Emerson XCM25D Quick Start Manual

XCM25D Quick Start Guide
Manual Defrost
Restart
Power Indicator
Set/Select
Navigation
Enter program mode*
Cycle through options/adjust values
Select funtion/store function
Exit program mode
+
*Program mode will terminate after 60 seconds of inactivity.
1
Set the clock
A
The unit will fl ash  the fi rst
time power is applied or if the
clock has lost its setting.
C
Press to select the
 menu .
Clock Parameters
Par. Description Value Range
 Minute
 Hour
 Day
 Month
 Year
2015ECT-3 (3/15) Emerson is a trademark of Emerson Electric Co. ©2015 Emerson Climate Technologies, Inc. All rights reserved.
Down
Alarm Info
3 seconds ( fl ash)
+
B
Press and hold
+
until fl ashes.
D
Use and
buttons to select and
adjust clock parameters.





2
Set pressure controls
A
Up
Press and to exit the
 menu. If and
held, the control will exit
program mode. Use
to return to program mode.
C
Use and
buttons to select and
adjust pressure parameters.
3
Set defrost parameters
and schedule
A
From the menu, use
and buttons to select
and adjust defrost parameters.
Defrost Parameters
Par. Description
Interval

between defrost
 Max duration
 Defrost mode
1st start time

2nd start time

3rd start time

4th start time

5th start time

6th start time

B
Use the or
are
to fi nd the  menu, then
press to select.
and
Pressure Parameters
Par. Description Value Range
 Cut In 10-135 (psi)
 Cut Out 0-30 (psi)

Refrigerant 22, 134, 404,
(4)07A, (4)07C,
507 (may vary
by model)
B
Press and hold
to exit program mode.
Value Range
(hours)
(minutes)
(off), (interval),
(clock)
(not used),:
buttons
and
