Page 2
Radio waves may affect electro-medical devices. dangerous and may cause fire, damage to this unit, Do not use this unit near medical devices or inside and/or personal injury. Yamaha will not be held medical facilities. responsible for any damage resulting from use of this unit with a voltage other than specified.
– Supplying power to smartphones, tablets, etc. via USB port on the rear panel. – Rich sound by 5cm full-range custom speaker and DSP (Digital Signal Processor) made by Yamaha. – Enhanced treble and thick mid/bass, even when playing a compressed audio source, such as MP3, etc.
NAMES OF PARTS AND THEIR FUNCTIONS ■ Top panel 88.35 MHz Volume 25 D Information display (☞ page 7) A Grille E VOLUME (☞ page 3) Controls volume. F DISPLAY Switches the information display (☞ page 8). G OPTION (CLOCK) •...
NAMES OF PARTS AND THEIR FUNCTIONS Caution A grille is attached to this product to protect the speakers. • Since the grille cloth is made of soft material, it can be easily damaged, so do not scratch it with a sharp object. •...
OPERATION BASIC FUNCTIONS Adjusting the clock A Press and hold OPTION for more than 2 seconds. A , C The clock display flashes. B Adjust the time with TUNING. If you press and hold TUNING, the numbers advance quickly. C Press OPTION. If you want to cancel clock setting mode, press •...
BASIC FUNCTIONS ■ Switching the alarm on/off You can switch the alarm to ON or OFF with the alarm switch. When the alarm is on, the alarm indicator ( lights. Operations during playing back alarm sound At the set time, alarm sound plays back. ■...
LISTENING TO FM STATIONS Tuning radio stations A Press SOURCE to select RADIO. The RADIO indicator lights. If you want to check if this unit is currently receiving DAB or FM, see the information display. B For automatic tuning, press and hold TUNING.
LISTENING TO DAB STATIONS DAB (Digital Audio Broadcasting) and DAB+ use digital signals for clearer sound and more stable reception compared to analog signals. DAB+ is based on the original DAB standard but uses a more efficient audio codec. DAB and DAB+ are broadcast in blocks of data called “ensembles” containing up to several radio stations that are simultaneously broadcast.
Page 10
LISTENING TO DAB STATIONS 1 Signal strength indicator: Shows current signal strength. 2 Secondary indicator: Some stations have sub (secondary) stations. If a secondary station is playing, the secondary indicator is displayed. 3 DAB station name 4 DAB station Information For details, refer to “Switching DAB station information”.
Page 11
LISTENING TO DAB STATIONS Confirming the reception You can confirm the DAB signal level. This is useful when you set the antenna. A Press OPTION when the source is “DAB”. Option menu is shown on the information display. A , B , D B Press TUNING to select “Manual tune”...
LISTENING TO MUSIC FROM YOUR Bluetooth DEVICE This unit provides Bluetooth functionality. You can enjoy wireless music playback from your Bluetooth device (smartphone, digital audio player, etc.). Please also refer to the owner’s manual of your Bluetooth device. Installation Install in a stable place, being careful of the following points: •...
“Bluetooth” on. The Bluetooth connection list will appear in “Devices”. (This procedure or display may differ depending TSX-B15D Yamaha on the type of your iPhone/iPad/iPod touch.) D From the Bluetooth connection list of the connecting device, choose this unit (TSX-B15D Yamaha).
• Bluetooth is a technology for wireless communication between devices within an area of about 10 meters (33 ft) employing the 2.4 GHz frequency band, a band which can be used without a license. • Bluetooth is a registered trademark of the Bluetooth SIG and is used by Yamaha in accordance with a license agreement. Handling Bluetooth communications •...
• This unit does not function as memory USB cable from storage. portable device • Yamaha will not be held responsible for any damage to the portable device or data loss occurred while using this unit. • Disconnect the USB cable immediately after charging completes, since power continues to be supplied to the connected device.
Refer to the table below if the unit does not operate properly. If the problem you are experiencing is not listed below, or if the instruction below does not help, press to enter standby mode, disconnect the power cable, and contact the nearest authorized Yamaha dealer or service center. General Problem...
TROUBLESHOOTING DAB reception Problem Cause Solution Cannot tune into any DAB Full Scan operations were not performed. Perform Full Scan operations (☞ page 7). stations. There is no DAB coverage in your area. Check with your dealer or WorldDMB Online at “http://www.worlddab.org”...
Page 18
Delete any pairing history of TSX-B15D on the iPhone/iPad/iPod touch, then pair with the TSX-B15D again (☞ page 10). No sound is produced or...
For detailed guarantee information about this Yamaha product, and Pan-EEA* and Switzerland warranty service, please either visit the website address below (Printable file is available at our website) or contact the Yamaha representative office for your country. * EEA: European Economic Area...
