Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
FJR13AA(C)
LIT-11626-24-62
1CY-28199-11

Advertisement

Table of Contents
loading

Related Manuals for Yamaha FJR13AA

Summary of Contents for Yamaha FJR13AA

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL FJR13AA(C) LIT-11626-24-62 1CY-28199-11...
  • Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 INTRODUCTION EAU10083 Congratulations on your purchase of the Yamaha FJR13AA(C). This model is the result of Yamaha’s vast experience in the production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10193 FJR13AA(C) OWNER’S MANUAL ©2010 by Yamaha Motor Corporation, U.S.A. 1st edition, December 2010 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Storage compartments ....4-19 General maintenance and LABELS ..........1-1 Accessory box ......4-20 lubrication chart ......7-5 Adjusting the headlight beams ..4-21 Removing and installing panels ..7-9 SAFETY INFORMATION ....2-1 Handlebar position ....... 4-21 Checking the spark plugs ....
  • Page 7 Checking the wheel bearings ..7-32 MOTORCYCLE LIMITED Battery ..........7-32 WARRANTY ......10-7 Replacing the fuses ......7-33 YAMAHA EXTENDED SERVICE Headlight bulb ......7-35 (Y.E.S.) ........10-9 Front turn signal light ....7-35 Replacing a rear turn signal light bulb or a tail/brake light bulb ..7-35 Replacing the license plate light bulb ...........7-36...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 1,2,3,4...
  • Page 9 LOCATION OF IMPORTANT LABELS 1 California only 3 California only PRESS. REGULATOR 2 California only LOAD LIMIT 3 kg (7 lbs) 3TB-24877-A0 LOAD LIMIT 1 kg (2 lbs) 4BR-24877-A0...
  • Page 10 LOCATION OF IMPORTANT LABELS NOTICE • Cleaning with alkaline or acid cleaner, 270 kPa, {2.70 kgf/cm }, 39 psi gasoline or solvent will damage windshield. 290 kPa, {2.90 kgf/cm }, 42 psi • Use neutral detergent. 270 kPa, {2.70 kgf/cm }, 39 psi 8ET-2815K-00 290 kPa, {2.90 kgf/cm...

  • Page 11: Safety Information

    SAFETY INFORMATION Safe Riding • Ride where other motorists can EAU10288 Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 12 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective Apparel...
  • Page 13 Yamaha accessories, which are avail- Shifting weights can create a sud- accessories to your motorcycle. Use able only from a Yamaha dealer, have den imbalance. Make sure that ac- extra care when riding a motorcycle been designed, tested, and approved cessories and cargo are securely that has added cargo or accessories.

  • Page 14: Specifications

    SAFETY INFORMATION modifications not specifically recom- clearance or cornering clearance, tor and may limit control ability, mended by Yamaha, even if sold and limit suspension travel, steering therefore, such accessories are installed by a Yamaha dealer. travel or control operation, or ob- not recommended.
  • Page 15 SAFETY INFORMATION Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.

  • Page 16: Description

    DESCRIPTION EAU10410 Left view 1. Accessory box (page 4-20) 9. Shock absorber assembly spring preload adjusting lever (page 4-25) 2. Front fork spring preload adjusting bolt (page 4-23) 10.Air filter element (page 7-19) 3. Front fork rebound damping force adjusting knob (page 4-23) 11.Shift pedal (page 4-11) 4.

  • Page 17: Right View

    DESCRIPTION EAU10420 Right view 11 10 1. Storage compartment (page 4-19) 9. Brake pedal (page 4-12) 2. Fuel tank cap (page 4-13) 10.Shock absorber assembly rebound damping force adjusting knob (page 4-25) 3. Fuse box (page 7-33) 11.Rear brake fluid reservoir (page 7-26) 4.

  • Page 18: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Rear view mirror (page 4-23) 9. Right handlebar switches (page 4-9) 2. Clutch lever (page 4-10) 10.Brake lever (page 4-11) 3. Left handlebar switches (page 4-9) 11.Throttle grip (page 7-20) 4. Clutch fluid reservoir (page 7-26) 12.Main switch/steering lock (page 4-1) 5.

  • Page 19: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS To lock the steering EAU10460 EAU10661 Main switch/steering lock All electrical systems are off. The key can be removed. EWA10061 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in loss of control or an accident.

  • Page 20: Indicator Lights And Warning Lights

    7. Oil level warning light “ ” initially when the key is turned to “ON”, or if the warning light remains on, have EAU11030 a Yamaha dealer check the electrical Turn signal indicator lights “ ” circuit. and “ ”...

  • Page 21: Speedometer

    ABS may not work cor- warning light may flicker when riding on a slope or during sudden acceleration rectly. If this occurs, have a Yamaha or deceleration, but this is not a mal- dealer check the system as soon as possible.

  • Page 22: Tachometer

    INSTRUMENT AND CONTROL FUNCTIONS The multi-function display is equipped EAU11872 EAU4029A Tachometer Multi-function display with the following: an odometer two tripmeters (which show the distance traveled since they were last set to zero) a fuel reserve tripmeter (which shows the distance traveled on the fuel reserve) a clock a fuel meter...
  • Page 23 INSTRUMENT AND CONTROL FUNCTIONS Odometer and tripmeter modes case, pushing the select button switch- Clock es the display between the various trip- meter and odometer modes in the following order: Trip F → ODO → Trip 1 → Trip 2 → Trip When selecting “Trip 1”, “Trip 2”...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS Fuel meter segments will start flashing. If this oc- ECA10021 NOTICE curs, have a Yamaha dealer check the electrical circuit. Do not continue to operate the en- gine if it is overheating. Coolant temperature meter Transmission gear display 1.
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS Ambient temperature, instanta- Ambient temperature mode 20 km/h (12.5 mi/h)] or when neous fuel consumption and aver- stopped at traffic signals, railroad age fuel consumption modes crossings, etc. Instantaneous fuel consumption mode 1. Ambient temperature This display shows the ambient tem- 1.
  • Page 26 If the multi-function display indicates ECA15473 any error codes, note the code number, NOTICE and then have a Yamaha dealer check If there is a malfunction, “– –.–” will the vehicle. be continuously displayed. Have a ECA11790 Yamaha dealer check the vehicle.

  • Page 27: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS Right EAU12348 EAU12493 Handlebar switches Windshield position adjusting switch “ ” Left To move the windshield up, push this switch in direction (a). To move the windshield down, push the switch in di- rection (b). 1. Engine stop switch “ ”...

  • Page 28: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS The hazard lights are used in case of EAU12660 EAU12830 Engine stop switch “ ” Clutch lever an emergency or to warn other drivers Set this switch to “ ” before starting when your vehicle is stopped where it the engine.

  • Page 29: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS Make sure that the appropriate setting EAU12871 EAU26823 Shift pedal Brake lever on the adjusting dial is aligned with the The brake lever is located at the right arrow mark on the clutch lever. handlebar grip. To apply the front The clutch lever is equipped with a brake, pull the lever toward the handle- clutch switch, which is part of the igni-...

  • Page 30: Brake Pedal

    EAU39540 EAU39533 Brake pedal can be felt at the lever and pedal, The Yamaha ABS (Anti-lock Brake but these do not indicate a mal- System) features a dual electronic con- function. trol system, which acts on the front and When the ABS is activated, the rear brakes independently.

  • Page 31: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAU13074 Fuel tank cap The fuel tank cap cannot be closed un- less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11091 WARNING Make sure that the fuel tank cap is properly closed after filling fuel.

  • Page 32: Fuel

    EWA15151 refueling, be sure to insert the WARNING Your Yamaha engine has been de- pump nozzle into the fuel tank filler Gasoline is poisonous and can signed to use regular unleaded gaso- hole. Stop filling when the fuel cause injury or death.

  • Page 33: Fuel Tank Breather/Overflow Hose

    Do not park the vehicle near ohol containing methanol possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn. or vehicle performance problems. 1. Fuel tank breather/overflow hose...

  • Page 34: Seats

    INSTRUMENT AND CONTROL FUNCTIONS To install the passenger seat ECA10701 EAU39493 Seats NOTICE 1. Insert the projections on the rear of Use only unleaded gasoline. The use the passenger seat into the seat Passenger seat holders as shown, and then push of leaded gasoline will cause unre- the front of the seat down to lock it pairable damage to the catalytic...

  • Page 35: Adjusting The Rider Seat Height

    INSTRUMENT AND CONTROL FUNCTIONS 2. Install the passenger seat. EAU39632 Adjusting the rider seat height The rider seat height can be adjusted to Make sure that the seats are prop- one of two positions to suit the rider’s erly secured before riding. preference.
  • Page 36 INSTRUMENT AND CONTROL FUNCTIONS 6. Align the projection on the bottom of the rider seat with the “H” posi- tion slot, and then push the rear of the seat down to lock it in place as shown. 1. Rider seat height position adjuster 1.

  • Page 37: Storage Compartments

    INSTRUMENT AND CONTROL FUNCTIONS 6. Align the projection on the bottom EAU40252 Storage compartments of the rider seat with the “L” posi- This vehicle is equipped with two stor- tion slot, and then push the rear of age compartments. the seat down to lock it in place as Storage compartment A is located un- shown.

  • Page 38: Accessory Box

    INSTRUMENT AND CONTROL FUNCTIONS Do not exceed the maximum EAU39480 Accessory box load of FJR13AA 212 kg (467 lb) The accessory box is located beside FJR13AAC 211 kg (465 lb) for the meter panel. the vehicle. To open the accessory box 1.

  • Page 39: Adjusting The Headlight Beams

    To raise the headlight beams, turn the Do not exceed the maximum knobs in direction (a). To lower the load of FJR13AA 212 kg (467 lb) headlight beams, turn the knobs in di- FJR13AAC 211 kg (465 lb) for rection (b).

  • Page 40: Opening And Closing The Cowlings

    INSTRUMENT AND CONTROL FUNCTIONS EAU39621 Opening and closing the cowl- ings The cowlings can be tilted back 30 mm (1.18 in) for added ventilation to suit the riding conditions. 1. Quick fastener screw 1. Quick fastener screw 2. Pull the cowling to the open posi- 2.

  • Page 41: Rear View Mirrors

    INSTRUMENT AND CONTROL FUNCTIONS EAU39671 EAU14733 Rear view mirrors Adjusting the front fork The rear view mirrors of this vehicle can EWA10180 WARNING be folded forward or backward for park- ing in narrow spaces. Fold the mirrors Always adjust both fork legs equal- back to their original position before ly, otherwise poor handling and loss riding.
  • Page 42 INSTRUMENT AND CONTROL FUNCTIONS Spring preload setting: Rebound damping setting: Compression damping setting: Minimum (soft): Minimum (soft): Minimum (soft): 17 click(s) in direction (b)* 21 click(s) in direction (b)* Standard: Standard: Standard: 12 click(s) in direction (b)* 12 click(s) in direction (b)* Maximum (hard): Maximum (hard): Maximum (hard):...

  • Page 43: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS EAU14916 Adjusting the shock absorber assembly This shock absorber assembly is equipped with a spring preload adjust- ing lever and a rebound damping force adjusting knob. ECA16570 NOTICE To avoid damaging the mechanism, 1. Spring preload adjusting lever 1.

  • Page 44: Grip Warmer Adjusting Knob

    “OFF” to turn the grip warmers off. the engine is running. sembly yourself. Take the shock Use the grip warmer adjusting knob, lo- absorber assembly to a Yamaha cated near the accessory box, to adjust dealer for any service. When the vehicle is stopped or travel- the grip warmer temperature.

  • Page 45: Sidestand

    EAU15305 EAU44902 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left side The ignition circuit cut-off system (com- function properly. of the frame. Raise the sidestand or...
  • Page 46 ”. stand during this inspection. • 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Push the start switch. Does the engine start? With the engine still running: The neutral switch may not be working correctly.

  • Page 47: Auxiliary Dc Jack

    INSTRUMENT AND CONTROL FUNCTIONS EAU39655 Auxiliary DC jack EWA14360 WARNING To prevent electrical shock or short- circuiting, make sure that the cap is installed when the auxiliary DC jack is not being used. ECA15431 NOTICE 1. Auxiliary DC jack cap The accessory connected to the 4.

  • Page 48: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-17 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 49 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-20, 7-28 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-27 •...
  • Page 50 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-27 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 51: Operation And Important Riding Points

    Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this EWA10271 position.

  • Page 52: Shifting

    NOTICE tral position. The neutral indicator light should come on. If not, ask a Even with the transmission in Yamaha dealer to check the elec- the neutral position, do not trical circuit. coast for long periods of time 3. Start the engine by pushing the with the engine off, and do not start switch.

  • Page 53: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped.

  • Page 54: Parking

    Do not park on a slope or on soft cur during the engine break-in ground, otherwise the vehicle period, immediately have a may overturn, increasing the Yamaha dealer check the vehi- risk of a fuel leak and fire. cle. Do not park near grass or other flammable...

  • Page 55: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-2 for more in- graphical location, and individual use, dealers are trained and equipped to...

  • Page 56: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 57: Periodic Maintenance Chart For The Emission Control System

    From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601...
  • Page 58 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...

  • Page 59: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 60 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 61 16000 mi (25000 km) or 24 months. Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly.
  • Page 62 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 63: Removing And Installing Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1.
  • Page 64 PERIODIC MAINTENANCE AND ADJUSTMENT 3. Pull the bottom of the panel out- ward, pull the front of the panel downward, and then slide the pan- el forward to release it in the rear as shown. 1. Panel B 1. Panel B 2.
  • Page 65 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Panel C 1. Panel B 1. Panel B 2. Rear cowling 1. Panel C 1. Panel C 1. Panel B 2. Rear cowling 2. Fuel tank side cover To install a panel 1. Insert the rear of the panel into the 2.

  • Page 66: Checking The Spark Plugs

    0.7–0.8 mm (0.028–0.031 in) such problems yourself. Instead, have 1. Panel C a Yamaha dealer check the vehicle. Clean the surface of the spark plug 3. Install the bolts and the quick fas- If a spark plug shows signs of electrode gasket and its mating surface, and then tener screws.

  • Page 67: Canister (For California Only)

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU19681 EAU19886 Tightening torque: Canister (for California only) Engine oil and oil filter car- Spark plug: tridge 13 Nm (1.3 m·kgf, 9.4 ft·lbf) The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- If a torque wrench is not available when tridge replaced at the intervals speci-...
  • Page 68 4. If the engine oil is below the mini- An oil filter wrench is available at a 1. Engine oil filler cap mum level mark, add sufficient oil Yamaha dealer. 2. Engine oil drain bolt of the recommended type to raise 3. Gasket it to the correct level.
  • Page 69 PERIODIC MAINTENANCE AND ADJUSTMENT ECA11620 Tightening torque: NOTICE Oil filter cartridge: In order to prevent clutch slip- 17 Nm (1.7 m·kgf, 12 ft·lbf) page (since the engine oil also 8. Install the engine oil drain bolt and lubricates the clutch), do not its new gasket, and then tighten mix any chemical additives.

  • Page 70: Final Gear Oil

    If any or remains on even if the oil level is leakage is found, have a Yamaha deal- correct, immediately turn the engine er check and repair the vehicle. In addi- off and have a Yamaha dealer check tion, the final gear oil level must be the vehicle.

  • Page 71: Coolant

    1. Place the vehicle on a level sur- and lubrication chart. face. Recommended final gear oil: 2. Place an oil pan under the final Yamaha genuine shaft drive gear oil EAU40154 To check the coolant level gear case to collect the used oil. SAE 80 API GL-5 1.

  • Page 72: Changing Coolant

    Have a hot. NOTICE: If coolant is [EWA15161] Yamaha dealer change the coolant. not available, use distilled water WARNING! Never attempt to remove or soft tap water instead. Do not the radiator cap when the engine is use hard water or salt water hot.

  • Page 73: Cleaning The Air Filter Element

    PERIODIC MAINTENANCE AND ADJUSTMENT out with compressed air as shown. EAU20473 Cleaning the air filter element If the air filter element is damaged, The air filter element should be cleaned replace it. or replaced at the intervals specified in the periodic maintenance and lubrica- tion chart.

  • Page 74: Checking The Engine Idling Speed

    The throttle grip free play should mea- 9. Install the panel. sure 3.0–5.0 mm (0.12–0.20 in) at the inner edge of the throttle grip. Periodi- cally check the throttle grip free play and, if necessary, have a Yamaha deal- er adjust it. 7-20...

  • Page 75: Valve Clearance

    Rear: from occurring, the valve clearance the specified tires. 290 kPa (2.90 kgf/cm², 42 psi) must be adjusted by a Yamaha dealer FJR13AA 90–212 kg (198–467 lb) at the intervals specified in the periodic Tire air pressure FJR13AAC 90–211 kg (198–465 maintenance and lubrication chart.
  • Page 76 EWA10481 characteristics. WARNING in it, or if the sidewall is cracked, con- tact a Yamaha dealer immediately and The front and rear tires should have the tire replaced. be of the same make and de- sign, otherwise the handling...

  • Page 77: Cast Wheels

    The wheel rims should be checked Use only the specified replace- model by Yamaha Motor Co., Ltd. for cracks, bends, warpage or oth- ment tires. Other tires may run er damage before each ride. If any...

  • Page 78: Clutch Lever

    If there is air 1. No brake lever free play in the hydraulic system, have a Yamaha dealer bleed the system be- There should be no free play at the fore operating the motorcycle.

  • Page 79: Brake Light Switches

    EAU22500 Rear brake pads fect. If necessary, have a Yamaha deal- ified in the periodic maintenance and er adjust the brake light switches. lubrication chart. EAU43431 Front brake pads 1.

  • Page 80: Checking The Brake And Clutch Fluid Levels

    PERIODIC MAINTENANCE AND ADJUSTMENT Clutch When checking the fluid level, EAU40270 Checking the brake and clutch make sure that the top of the brake fluid levels or clutch fluid reservoir is level. Use only the recommended quality Front brake brake fluid, otherwise the rubber seals may deteriorate, causing leakage and poor braking or clutch performance.

  • Page 81: Changing The Brake And Clutch Fluids

    ABS hy- clutch fluids cables draulic unit valves. Have a Yamaha dealer change the The operation of all control cables and Brake fluid may deteriorate paint- brake and clutch fluids at the intervals the condition of the cables should be ed surfaces or plastic parts.

  • Page 82: Checking And Lubricating The Throttle Grip And Cable

    Brake pedal be checked before each ride. In addi- tion, the cable should be lubricated by a Yamaha dealer at the intervals speci- fied in the periodic maintenance chart. The throttle cable is equipped with a rubber cover. Make sure that the cover is securely installed.

  • Page 83: Checking And Lubricating The Brake And Clutch Levers

    EWA10741 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground The operation of the brake and clutch and distract the operator, resulting levers should be checked before each in a possible loss of control.

  • Page 84: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- The pivoting points of the rear suspen- ed by a Yamaha dealer at the intervals sion must be lubricated by a Yamaha specified in the periodic maintenance dealer at the intervals specified in the and lubrication chart.

  • Page 85: Checking The Front Fork

    2. Hold the lower ends of the front fork does not operate smoothly, tion. WARNING! To avoid injury, fork legs and try to move them for- have a Yamaha dealer check or re- securely support the vehicle so ward and backward. If any free pair it.

  • Page 86: Checking The Wheel Bearings

    EWA10760 WARNING To charge the battery Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the burns.

  • Page 87: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT battery tends to discharge more quickly is turned to “OFF”, then con- EAU23659 Replacing the fuses if the vehicle is equipped with optional nect the positive lead before The main fuse, the fuse boxes and the electrical accessories.
  • Page 88 4. If the fuse immediately blows [EWA15131] again, have a Yamaha dealer Specified fuses: check the electrical system. Main fuse: 50.0 A Headlight fuse: 25.0 A...

  • Page 89: Headlight Bulb

    If a front turn signal light does not come light bulb or a tail/brake light Yamaha dealer check its electrical cir- on, have a Yamaha dealer check its bulb cuit or replace the bulb. electrical circuit or replace the bulb.

  • Page 90: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT 5. Install the socket (together with the EAU24313 Replacing the license plate bulb) by turning it clockwise. light bulb 6. Install the passenger seat. 1. Remove the license plate light unit by removing the screws. 1. License plate light bulb 2.

  • Page 91: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 92: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 93 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 94: Motorcycle Care And Storage

    Cleaning ble. Rust and corrosion can develop matte colored finished parts. Be ECA10772 sure to consult a Yamaha dealer for even if high-quality components are NOTICE used. A rusty exhaust pipe may go un- advice on what products to use be-...
  • Page 95 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.

  • Page 96: Storage

    WARNING ing it with a tarp, while it is still Contaminants on the brakes or tires Consult a Yamaha dealer for ad- wet, will allow water and humid- can cause loss of control. vice on what products to use.
  • Page 97 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 98: Specifications

    Clutch: Final gear oil: 1298 cm³ Clutch type: Type: Bore × stroke: Wet, multiple-disc Yamaha genuine shaft drive gear oil SAE 79.0 × 66.2 mm (3.11 × 2.61 in) Transmission: 80 API GL-5 Compression ratio: Primary reduction ratio: Quantity: 10.80 : 1 1.563 (75/48)
  • Page 99 2.529 (43/17) Loading: Wheel type: 2nd: Maximum load: Cast wheel 1.773 (39/22) FJR13AA 212 kg (467 lb) Rim size: 3rd: FJR13AAC 211 kg (465 lb) 17M/C x MT5.50 1.348 (31/23) (Total weight of rider, passenger, cargo and Unified brake system:...
  • Page 100 SPECIFICATIONS Rear suspension: Neutral indicator light: Auxiliary DC jack fuse: 3.0 A Type: High beam indicator light: Backup fuse: Swingarm (link suspension) 10.0 A Spring/shock absorber type: Oil level warning light: Coil spring/gas-oil damper Wheel travel: Turn signal indicator light: 125.0 mm (4.92 in) Electrical system: Engine trouble warning light:...

  • Page 101: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 102 This informa- illustration. This label shows specifica- tion will be needed when ordering tions related to exhaust emissions as spare parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...

  • Page 103: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 104: Motorcycle Noise Regulation

    CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 105: Maintenance Record

    CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 106 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...

  • Page 107: Yamaha Motor

    CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period...
  • Page 108 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.

  • Page 109: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 110 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 111 INDEX Engine oil and oil filter cartridge ....7-13 Maintenance and lubrication, periodic ..7-5 Engine stop switch ........4-10 Maintenance, emission control system ... 7-3 ABS ............4-12 Engine trouble warning light ....4-3 Maintenance record ......10-5 ABS warning light ........4-3 Matte color, caution ........
  • Page 112 INDEX Storage compartments......4-19 Swingarm pivots, lubricating ....7-30 Tachometer..........4-4 Throttle grip and cable, checking and lubricating ........... 7-28 Throttle grip free play, checking.... 7-20 Tires ............7-21 Tool kit ............ 7-2 Troubleshooting ........7-37 Troubleshooting charts ......7-38 Turn signal indicator lights ......
  • Page 114 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2011.01-0.4×1 CR...
