D-Link GO-SW-5E Manual

5-port fast ethernet easy desktop switch
Hide thumbs Also See for GO-SW-5E:
Table of Contents

Advertisement

Quick Links

GO-SW-5E
5-PORT FAST ETHERNET
EASY DESKTOP SWITCH
Manual
RECYCLABLE
V1.01

Advertisement

Table of Contents
loading

Related Manuals for D-Link GO-SW-5E

Summary of Contents for D-Link GO-SW-5E

  • Page 1 GO-SW-5E 5-PORT FAST ETHERNET EASY DESKTOP SWITCH Manual RECYCLABLE V1.01...

  • Page 2: Table Of Contents

    RONT ANEL LED I ................7 NDICATORS ..................8 ANEL ..................8 ANEL CONNECTING THE SWITCH ............9 GO-SW-5E ................9 GO-SW-5E ................9 UB TO GO-SW-5E ............9 TO OTHER DEVICES & D ............10 PEED UPLEX TECHNICAL SPECIFICATIONS ..........11...

  • Page 3: About This Guide

    Congratulations on your purchase of the D-Link GO-SW-5E. This device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in one high-performance, easy-to-use solution. Purpose This manual will familiarize you with the GO-SW-5E and guide you through the installation process.

  • Page 4: Introduction

    D-Link’s Green Technology implements special power-saving features under speed at 100Mbps that link status and adjust power usage accordingly. Further, D-Link Green implements the newly ratified IEEE 802.3az Energy Efficient Ethernet standard for reducing energy consumption of network links during periods of low utilization by transitioning interfaces into low-power state without interrupting the network connection.

  • Page 5: Switching Technology

    Power saving by link status. If there is no link on a port, such as when there is no computer connected to the port or the connected computer is powered off, D-Link’s Green Technology will enter a "sleep mode", drastically reducing power used for that port.

  • Page 6: Features

    The GO-SW-5E, with its small, compact size, was specifically designed for small to mid-sized workgroups. The GO-SW-5E can be installed where space is limited; moreover, it provides immediate access to a rapidly growing network through a wide range of user-reliable functions.
  • Page 7 Full-Duplex Fast Ethernet pipe. The GO-SW-5E is the perfect choice for a department or office planning to upgrade to Fast Ethernet. The GO-SW-5E can accommodate 10Mbps or 100Mbps devices, providing a flexible solution for existing (10Mbps) Ethernet workgroups.

  • Page 8: Unpacking And Setup

    Setup The setup of the GO-SW-5E can be performed using the following steps:  The power outlet should be within 1.82 meters (6 feet) of the Switch.  Visually inspect the DC power jack and make sure that it is fully secured to the power adapter.

  • Page 9: Identifying External Components

    DENTIFYING XTERNAL OMPONENTS Front Panel The figure below shows the front panel of the GO-SW-5E. GO-SW-5E 5-PORT FAST ETHERNET EASY DESKTOP SWITCH LED Indicators  Power Indicator: This green indicator light is on when the Switch is receiving power; otherwise, it is off.

  • Page 10: Rear Panel

    Power is supplied through an external power adapter. Check the technical specification section for information about the power input voltage. Since the GO-SW-5E does not require a power button, plugging its power adapter into a power outlet will immediately power it on.

  • Page 11: Connecting The Switch

    CONNECTING THE SWITC H PC to GO-SW-5E A computer can be connected to the GO-SW-5E via a two-pair Category 3, 4, 5 UTP/STP Straight-Through or Crossover cable. A computer equipped with a RJ-45 10/100Mbps port can be connected to any of the five GO- SW-5E ports.

  • Page 12: Port Speed & Duplex Mode

    Port Speed & Duplex Mode After plugging the selected cable to a specific port, the system uses auto- negotiation to determine the transmission mode, auto-detecting the network speed (10Mbps or 100Mbps) for any new twisted-pair connection. If the attached device does not support auto-negotiation or has auto- negotiation disabled, an auto-sensing process is initiated to select the speed and half-duplex mode is selected.

  • Page 13: Technical Specifications

    ECHNICAL PECIFICATIONS General Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet Protocol CSMA/CD Data Transfer Rate Ethernet: 10Mbps (half duplex) 20Mbps (full-duplex) Fast Ethernet: 100Mbps (half duplex) 200Mbps (full- duplex) Topology Star Network Cables 10BASE-T: 2-pair UTP CAT. 3,4,5/5e (100 m), EIA/TIA- 568 100-ohm STP (100 m) 100BASE-TX: 2-pair UTP CAT.
  • Page 14 Performance Transmission Method: Store-and-forward RAM Buffer 384Kbits(48KBytes) Filtering Address Table 2K entries per device Packet Filtering / 10Mbps Ethernet: 14,880/pps Forwarding Rate: 100Mbps Fast Ethernet: 148,800/pps MAC Address Learning: Automatic update...

  • Page 15: Pin Specification

    RJ-45 P PECIFICATION The following diagram and tables show the standard RJ-45 receptacle/connector and their pin assignments. RJ-45 Connector pin assignment Contact Media Direct Interface Signal Rx +(receive) Rx - (receive) Tx + (transmit) Not used Not used Tx - (transmit) Not used Not used RJ-45 pin assignment...
