OWNER'S MANUAL
SoundPlate
Please read this manual carefully before operating
your set and retain it for future reference.
LAP250H
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG LAP250H

Summary of Contents for LG LAP250H

  • Page 1 OWNER’S MANUAL SoundPlate Please read this manual carefully before operating your set and retain it for future reference. LAP250H www.lg.com...
  • Page 2 Getting Started Safety Information WARNING: Do not install this equipment in a confined space such as a book case or similar unit. CAUTION: Do not block any ventilation openings. CAUTION Install in accordance with the manufacturer’s instructions. RISK OF ELECTRIC SHOCK Slots and openings in the cabinet are provided for DO NOT OPEN ventilation and to ensure reliable operation of the...

  • Page 3: Important Safety

    Getting Started This device is equipped with a portable battery or 11. Only use attachments/accessories specified by accumulator. the manufacturer. Safety way to remove the battery from the 12. Use only with the cart, stand, tripod, bracket, or equipment: Remove the old battery or battery table specified by the manufacturer, or sold with pack, follow the steps in reverse order than the apparatus.
  • Page 4 Responsible Party : equipment generates, uses, and can radiate radio frequency energy and, if not installed and used LG Electronics USA, Inc. 1000 Sylvan Avenue in accordance with the instructions, may cause Englewood Cliffs, NJ 07632 harmful interference to radio communications.

  • Page 5: Table Of Contents

    – DRC (Dynamic Range Control) – AV Sync – Turn off the sound temporarily – Displaying file and input source – Sleep timer setting – Using your TV remote control – AUTO POWER On/Off – Auto function change LG Sound Sync...

  • Page 6: Getting Started

    Notebook, etc) Remote control (1) Batteries (2) LG Sound Sync Controls volume level of this unit by the remote control of your LG TV that is compatible with LG Sound Sync. Power cord (1) Optical cable (1) Introduction Symbols used in this manual Note Indicates special notes and operating features.

  • Page 7: Remote Control

    Getting Started Remote control • • • • • • • • • • a • • • • • • • • • 1 (Power) : Switches the unit ON or OFF. / Switches to the standby mode. FUNC : Selects the function and the input source. (Mute) : Mutes the sound.

  • Page 8: Front Panel

    Getting Started Front panel A 1/! (Standby/On) D Standby LED It lights up in red on standby mode. B F (Function) Selects the function and input source. E Display window C p/o (Volume) F Remote sensor Adjusts volume level.

  • Page 9: Rear Panel

    Getting Started Rear panel A AC IN D USB port B HDMI OUT (TV ARC) : HDMI output E OPTICAL IN : Optical input C HDMI IN : HDMI input F PORTABLE IN : Portable input...

  • Page 10: Setting Up The Unit

    Getting Started > Caution Setting up the unit y Be careful not to make scratches on the surface of the Unit /Sub-Woofer when This unit is designed to be positioned under your installing or moving them. y Do not try to set up this unit alone. It may Before setting up this system with your TV, make need at least 2 persons to lift your TV.
  • Page 11 You can connect a USB in a way that is easier DVD player. You should also connect a power and more convenient by using a USB extension cord supplied as an accessory. cable and purchase the cable from nearest LG Electronic Service point. > Caution...
  • Page 12 Getting Started > Caution y Do not place your TV on the edge of this unit. Otherwise it may result in a personal injury and/or property damages. y If your TV is over recommended weight (max 39.6 lbs (18 kg)) or has a Base larger in area than the Unit do NOT place TV on the Unit.

  • Page 13: Connecting

    Connecting Connecting to your TV Using an HDMI cable If you connect this unit to a TV that supports HDMI CEC and ARC (Audio Return Channel), you can Please connect with this unit and TV using the enjoy the TV audio through the speakers of this unit optical digital cable or HDMI cable considering the without connecting the optical cable.

  • Page 14: What Is Simplink

    HDMI IN of the TV that supports ARC function using an HDMI cable. ※ Trade names for CEC are SimpLink (LG) , Anynet+ (Samsung), BRAVIA Sync/ Link (Sony), EasyLink - You can connect only one unit to TV compatible (Philips), EZ-Sync/ VIERA Link (Panasonic), etc.

  • Page 15: Additional Information For Hdmi

    Connecting Note Additional information for y If a connected HDMI device does not accept HDMI the audio output of the player, the HDMI device’s audio sound may be distorted or y When you connect an HDMI or DVI compatible may not output. device make sure of the following: y Changing the resolution when the - Try switching off the HDMI/DVI device and...

  • Page 16: Optional Equipment Connection

    Connecting Optional equipment For enjoying both sound and picture You can enjoy both sound and picture from the connection external device you connect. HDMI connection You can enjoy the sound and picture from HDMI connection on external device. For enjoying sound only You can enjoy the sound from the external device you connect.

  • Page 17: Optical In Connection

    Connecting OPTICAL IN connection PORTABLE IN connection Listens to sound from TV, DVD or Digital Device with 2.1 or 2 ch mode. To the optical output jack of external device 1. Connect the OPTICAL IN jack on the back of the unit to optical out jack of your TV (or digital Listening to music from your device etc.) by using an optical cable.

  • Page 18: Usb Connection

    Connecting USB connection y Depending on some devices, it may not available to recognize the followings on this unit. Connect a USB device to the Unit. - External HDD - Card readers - Locked devices - Hard type USB devices - USB hub - Using USB extension cable - iPhone/iPod/iPad...
  • Page 19 Connecting Note y Folders and files on the USB are recognized as below. : Folder *ROOT : File y If there is no file in a folder, the folder will not appear. y File will be played from file $A to file $J one by one.

  • Page 20: Operating

    Operating Note Basic operations y The resume point may be cleared when you pull out the power cord or removing the USB device from the unit. USB operation y Repeat/Random playback operates as 1. Connect the USB device to the USB port. follows.

  • Page 21: Other Operations

    Operating Other operations Displaying file and input source You can display various information of the input DRC (Dynamic Range Control) source by pressing INFO. USB : File information contained on a USB (MP3/ Make the sound clear when the volume is turned WMA/OGG/FLAC/WAV) down and prevent sudden increase of sound (Dolby Digital only).

  • Page 22: Using Your Tv Remote Control

    Supported TV brands function, it will be automatically turned off if there is no signal for a certain period of time Panasonic Philips Samsung from the TV connected by LG Sound Sync (Optical/Wireless). Sharp Sony Toshiba Vizio y After the unit is turned on by AUTO POWER...

  • Page 23: Auto Function Change

    When LG TV signal comes in When you turn on your LG TV connected by LG Sound Sync (Wireless connection), this unit changes the function to LG TV. You can hear the sound from your TV. Note y To change to optical function, it needs 5 seconds of no signal.

  • Page 24: Lg Sound Sync

    Operating LG Sound Sync With wired connection 1. Connect your LG TV to the unit by using an optical cable. You can control some functions of this unit by your TV's remote control with LG Sound Sync. The Feature is only compatible with LG TV’s that support LG Sound Sync.

  • Page 25: With Wireless Connection

    "PAIRED" appears on the display window for or you connect the Bluetooth in the other rooms. about 3 seconds and then you can see "LG TV" Connecting individual devices under Bluetooth® on the display window if connecting normally wireless technology does not incur any charges.

  • Page 26: Listening To Music Stored On The Bluetooth Devices

    Bluetooth device, a list of the devices found may appear in the Bluetooth device display depending on the type of Bluetooth device. Your unit appears as “LG LAP250H (XX)”. 3. Select “LG LAP250H (XX)”. Note y XX means the last two digits of Bluetooth address.

  • Page 27: Using Bluetooth App

    Operating Note Using Bluetooth App y When using Bluetooth® technology, you have to make a connection between the Note unit and the Bluetooth device as close as possible and keep the distance. Only Android OS is available to use “Music Flow However you may experience issues in the Bluetooth”...

  • Page 28: Activate Bluetooth With "Music Flow Bluetooth" App

    Operating Note Install “Music Flow Bluetooth” App through “Google Android Market y “Music Flow Bluetooth” app will be available in the software version as follow; (Google Play Store)” - Android O/S : Ver 4.0.3 (or later) 1. Tap the “Google Android Market (Google Play y If you use “Music Flow Bluetooth”...

  • Page 29: Sound Adjustment

    Operating Sound adjustment Adjust volume level automatically This unit supports Auto volume function that Setting sound effect automatically adjusts the volume level. When the output sound is too loud or too low, This system has a number of pre-set surround press AUTO VOL on the remote control.

  • Page 30: Troubleshooting

    Check the state of SIMPLINK and turn off SIMPLINK. work. y Depending on the connected device, this function may not operate. y Check whether your LG TV supports LG Sound Sync. LG Sound Sync does y Check connection of LG Sound Sync (Optical or wireless).
  • Page 31 Troubleshooting PROBLEM CAUSE & CORRECTION Check the details below and adjust the unit according to them. y Switch [ON] state of DRC function to [OFF] by using remote controller. y With the unit connected with TV, change the AUDIO DIGITAL OUT setting on TV When you feel the Setup Menu from [PCM] to [AUTO] or [BITSTREAM].

  • Page 32: Appendix

    Manufactured under license from Dolby by the Bluetooth® SIG, Inc. and any use of such Laboratories. Dolby and the double-D symbol marks by LG Electronics is under license. are trademarks of Dolby Laboratories. Other trademarks and trade names are those of their respective owners.

  • Page 33: Specifications

    Appendix Specifications General (LAP250H) Power requirements 120 V ~ 60 Hz Power consumption 20 W 530 mm x 60 mm x 350 mm Dimensions (W x H x D) (20.9 inch x 2.4 inch x 13.8 inch) Net Weight (Approx.) 5.3 kg (11.7 lb)

  • Page 34: Maintenance

    Appendix Maintenance Handling the unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Keeping the exterior surfaces clean y Do not use volatile liquids such as insecticide spray near the unit.
