Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
Features
Iron, Azur
- Careeza soleplate
- Max. steam output 60 g/min
- Cord length 1.9 m
Boiler
- Inox boiler
- Capacity 1 litre
Published by Philips Domestic Appliances and Personal Care
4322 277 00840
02/03
Boiler steam iron Provapor
TECHNICAL INFORMATION
Voltage
Frequency
Power consumption : Iron
Water advice
Soleplate
Careeza is a multi layer chemical substance that gives an excellent
gliding over various fabrics and better care for the garments.
This product meets the requirement regarding
interference suppression on radio and television.
Printed in the Netherlands
© Copyright reserved
GC 6022
: 220 - 240 V
: 50 - 60 Hz
: 800 W
Boiler
: 1200 W
Pressure : 2.5 bar
: Suitable for tap water use. However if the
tap water in your area is very hard, we
advise you to mix it with a equal portion
of distilled water or to use distilled water
only.
Subject to modification
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Related Manuals for Philips GC 6022
Iron Philips GC6068/02 User Manual
Iron sys.pro vapor hv-solg-fu (70 pages)
Iron Philips GC6026/03 User Manual
Iron sys. blue/white (68 pages)
Iron Philips GC6028/03 User Manual
Steam iron provapor (109 pages)
Iron Philips GC6268/02 User Manual
Iron sys.pro vapor hv-solg-fu (82 pages)
Iron Philips GC6268/22 User Manual
Iron sys.pro vapor special (42 pages)
Iron Philips Provapor GC6268 User Manual
(82 pages)
Iron Philips Provapor GC6026 Manual
(66 pages)
Iron Philips Provapor GC6026 User Manual
(118 pages)
Iron Philips GC6048/03 User Manual
Iron sys. supervapor (60 pages)
Iron Philips GC6007/03 User Manual
Iron sys.provapor azur exc. anti calc (52 pages)
Iron Philips GC6002/03 User Manual
Iron sys.provapor elance inox boiler (56 pages)
Iron Philips HI 915 Operating Instructions Manual
(52 pages)
Iron Philips Provapor excel pro GC 6007 Service Manual
(6 pages)
Iron Philips GC 6012 Service Manual
Provapor new profi (6 pages)
Iron Philips Supervapor GC6046 Manual
(101 pages)
Iron Philips GC 6005 Service Manual
(6 pages)
Summary of Contents for Philips GC 6022
Page 1
This product meets the requirement regarding interference suppression on radio and television. Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification...
Page 2
EXPLODED VIEW IRON...
Page 3
PARTS LIST IRON Description Service code Dial 9965 000 13233 Backplate 9965 000 13234 Inlay 9965 000 13235 Iron Lamp 9965 000 01686 Micro switch 9965 000 01888 Iron Handle 9965 000 13236 Intermediate cable + microswitch 9965 000 13237 Swivel 9965 000 13238 Thermostat bush...
Page 4
DISASSEMBLY ADVISE IRON REPLACE DIAL 1 REPLACE INLAY 3 REPLACE IRON REPLACE HANDLE 6 IRON SKIRT 10 IRON LAMP 4 disassemble DIAL 1 SOLEPLATE UNIT 11 MICRO SWITCH 5 remove screw A disassemble DIAL 1 remove connection remove screw A remove hose remove...
Page 5
EXPLODED VIEW STAND...
Page 6
Inox boiler unit 9965 000 13250 Electrovalve 4822 218 11561 Main switch 9965 000 13251 Note: pressure fi xation rubber Superior stand printed GC 6022 9965 000 13257 through the tray. Inferior stand 9965 000 13258 SUPERIOR STAND PRINTED 29...
