Table of contents 1. Introduction to the manual Contents of this chapter ..........15 Applicability .
Page 6
4. Cabinet construction Contents of this chapter ..........39 General guidelines .
Page 7
Construction of supply module cubicle – 2×D8T, 12-pulse, Rittal TS 8 ... 83 Kits for 2×D8T, 12-pulse, Rittal TS 8 ........84 Stage 1: Installation of common parts .
Introduction to the manual Contents of this chapter This chapter gives basic information on the manual. Applicability The manual is applicable to the ACS880-304 +A018 diode supply modules with diode- thyristor bridges. Safety instructions Follow all safety instructions delivered with the drive.
The codes are listed in section Type designation key on page 36. Use of item designations Some device names include the item designations in brackets, for example [Q11] to make it possible to identify the components in the example circuit diagrams by ABB.
Introduction to the manual 17 Terms and abbreviations Term/Abbreviation Description BCON Type of a control board Type of a control unit (contains BCON) BDPS Type of the module internal power supply board. BDPS board is a double fed (AC/DC) power supply, which internally powers up the circuit boards of the module.
Page 18
18 Introduction to the manual Term/Abbreviation Description Inverter module Inverter bridge, related components and drive DC link capacitors enclosed inside a metal frame or enclosure. Intended for cabinet installation. Inverter unit Inverter module(s) under control of one control board, and related components. One inverter unit typically controls one motor.
Contents of this chapter This chapter contains a description of the diode supply unit. The information is valid for the units with ACS880-304 +A018 diode supply modules. Operation principle The heart of the diode supply unit is a diode-thyristor bridge. It rectifies three-phase AC current to direct current for the intermediate DC link of the drive.
20 Operation principle and hardware description There are two control modes for the upper leg thyristor firing: the charging mode and the normal mode: • The charging mode is in operation a short period after the power switch on: the supply control program controls the thyristor firing angle gradually towards zero while the intermediate circuit capacitors located in the inverter module(s) get charged.
Operation principle and hardware description 21 6- and 12-pulse supply units The figure below illustrates the difference between 6-pulse and 12-pulse AC supply connections. The 6-pulse connection is standard. If the drive has an even number of supply modules, you can order it as a 12-pulse version (option +A004). The 12-pulse supply connection eliminates the fifth and seventh harmonics, which remarkably reduces the harmonic distortion of the line current and the conducted emissions.
The supply unit overview diagrams also show examples of division of components in cubicles, and indicate which components you can order from ABB and which you need to acquire separately. Overview diagram of the drive system ...
This is an overview diagram of a 6-pulse supply unit with one D8T supply module. Cubicle Explanation Available through AC supply Incoming cubicle (ICU) Main switch-disconnector ABB or third party Main AC fuses ABB or third party Main contactor ABB or third party Diode supply unit cubicle Diode supply module...
40. Cubicle Explanation Available through AC supply Incoming cubicle (ICU) Main switch-disconnector ABB or third party Main AC fuse ABB or third party Contactor (optional) ABB or third party Main circuit breaker ABB or third party Diode supply unit cubicle...
This is an overview diagram of a 6-pulse supply unit with three D8T supply modules. Cubicle Explanation Available through AC supply Incoming cubicle (ICU) Main breaker ABB or third party Diode supply unit cubicle AC fuses for diode supply ABB or third party modules Diode supply modules DC link...
Cubicle Explanation Available through AC supply. Winding Y AC supply. Winding D Incoming cubicle (ICU) Main switch-disconnector (6-pole) ABB or third party Main AC fuses ABB or third party Main contactors ABB or third party Diode supply unit cubicle Diode supply modules...
Operation principle and hardware description 27 Hardware of the supply modules The D8T modules run on wheels, and can easily be removed from the cubicle for cable installation or service. For moving the D7T modules you need a lifting device. The quick connector for the AC supply input at the back of the D8T module couples when the module is inserted into the cubicle.
28 Operation principle and hardware description Layout drawings of the supply modules Layout drawing of D7T supply module Front Back Description AC input busbars DC output busbars Type designation label Cover of the module’s DC fuses Lifting eyes Unpainted fastening hole. Grounding point (PE) between module frame and cabinet frame. Terminal block [X53].
Operation principle and hardware description 29 Connectors X50 and X53 of D7T supply module Connector X50 Description Not in use. 115/230 V AC input for internal power supply (BDPS) (115V with option +G304) PE 115/230 V AC (50/60 Hz) supply for optional DOL (direct-on-line) cooling fan (option +C188).
30 Operation principle and hardware description Layout drawing of D8T supply module Front Back Description AC quick connector and AC input busbars DC output busbars Type designation label Cover of the module’s DC fuses Lifting eyes Unpainted fastening hole. Grounding point (PE) between module frame and cabinet frame. Terminal block [X53] (24 V DC power for supply module control unit) Terminal block [X50] (power supply for internal boards and module heating element, option +C183;...
Operation principle and hardware description 31 Connectors X50 and X53 of D8T supply module Connector X50 Description Not in use. N 115/230 V AC input for optional heating element (option +C183) Not in use. N 115/230 V AC input for internal power supply (BDPS) (115V with option +G304) W 400 V AC (50/60 Hz) supply for optional DOL (direct- on-line) cooling fan (option +C188).
32 Operation principle and hardware description Overview of control connections The figure shows the control interfaces of the supply unit. The control connections are made to the control unit (BCU). Description Description Analog and digital I/O extension modules Control panel. and fieldbus communication modules can be inserted into slots 1, 2 and 3.
The supply unit I/O control interface is in internal use. See section Default I/O connection diagram of the supply unit on page 232. The data in brackets, for example [Q1], refer to the item designations in ABB example circuit diagrams. Main disconnector [Q1] ...
34 Operation principle and hardware description The ACS-AP-I control panel With the control panel, you can: • start and stop the supply unit • view and reset the fault and warning messages, and view the fault history • view actual signals •...
Operation principle and hardware description 35 Type designation label The type designation label is attached to the module. An example label is shown below. Description Frame size Degree of protection Type designation, see section Type designation label on page 35. Ratings.
36 Operation principle and hardware description Type designation key Type designation describes the composition of the supply module in short. The type designation is visible on the label (sticker) which is attached to the module. The complete designation is divided in subcodes: •...
Moving and unpacking the module 37 Moving and unpacking the module Contents of this chapter This chapter contains moving, lifting and unpacking instructions for the supply module. Moving and lifting the transport package Move the transport package by a pallet truck or lift. Lift the transport package in horizontal position.
38 Moving and unpacking the module Unpacking The module is delivered on a wooden base, boxed in corrugated cardboard. The cardboard box is tied to the base with PET bands. Unpacking: 1. Cut off the bands. 2. Lift off the cardboard box. 3.
Cabinet construction 39 Cabinet construction Contents of this chapter This chapter contains cabinet installation instructions for the ACS880-304 +A018 supply modules. It also list the parts and components for the example installations. General guidelines For the general cabinet installation guidelines, see Cabinet design and construction instructions for ACS880 multidrive modules (3AUA0000107668 [English]).
40 Cabinet construction Switching, disconnecting and protecting solution To arrange the switching, disconnection and protection of the ACS880-304 +A018 module, you can use the following solution: 1. Equip the drive with a disconnector (main switch-disconnector or a main breaker) [Q1].
Cabinet construction 41 Incoming cubicle We recommend a separate incoming cubicle beside the supply module cubicle for the main AC fuses and switching and disconnecting devices. There is an example in section Layout drawing of the supply unit on page 47. Example of the AC fuse cooling ...
C2 requirements.The following figure shows an example of installing an RFI filter to the cabinet. For more information about EMC requirements, see Electrical planning instructions for ACS880 multidrive cabinets and modules (3AUA0000102324 [English]). The RFI filter is available through ABB. See RFI filters on page 213.
Cabinet construction 43 Configuration overviews of the supply module cubicles This section shows configuration examples of the supply module cubicles. You can build larger units by combining the basic configurations. Frame D7T modules are used in 12- pulse 2xD7T configurations. Frame D8T modules are used in both 6- and 12-pulse single or parallel configurations.
Page 44
44 Cabinet construction Generic cabinets D8T D8T D8T D8T D8T D8T D8T D8T Description The incoming cubicle contains the power input cable terminals and switchgear. It is to be designed by the customer. Diode supply unit...
Cabinet construction 45 Configuration overviews – 12-pulse Rittal TS 8 ICU1 ICU2 ICU1 ICU2 D8T D8T D8T D8T ICU1 ICU2 ICU1 ICU2 D8T D8T D8T D8T D8T D8T D8T D8T Description The incoming cubicle contains the power input cable terminals and switchgear. It is to be designed by the customer.
Page 46
46 Cabinet construction Generic cabinets ICU1 ICU2 ICU1 ICU2 D7T D7T D7T D7T D8T D8T D8T D8T ICU1 ICU2 ICU1 ICU2 D8T D8T D8T D8T Description The incoming cubicle contains the power input cable terminals and switchgear. It is to be designed by the customer.
Cabinet construction 47 Layout drawings Layout drawing of the supply unit This is an example layout drawing of a supply unit with an auxiliary control cubicle, incoming cubicle and supply module cubicle. Description Auxiliary control cubicle. Contains control unit (BCU), and auxiliary control devices such as auxiliary voltage transformer, circuit breakers, terminal blocks for the control wirings etc.
48 Cabinet construction Layout of supply module cubicle – 2×D7T, 12-pulse, in 600 mm wide Rittal TS 8 enclosure The figure show the layout of the supply module cubicle. 1. AC input 2. D7T diode supply module 3. DC output...
Cabinet construction 49 Layout of supply module cubicles – 1×D8T and 2×D8T, 6-pulse, in 400 mm / 600 mm wide Rittal TS 8 enclosures The figures show the layout of the supply module cubicles. 1×D8T 2×D8T 1. AC input 2.
50 Cabinet construction Layout of supply module cubicles – 2×D8T and 4×D8T, 12-pulse, in 600 mm wide Rittal TS 8 enclosures The figures show the layout of the supply module cubicles. 2×D8T 4×D8T 1. AC input 2. AC fuses 3.
You can find the kit-specific assembly drawings, step-by-step instructions and kit information on the Internet. Go to: https://www151.abb.com/spaces/lvacdrivesengineeringsupport/content. The examples also include cabinet assembly drawings that show each stage listed in the table. More detailed steps of each stage are described in the kit-specific assembly drawings.
Cabinet construction 69 Construction of supply module cubicle – 1×D8T, 6-pulse generic cabinet Parts to be installed Instruction code Kit code Kit ordering code Module installation parts 3AXD50000002715 A-4-8-307 3AXD50000002716 AC busbars to quick connectors 3AXD50000006192 A-4-8-183 3AXD50000004849 Quick connectors 3AUA0000118667 A-468-8-100 3AUA0000119227...
Cabinet construction 81 Construction of supply module cubicle – 2×D8T, 6- and 12-pulse, generic cabinet Parts to be installed Instruction code Kit code Kit ordering code Module installation parts 3AXD50000006128 A-6-8-313 3AXD50000006135 AC busbars to quick connectors 3AXD50000006270 A-6-8-184 3AXD50000006136 Quick connectors 3AUA0000118667...
Cabinet construction 93 Construction of supply module cubicle – 3×D8T, 6-pulse, generic cabinet Parts to be installed Instruction code Kit code Kit ordering code Module installation parts 3AXD50000006142 A-8-8-314 3AXD50000006517 AC busbars to quick connectors 3AXD50000006272 A-8-8-185 3AXD50000006514 Quick connectors 3AUA0000118667 A-468-8-100 3AUA0000119227...
• instructions for connecting auxiliary power supply for the diode supply module and to BCU control unit. The information is valid for the example cabinet installations of the ACS880-304 +A018 diode supply modules by ABB. Safety and liability WARNING! Only qualified electricians are allowed to do the work described in this chapter.
For more information on cable selection, protections, etc., see Electrical planning instructions for ACS880 multidrive cabinets and modules (3AUA0000102324 [English]). You can find more support material on the Internet. Go to: https://www151.abb.com/spaces/lvacdrivesengineeringsupport/content. Basic electrical safety precautions WARNING! Perform the electrical safety precautions below before starting any work on the installation.
Maximum long-term tensile load: 1 N (0.22 lbf) • Flexing: Max. 1000 cycles ABB drive products in general utilize 5 and 10 MBd (megabaud) optical components from Avago Technologies’ Versatile Link range. Note that the optical component type is not directly related to the actual communication speed.
The RFI filter is not suitable for use in IT (ungrounded) systems. Disconnect the filter before connecting the drive to the supply network. For instructions on how to do this, contact your local ABB representative. WARNING! If a drive with an RFI filter is installed on an IT system (an ungrounded power system), the system will be connected to earth potential through the filter capacitors of the drive.
Electrical installation 99 Connecting the power cables and busbars The circuit diagrams in this section are templates for the final main circuit diagrams. They do not contain details, such as terminal markings, etc. and are not suitable for the installation work as such. The designer of the cabinet-installed drive must: •...
100 Electrical installation Connection diagram – 2×D8T, 6-pulse Fuses or other protection means. Ground the cable shield 360 degrees at the cable lead-through (recommendation). See section Connection procedure on page 103. Use a separate PE conductor in addition to the input cable shield if the conductivity of the shield does not meet the requirement for the PE conductor.
Electrical installation 101 Connection diagram – 3×D8T, 6-pulse Fuses or other protection means. Ground the cable shield 360 degrees at the cable lead-through (recommendation). See section Connection procedure on page 103. Use a separate PE conductor in addition to the input cable shield if the conductivity of the shield does not meet the requirement for the PE conductor.
102 Electrical installation Connection diagram – 2×D8T, 12-pulse Fuses or other protection means. Ground the cable shield 360 degrees at the cable lead-through (recommendation). See section Connection procedure on page 103. Use a separate PE conductor in addition to the input cable shield if the conductivity of the shield does not meet the requirement for the PE conductor.
Electrical installation 103 Connection procedure WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. 1. Disconnect the drive from the AC power line and make sure it is safe to start the work. Obey the instructions in section Basic electrical safety precautions on page 96.
Page 104
104 Electrical installation A cable lead-through example. This is to be acquired by the cabinet installer.
Connectors X50 and X53 of D7T supply module on page Connectors X50 and X53 of D8T supply module on page 31. The plug connector is available from ABB. See section Control circuit plug connectors for supply modules on page 188. See also section Auxiliary circuit current/power consumption on page 224.
Control unit on page and sections Auxiliary circuit current/power consumption on page 224. The plug connector is available from ABB. See section Control circuit plug connectors for supply modules on page 188. Connection procedure WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive.
Electrical installation 107 Connecting the control cables Connection diagram See the final circuit diagrams by the designer of the cabinet-installed drive. For the default I/O connection diagram of the supply unit, see section Default I/O connection diagram of the supply unit on page 232.
Page 108
108 Electrical installation An example control cable lead-through with 360 degrees grounding of the cable shields. To be acquired by the cabinet-installer. Fiber optic connectors of the module FAULT Name Description BFPS Fan control connection. ENABLE / STO Connected at the factory. POWER OK Control unit connection.
Electrical installation 109 Connecting a PC to the supply unit Connect a PC to the drive with an USB data cable (USB Type A <-> USB Type Mini-B) as follows: 1. Lift the USB connector cover on the control panel from bottom upwards. 2.
110 Electrical installation Installing option modules Note: For the optional modules supported by the control program, see the appropriate firmware manual. Note: Pay attention to the free space required by the cabling or terminals coming to the optional modules. WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive.
Installation checklist 111 Installation checklist Contents of this chapter This chapter contains an installation checklist for the ACS880-304 +A018 diode supply modules. Before you start Disconnect the drive from the AC power line and make sure it is safe to start the work.
Page 112
112 Installation checklist Check that... The ambient operating conditions meet the specifications given in chapter Technical data. The cabinet has been fixed to floor, and if necessary due to vibration etc, also from top to the wall or roof. The cooling air flows freely, and air recirculation inside the cabinet is not possible. There is sufficient free space around the drive cabinet.
The underlined tasks are needed for certain cases only. The item designations are given in brackets. They refer to the circuit diagram of the example installation by ABB. The underlined tasks are needed for certain cases only, for example, The supply unit is equipped with a main breaker ([Q1], option +F255).
114 Start-up Start-up procedure The instructions in this manuals are not suitable for the start-up work as such. They are valid for the example supply unit only and intended for the starting point for the final start- up instructions. The designer of the cabinet-installed drive must: •...
If your supply unit consists of more than one module: • Set parameter 195.12 accordingly. For the settings, see table on page 117. For setting this parameter, you need a service level pass code. To obtain the pass code, contact your ABB representative.
116 Start-up Action Validate the operation of safety functions if any (for example, emergency stop). See the final circuit diagrams by the designer of the cabinet-installed drive. WARNING! The safety functions are not safe before they are validated according to the instructions.
Contents of this chapter This chapter contains maintenance instructions. The information is valid for the cabinet- installed ACS880-304 +A018 diode supply modules. WARNING! Only qualified electricians are allowed to do the work described in this chapter. Read the complete safety instructions before you install, commission, use or service the drive.
R Replacement Maintenance and component replacement intervals are based on the assumption that the equipment is operated within the specified ratings and ambient conditions. ABB recommends annual drive inspections to ensure the highest reliability and optimum performance. Note: Long term operation near the specified maximum ratings or ambient conditions may require shorter maintenance intervals for certain components.
Maintenance 121 Cabinet Cleaning the interior of the cabinet WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. WARNING! Use a vacuum cleaner with an antistatic hose and nozzle, and wear a grounding wristband.
122 Maintenance Cleaning the door air inlets (IP54) WARNING! Use a vacuum cleaner with an antistatic hose and nozzle, and wear a grounding wristband. Otherwise an electrostatic charge might build up and damage the circuit boards. Check the dustiness of the air inlet meshes. If the dust cannot be removed by vacuum cleaning from outside through the grating holes with a small nozzle, proceed as follows: 1.
Maintenance 123 Power connections Tightening the power connections WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. 1.
124 Maintenance Fuses Checking and replacing the DC fuses of D7T supply module WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. WARNING! Wear protective gloves and long sleeves! Some parts have sharp edges.
126 Maintenance Checking and replacing the DC fuses of D8T supply module WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. WARNING! Wear protective gloves and long sleeves! Some parts have sharp edges.
128 Maintenance Checking and replacing the AC fuses WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. 1.
Maintenance 129 Fans Replacing the fan of the D7T supply module The fan replacement procedure is the same for both the standard speed-controlled cooling fan and direct-on-line fan (option +C188) of the D7T module. WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive.
130 Maintenance Replacing the fan of the D8T supply module If the module is equipped with a direct-on-line cooling fan (option +C188), see page 131. WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment.
Maintenance 131 Replacing the direct-on-line fan (option +C188) of the D8T supply module If the module is equipped with a standard speed-controlled cooling fan, see page 130. WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions given in Safety instructions for ACS880 multidrive cabinets and modules (3AUA0000102301 [English]) before you service the drive.
Maintenance 133 Replacing the circuit board compartment fan of the D8T module The D8T module is equipped with a fan blowing air through the circuit board compartment. The fan is accessible from the front of the module. WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions given in Safety instructions for ACS880 multidrive cabinets and modules (3AUA0000102301 [English]) before you service the drive.
Page 134
134 Maintenance 6. Remove the four M3 (5.5 mm) nuts which hold the fan. 7. Remove the fan from the fan holder. 8. Put the fan onto the threaded studs on the fan holder with the airflow direction arrow pointing towards the fan holder. 9.
Page 135
Maintenance 135 10. Connect the fan cable. 11. Align and push the fan holder into the module. 12. Install and tighten the two M4×12 (T20) screws.
136 Maintenance Replacing the cabinet cooling fans Cabinets with ABB air outlet kits WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions given in Safety instructions for ACS880 multidrive cabinets and modules (3AUA0000102301 [English]) before you service the drive.
Maintenance 137 Supply module Cleaning the heatsink The module heatsink fins pick up dust from the cooling air. Clean the heatsink when necessary. Overtemperature warnings and faults indicate that the heatsink is not clean. WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive.
This section contains instructions on replacing the module from Rittal TS 8 enclosure. The instructions are valid for the example Rittal installations presented in this manual. We assume that you have the ABB lifting device in use (order code: 3AXD50000004182). WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions of the drive.
Page 139
Maintenance 139 7. Attach the lifting hooks to the lifting eyes of the module: • Bend the DC busbars away from the module. • Carefully pull the module out along the module guide plates until you can attach the lifting hooks to the module. Tighten the chain. 8.
Rittal installations presented in this manual. We assume that you have the ABB module pull-out ramp in use (order code: 3AUA0000120467). If you do not have the ramp, always use a lifting device when you remove the module.
Page 142
142 Maintenance Support the top and Do not tilt! Do not leave the module bottom of the module! unattended on a sloping floor! max. 100 mm (3.94 in) max 50 mm Do not use this hole for lifting! Mind your fingers! Support the top and bottom of the module! NO LIFTING!
Page 143
Maintenance 143 9. Install the new module into the cubicle: • Push the module back in and attach. Be careful not to break the fastening screws: tighten the fastening screws of the module to 22 N·m (16.2 lbf.ft). Tighten the fastening bolts of the DC output busbars to 70 N·m (51.6 lbf.ft).
Maintenance 145 Control panel Replacing the control panel battery 1. Turn the lid on the back of the panel counter-clockwise until the lid opens. 2. Replace the battery with a new CR2032 battery. 3. Put the lid back and tighten it by turning it clockwise. 4.
146 Maintenance Control unit BCU control unit types There are three variants of the BCU control unit used in ACS880 drives: BCU-02, BCU-12 and BCU-22. These have a different number of converter module connections (2, 7 and 12 respectively) but are otherwise identical. The three BCU types are interchangeable as long as the number of connections is sufficient.
Maintenance 147 Control unit battery Replace the real-time clock battery if the BATT OK LED is not illuminated when the control unit is powered. For information on the LED, see Layout and connections on page 234. 1. Undo the fastening screw and remove the battery 2.
148 Maintenance LEDS and other status indicators This section instructs how to interpret the status indications of the diode supply unit. Information on warnings and faults reported by the control program and displayed on the drive/converter/inverter control panel on the cabinet door are contained within the Firmware manual delivered with the drive.
Maintenance 149 Reduced run The reduced run function is available for diode supply units consisting of parallel- connected diode supply modules. The function makes it possible to continue operation with limited current even if one (or more) module is out of service, for example, because of maintenance work.
150 Maintenance Resuming normal operation WARNING! Only qualified electricians are allowed to do this work. Read the complete safety instructions given in Safety instructions for ACS880 multidrive cabinets and modules (3AUA0000102301 [English]) before you service the drive. Ignoring the instructions can cause physical injury or death, or damage to the equipment. 1.
Contents of this chapter This chapter lists the types and ordering codes of the diode supply unit components. The data is valid for ACS880-304 +A018 supply modules and related accessories. You can find the kit-specific assembly drawings, step-by-step instructions and detailed kit information on the Internet.
152 Ordering information Kit code The format of the kit code is A-w-s-xxx, for example, A-4-7-001 where: • A = air-cooled • w = cabinet width • 4 = 400 mm (15.75 in) • s = module size / sizes •...
Ordering information 153 Diode supply units – 2×D7T, 12-pulse This section lists the component ordering codes for a diode supply unit which: • consists of two D7T supply modules • have a 12-pulse connection to AC power line • is installed in the Rittal TS 8 enclosure or in a generic cabinet. Diode supply modules –...
154 Ordering information Mechanical installation accessories – 2×D7T, 12-pulse, Rittal TS 8 Installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 2×D7T 600 mm A-6-7-320 3AXD50000008820 (23.62 in)
Ordering information 155 AC busbar support In D7T, AC busbars provide connection from the module input to the common AC Flat-PLS. Module Enclosure width Qty Kit code Ordering code Illustration size 2×D7T 600 mm A-6-7-150 3AXD50000008831 (23.62 in) Instruction code: 3AXD50000009155 DC busbars DC busbars provide connection from the module DC output to the common DC bus.
156 Ordering information Diode supply units – 1×D8T, 6-pulse This section lists the component ordering codes for a diode supply unit which: • consists of one D8T supply module • have a 6-pulse connection to AC power line • is installed in the Rittal TS 8 enclosure or in a generic cabinet. Diode supply modules –...
Ordering information 157 Mechanical installation accessories – 1×D8T, 6-pulse, Rittal TS 8 Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-303 3AUA0000115057 (15.75 in)
158 Ordering information AC busbars In D8T, AC busbars provide connection from the module input to the common AC Flat-PLS. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-102 3AUA0000115904 (15.75 in) Instruction code: 3AUA0000115889 AC busbars to quick connector The AC busbars to quick connector kit includes busbars for connecting the quick connector to the common AC Flat-PLS.
Ordering information 159 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-201 3AUA0000115815 (15.75 in) Instruction code: 3AUA0000115847 DC connection flanges Each diode supply module requires DC connection flanges.
160 Ordering information Mechanical installation accessories – 1×D8T, 6-pulse, generic cabinet Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-307 3AXD50000002716 (15.75 in)
Ordering information 161 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-209 3AXD50000004850 (15.75 in) Instruction code: 3AXD50000006191 DC connection flanges Each diode supply module requires DC connection flanges.
162 Ordering information Diode supply units – 2×D8T, 6-pulse This section lists the component ordering codes for a diode supply unit which: • consists of two D8T supply modules • have a 6-pulse connection to AC power line • is installed in the Rittal TS 8 enclosure or in a generic cabinet. Diode supply modules –...
Ordering information 163 Mechanical installation accessories – 2×D8T, 6-pulse, Rittal TS 8 Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-305 3AXD50000002489 (23.62 in)
164 Ordering information AC busbars In D8T, AC busbars provide connection from the module input to the common AC Flat-PLS. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-103 3AXD50000002491 (23.62 in) Instruction code: 3AXD50000001890 AC busbars to quick connector The AC busbars to quick connector kit includes busbars for connecting the quick connector to the common AC Flat-PLS.
Ordering information 165 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-202 3AXD50000002490 (23.62 in) Instruction code: 3AXD50000001867 DC connection flanges Each diode supply module requires DC connection flanges.
166 Ordering information Mechanical installation accessories – 2×D8T, 6-pulse, generic cabinet Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-313 3AXD50000006135 (23.62 in)
Ordering information 167 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-210 3AXD50000006524 (23.62 in) Instruction code: 3AXD50000006281 DC connection flanges Each diode supply module requires DC connection flanges.
168 Ordering information Diode supply units – 2×D8T, 12-pulse This section lists the component ordering codes for a diode supply unit which: • consists of two D8T supply modules • have a 12-pulse connection to AC power line • is installed in the Rittal TS 8 enclosure or in a generic cabinet. Diode supply modules –...
Ordering information 169 Mechanical installation accessories – 2×D8T, 12-pulse, Rittal TS 8 Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-305 3AXD50000002489 (23.62 in)
170 Ordering information AC busbars In D8T, AC busbars provide connection from the module input to the common AC Flat-PLS. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-105 3AXD50000008819 (23.62 in) Instruction code: 3AXD50000010218 AC busbars to quick connector The AC busbars to quick connector kit includes busbars for connecting the quick connector to the common AC Flat-PLS.
Ordering information 171 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-202 3AXD50000002490 (23.62 in) Instruction code: 3AXD50000001867 DC connection flanges Each diode supply module requires DC connection flanges.
172 Ordering information Mechanical installation accessories and tool – 2×D8T, 12-pulse, generic cabinet Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-313 3AXD50000006135...
Ordering information 173 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 2×D8T 600 mm A-6-8-210 3AXD50000006524 (23.62 in) Instruction code: 3AXD50000006281 DC connection flanges Each diode supply module requires DC connection flanges.
174 Ordering information Diode supply units – 3×D8T, 6-pulse This section lists the component ordering codes for a diode supply unit which: • consists of three D8T supply modules • have a 6-pulse connection to AC power line • is installed in the Rittal TS 8 enclosure or in a generic cabinet. In the Rittal installations, the supply unit consist of one 1×D8T supply module cubicle and one 2×D8T supply module cubicle.
Ordering information 175 Mechanical installation accessories – 3×D8T, 6-pulse, Rittal TS 8 Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-303 3AUA0000115057 (15.75 in)
Ordering information 177 AC busbars AC busbars provide connection from the module input to the common AC Flat-PLS. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-104 3AXD50000004437 (15.75 in) Instruction code: 3AXD50000004442 2×D8T 600 mm A-6-8-103 3AXD50000002491 (23.62 in) Instruction code: 3AXD50000001890...
178 Ordering information AC busbars to quick connector The AC busbars to quick connector kit includes busbars for connecting the quick connector(s) to the common AC Flat-PLS. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-180 3AUA0000115077 (15.75 in) Instruction code: 3AUA0000115846...
Ordering information 179 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 1×D8T 400 mm A-4-8-201 3AUA0000115815 (15.75 in) Instruction code: 3AUA0000115847 2×D8T 600 mm A-6-8-202 3AXD50000002490 (23.62 in)
180 Ordering information Mechanical installation accessories and tools – 3×D8T, 6-pulse, generic cabinet Module installation parts Module installation parts include, for example, top and bottom supports for the module. Module Enclosure width Kit code Ordering code Illustration size 3×D8T 800 mm A-8-8-314 3AXD50000006117...
Ordering information 181 DC busbars DC busbars provide connection from the module DC output to the common DC bus. Module Enclosure width Kit code Ordering code Illustration size 3×D8T 800 mm A-8-8-211 3AXD50000006516 (31.50 in) Instruction code: 3AXD50000006284 DC connection flanges The kit contains a pair of DC connection flanges.
182 Ordering information Diode supply units – 4×D8T, 5×D8T and 6×D8T 6-pulse This section lists the component ordering codes for a diode supply unit which: • consists of multiple D8T supply modules • have a 6-pulse connection to AC power line •...
184 Ordering information Diode supply units – 4×D8T and 6×D8T 12-pulse This section lists the component ordering codes for a diode supply unit which: • consists of multiple D8T supply modules • have a 12-pulse connection to AC power line •...
The control unit kit does not contain any cables but you need to acquire them separately: • You must connect the control unit to each supply module with a pair of fiber optic cables. You can order them from ABB. See section Fiber optic cables for supply modules on page 187.
Ordering information 187 Control units – 12-pulse The control unit kit contains: BCU control unit and memory unit with the control program. Supply module Size Control unit Ordering code =400 V, 500 V, 690 V ACS880-304-0910A-3+A004+A018 2xD7T BCU-02 kit for DxT 3AXD50000006338 ACS880-304-0910A-5+A004+A018 ACS880-304-0760A-7+A004+A018...
188 Ordering information Control circuit plug connectors for supply modules The control circuit plug connectors are not included in the module kit but you must order them separately: • You need one plug connector X50 for the AC auxiliary power supply connection for each diode supply module.
Ordering information 189 Main switch-disconnectors You must equip the electric supply of a machinery with a main disconnecting device (IEC/EN60204-1). This section lists suitable main switch-disconnectors. For the dimension drawings, see section Dimensions of main switch-disconnectors page 246. Note: For the high power units, you can use withdrawable main circuit breaker instead of the main switch-disconnector.
190 Ordering information IEC main switch-disconnectors – 12-pulse Supply module Size IEC switch-disconnectors Ordering code Type Data Un=400 V, 500 V, 690 V ACS880-304-0910A-3+A004+A018 2×D7T OT1250E12DD 1250 A, 3AXD50000009845 ** 1000 V ACS880-304-0910A-5+A004+A018 ACS880-304-0760A-7+A004+A018 ACS880-304-1210A-3+A004+A018 2×D8T OT1250E12DD 1250 A, 3AXD50000009845 ** 1000 V ACS880-304-1820A-3+A004+A018...
Ordering information 191 AC fuses The AC fuses protect the main contactor and the supply modules against short circuits. Always equip the supply unit with the main AC fuses. If there are parallel modules after the main AC fuses, equip each module with the module-specific AC fuses. For the dimension drawings, see section Dimensions of AC fuses on page 250.
192 Ordering information IEC/UL module-specific AC fuses – 6-pulse Supply module Size AC fuses (IEC, UL) Ordering code Type Data =400 V, 500 V, 690 V ACS880-304-1210A-3+A018 2×D8T 170M6415 1100 A, 690 V 68731658 ACS880-304-1820A-3+A018 170M6419 1600 A, 690 V 68393108 ACS880-304-1210A-5+A018 170M6415...
Ordering information 193 UL main AC fuses – 12-pulse Supply module Size AC fuses (UL) Qty Ordering code Type Data =400 V, 500 V, 690 V ACS880-304-0910A-3+A004+A018 2×D7T 170M6412 800 A, 690 V 68731640 ACS880-304-0910A-5+A004+A018 170M6412 800 A, 690 V 68731640 ACS880-304-0760A-7+A004+A018 170M6411...
194 Ordering information Main contactors You can use the main contactors for the on-off control of the AC input power. The contactors can make and break the full load current. The contactor package includes: • contactor unit • 2 x normally-open OA1G10 + 2 x normally-closed auxiliary contacts OA1G01. For the dimension drawings, see section Dimensions of main contactors on page 252.
Ordering information 195 IEC main contactors – 12-pulse Supply module type Size Main contactor (IEC) Qty Ordering code Type Data =400 V, 500 V, 690 V ACS880-304-0910A-3+A004+A018 2×D7T AF1250-30-22-70 1250 A, 1000 V 2 68687284 ACS880-304-0910A-5+A004+A018 ACS880-304-0760A-7+A004+A018 ACS880-304-1210A-3+A004+A018 2×D8T AF1250-30-22-70 1250 A, 1000 V 2 68687284 ACS880-304-1820A-3+A004+A018...
196 Ordering information Main circuit breakers You can use the main circuit breakers below for the on-off control of the AC input power. The breakers can make and break the full load current and also break a fault current. When installed in a wagon, the breakers are withdrawable and operate as main disconnecting device for the supply units.
MP3/ 220V 600 V 051791 3800A-7+A018 5×D8T E6H-A40 W- 4 kA, 3AUA0000 MP3/ 220V 600 V 051611 5470A-3+A018 6×D8T Not available from ABB. 5470A-5+A018 6×D8T 4560A-7+A018 6×D8T E6H-A40 W- 5 kA, 3AUA0000 E6H-A W 4000/5000 A 3AUA00000 MP3/ 220V 600 V...
198 Ordering information IEC main circuit breakers – 12-pulse 230 V Supply module Size Main circuit breaker (IEC) Wagon (IEC) ACS880-304- Type Data Qty Ordering Type Data Qty Ordering code code =400 V, 500 V, 690 V 2430A-3+A004+A018* 4×D8T E3S1600/230 1600 A, 68564611 E3WFP3P 3-pole rear...
200 Ordering information UL/CSA main circuit breakers – 6-pulse 115 V Supply module Size Main circuit breaker (UL) Wagon (UL) ACS880-304- Type Data Qty Ordering Type Data Qty Ordering code code =400 V, 500 V, 690 V 1210A-3+A018 2×D8T E3S-A16/115V 1600 A, 68398282 3-POLE, REAR...
202 Ordering information Control panel The control panel is not included with the diode supply module but must be ordered separately. One control panel is required for the commissioning of an ACS880 drive system, even if the Drive composer PC tool is used. The control panel can be flush mounted on the cabinet door with the help of a door mounting kit.
206 Ordering information Air outlet kits Air outlet kits for a 400 mm (15.75 in) cubicle The IP54 kits require a cooling fan that must be ordered separately. Enclosure width / Kit code Ordering code Illustration Degree of protection 400 mm A-4-X-042 3AUA0000125203 (15.75 in), IP20...
Page 207
Ordering information 207 Enclosure width / Kit code Ordering code Illustration Degree of protection 400 mm A-4-X-064 3AXD50000009187 (15.75 in), IP54 cubicle with forced cooling See the assembly drawing 3AXD50000010284 for the cutting instructions of the cabinet roof plate. 400 mm A-4-X-067 3AXD50000010362 (15.75 in), IP54, UL cubicle with forced...
210 Ordering information Cooling fans One or two cooling fans are to be installed inside the air outlet compartment to ensure sufficient cooling of the cabinet. IEC/UL Component Enclosure / Degree of Ordering code protection Name Data CRBB/4-315/112D ML 3AXD50000006934 Capacitor MSB MKP 6/603/E1679...
Ordering information 211 Miscellaneous Lifting device for the D7T supply module Use the lifting device when you remove or install a frame D7T module from or in the Rittal TS 8 enclosure. See also section Replacing the D7T supply module (page 138).
212 Ordering information Bracket for Rittal Flat-PLS busbar holder (common AC) If you use the Rittal Flat-PLS system, you can use this kit for correct positioning of the common AC bus in the Rittal TS 8 enclosure. Note: The designs presented in this manual for Rittal TS 8 enclosures employ the Rittal Flat-PLS busbar system.
Ordering information 213 RFI filters The RFI filter is used for improving the EMC characteristics of the unit and to fulfill category C2 requirements. See Electrical planning instructions for ACS880 multidrive cabinets and modules (3AUA0000102324 [English]). ACS880-304-… RFI filter Assembly kit for toroid Type Data...
Technical data 215 Technical data Contents of this chapter This chapter contains the technical data for ACS880-304 +A018 diode supply modules. Ratings Module type Nominal ratings No overload Light Heavy-duty overload use A (AC) A (DC) A (DC) kVA A (DC)
Page 216
216 Technical data Module type Nominal ratings No overload Light Heavy-duty overload use A (AC) A (DC) A (DC) kVA A (DC) A (DC) (DC) (DC) ACS880-304-1210A-5+A018 1215 1488 1680 1052 1004 1428 1113 ACS880-304-1820A-5+A018 1823 2232 2083 1579 1507 2143 1446 1670...
(k): 1.00 0.90 0.80 +40 °C +50 °C +104 °F +122 °F Altitude derating At altitudes 0 … 2000 m (6561.7 ft) - no derating. For derating at altitudes over 2000 m (6561.7 ft), contact ABB.
Technical data 219 Fuses AC fuses There must always be the main AC fuses in the supply unit. If there are parallel modules after the main AC fuses, there must also be separate module-specific AC fuses for each module. For the AC fuse types and ordering codes, see section AC fuses on page 191.
222 Technical data Free space requirements Frame size Above Front Left Right 7.87 0.39 0.39 0.39 Definitions Above Free space to enable cooling air flow Front Free space for cabling Left Free space for smooth installation Right Free space for smooth installation...
Frequency 50/60 Hz, Variation ± 5% of the nominal frequency Imbalance Maximum 3% of nominal phase-to-phase voltage Short-circuit withstand Supply units with the ABB-defined main switch-disconnector and fuses: strength • Rated peak withstand current (I ): 105 kA (IEC/EN 61439-1) •...
226 Technical data DC connection data Voltage (U ACS880-304-xxxxA-3+A018: 513 … 560 V DC. This is indicated in the type designation label as typical output voltage level 540 V DC. 6-pulse modules ACS880-304-xxxxA-5+A018: 513 … 675 V DC. This is indicated in the type designation label as typical output voltage levels 540/648/675 V DC.
The unit is to be used in a heated indoor controlled environment. Operation Storage Transportation Altitude above sea level 0…2000 m (0…6561.7 ft) For altitudes over 2000 m, contact ABB. Air temperature 0…+40 °C -40…+70 °C -40…+70 °C (+32…+104 °F), no (-104…+158 °F) (-104…+158 °F)
EU. They must be removed and handled according to local regulations. For further information on environmental aspects and more detailed recycling instructions, please contact your local ABB distributor. Standards See Electrical planning instructions for ACS880 multidrive cabinets and modules (3AUA0000102324 [English]).
ABB Ltd and its affiliates are not liable for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or...
230 Technical data Tightening torques (N·m / lbf·ft) Common tightening torques for screw connections Use torques given in component-specific documentation. If other torque values are not given, use the values listed in the following tables. For Rittal components, use torques given in the Rittal assembly documentation. Cable lugs ...
Control unit 231 Control unit Contents of this chapter This chapter • describes the connections of the control units used in ACS880-304 +A018 diode supply modules • contains the specifications of the inputs and outputs of the control units. General The ACS880 drive utilizes BCU-x2 control units.
232 Control unit Default I/O connection diagram of the supply unit XD2D Drive-to-drive link Drive-to-drive link (not in use by default) BGND Shield X485 RS485 connection Not in use (not in use by default) BGND Shield XRO1…XRO3 Relay outputs XRO1: Running (energized = running) 250 V AC / 30 V DC / 2 A XRO2: Fault(-1)
The BCU-x2 has an on-board data logger that collects real-time data from the converter to help fault tracing and analysis. The data is stored onto the SDHC memory card inserted into the SD CARD slot and can be analyzed by ABB service personnel. External power supply for the control unit (XPOW) ...
234 Control unit Layout and connections Description I/O terminals (Default I/O connection diagram of the supply unit) SLOT 1 I/O extension or fieldbus adapter module connection. (This is the sole location for an FDPI-02 diagnostics and panel interface.) SLOT 2 I/O extension or fieldbus adapter module connection SLOT 3...
Page 235
Control unit 235 Description Analog inputs Analog outputs Digital inputs, Digital input interlock (DIIL) XRO3 XDIO Digital input/outputs XD24 XPOW XD2D Drive-to-drive link XD24 +24 V output (for digital inputs) XRO2 XETH Ethernet port (eg. for PC communication) XDIO XPOW External power input XRO1 Relay output RO1...
236 Control unit Control unit connector data Power supply Connector pitch 5 mm, wire size 2.5 mm (XPOW) 24 V (±10%) DC, 2 A External power supply in. Two supplies can be connected to BCU for redundancy. Relay outputs RO1…RO3 Connector pitch 5 mm, wire size 2.5 mm (XRO1…XRO3) 250 V AC / 30 V DC, 2 A...
Page 237
Control unit 237 Analog outputs AO1 and AO2 Connector pitch 5 mm, wire size 2.5 mm (XAO) 0…20 mA, R < 500 ohm load Frequency range: 0…500 Hz Resolution: 11 bit + sign bit Inaccuracy: 2% of full scale range Drive-to-drive link Connector pitch 5 mm, wire size 2.5 mm (XD2D)
238 Control unit Ground isolation diagram XPOW +24VI +24VI +VREF -VREF AGND AI1+ Common mode voltage between AI1- each AI input and AGND is AI2+ AI2- +30 V AGND AGND XD2D BGND SHIELD XRO1, XRO2, XRO3 XD24 +24VD DICOM +24VD DIOGND XDIO DIO1...
Dimension drawings 239 Dimension drawings Contents of this chapter This chapter shows dimensions of the ACS880-304 +A018diode supply modules and related accessories.
Dimension drawings 245 Dimensions of ACS-AP-I control panel with door mounting kit Cutting in the cabinet door: 109 mm × 223 mm (4.29 in. × 8.78 in.) Plate thickness: 86.5 [3.41] 1.5…2.5 mm (0.059…0.098 in.) 123.1 [4.85] 11 [0.43] 125 [4.92]...
246 Dimension drawings Dimensions of main switch-disconnectors Dimensions of OT1250E12, OT1250E12DD (IEC) www.abb.com Dimensions in mm 1 mm = 0.0394 in...
252 Dimension drawings Dimensions of main contactors Dimensions of AF1250-30-22-70 and AF2050-30-22-70 AF1250-30-22-70 48,5 AF2050-30-22-70 Dimensions in mm www.abb.com 1 mm = 0.0394 in 312 340...
Inside edge of compartment door Segregation (when provided) M10 mounting holes for circuit breaker (use M10 screws) 1×M12 screw for earthing (included in the supply) 17.5 1 mm = 0.0394 in Dimensions in mm www.abb.com 1 mm = 0.0394 in...
Example circuit diagrams 261 Example circuit diagrams Contents of this chapter This chapter contains three example circuit diagram sets. Each set includes one supply module type and typical related equipment. These supply module types are presented: • ACS880-304-1820A-3+A018+C183+C188 (2×D8T 6-pulse connection) •...
262 Example circuit diagrams Component designations used in the diagrams 2×D8T 6-pulse circuit diagrams The 2×D8T 6-pulse circuit diagrams include: Designation Component A1.1 CVAR board for UL/CSA installations only BCU control unit DPMP-01 door mounting kit for control panel ACS-AP-I control panel Emergency stop safety relay Emergency stop extension safety relay...
Example circuit diagrams 263 5×D8T 6-pulse circuit diagrams The 5×D8T 6-pulse circuit diagrams include: Designation Component A1.1 CVAR board for UL/CSA installations only BCU control unit DPMP-01 door mounting kit for control panel ACS-AP-I control panel F3.x AC fuses for protecting the modules G24.1 Incoming cubicle fan for cooling the AC fuses Q1.1...
264 Example circuit diagrams Differences of 2×D8T 6-pulse, 5×D8T 6-pulse and 2×D7T 12-pulse circuit diagrams The main difference between 2×D8T 6-pulse, 2×D7T 12-pulse and 5×D8T 6-pulse diagrams is that in 5×D8T, the main AC fuses [F1.x], main switch-disconnector [Q1.1] and main contactor [Q2.1] are replaced with one component, main circuit breaker [Q1.1].
Sheet 002 – Main line, module connections DSU MODULE DSU MODULE +01.3 ;1L11 ;1L21 001/16A ;1L31 =-F3.11 =-F3.21 =-T1.1 =-T1.2 >;DCP:1 >;DCM:1 =-T1.1 =-T1.2 =-X50.1 =-X50.2 FAN U FAN U ;F112L:1 FAN V FAN V ;F112L:2 001/10K FAN W FAN W ;F112L:3 BDPS L...
FAN BOX FAN BOX FAN BOX HEATER HEATER HEATER HEATER HEATER DC FAN DC FAN DC FAN DC FAN DC FAN 11.11.2015 Vanin Oleg 5xD8T 6 pulse Circuit Diagram 11.11.2015 Asikainen Mika ACS880-304-4560A-3+A018+C183 Main line, module connection 3AXD10000285688 ABB Drives...
Sheet 002 – Main line, module connections DSU MODULE DSU MODULE +01.3 ;1L11 ;2L11 ;1L21 ;2L21 001/16A 001/16G ;1L31 ;2L31 =-T1.1 =-T1.2 >;DCP:1 >;DCM:1 =-T1.1 =-T1.2 =-X50.1 =-X50.2 FAN L FAN L ;DOL FAN:L 020/10E FAN N FAN N ;DOL FAN:N 020/6F BDPS L...
Product and service inquiries Address any inquiries about the product to your local ABB representative, quoting the type designation and serial number of the unit in question. A listing of ABB sales, support and service contacts can be found by navigating to www.abb.com/searchchannels.
Page 280
Contact us www.abb.com/drives www.abb.com/drivespartners 3AXD50000010104 Rev C (EN) 2015-12-03...
