MARK !ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST damaged by heat. ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. SECTION 1...
CFM-20L SECTION 2 DISASSEMBLY • The equipment can be removed using the following procedure. Cabinet (front) sub ASSY Record/playback head (HRP101), Reel/capstan motor (M101), Belt Batt(+) board, Power board MD ASSY Cabinet (rear) ASSY Jack board, Main board Note : Follow the disassembly procedure in the numerical order given.
CFM-20L 2-3. RECORD/PLAYBACK HEAD (HRP101), REEL/CAPSTAN MOTOR (M101), BELT • Attaching belt Flywheel ASSY Belt 9 Belt M101 MD ASSY 5 Lug (T), plate 4 Record/playback 8 Reel/capstan head (HRP101) motor (M101) 2 Guide, tape 6 Spring, Compr 3 Screws...
CFM-20L 2-5. BATT (+) BOARD, POWER BOARD Claw Batt (+) board Cabinet (rear) White 3 Screws (+ BVTP 3X10) Power board • DIAL POINTER SETTING Note : Follow the installation procedure in the numerical order given. 4 Set the right side edge...
CFM-20L SECTION 3 ADJUSTMENTS 3-1. MECHANICAL ADJUSTMENTS 3-2. ELECTRICAL ADJUSTMENTS PRECAUTION 0dB=0.775V TAPE RECORDER SECTION 1.Clean the following parts with a denatured-alcohol-moistened FUNOTION switch (S101) : TAPE (RADIO OFF) swab : VOLUME (RV101) : MIN record/playback head pinch roller erase head...
Page 7
CFM-20L Tape Speed Adjustment Procedure : level meter Mode : Playback 8Ω digital frequency test tape counter WS-48B (3kHz, 0dB) 8Ω J101 (Earphone jack) FM Section Function switch (S101) : FM J101 (Earphone jack) Volume : MIN FM RF signal...
Page 8
CFM-20L • Repeat the procedures in each adjustment several times, and the FM IF ADJUSTMENT frequency coverage and tracking adjustments should be finally Adjust for a maximum reading on level meter. done by the trimmer capacitors. 10.7MHz LW IF ADJUSTMENT FM FREQUENCY COVERAGE ADJUSTMENT Adjust for a maximum reading on level meter.
CFM-20L Refer to page 13 for Notes. Refer to page 14 for IC Block Diagrams. 4-4. SCHEMATIC DIAGRAM – MAIN SECTION (2/2) –...
Page 13
CFM-20L Note on schematic Diagram: MAIN SECTION (1/2), (2/2) • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and W or less unless otherwise specified.
CFM-20L • IC BLOCK DIAGRAMS IC1 TA2132AF (EL) AM RF AM RF FM RF FM RF AM/FM AM/FM QUAD FM/AM BUFF FM RF FM RF FM IF AM IF IC101 MM1315BD – – – – – – –...
CFM-20L SECTION 5 EXPLODED VIEWS NOTE : • -XX, -X mean standardized parts, so they • Hardware (# mark) list and accessories and may have some difference from the original packing materials are given in the last of this one.
CFM-20L SECTION 6 BATT(+) JACK MAIN ELECTRICAL PARTS LIST NOTE : • Due to standardization, replacements in the • SEMICONDUCTORS The components identified by mark 0 In each case, u : µ , for example : parts list may be different from the parts or dotted line with mark 0 are critical uA..
Page 22
CFM-20L REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision...
