The computer automatically recognizes the additional memory when you turn on the computer.

Removing the front panel

To access the internal components of the computer, such as the hard drive and memory module, you
must remove the front panel.
1. Push up on the bottom corners of the cable cover (1) and rotate the cover off the unit (2) to
expose two of the screws that must be loosened to remove the front panel.
2. Disconnect all cables from the rear I/O connectors, including the power cord.
3. Loosen the two captive screws in the top corners of the panel and the two captive screws in the
bottom corners of the panel.
NOTE:
panel is no longer secured by them.
The captive screws are not removable. They can only be loosened to the point that the
Removing the front panel 19
