- Page 1 Network IR PTZ Camera Owner’s Manual Owner’s Manual Network IR PTZ Camera Please read this manual carefully before operating your set and retain it for future reference. Model: LNP3021R LG P/N: COV33509901 1512 (V1.0)
- Page 2 Network IR PTZ Camera Owner’s Manual Operation of this equipment in a residential area is likely Safety Information to cause harmful interference in which case the user will be required to correct the interference at his own expense. A suitable conduit entries, knock-outs or glands shall be provided in the cable entries of this product in the end user.
- Page 3 Contact office for compliance of this product: operation of the camera. This camera is designed for mounting on the ceiling LG Electronics European Shared Service Center B.V. Krijgsman 1, 1186 DM Amstelveen, The Netherlands or wall. If you install this camera upside down, it may cause malfunction.
- Page 4 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com.
- Page 5 Network IR PTZ Camera Owner’s Manual Contents 1. Product Brief 2. Start Up 2.1 Client Installation Conditions ...........................2 2.2 Initial Configuration ..............................2 2.2.1 Modify Parameter ..............................2 2.2.2 Login Web Client ...............................2 2.2.3 Focus ................................3 3. Product Functions 3.1 Live View .................................4 3.1.1 Toolbar Buttons ..............................4 3.1.2 Image Adjustment .............................4 3.1.3 Auxiliary Function ..............................6...
-
Page 6: Product Brief
Network IR PTZ Camera Owner’s Manual 1. Product Brief The high speed dome camera is remote HD IP Camera based on IP network technology. It can be deployed at any point of a surveillance network and transmit HD video via public or private IP network. -
Page 7: Start Up
IP Search is green software free from Interface after login is shown in Picture 2-4. installation. Run LG IP Search: it will search devices in LAN automatically and display the list as shown in Picture 2-1. Select a camera to be configured, click “Modify Params”... -
Page 8: Focus
Network IR PTZ Camera Owner’s Manual NOTE: If more than 2 Clients connect to 1 camera at the same time, Live stream may not be shown and “Beyond Capacity” message is alerted. In this case, Select the UDP at Settings>Local Setting>Protocol or reduce the resolution and Bit Rate Upper Limit at Settings>Camera>Video. -
Page 9: Product Functions
Network IR PTZ Camera Owner’s Manual 3. Product Functions By Web Client, user can not only view live video, but also perform local snapshot and recording, and set alarm linkage. NOTE: Some functions not supported by this model at Web Client program are disabled. - Page 10 Network IR PTZ Camera Owner’s Manual *Enable IR Lamp The basic conception of White Balance is “to make all In low light situation, user can manually enable IR lamp colors white regardless of the color temperature of the light source”. It can compensate color rendition in to switch night mode for better images.
-
Page 11: Auxiliary Function
Network IR PTZ Camera Owner’s Manual Click “Edit” and the image will be divided into 16 Day, when alarm inputs, the system will switch to day mode. columns and 12 lines of squares. Click a square and drag an area from it, then the area will turn purple and is the motion detection area. -
Page 12: Preset Position
Network IR PTZ Camera Owner’s Manual 3.3.1 Preset Position Load Preset Preset position includes information of PT position After stop operating on camera for a certain period of and lens focal length. It is set by user and can be time, the lens will return to the defined preset position loaded, modified or cancelled any time. -
Page 13: Restricted Patrol
Network IR PTZ Camera Owner’s Manual number on each path is configurable and the Setting: maximum is 32. Go to Settings>Camera>PTZ>Guard Tour. Check “Enable” to enable patrol function, and select patrol mode from the drop-down list. Set Waiting Time according to the Guard Tour mode. -
Page 14: Scheduled Task
Network IR PTZ Camera Owner’s Manual stop recording. Each path can record for at most 10 minutes. Click “Preview” to browse all PTZ operations. Click “Stop” to stop browsing. Select a path and click “Delete Records” to delete all records of PTZ operations under this path. -
Page 15: Alarm Linkage
Network IR PTZ Camera Owner’s Manual 3.5 Alarm Linkage 3.5.3 Alarm Input Linkage Alarm Linkage is the system reaction after an alarm The camera supports on/off alarming device. signal is received. It is to raise watch man’s attention to handle the event. The alarm signal comes from Motion Detection (details in Chapter 3.2) or Alarm Input Device (such as smoke detector) in the surveillance area. -
Page 16: Privacy Mask
Network IR PTZ Camera Owner’s Manual 3.6.2 Clear Area Start from an undefined square and draw an area that contains the defined area, or click the defined squares one by one to clear setting, or click “Clear” directly. Click “Save” to make settings effective. 3.6.3 Disable Function To disable this function, uncheck Enable. -
Page 17: Playback
Please click “Upgrade” during system upgrading, and the upgrade file is usually in <*.pkg> format. Picture 3-16 Recording Method 2 Run LG IP Search. 3.9.1 Playback Select recording duration from the calendar. Click “Upgrade” to upgrade firmware of cameras If there is background color on a date, it means of the same model simultaneously. - Page 18 Network IR PTZ Camera Owner’s Manual 3.10.2 Web Client Upgrade After firmware upgrade, please login Web Client again. The page will prompt to download a new ActiveX control. After downloading it, client upgrade will be completed. Login again to enter the latest Web Client. NOTE: ...
-
Page 19: Settings
User operation is subject to the actual functions of password, and save. models. 4.1 Network Access Initial Configuration has introduced how to modify parameters via LG IP Search to make camera access network. Camera accepts multiple network access methods (via Ethernet and PPPoE). The following introduces configure... -
Page 20: Bnc Output
Network IR PTZ Camera Owner’s Manual 4.2 BNC Output Select filter method from the dropdown list according Camera with BNC output can output analog image to request, or select “Disable” to disable IP filter. directly when local display function is enabled. Add Black/White List: Go to Settings>Camera>Image>Rotate and BNC, After select filter method, click “Add”... -
Page 21: Multi-Stream
Network IR PTZ Camera Owner’s Manual 4.5 Multi-stream Camera supports multiple streams encoding and decoding. Multi-stream means the same video source is encoded into different streams of videos with different resolutions. User can select proper resolution to view or record according to the network bandwidth. Go to Settings>Camera>Video>Encoding Format, as shown in Picture 4-8. -
Page 22: References
Network IR PTZ Camera Owner’s Manual 5. References 5.1 Troubleshooting Unable to log into client Failure analysis: PC and camera cannot communicate with each other. Solution: Modify IP address of camera or PC to make camera and PC in the same network segment. ... - Page 23 Network IR PTZ Camera Owner’s Manual Picture 5-2 Add camera address to Trusted sites Add camera address to the trusted sites. Uncheck the option “Require server verification (https:) for all sites in this zone”.
-
Page 24: Specification
Network IR PTZ Camera Owner’s Manual 5.2 Specification Features LNP3021R Camera Image Sensor 6.40 mm (1/2.8 Type) CMOS Lens x30, 4.3-129 mm, F1.4-F4.6 Min. Illumination Color 0.05 lux @ F1.4 (AGC On) 0.005 lux @ F1.4 (AGC On) Day / Night... - Page 25 TCP / IP, UDP, HTTP, DHCP, DNS / DDNS, RTP / RTCP, RTSP, PPPoE, FTP, VSIP Web Viewer Microsoft Internet Explorer 7.0 ~ 9.0 (32bit) Video Management Software LG Ipsolute VMS Suite Connections Up to 10 Power Source AC24V Max. Power Consumption Max.
-
Page 26: Appendix: Glossary Of Terms
Network IR PTZ Camera Owner’s Manual 6. Appendix: Glossary of Terms 1080p Resolution of 1920*1080 pixels(16:9) 720p Resolution of 1280*720 pixels (16:9) High-definition Network Address Translation DHCP Dynamic Host Configuration Protocol DDNS Dynamic Domain Name Server Internet Protocol MPEG4 Moving Pictures Experts Group Resolution of 352*288 pixels QCIF Resolution of 176*144 pixels...
