Operating Instructions

RDE10.1DHW is a temperature controller that allows you to set the ideal room temperature at the time you want. In addition, it
offers independent control of DHW. There are 2 different switching patterns available: 1 for controlling the heating output and 1
for controlling DHW. Both can be set independently to meet your specific needs. You can either rely on the factory settings or
make your own settings that suit your personal needs.
°C
Temperature
Display
Auto DHW
activated
Weekday (1 = Monday / 7 = Sunday)
Measured room temperature,
setpoints and parameters
Actual room temperature symbol
Real time from 00:00 to 23:59
AM / PM (for 12-hour mode)
Replace batteries
Switching pattern
for DHW and heating
Energy saving mode
Normal operation
Confirmation
Batteries
Commissioning with quick startup
The controller is supplied with factory-set switching patterns, switching times and temperatures. To commission it,
proceed as follows:
Remove the black transit tab from the 2 included batteries. Check to see if the battery holder is in its correct position.
1.5V 'AA'
1.5V 'AA'
The controller switches itself on.
Press button
and then
1...7
1...7
Press button
(1 = Monday through 7 = Sunday).
Press button for the operating mode to select the required operating mode (default mode is automatic mode).
The display shows the
to normal
, energy saving
Press DHW button
The display shows the
automatic
, to permanently OFF and permanently ON
1/4
Operating Instructions
Normal operation
Energy saving mode
Frost protection mode
Automatic mode /
switching pattern settings
Heating ON
1.5V
1.5V
'AA'
'AA'
+
-
+
-
to set the current time of day and confirm by pressing
+
-
and then
to set the current weekday and confirm by pressing
symbol when powered up. The sequence of operating mode is started from automatic
and frost protection
to select the required DHW operating mode (default mode is Auto DHW
symbol when powered up. The sequence of DHW operating mode is started from
CE1B3038en / 19.10.2005
RDE10.1DHW
, or vice versa.
, or vice versa.
Operation
Warmer / colder
setting the
temperature setpoints
and the time of day
Button for operating
mode selection:
Auto (
),
Normal operation (
),
Energy saving mode (
),
Frost protection mode (
DHW control
Settings
Time of day
Weekday
1...7
Auto DHW program
Heating program
3038Z02en
.
).
Building Technologies / HVAC Products
)
,
