HILUX (LHD)
VSS 3

Installation instructions

Model year:
Vehicle code:
Part number:
Weight:
Manual reference number: AIM 002 206 - 0
June 2011
*****L-*****W
Main kit:
Inclination sensor:
0.750 kg
PZ464-00132-B0
(Vehicle Wireless Remote)
PZ464-00132-02

Advertisement

loading

Related Manuals for Toyota 2011 HILUX VSS 3

Summary of Contents for Toyota 2011 HILUX VSS 3

  • Page 1: Installation Instructions

    HILUX (LHD) VSS 3 Installation instructions Model year: June 2011 Vehicle code: *****L-*****W Part number: Main kit: PZ464-00132-B0 (Vehicle Wireless Remote) Inclination sensor: PZ464-00132-02 Weight: 0.750 kg Manual reference number: AIM 002 206 - 0...

  • Page 2: Revision Record

    Revision Record Rev. No. Date Page Picture Update Deleted Steps 2 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 3 3 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 4 4 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 5 5 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 6 T0053 T0044 T0046 T1423 T1424 T0058 T0065 M8x12 M6x10 T0060 T0063 Ø 6mm, 1.5m SCM goedgekeurde alarminstallatie Merk: Toyota T0069 T0068 T1425 T1430 T0062 T1641 Vehicule security system T0122 T1426 T0064 T0051 Ø 4mm, 2.1m xxxxxxxx xxxxx xxxxxxxxx xxxxxxxx xxxxx xxxxxxxxx...
  • Page 7 OPTIONAL - PZ464-00132-02 T1431 T0051 T1433 T0057 T0051 T1432 T1434 T0069 T0068 T1435 T0059 T0066 T0004 T0001 T0003 CLEANER T1438 T1506 T0006 T1650 8 mm 10 mm T0005 14 mm T0007 T3855 Schlemmer Art. No. T3659 9001543 7 of 49 Manual Ref.
  • Page 8 GR/B T4088 8 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 9 T1802 GR/B T1443 GR/B T1651 9 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 10 GR/B 89 - 96 T4089 GR/B T4091 10 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 11 PZ464-00132-02 GR/B PZ464-00132-02 T1442 T4090 11 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 12 Battery 2 Battery 1 T4119 T1445 T1444 T4093 T4092 12 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 13 10 mm 10 mm T4095 T4094 16 - 17 T1701 60mm 18mm T1702 13 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 14 60mm 18mm T1654 T1451 14 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 15 T1447 T1448 T1450 15 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 16 23 - 28 29 - 42 T1653 T1657 1100mm 1000mm T4096 16 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 17 CLEANER T0972 17 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 18 T4191 T4190 Click T1917 18 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 19 49 of 49 T1456 Ø 3 mm Ø 8 mm T1502 T1457 19 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 20 1100mm 1000mm T4096 T0451 CLEANER T1503 T0452 20 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 21 T0454 T0453 T0455 T1504 T1458 T1505 21 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 22 T4123 T1460 22 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 23 T1461 T4097 23 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 24 CLEANER T1452 CLEANER Vehicle security sistem xxxxxxxx xxxxx xxxxxxxxx T1803 T4098 24 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 25 T1455 T1463 25 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 26 10 mm 7,5 Nm L/P L/B W/B B T4099 26 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 27 “WIRE VIEW" 89 - 96 Pin IA1 wire color VSS wire color Signal L/B (w diode) Driver door L/P (w diode) Passenger door 89 - 96 T4100 27 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 28 Pin D12 wire color VSS wire color Signal “WIRE VIEW" 89 - 96 T4101 T4102 28 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 29 T4103 29 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 30 “FRONT SIDE" “WIRE VIEW" 89 - 96 “WIRE VIEW" 14 13 12 11 10 Pin 2E wire color VSS wire color Signal 89 - 96 Pin 2M wire color VSS wire color Signal T1469 30 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 31 “FRONT SIDE" “WIRE VIEW" “WIRE VIEW" 17 1615141312 11 89 - 96 Pin 2D wire color VSS wire color Signal CDL open 89 - 96 Pin 2A wire color VSS wire color Signal CDL close T3866 31 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 32 “WIRE VIEW" 89 - 96 Pin T22 wire color VSS wire color Signal Blinker T1470 “WIRE VIEW" 5 4 3 2 1 11 10 9 89 - 96 Pin S13 wire color VSS wire color Signal Horn T1471 32 of 49 Manual Ref.
  • Page 33 max 3 mm Not to damage any vehicle wires (just b e h i n d t h e h o l e ) while drilling T1472 T1473 33 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 34 T4104 T4105 34 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 35 T4106 T4107 35 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 36 T4108 T4109 36 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 37 T4111 T4110 T1482 37 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 38 T1483 T4112 T4113 38 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 39 100cm T1487 T4114 T1488 39 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 40 T1489 Click T1490 7,5 Nm 14 mm T4115 40 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 41 T4116 41 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 42 7 Nm 10 mm T4116 10 mm 10 mm Vehicule security system CLEANER T1500 42 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 43 Battery 2 Battery 1 5.6 Nm 5.6 Nm T4118 PZ464-00132-02 T1494 T1495 43 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 44 T1496 7 Nm 10 mm T1497 44 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 45 89 - 96 89 - 96 T1498 AJ AB I T1499 T1340 45 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 46 Ref: Toyota Wire Harness Repair Pub No. RM 1022E CHECK Page B30-31 Paragraph 6 T1341 10 mm 10 mm (0.39 in) (0.39 in) 10 mm (0.39 in) T1344 T1345 46 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 47 T1347 10 mm 10 mm (0.39 in) (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) T1346 47 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 48 48 of 49 Manual Ref. no. AIM 002 206 - 0...
  • Page 49 Windows Windows side side Rear Rear T4224 49 of 49 Manual Ref. no. AIM 002 206 - 0...
