CUTOUT
A
WIDTH
22 5/8"
(57.4 cm)
24" (60 cm)
22 13/16"
(58.0 cm)
28-11/16"
(72.9 cm)
30" (76.2cm)
28 15/16"
(73.5 cm)
34-1/16"
(86.5 cm)
36" (91.4 cm)
34-5/16"
(87.2 cm)
IMPORTANT
Under the cooktop it is necessary to install a
partition as shown in figure 2-3.
Important Preparation Suggestions
1. Chamfer all exposed edges of decorative laminate
to prevent damage from chipping.
2. Radius corners of cutout and file to Insure
smooth edges and prevent corner cracking.
Recommend 1/4"or 3/8"diameter drill In each
corner.
3. Rough edges, inside corners which have not been
rounded and forced fits can contribute to cracking
of the countertop laminate.
B
C
19-1/4"
(49.0 cm)
24"
19-9/16"
(60 cm) min
(49.7 cm)
19-1/4"
(49.0 cm)
30"
19-9/16"
(76.2 cm) min
(49.7 cm)
19-1/4"
(49.0 cm)
36"
19-9/16"
(91.4 cm) min
(49.7 cm)
* NOTE
24" (61 cm) min. clearance if bottom of wood or metal cabinets is protected
by not less than 1/4" (0.6 cm) flame retardant millboard covered with no less
than No. 28 MSG sheet steel 0.015" (0.04 cm) stainless steel, or 0.024"
(0.06 cm) aluminum or 0.020" (0.05cm) copper. 30"(76.2 cm) min.
clearance between top of cooking platform and bottom of unprotected
wood or metal cabinet
D
E
30" (76.2 cm)
18" (45.7 cm)
min.(see note*)
min Height from
Clearance from
countertop to
countertop to
nearest cabinet
unprotected
on either side
overhead
of unit
surface
This cooktop has been designed with wide
tolerances of cut-out to cover possible
replacement with other brands. We recommend
to that you consider the minimum dimension of
cut-out size In the case of new Installation.
Some cut out sizes for possible replacements:
Dim .
Inches
• 24"
22 13/16" x 19-9/16"
• 30"
28-15/16" x 19-9/16"
• 36"
34-5/16" x 19-9/16"
Installation Manual
ENGLISH
F
G
2" (5 cm) min
13" (33 cm)
Clearance from
Depth of
cutout to side
unprotected
wall on the left
overhead
and right of the
cabinets
unit
cm
58.0 x 49.7
73.5 x 49.7
87.2 x 49.7
5
