WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.
Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.
LEAD-FREE SOLDER This product is manufactured using lead-free solder as a part of a movement within the consumer products industry at large to be environmentally responsible. Lead-free solder must be used in the servicing and repair of this product. WARNING: This product is manufactured using lead free solder.
SAFETY INSTRUCTION WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" INSTRUCTIONS BELOW. Safety Precaution WARNING: SERVICING SHOULD NOT BE ATTEMPTED BY ANYONE UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER. THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED BEFORE SERVICING THIS CHASSIS.
Page 6
6. Always use the replacement parts specified for the particular model when making repairs. The parts used in products require special safety characteristics such as inflammability, voltage resistance, etc. therefore, use only replacement parts that have these same characteristics. Use only the specified parts when the mark is indicated in the circuit diagram or parts list.
Page 7
Resistance values in orms (Ω). V: Voltmeter or oscilloscope (r.m.s. or peak reading) Input resistance : 1 MΩ Input capacitance : 200 pF Frequency range : 15 Hz to 1 MHz and d.c. respectively Note: Appropriate measures should be taken to obtain the correct value in case of non sinusoidal waveforms.
- for d.c. : = 1.0 V Note: The limit values of = 0.35 V (peak) for a.c. and = 1.0 V for d.c. correspond to the values 0.7 mA (peak) a.c. and 2.0 mA d.c. Product Safety Notice Many electrical and mechanical parts in this chassis have special safety-related characteristics.
SAFETY INSTRUCTION Handling the LCD Module Safety Precaution In the event that the screen is damaged or the liquid crystal (fluid) leaks, do not breathe in or drink this fluid. Also, never touch this fluid. Such actions could cause toxicity or skin irritation. If this fluid should enter the mouth, rinse the mouth thoroughly with water.
Page 10
because any impact can adversely affect the performance. Also use caution when handling the polarized screen because it can easily be damaged. 3. If the panel surface becomes soiled, wipe with cotton or a soft cloth. If this does not remove the soiling, breathe on the surface and then wipe again.
Page 11
6. CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static electricity. When handling the module, use a wrist ground or anchor ground. 7. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for an extended period of time.
Page 12
9. Do not disassemble the LCD module. Such actions could result in improper operation. 10. When transporting the LCD module, do not use packing containing epoxy resin (amine) or silicon resin (alcohol or oxim). The gas generated by these materials can cause loss of polarity.
Page 14
AV BOARD SIGNAL BOARD PANEL DDR RAM FLI8538 CORTEZ Plus VBI Data Processor PANEL I/F DCDi Video Input Analog MADi Decoder Terminal Front Scaling (Audio) (16port) CVBS(L/R) S-VIDEO(L/R) YCbCr(L/R) Channel Standby Process uCON Digital Input A EEPROM PC_IN(L/R) Digital Input B Micro- processor IR I/F...
SCHEMATIC DIAGRAM Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 16
Unless otherwise noted in schematic, all capacitor values less than 1 are expressed in µF, and the values more than 1 in pF. All capacitors are ceramic 50 V, unless otherwise noted as the following marks. = Electrolytic capacitor = Mylar capacitor 3.
ADJUSTMENT Service Mode Entering to Service Mode 1. Press button once on remote control. ↓ 2. Press button again and keep in pressing. ↓ Service Mode display 3. While pressing the button, press MENU button on TV set.
Page 89
Displaying the Adjustment Menu Press MENU button on TV. Service Mode Press ↑ ↓ Press Adjustment Mode...
Page 90
Key Function in the Service Mode The following key entry during display of adjustment menu provides special functions. CAUTION: Never try to perform initialization unless you have changed the memory IC. button (on remote control) Test signal selection Selection of the adjustment items (on TV or remote control) Change of the data value Volume...
SETTING & ADJUSTING DATA [ SERVICE MODE ] ADJUSTING ITEMS AND DATA IN THE SERVICE MODE: Note: The image system data of RCUT-BDRV is different by each image format. The PAL value is indicated in the table. Never adjust H.POS and V.POS except PAL/WIDE mode. Item Name of adjustment Preset Data...
Adjusting the Data Pressing of VOLUME +/- button will change the value of data in the range from 00H to FFH. The variable range depends on the adjusting item. Exit from Service Mode Pressing POWER button to turn off the TV once. Initialization of Memory Data of QA02 After replacing QA02, the following initialization is required.
Picture Signal Red raster Green raster Blue raster All Black All White Self Diagnostic Function 1. Press "9" button on remote control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC's is executed properly. 2.
Page 94
(1) Firmware : Version information of microprocessor In case of file name : WL66_EU and Version : 0326 indicates [WL66_EU_0326]. (2) Time : Total hour of turn the TV on. (Unit : H) (3) Bus line : -- "OK" is normal SCL-GND (Red indication) : SCL-GND short circuit SDA-GND (Red indication) : SDA-GND short circuit SCL-SDA (Red indication) : SCL-SDA short circuit...
Page 95
(SCART (FULL)) (SCART (S+AV)) (Composite/Component) HDMI1 HDMI2 Version Check Mode 1. Press "9" button twice on remote control during display of adjustment menu in the service mode. The version of main MPU will begin to check. 2. During Version Check, the following displays are shown.
Page 96
(1) MAIN MPU : Version information of microprocessor In case of file name : WL66_EU, Version 0326 for Code Program Version and (E01) for OSD Version indicates [WL66_EU_0326 (E01)] (2) EEPROM : Version information of EEPROM : Display 1 byte data. (3) SUB MPU : Version information of SUB MPU : Display 1 byte data.
Page 97
A/D adjustment item. --COMP : Component input --PC : PC input --PAL : PAL (50 Hz) SD signal (composite input) --NTSC : NTSC (60 Hz) SD signal (composite input) --OK : A/D adjustment set correctly. --NG : A/D adjustment set incorrect. (9) LCD Panel Vender information display The following Panel Vender and screen size are displayed.
(1) MAIN : Main source information : Display RF position number (0 - 99) on the main screen, or Input Source (EXT1/2/3/HDMI etc.) (2) MAIN FORMAT : Display Video and PC format information (3) MAIN PLL : Main PLL information : Display 1 byte data at five. (4) SUB : Sub source information : Display RF position number (0 - 99) on the Sub screen, or Input Source...
Exact Scan Wide Super Live 2 Cinema 2 Super Live 1 Cinema 1 Subtitle 14:9 (8) OTHER STATUS : Other status information : Display three numbers of 2 byte data. Setting Hotel Mode Enter to service mode and select Hotel Mode menu by pressing P or P .
(Service mode and Super User mode may possible to setting only) D2 (bit2) Language display except SETUP Disable Enable MENU language Display the language only (tuning adjustment etc.) D1 (bit1) SETUP MENU Disable Enable D0 (bit0) HOTEL Mode On (Enable the setting of D1 Off (Normal) to D7) LED Indications...
PARTS LIST Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 102
: Plastic Film : Carbon Composition : Variable Resistor : Electrolytic : Metal Film : Fusible Resistor All CD and PF capacitors are ±5 %, 50 V and all resistor, ±5 %, 1/6 W unless otherwise noted.
Page 103
U01A POWER (PE0071A1) Location Parts No. Description U01A 75002162 PC BOARD ASSY, PE0071A1, POWER C812 76109102 CERAMIC CHIP, 50V B 1000PF K C814 76109102 CERAMIC CHIP, 50V B 1000PF K C815 76073037 ELECTROLYTIC, 16V 47UF M C815A 23960136 ADHESIVE, SILICONE, TSE3843-W C816 76109102 CERAMIC CHIP, 50V B 1000PF K...
Page 113
U01B AC IN (PE0071A2) Location Parts No. Description U01B 75002163 PC BOARD ASSY, PE0071A2, AC IN C801 76168007 MT PLA AC275V 1UF M C802 76503508 MT PLA PCX2 337 11474 C806 76092567 CERAMIC DISC, AC250V E 1000PF M C807 76092567 CERAMIC DISC, AC250V E 1000PF M C808 76092565...
Page 114
U02A LOW B (PE0063C1) Location Parts No. Description U02A 75002165 PC BOARD ASSY, PE0063C1, LOW B CE10 76666470 ELECTORLYTIC, 16V 47UF M CE11 76539474 PLASTIC FILM, 50V 0.47UF J CE12 76666470 ELECTORLYTIC, 16V 47UF M CE40 76073204 ELECTROLYTIC CE04P 50V 330UF M 3A CE41 76073158 ELECTROLYTIC, 16V 2200UF M 3A...
Page 118
U02A AV TERMINAL (PE0029A1) Location Parts No. Description U02A 75002060 PC BOARD ASSY, PE0029A1, AV TERMINAL C101 76109103 CERAMIC CHIP, 50V B 0.01UF K C102 76073019 ELECTROLYTIC, 10V 470UF M C103 76109102 CERAMIC CHIP, 50V B 1000PF K C104 76766479 ELECTROLYTIC, 50V 4.7UF M C105 76073019...
Page 119
C623 76092463 CERAMIC CHIP, 16V B 0.22UF K C624 76092730 CERAMIC CHIP, 16V B 0.1UF K C625 76092463 CERAMIC CHIP, 16V B 0.22UF K C627 76092730 CERAMIC CHIP, 16V B 0.1UF K C629 76669010 ELECTROLYTIC, 50V 1UF M C630 76092730 CERAMIC CHIP, 16V B 0.1UF K C635 76666221...
Page 120
CA70 76100104 CERAMIC CHIP, 25V F 0.1UF Z CA71 76100104 CERAMIC CHIP, 25V F 0.1UF Z CA90 76100104 CERAMIC CHIP, 25V F 0.1UF Z CA91 76105101 CERAMIC CHIP, 50V CH 100PF J CA92 76105101 CERAMIC CHIP, 50V CH 100PF J CA93 76105101 CERAMIC CHIP, 50V CH 100PF J...
Page 121
CG25 76092730 CERAMIC CHIP, 16V B 0.1UF K CG26 76092726 CERAMIC CHIP, 10V B 2.2UF K CG27 76092726 CERAMIC CHIP, 10V B 2.2UF K CG28 76092726 CERAMIC CHIP, 10V B 2.2UF K CG29 76092726 CERAMIC CHIP, 10V B 2.2UF K CG30 76092726 CERAMIC CHIP, 10V B 2.2UF K...
Page 122
CS11 76092726 CERAMIC CHIP, 10V B 2.2UF K CS12 76092726 CERAMIC CHIP, 10V B 2.2UF K CS13 76797479 ELECTROLYTIC, 50V 4.7UF M CS14 76797479 ELECTROLYTIC, 50V 4.7UF M CS15 76797100 ELECTROLYTIC, 50V 10UF M CS16 76797100 ELECTROLYTIC, 50V 10UF M CS17 76092726 CERAMIC CHIP, 10V B 2.2UF K...
Page 123
CV201 76794101 ELECTROLYTIC, 16V 100UF M CV210 76092621 CERAMIC CHIP, 10V B 1UF K CV211 76092621 CERAMIC CHIP, 10V B 1UF K CV212 76793471 ELECTROLYTIC, 10V 470UF M CV213 76100104 CERAMIC CHIP, 25V F 0.1UF Z CV221 76092621 CERAMIC CHIP, 10V B 1UF K CV222 76092621 CERAMIC CHIP, 10V B 1UF K...
Page 138
U02B FRONT AV (PE0029A2) Location Parts No. Description U02B 75002061 PC BOARD ASSY, PE0029A2, FRONT AV C604 76109103 CERAMIC CHIP, 50V B 0.01UF K C605 76109103 CERAMIC CHIP, 50V B 0.01UF K CC11 76109102 CERAMIC CHIP, 50V B 1000PF K CC12 76109102 CERAMIC CHIP, 50V B 1000PF K...
Page 139
U02C LED (PE0029A3) Location Parts No. Description U02C 75002062 PC BOARD ASSY, PE0029A3, LED CB02 76202221 ELECTROLYTIC, 10V 220UF M CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z CB05 76202221 ELECTROLYTIC, 10V 220UF M DB01 23358606 DIODE, LED, SLR-56VC3FPQ...
FUNCTION AND OPERATION The Remote Control Simple at-a-glance reference of your remote control.
Page 169
Inserting Battery and Effective Range of the Remote Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the right way round. Suitable battery types for this remote are AAA, IEC R03 1.5V. Do not combine a used, old battery with a new one or mix battery types. Remove dead batteries immediately to prevent acid from leaking into the battery compartment.
Using the Control and Connection Tuning the Television for the First Time Before switching on the television put your decoder and media recorder to Standby if they are...
Page 172
connected and ensure the aerial is connected. To set up the television use the buttons on the remote control.
Digital - Programme Sorting, Manual Tuning Note: When the television is switched off the mode being viewed at the time will automatically be selected when the television is switched back on. Programme Sorting...
Manual Tuning Tuning Analogue Mode for the First Time The Quick Setup feature will tune all analogue channels currently available in the area. To put the television into ATV mode press and hold then use to highlight ATV. Press OK to select.
Page 181
Analogue - Manual Tune The television can be tuned-in manually using Manual tuning. For example: if the television cannot be connected to a media recorder/decoder with a SCART lead or to tune-in a station on another System. to move across the screen and select any of these Manual Tune options. Programme : The number to be pressed on the remote control.
Page 182
Colour system : Factory set to Auto, should only be changed if problems are experienced, i.e. NTSC input from external source. means nothing has been stored or the facility to skip the Programme skip channel is ON. Channel : The channel number on which a station is being broadcast. Search : Search up and down for a signal.
