Revolabs Single Channel System — Sony PCS-HG90 Setup Guide This setup guide will guide you through the steps needed to properly connect a Revolabs Single Channel System to a Sony PCS-HG90 video codec. It is important to carefully follow these instructions in order and completely.
Page 2
1. Connect the 07-STEMIC-PPP Line to Mic adapter cable to the 2.5mm AUDIO port on the Single Channel System 2. Connect the XLR male connector on the 07-STEMIC-PPP cable to the left MIC port on the Sony PCS-HG90. Disregard the RCA portion of the 07-STEMIC-PPP cable. Configuring the Sony PCS-HG90 Video Codec 1.
