settings back to the factory defaults. Please note that this will erase all settings and changes made to the device’s configuration. Click the Clear button to clear the current Language pack running. D-Link DAP-3315 User Manual...

  • Page 60: Help

    Section 3 - Configuration Help Further information and in depth help can be found anytime from the AP’s online help function. Scroll down the Help page for topics and explanations. D-Link DAP-3315 User Manual...

  • Page 61: Troubleshooting

    Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link access point in the address bar. This should open the login page for your the web management.
  • Page 62 10 seconds. Release the button and the access point will go through its reboot process. Wait about 30 seconds to access the access point. The default IP address is 192.168.0.50. When logging in, the username is Admin and leave the password box empty. D-Link DAP-3315 User Manual...
  • Page 63 DHCP request on newly installed adapters. If you are connecting to a wireless network at a hotspot (e.g. hotel, coffee shop, airport), please contact an employee or administrator to verify their wireless network settings. D-Link DAP-3315 User Manual...

  • Page 64: Technical Specifications

    Range will vary depending on country’s maximum transmit power output regulation. Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range. D-Link DAP-3315 User Manual...
  • Page 65 Trademarks: D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. Other trademarks or registered trademarks are the property of their respective owners. Copyright Statement: No part of this publication or documentation accompanying this product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the...
  • Page 66 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. D-Link DAP-3315 User Manual...

  • Page 67: Antenna Pattern

    Antenna Pattern Antenna Patterns Orientation H-Plane E-Plane 2.4 GHz Wall Mounted D-Link DAP-3315 User Manual...
