Toyota Audio 2000 Avensis Installation Instructions Manual

Hide thumbs

Advertisement

Table of Contents

Toyota Genuine Audio
INSTALLATION INSTRUCTIONS
FOR
T22
R - MMC (07/00)
**
*
3A3RT22/W-1.pdf
TOYOTA MOTOR CORPORATION

Advertisement

Table of Contents
loading

Related Manuals for Toyota Audio 2000 Avensis

Summary of Contents for Toyota Audio 2000 Avensis

  • Page 1 Toyota Genuine Audio INSTALLATION INSTRUCTIONS Avensis (RHD) R - MMC (07/00) 3A3RT22/W-1.pdf TOYOTA MOTOR CORPORATION...

  • Page 3: Table Of Contents

    Avensis (T22) TOYOTA GENUINE AUDIO TABLE OF CONTENTS 1. Audio Application Chart ............................2. Required Parts ..............................3. Combo Installation ............................. 4. 6 Disc CD Changer Installation in glove box ....................5. CD Changer Installation ............................6. MD Changer Installation .............................
  • Page 4 p. 1/4...
  • Page 5 p. 2/4...
  • Page 6 p. 3/4...
  • Page 7 p. 4/4...

  • Page 8: Audio Application Chart

    Avensis (T22) TOYOTA GENUINE AUDIO 2. REQUIRED PARTS JUNCTION CORD 08695-00260 This wire harness splitter is required for certain applications. See Audio Application Chart to find out if this part is needed. GLOVE BOX MOUNTING KIT 08695-05800 This is only required for applications that are mounted in the glove box. See audio application chart for more information.

  • Page 9: Combo Installation

    Avensis (T22) TOYOTA GENUINE AUDIO 3. COMBO INSTALLATION Remove the centre cluster panel Fig. 1 Remove the audio assembly and the cover plate : Screw (4x) Fig. 2 Remove the brackets from the cover plates : Screw (2x) Fig. 3...

  • Page 10: Table Of Contents

    Avensis (T22) TOYOTA GENUINE AUDIO Mount the brackets onto the audio assembly and combo : Screw (4x) NOTE: For part number see audio application chart pages 4 to 8. Fig. 4 Fit the audio assembly and combo Fig. 5 Fit the centre cluster panel Fig.

  • Page 11: Disc Cd Changer Installation In Glove Box

    Avensis (T22) TOYOTA GENUINE AUDIO 4. 6 DISC CD CHANGER INSTALLATION IN GLOVE BOX Remove the under cover : Clip (3x) Fig. 7 Remove the centre cluster panel : Clip (6x) : Hook (2x) NOTE: First pull the cluster forward to...
  • Page 12 Avensis (T22) TOYOTA GENUINE AUDIO Release the glove box buffer hook and pins (2x). Remove the glove box Fig. 9 Cut the foam (*) (10 pieces). (*) Part of mounting kit 08695-05800 Fig. 10 10-00 Avensis (RHD) - 12...
  • Page 13 Avensis (T22) TOYOTA GENUINE AUDIO Locate and remove the wire harness clamp Wrap the wire loom in the foam (*). Route the wire loom beside the ECU Harness beside the ECU Fig. 11 Cut the clamp holder Fig. 12 Attach the square adhesive felt...
  • Page 14 Avensis (T22) TOYOTA GENUINE AUDIO Locate the 4 holes in the instrument panel reinforcement. Screw a tapping screw (*) in the front right hole NOTE: Leave a clearance of about 7 mm. Tap the other 3 holes using the tapping...
  • Page 15 Avensis (T22) TOYOTA GENUINE AUDIO Connect the CD-changer wire to the junction cord (*) and wrap the connectors in the foam (*) . Route the junction cord (*) as shown. Connector (*) Part of mounting kit 08695-05800 Fig. 16 11. Remove the glove box buffer...

  • Page 16: Avensis (Rhd)

    Avensis (T22) TOYOTA GENUINE AUDIO 12. Cut the glove box buffer as shown. Fig. 18 Drill two holes of 10mm as indicated. Marked line Cut the glove box along the marked 2 x Ø10mm line. Cut the saw off Fig. 19 14.
  • Page 17 Avensis (T22) TOYOTA GENUINE AUDIO 15. Refit the glove box : Pin (2x) NOTE: Make sur the glove compartment opens and closes smoothely. Fig. 21 16. Fit the panel (*) to the CD-changer (*) Part of mounting kit 08695-05800 Fig. 22 Refit the trim and removed parts.

  • Page 18: And Combo

    Avensis (T22) TOYOTA GENUINE AUDIO 5. CD CHANGER INSTALLATION Remove the centre cluster panel and combo : Clip (6x) : Hook Fig. 23 Remove the front scuff plate cowl side trim : Nut Fig. 24 Remove the rear scuff plate Fig.
  • Page 19 Avensis (T22) TOYOTA GENUINE AUDIO Remove the centre pillar cover : Clip (3x) Fig. 26 FOR S/D MODEL Remove the rear seat cushion Fig. 27 FOR S/D MODEL Remove the rear seat back : Bolt with washer (2x) CAUTION: Fasten the bolt using specified torque when reassembling.
  • Page 20 Avensis (T22) TOYOTA GENUINE AUDIO FOR L/B MODEL Remove the luggage finish plate and luggage rear trim : Clip (4x) : Clip (2x) Fig. 29 FOR S/D MODEL Remove the luggage finish plate and luggage rear trim : Clip (2x) Fig.
  • Page 21 Avensis (T22) TOYOTA GENUINE AUDIO 10. Route the changer wire and con- nect the junction cord (*). : Tape (3x) (*) Junction cord 08695-00260 to be ordered separately. Fig. 32 11. Route the changer wire : Tape (2x) Fig. 33 FOR S/D MODEL 12.
  • Page 22 Avensis (T22) TOYOTA GENUINE AUDIO FOR L/B OR W/G MODEL 13. Route the changer wire : Tape (5x) Fig. 35 FOR S/D MODEL 14. Remove the luggage carpet before the installation. 15. Attach the tape and spacer the base bracket : Screw (2x) •...
  • Page 23 Avensis (T22) TOYOTA GENUINE AUDIO 16. Locate the base bracket on the Location of floor. Location of : Hook 55mm Luggage inner trim Fig. 37 17. Attach the base bracket on the floor. Fig. 38 18. Fit the side brackets...
  • Page 24 Avensis (T22) TOYOTA GENUINE AUDIO 19. Replace the luggage carpet make slits at two places for the base Wooden board bracket to come through. 50mm ¡ NOTE: ¿ Cut the carpet for the base bracket ¿ 80mm (2 places). 80mm ¿...
  • Page 25 Avensis (T22) TOYOTA GENUINE AUDIO FOR L/B AND W/G MODEL 14. Remove the luggage carpet before installation. 15. Attach the tape and spacer the base bracket : Screw (4x) • Component parts of CD changer Fig. 42 16. Locate the base bracket...
  • Page 26 Avensis (T22) TOYOTA GENUINE AUDIO 17. Attach the base bracket on the floor. Fig. 44 18. Fit the side brackets (2x) to the changer unit : Screw (4x) Fig. 45 19. Replace the luggage carpet Wooden board make slits at two places for the base bracket to come through.
  • Page 27 Avensis (T22) TOYOTA GENUINE AUDIO 20. Reposition the carpet and place the base bracket underneath it. Also make the changer wire go through the carpet CAUTION: Cover the edge of the base bracket where the changer wire crosses it. (See position *A) 21.
  • Page 28 Avensis (T22) TOYOTA GENUINE AUDIO 6. MD CHANGER INSTALLATION Remove the centre cluster panel and combo : Clip (6x) : Hook Fig. 48 Remove the front scuff plate cowl side trim : Nut Fig. 49 Remove the rear scuff plate Fig.
  • Page 29 Avensis (T22) TOYOTA GENUINE AUDIO Remove the centre pillar cover : Clip (3x) Fig. 51 FOR S/D MODEL Remove the rear seat cushion Fig. 52 FOR S/D MODEL Remove the rear seat back : Bolt with washer (2x) CAUTION: Fasten the bolt using specified torque when reassembling.
  • Page 30 Avensis (T22) TOYOTA GENUINE AUDIO FOR L/B MODEL Remove the luggage finish plate and luggage rear trim : Clip (4x) : Clip (2x) Fig. 54 FOR S/D MODEL Remove the luggage finish plate and luggage rear trim : Clip (2x) Fig.
  • Page 31 Avensis (T22) TOYOTA GENUINE AUDIO 10. Route the changer wire : Tape (3x) Fig. 57 11. Route the changer wire : Tape (2x) Fig. 58 12. Route the changer wire : Tape (5x) ADD THE GROUND WIRE TO THE APPROPRIATE GROUND LOCATION.

  • Page 32: Tweeter Installation

    Avensis (T22) TOYOTA GENUINE AUDIO 7. TWEETERS INSTALLATION Tweeters in mirror cover FOR ALL VEHICLES Remove the inside handle bezel Using a screwdriver, raise up the plug. Remove the screw. Using a screwdriver, pry out the bezel. Fig. 60 Remove the screw.
  • Page 33 Avensis (T22) TOYOTA GENUINE AUDIO a) Remove the door trim b) Remove the 2 clips and 6 screws. : Clip (2x) : Screw (6x) c) Pull the door trim upward to remove it. d) Pull out from bottom, then lift the whole panel to remove it the lining.
  • Page 34 Avensis (T22) TOYOTA GENUINE AUDIO 7. Remove the kick panel on both sides. : Nut (1x) Fig. 66 Cut out the “Avensis” template and put it on the A-pillar cover Drill 2 holes of 7 mm. Drill a hole of 32 mm.
  • Page 35 Avensis (T22) TOYOTA GENUINE AUDIO 10. Guide the tweeter wire to the cowl side area. Fig. 69 LEFT HAND SIDE 11. Locate and disconnect the 8P connec- tor (white). 8P connector (white) Fig. 70 Turn the connector so that the wires WIRE SIDE VIEW face you.
  • Page 36 Avensis (T22) TOYOTA GENUINE AUDIO 13. Connect the red wire of the tweeter to the pink wire of the wire harness. WIRE SIDE VIEW pink Splice connector rot / red / rouge Fig. 72 RIGHT HAND SIDE 14. Locate and disconnect the 13P white connector at the cowl side area.
  • Page 37 Avensis (T22) TOYOTA GENUINE AUDIO 16. Connect the red wire of the tweeter to the blue wire of the wire harness. WIRE SIDE VIEW blue Splice connector blue Fig. 75 Avensis (RHD) - 37 10-00...
  • Page 38 Avensis (T22) TOYOTA GENUINE AUDIO NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................10-00 Avensis (RHD) - 38...
  • Page 39 GENUINE PARTS...
