DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC9081 - To open the appliance, first remove the exhaust filter cover - To be able to remove the upper housing the cord outlet and filter. must be removed using a screwdriver in the lower section (see picture).
Page 3
Service code Description 4222 459 45586 Hinge pin 4222 459 45606 Motor housing top 4222 459 45582 Dustcover assy FC9081 Beige 4322 001 73440 Bufferring front 4222 459 45583 Dustbag detector incl. spring 4322 009 09430 Motor Domel 1761 220-240 V...
