Panasonic KX-TD194 Technical Advisory

Subject:
KX-TD194 Installation On KX-TD816/1232
Document Number: KXTD1232006
The KX-TD194 is an external device that allows the use of single line phones with message waiting lamps. This device uses a data pair from the KX-TD system
as control to turn on and off the lamps. The 16 ports on the KX-TD194 basically pass through the Tip and Ring and the KX-TD194 adds the AC voltage
necessary to light the message waiting lamps.
• You do not have to use jacks in consecutive order.
• You do not have to use up all 16 ports.
Wiring*
1. Connect the data pair of the port you will use for control to the first pair (Wht-Blu/Blu-Wht) of cable labeled "To System". (You
can use any jack except Jack 01, a manager, Voice Mail, DSS, or already assigned to KX-TD194)
2. Connect each feed (From System) Tip and Ring pair for each phone to the punch down block labeled "To System" Starting with
the Second pair (Wht-Org/Org-Wht) for the First extension.
3. Connect the Tip and Ring from each extension to the block labeled "To Extension" Starting with the First pair (Wht-Blu/Blu-
Wht) for the First extension.
* Refer to page two for details.
Programming
1. In program 130 enter the jack you wired to the first pair (Wht-Blu/Blu-Wht) of the "To System" punch down block.
2. In program 131 set the message waiting light pattern.
3. In program 132 assign which standard telephone ports will have message waiting lamps. Be careful to enter the data correctly.
First chose the unit number, then enter the port number (This is the port on the KX-TD194 going to the extension), then enter the
feed port number from the system XX-X (This is the port on the system going to the KX-TD194).
Panasonic
Communication Systems Division
Technical Advisory
Updated: Nov. 16, 00
