Installation Manual Double DIN Kit
8.
Mount harzard light switch and
top display to facia plate
9.
Mount air condition
control unit to panel
10. Connect all required circuit points
Mount double DIN head unit
Mount center panel to dash board
• Hyundai iX20 2010->
• Hyundai iX20 2010->
Compatible with these double DIN devices
Kenwood Navigation
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
© 12/2010 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Installation Manual
Double DIN Kit
Part-No.: CH-HM-HYU.009
